Hobot LEGEE-D8 User manual

User Manual
Vacuum Mop ECO Compactor
ECO COMPACTOR™
TANGLESS™SUCTION
HSSPL™MOPPING
---HOBOT---

- 1 -
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not be made by
children without supervision.
Table of Contents
Important Safety Instructions --------------------------------------------------------------------- - 1 -
Laser Safety-------------------------------------------------------------------------------------------- - 2 -
Copyright & Trademarks---------------------------------------------------------------------------- - 3 -
Disclaimer---------------------------------------------------------------------------------------------- - 3 -
Limited Warranty------------------------------------------------------------------------------------- - 3 -
Product Overview ------------------------------------------------------------------------------------ - 4 -
Installation--------------------------------------------------------------------------------------------- - 6 -
App Instructions -------------------------------------------------------------------------------------- - 7 -
Maintenance ------------------------------------------------------------------------------------------ - 8 -
Common Issues (FAQ)-------------------------------------------------------------------------------- 11 -
Product Specifications and Accessories---------------------------------------------------------- 14 -
Important Safety Instructions
When using an electrical appliance, basic precautions should always be followed, including
the following:
READ ALL INSTRUCTIONS & SAVE THIS USER MANUAL
WARNING
Do not attempt to repair your LEGEE yourself. Disassembling the device may cause
injury to you. Unauthorized repairs or modifications could result in permanent damage
to the device and may affect your warranty coverage and regulatory authorizations.
Any service other than regular cleaning should be only performed by an authorized
service representative. Contact your local waste management authority to follow local
disposal regulations and never dispose the device and rechargeable batteries with
normal household waste.
GENERAL
This product is designed for indoor floor cleaning only, do not use it outdoors, on
greasy surfaces or any uneven surface (such as a sofa), or for commercial or industrial
purposes.
Do not fill the water tank with any liquid other than pure water or the LEGEE detergent.
Other detergents are not allowed.
Keep the device and accessories away from children.
---HOBOT---

- 2 -
Keep the device in dry and cool place, away from direct sunlight, naked flames, heat,
humidity, water and any other liquids.
Do not store the device near oil, combustible spray or flammable materials.
Product operating temperatures: 0°C ~40°C (32°F ~104°F)
Product storage temperatures: -10°C ~50°C (14°F ~122°F)
Do not use the device if any part or any accessory is damaged or defective.
Before using the device, clear away as much objects as you can from the floor
especially electric cords, glass pieces or any other objects that could tangle, block, or
damage the device.
Do not use the device on the shag/frieze carpet, the device could be trapped and wet
or damage the carpet.
The device may not work properly on the dark-colored carpet.
Do not leave any fragile objects at the edge of tables and cabinets where they could be
easily knock down by the device during cleaning.
Keep your children and pets away from the cleaning path.
Switch off the power and disconnect the power plug before dismantling, assembling or
cleaning the device, power adapter and charging station.
Do not clean the device by spraying water on it or immersing it in water. The device is
not waterproof.
BATTERY & CHARGING STATION
Connect the power adapter to a power source that matches the specifications. The
power adapter is designed for connection to hazardous electrical voltages. Do not
attempt to repair the adapter. Replace the whole unit if it is damaged or exposed to
high moisture. Consult local HOBOT dealer for help and maintenance.
Make sure the device, power adapter and charging station are not trapped under
heavy objects.
Allow adequate ventilation around the device, power adapter and charging station. Do
not cover them with objects.
Do not use the device, power adapter and charging station in a strong magnetic field,
humid or high heat environment.
Use the original power adapter, battery and charging station that came with the device.
Use the third-party components may result in damage, malfunction and/or danger.
This device contains batteries that can only be replaced by professionals.
Battery can explode, catch fire, and/or cause burns if disassembled, crushed, cut,
punctured, short-circuited, incinerated, recharged (disposable cells), or exposed to
water, fire, or temperatures above 60°C (140°F).
If the device is not in use for a long period of time, store it in a dry and safe location.
The battery will need to be charged every 3 months to maintain battery life.
Never operate this device if the cord or power adapter is damaged. Ensure the power
cord is not stretched or exposed to sharp object or edges.
Laser Safety
The laser distance sensor of this product meets the standards for Class I Laser Products in
IEC 60825-1:2014 and will not generate hazardous laser radiation.
---HOBOT---

- 3 -
Copyright & Trademarks
Copyright © 2022 by HOBOT® Technology Inc. All rights reserved. No part of this
publication may be reproduced, transmitted, transcribed, stored in a retrieval system or
translated into any language or computer language, in any form or by any means,
electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the
prior written permission of this company. All other logos, products, or company names
mentioned in this manual may be the registered trademarks or copyrights of their
respective companies, and are used for informational purposes only.
Disclaimer
HOBOT Technology Inc. makes no claims or warranties, either expressed or implied, with
respect to the contents hereof and specifically disclaims any warranties, tradability or
suitability for any particular purpose. Furthermore, HOBOT Technology Inc. reserves the
right to revise this publication and to make changes from time to time in the contents
hereof without obligation of this company to provide notification of such revisions or
changes. The user should follow the instructions provided in this user manual, but is
ultimately responsible for assessing placement and safety when using this cleaning tool.
Limited Warranty
If there are defects in your LEGEE due to faulty materials, poor workmanship, or
malfunction within the warranty period from the date of purchase or delivery, please
immediately contact a local retailer or local authorized dealer for repairs or replacement.
This limited warranty does not cover:
Normal wear and tear, including parts that might wear out over time (side brush,
brushroll, cleaning cloth, caterpillar belt, spray nozzle and filter, etc.)
Reduction in battery runtime due to battery age or use, as the life of the battery and
number of times the device is used.
Transit, delivery or accidental damage or misuse and abuse that is not in accordance
with the instructions.
Faults or damage caused by:
-Negligent use, misuse, abuse or careless operation of the device.
-Use of the device which is not in accordance with this manual.
-Use of anything other than normal domestic household purposes in the country in
which it was purchased.
-Use of parts not assembled or installed in accordance with this instruction.
-Use of any unauthorized parts and accessories. Please contact a local retailer or local
authorized dealer for spares and accessories.
-Faulty assembly or installation.
-Repairs or alterations carried out by parties other than HOBOT authorized dealer.
---HOBOT---

- 4 -
Product Overview
TOP VIEW
Orange
Battery Charging
Orange Flashing
Low Battery
Green
Battery Fully Charged
Blue
Wet Mopping
White
Dry Mopping
White Flashing
Connecting
White & Blue
Spraying Water
Orange & Blue
Search for Charging Station
Control Buttons/LED Indicator
Bumper
LiDAR Sensor
FDS Array Sensors
Trash Bin
Water Tank Lid
Water Tank
Cleaning Tool
Power Switch
Refilling Port
Charging Contacts
(Use with LEGEE-LuLu)
Ag+ion Cleaning Cloth
LiDAR Cover Sensor
Start/Pause Cleaning
Home
Stop Cleaning/Child Lock
(Press 3sec.)
Switch Talent Clean Modes
---HOBOT---

- 5 -
BOTTOM VIEW
TRASH BIN
CHARGING STATION
Charging Contacts
Charging Indicator
Blue
Stand-by
Blue Flashing
Charging
Wire Storage
DC Jack
Screen Filter
Dust Sheet
Release Latch
Compressor/Scraper
High Efficiency Filter
Side Brush
Front Suction
Spray Nozzles
Brushroll
Universal Wheel
Auto Lifting Mopping Pad
Rear Cliff Sensors
Caterpillar Belts
Charging Contacts
Front Cliff Sensors
---HOBOT---

- 6 -
Installation
Important Notes Before Cleaning
Put away objects including wires, cloths, slippers, fragile objects…etc. on the floor to
improve cleaning efficiency and safety.
1. Position the Charging Station
Peel off the backings paper from the bottom of
the charging station and keep the charging
station on a level surface, flat against a wall.
Clear the objects around the charging station.
Connect the power cord to the charging station
and tidy the wires from the floor.
To ensure a better user experience of the App,
place the charging station in an area with good
Wi-Fi coverage.
2. Power on & Charge your LEGEE
Use the Home button to ensure LEGEE is
returned to the charging position properly.
Before the first time of use, fully charge the
battery for at least 6 hours until the LED
indicator green light is ON. To maintain the
performance of the Li-ion battery, keep your LEGEE charged.
3. Install the Side Brush & Attach the Ag+ion Cleaning Cloth
Press down the side brush until you hear a click sound. Attach the cleaning cloth flatly
to the mopping pad.
---HOBOT---

- 7 -
➢LEGEE supports either 5G or 2.4G Wi-Fi (3
accounts), or mobile Hotspot.
➢Turn on the Bluetooth and Wi-Fi on your
phone
➢LEGEE will automatically memorize and
switch between 3 SSID for best connectivity
4. Fill the LEGEE Water Tank
1. Open the water tank lid. Fill with
pure water or LEGEE detergent.
2. Close the lid tightly.
*DO NOT use any other detergent or liquid to prevent blockage of the pipes and the
spray nozzles.
App Instructions
1. Download and Open the LEGEE App
Search for “LEGEE” in the App Store or
Google Play or scan the QR code on the
right to download and install the App.
2. Create a HOBOT Account/Quick Login
HOBOT account
Create and log into your HOBOT Account and control
your LEGEE with different devices.
Note: The only thing stored in your HOBOT Account is
the device’s initial name. All customized settings are
stored on the device and will never be accessible via
HOBOT account. When you log into your HOBOT account on another smartphone,
HOBOT account will help you to link to the devices associated to your account and
retrieve the data stored on your device for you.
Quick Login
Login to your social media account and start using the App in just a few seconds.
Please note, you won’t be able to share LEGEE’s control with others if you choose to
use Quick Login. Also, LEGEE can’t connect to Ok Google and Alexa when you use
Quick Login. Please register and switch to HOBOT account to enable the above
function. (The maps and settings are kept)
3. Connect Device with the LEGEE App
Open the LEGEE App, tap “Add a New LEGEE” and follow the instructions on the
screen to add the device.
---HOBOT---

- 8 -
Maintenance
Please maintain LEGEE according to the following guidelines for optimum performance;
contact a local retailer or authorized dealer for additional consumable spare parts.
Part
Care Frequency
Replacement Condition*
Trash Bin & Screen
Filter
Clean as needed
/
High Efficiency Filter
Clean as needed
When it is too dirty (when the App shows
that the trash bin is full even after you’ve
emptied it and washed the filter)
Side Brush &
Brushroll
After each use
When it is too dirty or when it is worn out
and bristles are falling off.
Cleaning Cloth
After each use
When it is too dirty, smells funky or when
it is worn out.
Spray Nozzle
Clean as needed
When it is clogged and cannot be cleaned
with the pin.
Bumper/Sensors/
Charging Contacts/
Refilling Port
Once every month
/
Universal Wheel
Clean as needed
/
Brushroll
1.Push open the brushroll cover. 2.Take out the brushroll.
3.Use the cleaning tool to cut loose the
tangled hair and debris to clean the
brushroll, rinse then dry when needed.
4.Reinstall the brushroll.
---HOBOT---

- 9 -
Side Brush
1.Pull off the side brush
from the device and
remove any tangled hair
or debris.
2.If necessary, rinse the side
brush with warm water to
clean dirt off and restore
it to its original shape.
3.Reinstall the side brush.
Push down until you hear
a click sound.
Trash Bin
1.Take out the trash bin by
releasing the latch and
lifting the handle.
2.Remove the screen filter
and empty the trash bin.
3.Wash and air-dry the trash
bin.
Screen Filter & High Efficiency Filter
1.Shake off debris by tapping the filters
against your trash container.
2.Rinse the filters if necessary. Do NOT rub
the filters or use high-pressure water. Be
sure to leave the filters to dry thoroughly
before reinstalling them.
---HOBOT---

- 10 -
Wash under 40°C (104°F)
Do not bleach
Do not tumble dry
Do not iron.
Do not dry clean.
Ag+ion Cleaning Cloth
You can wash the cleaning cloth in two ways:
1.Hand washing: Thoroughly wash the cloth with
warm water and general-purpose laundry
detergent.
2.Washing machine: Wash using the warm cycle,
then air dry.
3.A dirty cleaning cloth will decrease the mopping
performance. Always start with a clean cloth.
Sensors & Charging Contacts
Use a soft dry cloth to wipe and clean the charging contacts and all sensors.
1. Press the right end of the bumper and pull the left end to detach the bumper from
the device.
2.Wipe clean the bumper, 7 FDS sensors
and reinstall the bumper.
3.Wipe clean the cliff sensors, charging
contacts and refilling port.
(use with LEGEE-LuLu)
---HOBOT---

- 11 -
Universal Wheel
Pull up the universal wheel and clear the hair, rinse
and dry when needed.
Spray Nozzle
Test the spray nozzles using the button in the App
To unclog the spray nozzle: To replace the spray nozzle:
Clean the spray nozzle with
the push pin.
1.Use a screwdriver to loosen
the screws holding the
spray nozzle in place.
2.Replace the old nozzles
with new ones, then
reinstall the nozzles.
Common Issues (FAQ)
Case
Solution
LEGEE does not start
cleaning.
Check if the power is switched ON and the battery is fully
charged.
If LEGEE can’t be started by the on-device buttons, please check if
the child lock is engaged in the App, press the child lock button
for 3 seconds or disengage the child lock in the App.
Please check if there’s hardware error alert in the App.
LEGEE returns to the
charging station
without completing
the cleaning task.
The battery is low (orange and blue light flashing). LEGEE will
resume cleaning after it’s sufficiently charged.
If LEGEE returns to the charging station with sufficient power:
-LEGEE may have misjudged the landscape due to the floor
molding or due to moving furniture, closed doors and
considered the task completed. LEGEE could also be blocked by
narrow hallways or doorways so make sure to clear away the
---HOBOT---

- 12 -
obstacles.
-Please check if there are virtual barriers blocking the way so
LEGEE considered the task completed.
-Check if you have only chosen specific rooms instead of the
entire house for the current cleaning task.
LEGEE cannot return
to the charging
station.
Place the charging station in an open space or clear the objects
around it and clean the sensors with clean dry cloth.
Check if the adapter is properly connected to the charging station
and is plugged into the power socket, the charging indicator will
show blue light
There is adhesive—which leaves no stain on the floor—under the
charging station for fixation, please make sure the charging
station is firmly fixed on the ground.
LEGEE does not
resume the
unfinished task after
charging.
Check if it’s under the Do Not Disturb period.
LEGEE does not start
charging.
Check if the adapter is properly connected to the charging station
and is plugged into the power socket.
The charging indicator will flash blue light when charging.
Poor contact with the charge contacts. Please switch off the
power and remove the power source from the charging station.
Clean all charging contacts by using a clean cloth with rubbing
alcohol to remove the oxide then try again.
Tips when charging
LEGEE.
Use the Home button to ensure LEGEE is returned to the
charging position properly.
It is advised to keep LEGEE switched on when charging, LEGEE will
be able to return to the charging station automatically in case
LEGEE is moved.
LEGEE will stop charging when the battery is full, the power
consumption is very low when LEGEE is standing by, however, it
will resume charging for a short period of time once in a while.
Letting LEGEE stay connected to the charging station can help to
maintain the battery’s best performance.
LEGEE is Making a
Buzzing Noise When
Charging
Poor contact between the charging contacts, please use the
Home button to let LEGEE return to the charging position
again.
Switch off LEGEE and disconnect the charging station from the
power source. Wipe clean the charging contacts with a clean
cloth and alcohol to remove dust or rust.
Both overpowered outlet and/or underpowered outlet can cause
the charging station to make the buzzing noise. Try to use a
different power outlet in the house.
---HOBOT---

- 13 -
The sound frequency at which a human can hear ranges between
20 Hz to 20,000 Hz, you are likely to hear buzzing noises amplified
from your charger.
All power adapters or transformers will make a buzzing sound to
some degree, the device may still be used without any concern as
there is no need to worry from a safety point of view.
The cleaning result is
less satisfying.
Switch off LEGEE, clean/change the side brush, empty the trash
bin, and wash/change the high efficiency filter and the cleaning
cloth.
LEGEE does not spray
water.
Check if there is water in the water tank.
Test the spray nozzles using the button in the App, it will
make LEGEE to spray once.
If LEGEE does not spray water, please clean the spray nozzles or
replace with new ones.
The side brush does
not spin normally.
Remove the side brush from the device, clean the hair between the
side brush and the device and reinstall it.
How does the cliff
sensors work?
The cliff sensors can avoid the damage to LEGEE by preventing it to
fall off the cliffs such as stairs or the edge of the floor. To avoid
LEGEE to enter the recessed area, please set a virtual barrier in the
App.
LEGEE works/moves
abnormally.
Switch off LEGEE, clean the side brush
and cliff sensors.
Check if the cleaning cloth is firmly
attached to the device and if it’s too
dirty.
Clean the bumper and FDS sensors.
Check if the LiDAR cover sensor is
working properly by pushing the top of the LiDAR sensor cover, it
should bunce back smoothly.
LEGEE does not play
the voice prompts.
Check the volume.
Check if it’s under the Do Not Disturb period.
Unable to add LEGEE
to the App via Wi-Fi.
Restart LEGEE and the App.
Check if the Wi-Fi signal is stable, and if LEGEE and your
smartphone are under the same Wi-Fi network.
Check if the App needs an update.
Check if you have entered a wrong Wi-Fi password.
How to use LEGEE
without a Wi-Fi
router?
Please turn on the Hotspot function, tap “No Wi-Fi?” during the
connecting process and follow the instruction.
LEGEE is offline.
Check if the Wi-Fi or Hotspot signal is stable.
If LEGEE has been moved to a different wireless network, please
re-establish the connection between LEGEE and the App before
use.
---HOBOT---

- 14 -
LEGEE-D8
Charging station
AC adapter
Water bottle
Ag+ ion cleaning cloth
Spray nozzles pack
Side brushes
High efficiency filter
User manual
Can LEGEE work
when offline?
LEGEE can work following the schedule queue even when it is
offline, all the cleaning data will be stored in the device first, when
it is connected again, the stored data will show up in the App.
Unable to save a
default map.
The cleaned area must be larger than 3m2.
Use the “Quick Mapping” function so LEGEE will enter the rooms
to make a brief scan and complete map-drawing in a shorter
period of time.
Make sure LEGEE has not been moved or lifted off the floor
during cleaning.
If any problems occur and this manual cannot provide the solution you need,
please contact a local retailer or authorized dealer.
Product Specifications and Accessories
Model
LEGEE-D8
Wi-Fi
802.11a/b/g/n/bt
Dimensions (L × W × H)
344 × 343 × 97.5 mm
Li-ion Battery
Rated Capacity: 4400mAh
Cell Capacity: 4900mAh
Charging Station
Dimensions (L × W × H)
160 × 147 × 110 mm
Input Voltage
100~240 VAC, 50~60 Hz
Power Consumption
19V/1.05A, 19.95W
---HOBOT---

---HOBOT---
