Hoggi BINGO Evolution Operating instructions

en
BINGO Evolution
Service instructions
Partnerschaft für mobile Kinder

BINGO Evolution- Service and maintenance instructions
Content Page
1 Model identication & basic conguration
 1.1 Model identication (label)_____________________________________________________ 4
 1.2 Basic conguration __________________________________________________________ 4
2Overview BINGO Evolution _____________________________________________________5-12
3Common information ___________________________________________________________ 14
 3.1 Preface __________________________________________________________________ 14
 3.2 Application________________________________________________________________ 14
 3.3 Declaration of conformity_____________________________________________________ 14
 3.4 Terms of warranty __________________________________________________________ 14
 3.5 Customer service __________________________________________________________ 15
 3.6 Service and repairs _________________________________________________________ 15
 3.7 Packing and shipping instructions ______________________________________________ 15
4Safety Instructions _____________________________________________________________ 16
 3.1 Meaning of symbols ________________________________________________________ 16
 3.2 Common safety instructions __________________________________________________ 16
5Required tools and maintenance schedule _________________________________________ 17
 5.1 Required tools _____________________________________________________________ 17
 5.2 Maintenance schedule ____________________________________________________18-19
6Seat settings __________________________________________________________________ 20
6.1 Seat height + lower leg length_________________________________________________ 20
6.2 Footrest angle _____________________________________________________________ 21
6.3 Seat width ________________________________________________________________ 21
6.4 Seat depth________________________________________________________________ 22
6.5 Back height _____________________________________________________________22-23
6.6 Thorax width ____________________________________________________________23-24
6.7 Headrest width ____________________________________________________________ 24
6.8 Seat angle adjustment_______________________________________________________ 25
6.9 Recline __________________________________________________________________ 25
7Maintenance schedule __________________________________________________________ 26
7.1 Chassis ________________________________________________________________26-27
7.2 Front strut ________________________________________________________________ 27
7.3 Rear frame _______________________________________________________________ 27
7.4 Rear axle_________________________________________________________________ 27
7.5 Push bar _________________________________________________________________ 28
7.6 Seat bearing ______________________________________________________________ 28
7.7 Front wheels ______________________________________________________________ 29
7.8 Rear wheels ______________________________________________________________ 30
7.9 Accessory bag_____________________________________________________________ 30
7.10 Braking system __________________________________________________________30-31

7.11 Tie down kit _______________________________________________________________ 31
7.12 Swivel lock________________________________________________________________ 32
7.13 Seat base ________________________________________________________________ 32
7.14 Seating surface ____________________________________________________________ 32
7.15 Thigh supports_____________________________________________________________ 32
7.16 Hip supports ______________________________________________________________ 33
7.17 Lateral supports____________________________________________________________ 33
7.18 Back base ______________________________________________________________33-34
7.19 Back insert________________________________________________________________ 34
7.20 Individual upholstery system __________________________________________________ 35
7.21 Footrest hanger____________________________________________________________ 35
7.22 Footrest holder __________________________________________________________35-36
7.23 Footrests _________________________________________________________________ 36
7.24 Headrest pads___________________________________________________________36-37
7.25 Thorax pads ______________________________________________________________ 37
7.26 Belt xations ____________________________________________________________37-38
 7.27 Abduction block ____________________________________________________________ 38
7.28 Grab rail__________________________________________________________________ 39
7.29 Therapy tray ______________________________________________________________ 39
7.30 Retainer for accessories _____________________________________________________ 39
7.31 Winter warmer _____________________________________________________________ 39
7.32 Canopy __________________________________________________________________ 40
8 Operating life _________________________________________________________________ 41
9 Specications _______________________________________________________________41-42

4
1 Model identication
1.1 Model identication (label)
 The BINGO Evolution mobility base label is is mounted on the inside of the left side strut and under the seat panel.
Hoggi GmbH
Eulerstr. 27
56235 Ransbach-Baumbach
MADE IN GERMANY
(01)04047349096062(21)202178999
3234-1000-052
BINGO Evolution
Straßengestell Gr. 2
Lenkräder, vorne
2021178999
2021/04/21
max. load
60kg
Hoggi GmbH
Eulerstr. 27
56235 Ransbach-Baumbach
MADE IN GERMANY
(01)04047349096062(21)202178999
3234-1000-052
BINGO Evolution
Straßengestell Gr. 2
Lenkräder, vorne
2021178999
2021/04/21
max. load
60kg
Hoggi GmbH
Eulerstr. 27
56235 Ransbach-Baumbach
MADE IN GERMANY
(01)04047349096062(21)202178999
3234-1000-052
BINGO Evolution
Straßengestell Gr. 2
Lenkräder, vorne
2021178999
2021/04/21
max. load
60kg
Serial number
Classication / Product name
Year of manufacture
UDI Code
Manufacturer
Place of manufacture
Date of manufacture
Maximum load / load capacity
CE label
Colour code
Article number
1.2 Basic conguration
- Bingo Evolution rehab pushchair (Mobility base and seat unit)
- Front and rear wheels with air or PU tires
- Padding (IUS)
- Thigh supports
- Footrest hanger
- Foot rest bracket und footrest

5
2 Overview BINGO Evolution
2.1 Mobilitybase,swiveling

6
2.2Mobilitybase,rigid

7
2.3Mobilitybaseforrespiratoryequipment

8
2.4MobilitybaseTrike

9
2.5Mobilitybasemini

10
2.6 Mobility base Cross

11
2.7 Seat unit

12
2.8 Seat unit mini

13
3 Common Information
3.1 Preface
Thank you for selecting the BINGO Evolution rehab pushchair. We have designed this high-quality product to make your
life safer and easier,and we’ve included this manual to help you use and care for it.
Please read the following instructions to make sure you use this product as recommended. If you have any further
questions, or if you have any problems, please contact your healthcare provider.
We hope that BINGO Evolution meets your expectations.
We reserve technical modications regarding the specied model in this manual. Before using the rehab pushchair the rst
time, this manual has to be read and understood by patient and support personnel in oder to ensure asafe handling with
the rehab pushchair.
Regular maintenance is important -it increases safety and prolongs the life of the product. Every
rehab product should be checked and serviced once ayear.
However, it is recommended to check, readjust and, if necessary,service products with ahigh frequency of use, with users
in growth or users with achanging clinical picture at 6-month intervals.
Only original spare parts should be used for all service and maintenance work.
The service and maintenance work described here should only be carried out by trained specialist personnel and not by the
user of the aid.
These service and maintenance instructions refer to the respective spare parts catalogs and operating instructions of the
products described. Please use all documents together.
Use the maintenance schedule (Chapter 5.2, Checklist to tick o󰀨) as acopy template.
Retain completed maintenance schedules and provide acopy to the customer.
Bingo Evolution User manual 1910-0030-EN
Bingo Evolution Spare parts catalog 1910-1006-EN
3.2 Application
Rehab pushchairs, paediatric postural positioning systems or strollers are appropriate for childern
and adolescents who are unable to walk or who have a walking impediment and thus requiring mobility assistance.
Assistance may be required due to:
• Atypical muscle tone • Joint contractures
• Loss of limbs (dysmelia/lower limb amputation) • Joint defects
• Limb defect and / or deformity • General weakness
TheBINGO Evolution rehabpushchairisabletobeusedindoorandoutdooraswellasforfurtherservice.Forfurther
servicetheproducthastobecleanedandsanitisede󰀩ciently.Afterwardstheproducthastobecheckedconcerning
condition,wearoutanddamagebyanauthorisedtechnician.Alldamagedandinapropptiatepartsneedtobechanged.
Pleaseseealsotheservicemanualfordetailledinformation.
3.3 Declaration of Conformity
HOGGIGmbHasmanufacturerdeclaresundersoleresponsibilitythattherehab-pushchairforkidsandadolescents
BINGO Evolution meetsthegeneralsafetyandperformancerequirementstoAnnexIoftheRegulation(EU)2017/745
oftheEuropeanParliamentandoftheCouncil.HarmonisedEuropeanStandardshavebeenapplied.Applicable
harmonizedstandardshavebeenapplied.BINGO Evolution meetstherequirementsofISO7176-8,DINENISO12182
and DIN EN ISO 12183.
3.4TermsofWarranty
Warrantyappliesonlywhentheproductisusedaccordingtothespeciedconditionsandfortheintendedpurposes,
followingallmanufacturer’srecommendations.Themanufacturerisnotresponsiblefordamagescausedbycomponents
andsparepartsnotapprovedbythemanufacturer.Seealso§8oftermsandconditionson: www.hoggi.de

14
3.5 Customer service
Our customer service will be happy to answer any technical questions you may have.
Please refer to the last page for contact addresses and telephone numbers.
3.6 Service and repairs
Service and repairs on the BINGO Evolution rehab pushchair may only be carried out by your specialist dealer. In case
of problems, contact your responsible specialist dealer. In case of repairs, you will only receive original spare parts there.
Spare parts and replacement units are available during the entire service life of the product, but only for a maximum of 2
years after the sale of the last product in this series.
The wheelchair is custom made for the rst time user. Therefore, no replacement wheelchair is available in the
initial conguration. In order to ensure a correct spare parts delivery the serial no. of your wheelchair is required.
We are happy to help you nd a dealer near you.
You can reach us at: [email protected]
3.7 Packing and shipping instructions
If BINGO Evolution has to be sent back to the manufacturer for repair or exchange the product must be thoroughly
cleaned/disinfected beforehand and put in a hygienically safe condition.
Packaging is done by wrapping the product in a clean lm, ideally with air cushions and the subsequent use of a
su󰀩ciently large cardboard box, so that no transport damage can occur.

15
4 Safety instructions
4.1 Meaning of symbols
Caution!
Warning of possible danger of accident and injury. Warning of possible technical
damage.
Information!
About use of product.
Information!
For service-personnel.
Attention!
Read manual before use!
4.2 Common safety instructions
For all maintenance and repair work, you should generally observe afew points:
Attention!
Familiarize yourself with the functions of the product. If you are not familiar with the
product, study the user manual before testing. If no user mauals are available, request
them from us. You can also download documents from our homepage at: www.hoggi.de
Attention!
Study the service and maintenance instructions before starting work.
Attention!
Use suitable tools (see page 4 󰀨.).
Attention!
Wear suitable clothing and, if necessary, gloves and protective goggles.
Attention!
Secure the product from tipping over or falling down, e.g. from the workbench.
Attention!
Clean / disinfect the product before starting the test. If necessary, observe the instructions
in the user manual and product-specic test instructions.
Note!
Screws and nuts with thread locking are used for alarge number of screw connections.
If you have to open such screw connections, replace the respective nut or screw with
one with new thread locking. If new nuts or bolts with thread locking are not available,
use liquid thread locking compound with medium strength (e.g. Loctite 241 or Euro Lock
A24.20).

16
5Required tools and maintenance schedule
5.1 Required tools
The following list shows the tools and utilities required for service.
Reversible ratchet and sockets
size 8-24
Torque wrench
Measuring ranges 5-50 Nm
Wrench
Size 6-24
Hexagon wrench
Gr. 3-6
Screwdriver
Blade width 2.5 3.5 and 5.5
Phillips screwdriver
Size 2
Plastic hammer Hammer approx. 300 gCarpet knife with sickle and
standard blade
Side cutter Liquid thread locking
„medium strength
Riveting pliers for rivets up to
5mm

17
5Required tools and maintenance schedule
5.1 Required tools
The following list shows the tools and utilities required for service.
5.2 Maintenance
schedule BINGO Evolution
Mobility base
Customer:
...............................................
Pos. Area Check(Checklist to tick o󰀨 )
Serial number:
.......................................
1.)
Function / Setting
(siehe Bedienungsanleitung)
2.)
none
damage / defor-
mation
3.)
Screw connections
Mobility base
1.1 Front frame (Variants) oo o
1.2 Front struts - Suspension oo o
1.3 Rear frame o o
1.4 Brake with rear axle - Parking brake oo o
1.5 Push bar - Folding mechanism
- Locking
- Angle adjustment of the
push handle
o
o
o
o
o
o
o
1.6 Seat bearing oo o
1.7 Front wheels, rigid - Tires
- Air pressure
- Running behavior of the wheels
- Quick release
o
o
o
o
o o
Front wheels, steerable -
additional - Swiveling the wheel forks oo o
1.8 Rear wheels - Tires
-Air pressure
- Runningbehaviorofthewheels
- Quickrelease
o
o
o
o
o o
Accessories
1.9 Accessories bag - Fold with o o o
1.10 Braking system - Brakes o o o
1.11 Tie down kit o o
1.12 Swivel lock - Locking device
- Straight run
o
o
o o
Do the settings on the base frame
meet the user‘s requirements? o
Notes:
The maintenance was performed by: .............................................................. on: ......................................

18
BINGO Evolution
Seat unit
Customer:
...............................................
Pos. Area Check(Checklist to tick o󰀨 )
Serial number:
.......................................
1.)
Function / Setting
(siehe Bedienungsanleitung)
2.)
none
damage / defor-
mation
3.)
Screw connections
Seat unit
2.1 Seat base - Seat angle adjustment
- Seat lock
o
o
o
o
o
o
2.2 Seat - Seat depth adjustment oo o
2.3 Thigh support - Seat width adjustment oo o
Hip support - Seat width adjustment
- Depth adjustment hip supports
- Remove
o
o
o
o o
o
2.4 Lateral support - Fold / Remove oo o
2.5 Back base - Recline oo o
2.6 Back insertion - Back height adjustment oo o
2.7 all upholstery parts o
2.7 Footrest hanger 90° -Snap-in mechanism 90° oo o
Footrest hanger 90°-160° - Angle adjustment oo o
2.8 Footrest - Height adjustment
- Angle adjustment
-Locking (optional)
o
o
o
o o
Accessories
2.9 Headrest pads - Width adjustment oo o
2.10 Thorax support - Width & height adjustment oo o
2.11 Beltxings:
Lapbelt,five-pointharness,foot
belts,anklehugger,groinstrap,
xationjacket,chest-shoulderpad
- Closures oo o
2.12 Pelvic bracket (accessories) - Locking of the toothed belts oo o
2.13 Abduction block (accessories) o o
2.14 Grab rail (accessories) - Locking (tripod springs) oo o
2.15 Therapy tray (accessories) - Locking (tripod springs)
- Angle adjustment
- Depth adjustment
o
o
o
o o
2.16 Canopies (accessories) - Angle adjustment of canopy
- Plug connection to the adapter
o
o
o o
Do the seat unit settings meet the
user‘s requirements? o
Notes:
The maintenance was performed by: .............................................................. on: ......................................
5.2 Maintenance
schedule

19
6. Seat settings
6.1 Seat height &lower leg length
The front seat height is approx. 47 cm with the seat in astraight
position. Adjustable lower leg lengths vary depending on size.
Size mini:
Size 1:
Size 2:
Size 2XL:
However, with the adapter shown, the seat height can be increased by
10 cm.
16 - 34 cm
16 - 37 cm
16 - 40 cm
16 - 40 cm
Lower leg lenght
BINGO Evolution can basically be equipped with 2 di󰀨erent footrest
hanger.
Shown here is the footrest hanger 90°
The footrest hanger can be swiveled up via the tension catches,
but not xed in place.
Footrest hanger angle adjustable
Adjustable between 85° and 170° via clamping lever.
Minimum LLL 19 cm
Standard for BINGO Evolution mini
The height adjustment of the footrest is done by loosening the
wing nuts on the back.
Thereupon, the respective footrest mounted on the carrier, can be
adjusted to the individual needs.

20
6.2 Footrest angle
The footrest angle is preset to 90°. The adjustment range is +- 10°
(80° - 100°).
After loosening the four marked screw connections on the footrest holder
the footrest can be adjusted in depth.
This changes the anchor point of the footrest and thus also the footrest
angle. The further the footrest is pulled out to the front, the the greater
the angle. If the procedure is reversed the angle decreases accordingly.
6.3 Seat width
The seat width of the BINGO Evolution can be adjusted by moving the
the thigh - or the hip supports.
The following adjustment ranges result for the four sizes:
Size mini:
Size 1:
Size 2:
Size 2XL:
The pad is secured to the seat panel by a screw connection.
The desired seat widths can be achieved by shifting in 2 slotted holes.
In addition, the depth positioning can be adjusted.
Wing nut screws on the underside of the seat plate secure the connecti-
on.
An additionally attached nut serves as protection against loss and should
always be mounted.
13 - 25 cm
18 - 30 cm
23 - 35 cm
23 - 35 cm
