I. Introduction
Thank you for purchasing and using the general-purpose inverter of
HLP-NV series of multi-functions and high performance.
Please read carefully the operation manual before putting the inverter to
use so as to correctly install and operate the inverter, give full play to its
functions and ensure the safety. Please keep the operation manual handy
for future reference, maintenance, inspection and repair.
Due to the inverter of a kind of electrical and electronic product it
must be installed, tested and adjusted with parameters by specialized
engineering persons of motors.
The marks of Danger Caution and other symbols in the manual
remind you of the safety and prevention cautions during the handling,
installation, running and inspection. Please follow these instructions to
make sure the safe use of the inverter. In case of any doubt please contact
our local agent for consultation. Our professional persons are willing and
ready to serve you.
The manual is subject to change without notice.
Danger indicates wrong use may kill or injure people.
Caution indicates wrong use may damage the inverter or
mechanical system.
Danger
● Be sure to turn off the input power supply before wiring.
● Do not touch any internal electrical circuit or component when the
charging lamp is still on after the AC power supply is disconnected,
which means the inverter still has high voltage inside and it is very
dangerous.
● Do not check components and signals on the circuit boards during
the operation.
● Do not dissemble or modify any internal connecting cord, wiring or
component of the inverter by yourself.
● Be sure to make correct ground connection of the earth terminal of
the inverter.
● Never remodel it or exchange control boards and components by
yourself. It may expose you to an electrical shock or explosion, etc.

HLP-NV Series
HLP-NV Series
- 2-
1. Checks upon Delivery
The inverter has been strictly and well packed before ex-work. In
consideration of various factors during the transportation special
attention should be paid to the following points before the assembly and
installation. If there is anything abnormal please notify the dealer or the
relevant people of our company.
● Check if the inverter has got any damage or deformation during the
transportation and handling.
● Check if there is one piece of HLP-NV series inverter and one copy of
the instruction manual available when unpacking it.
● Check the information on the nameplate to see if the specifications
meet your order (Operating voltage and KVA value).
● Check if there is something wrong with the inner parts, wiring and
circuit board.
● Check if each terminal is tightly locked and if there is any foreign
article inside the inverter.
● Check if the operator buttons are all right.
● Check if the optional components you ordered are contained.
● Check if there is a certicate of qualication and a warranty card.
Caution
● Motor overload protection is included in the default settings.
Parameter C01.90 Motor thermal protection is set to value ETR trip.
● Do not make any voltage-withstanding test with any component
inside the inverter. These semi-conductor parts are subject to the
damage of high voltage.
● Never connect the AC main circuit power supply to the output
terminals U.V W of the inverter.
● The main electric circuit boards of CMOS and IC of the inverter are
subject to the effect and damage of static electricity. Don’t touch the
main circuit boards.
● Installation, testing and maintenance must be performed by qualied
professional personnel.
● The inverter should be discarded as industrial waste. It is forbidden
to burn it.

HLP-NV Series
HLP-NV Series - 3-
Software Version: A
2. Nameplate Description of HLP-NV Series Inverter
Model HLP NV 0D75 23 A
Voltage Rating: 21:1-Phase AC 220V
23:3-Phase AC 220V
43:3-Phase AC 380V
Inverter Capacity:0 D 75 means 0.75KW
Serial No: NV means NV series
Trade Mark: HOLIP

HLP-NV Series
HLP-NV Series
- 4-
II. Safety Precautions
1. Before the Power-up
Caution
● Check to be sure that the voltage of the main circuit AC power supply
matches the input voltage of the inverter.
● The symbol , represents ground terminals. Be sure to make
correct ground connection of the earth terminals of the motor and the
inverter for safety.
● No contactor should be installed between the power supply and the
inverter to be used for starting or stopping of the inverter. Otherwise
it will affect the service life of the inverter.
Danger
● R(L),S,T(N) terminals are power input terminals, never mixed
with U.V.W terminals. Be sure that the wiring of the main circuit is
correct. Otherwise it will cause damages of the inverter when the
power is applied to it.
● The terminal of must be grounded separately and never connected
to line zero. Otherwise it will easily cause the protection or errors of
the inverter.
Caution
● Do not carry the front cover of the inverter directly when handling.
It should be handled with the base to prevent the fall-off of the front
cover and avoid the dropping of the inverter, which may possibly
cause the injuries to people and the damages to the inverter.
● Mount the inverter on a metal or other noncombustible material to
avoid the risk of re.
● Install the inverter in a safe location, avoiding high temperature,
direct sunlight, humid air or water.
● Keep the inverter from the reach of children or persons not
concerned.
● The inverter can only be used at the places accredited by our
company. Any unauthorized working environment may have the
risks of re, gas explosion, electric shock and other incidents.
● Install a heat sink or other cooling device when installing more than
one inverter in the same enclosure so that the temperature inside the
enclosure be kept below 40℃ to avoid overheat or the risk of re.

HLP-NV Series
HLP-NV Series - 5-
● Be sure to turn off the power supply before dissembling or
assembling the operation keypanel and xing the front cover to avoid
bad contact causing faults or non-display of the operator.
● Do not install the inverter in a space with explosive gas to avoid the
risk of explosion.
● If the inverter is used at or above 1000m above seal level, the cooling
efciency will be worse, so please run it by de-rating.
● Do not install any contactor and other components of capacitor or
varistor on the output side of the inverter. Otherwise it will cause
malfunctions and damages of components of the inverter.
● Do not install any switch component like air circuit breaker or
contactor at the output of the inverter. If any of such components
must be installed because of the requirements of process and
others, it must be ensured that the inverter has no output when the
switch acts. In addition, it is forbidden to install any capacitor for
improvement of power factor or any varistor against thunder at the
output. Otherwise it will cause malfunctions, tripping protection and
damages of components of the inverter. Please remove them as shown
in the below diagram.
● It will affect the service life of the inverter if a contact is connected
to the front end of input of the inverter to control its starts and stops.
Generally it is required to control it through Control terminals.
Special attention should be paid to its use in the case of frequent
starts and stops.
● Please use an independent power supply for the inverter. Do avoid
using the common power supply with an electrical welder and other
equipment with strong disturbance. Otherwise it will cause the
protection or even damage of the inverter.

HLP-NV Series
HLP-NV Series
- 6-
Caution
● Do not touch the heat sink, braking resistor, or other heat elements.
These can become very hot.
● Be sure that the motor and machine is within the applicable speed
ranges before starting operation because the inverter is quite easy to
run from lower speed to higher speed.
● Do not check the signals on circuit boards while the inverter is
running to avoid danger.
● Be careful when changing the inverter settings. The inverter has been
adjusted and set before ex-work. Do not adjust it wantonly. Please
make proper adjustments according to the required functions.
● Do consider the vibration, noise and the speed limit of the motor
bearings and the mechanical devices when the inverter is running at
or above the frequency of 50Hz.
2. During the Power-up
Danger
● Do not plug the connectors of the inverter during the power up to
avoid any surge into the main control board due to plugging, which
might cause the damage of the inverter.
● Always have the protective cover in place before the power up to
avoid electrical shock injury.
3. During the Operation
Danger
● Never connect or disconnect the motor set while the inverter is in
running. Otherwise it will cause over-current trip and even burn up
the main circuit of the inverter.
● Never remove the front cover of the inverter while the inverter is
powered up to avoid any injury of electric shock.
● Do not come close to the machine when the fault restart function is
used to avoid anything unexpected. The motor may automatically
restart after its stop.
● The function of STOP Switch is only valid after setting, which is
different with the use of emergent stop switch. Please pay attention to
it when using it.

HLP-NV Series
HLP-NV Series - 7-
4. After the Power-off
● Touching the electrical parts may be fatal - even after the equipment
has been disconnected from mains. Also make sure that other
voltage inputs have been disconnected, (linkage of DC intermediate
circuit).
● Be aware that there may be high voltage on the DC link even when
the LEDs are turned off.
● Before touching any potentially live parts of the VLT Micro, wait at
least as follows:
200 - 240 V, 0.4 – 1.5 kW: wait at least 4 minutes.
380 - 480 V,0.75 – 2.2 kW: wait at least 4 minutes.
Shorter time is allowed only if indicated on the nameplate for the
specic unit.

HLP-NV Series
HLP-NV Series
- 8-
III. Standards and Specications
1. Particular Specications
Model Input Voltage Power
(KW)
Output
Current
(A)
Suitable
Motor
(KW)
HLPNV0D1821A 1×200-240V 50/60Hz 0.18 1.2 0.18
HLPNV0D3721A 1×200-240V 50/60Hz 0.37 2.2 0.37
HLPNV0D7521A 1×200-240V 50/60Hz 0.75 4.2 0.75
HLPNV01D521A 1×200-240V 50/60Hz 1.5 6.8 1.5
HLPNV02D221A 1×200-240V 50/60Hz 2.2 9.6 2.2
HLPNV0D2523A 3×200-240V 50/60Hz 0.25 1.5 0.25
HLPNV0D3723A 3×200-240V 50/60Hz 0.37 2.2 0.37
HLPNV0D7523A 3×200-240V 50/60Hz 0.75 4.2 0.75
HLPNV01D523A 3×200-240V 50/60Hz 1.5 6.8 1.5
HLPNV02D223A 3×200-240V 50/60Hz 2.2 9.6 2.2
HLPNV03D723A 3×200-240V 50/60Hz 3.7 15.2 3.7
HLPNV0D3743A 3×380-480V 50/60Hz 0.37 1.2 0.37
HLPNV0D7543A 3×380-480V 50/60Hz 0.75 2.2 0.75
HLPNV01D543A 3×380-480V 50/60Hz 1.5 3.7 1.5
HLPNV02D243A 3×380-480V 50/60Hz 2.2 5.3 2.2
HLPNV03D043A 3×380-480V 50/60Hz 3.0 7.2 3.0
HLPNV04D043A 3×380-480V 50/60Hz 4.0 9.0 4.0
HLPNV05D543A 3×380-480V 50/60Hz 5.5 12 5.5
HLPNV07D543A 3×380-480V 50/60Hz 7.5 15.5 7.5
HLPNV001143A 3×380-480V 50/60Hz 11 23.0 11
HLPNV001543A 3×380-480V 50/60Hz 15 31.0 15
HLPNV18D543A 3×380-480V 50/60Hz 18.5 37.0 18.5
HLPNV002243A 3×380-480V 50/60Hz 22 43.0 22

HLP-NV Series
HLP-NV Series - 9-
2. General Specications
Inverter Series HLP-NV
Power
supply
Frequency 48~62HZ
Supply Voltage
380~480V±10% for 380V;
single/three phase
200~240V±10% for 220V
Motor
output
Output voltage 0~100% of supply voltage
Output frequency 0-200HZ(VVC+),
0-400HZ(V/F)
Over load 150% of rated current
Acc/Dec time 0.05~3600s
Control
Running control LCP operate;
Multi input terminals;
RS 485 serial
communication
Frequency setting
Control
terminals
Programmable
digital inputs
Number 5, terminal nos.: RUN,
F/R,RST,JOG,EMS
Voltage level
0~24V DC (“PNP” OR
“NPN”) ; Maximum
input: 28V DC
Logic Voltage level
PNP: “0”<5VDC;
“1”>10VDC;
NPN: “0” >19VDC;
“1” <14VDC
Input resistance 4KΩ
Anology
inputs
Volt age
Number 1;terminal nos.: VIN
Voltage level 0-10V DC ;
Maximum input 20V DC
Input resistance 10KΩ
Current
Number 2; terminal nos.: VIN,AIN
Current range 0/4-20mA(scaleable);
Maximum input: 30mA
Input resistance 200 Ω
Anology
outputs
Number 1;Terminal nos.: AO
Output Current range 0/4-20mA
Max.Load 500 Ω
Accuracy Max.error:0.5% of full
scale
Resolution 8bit

HLP-NV Series
HLP-NV Series
- 10 -
Control
terminals
24V DC Terminal number EV
Max.load 200mA
RS 485 Terminal number RS+( TX+, R X+),
RS- (TX-,RX-)
Ground for RS485 COM
Realy outpus
Terminal number 1,FA-FB(make),
FA-FC(break)
Max
load
Resistive load 250V AC 2A
30V DC 2A
Inductive load 250V AC 0.2A
24V DC 0.1A
10V DC output
Terminal number +10V
Output voltage 10.5±0.5V
Max.load 25mA
Surro-
undings
Enclosure IP20
Ambient temperature -10℃~50℃
Max.relative humidity 5%-95%
Vibration test 1.0g
Max.altitude above sea level 1000m
3000m(derating)
Protection
Functions
Electronic thermal motor protection against overload.
Temperature monitoring of the heatsink ensures that the frequency
converter trips if the temperature reaches 95 °C ± 5°C. An overload
temperature cannot be reset until the temperature of the heatsink
is below 70 °C ± 5°C (Guideline - these temperatures may vary for
different power sizes, enclosures etc.).
The frequency converter is protected against short-circuits on motor
terminals U, V, W.
The frequency converter is protected against earth faults on motor
terminals U, V, W.
Monitoring of the intermediate circuit voltage ensures that the
frequency converter trips if the intermediate circuit voltage is too low
or too high.
If a motor phase is missing, the frequency converter may trip.
If mains fault occurs, the frequency converter will ramp down to stop
and issues a warning.
If a mains phase is missing, the frequency converter trips or issues a
warning (dependingon the load).

HLP-NV Series
HLP-NV Series - 11 -
IV. Storage and Installation
1. Storage
The inverter must be kept in its original package box before installation.
Pay attention to the followings when keeping it in storage if the inverter
is not used for the time being:
● It must be stored in a dry place without rubbish or dust.
● The suitable temperature for storage is between -20℃ and +65℃.
● The relative humidity required is 0-95% without condensation.
● There is no corrosive gas or liquid in the storage ambience.
● It’s better to lay the inverter on a rack and keep it in a proper package.
● It is better not to store the inverter for long time. Long time storage of
the inverter will lead to the deterioration of electrolytic capacity. If it
needs to be stored for a long time make sure to power it up one time
within a year and the power-up time should be at least above ve hours.
When powered up the voltage must be increased slowly with a voltage
regulator to the rated voltage value.
2. Installation Site and Environment
The inverter should be installed at the following location:
● Ambient temperature -5℃ to 40℃with good ventilation.
● No water drop and low moisture.
● Free from direct sunshine, high temperature and heavy dust fall.
● Free from corrosive gas or liquid.
● Less dust, oil gas and metallic particles
● Free from vibration and easy for service and inspection.
● Free from the interference of electromagnetic noise.
Attention: The ambient conditions of the inverter will affect its
service life.
3. Installation and Direction
● There must be enough space left around the inverter for easy
maintenance and cooling.
● The inverter must be installed vertically with the smooth ventilation

HLP-NV Series
HLP-NV Series
- 12 -
for effective cooling.
● If there is any instability when installing the inverter, please put a at
board under the inverter bottom base and install it again. If the inverter
is installed on a loose surface, stress may cause damage of parts in the
main circuit so as to damage the inverter.
● The inverter should be installed on non-combustible materials, such as
iron plate.
● If several inverters are installed, upper and lower, together in one
cabinet, please add heat dissipation plates and leave enough space
between the inverters.

HLP-NV Series
HLP-NV Series - 13 -
V. Wiring
1. Main Circuit Wiring Schematic Diagram
Power supply:
● Verify that the inverter’s rated voltage coincides
with AC power supply voltage to avoid a damage
of the inverter.
No fuse breaker:
● Refer to the related list.
Ground fault circuit interrupter:
● Use one of anti-high harmonic.
Electromagnetic contactor:
● Note: Do not use the electromagnetic contactor as
the on/off button of power supply for the inverter.
AC reactor:
● It is recommended to install an AC reactor for
power factor improvement if the input capacity is
more than 1000KVA.
Inverter:
● Be sure to make correct connections of the main
circuit wires and control signal wires of the
inverter.
● Be sure to make correct setting of parameters for
the inverter.

HLP-NV Series
HLP-NV Series
- 14 -
2. Description of Terminal Block
1） Arrangement of Main circuit Terminals
POWER MOTOR
R
(L) ST
(N) -UDC +UDC BR U V W
2) Arrangement of Control Circuit Terminals
Function Description of Control Circuit Terminals
Function Description of Main circuit Terminals
Symbol Function Description
R S T Input terminal of AC line power. (220V class:for both
single/three phase, single phase connected to L and N)
U.V.W Output terminal of the inverter
+UDC BR Connector for braking resistor (optional).
-UDC Connector for DC reactor
Ground terminal: the third method of grounding for 220V
and special grounding for 380 V of Electrical Engineering
Regulations.
Symbol Function Description Default setting
setting
EV Common Terminal of Digital and
Control Signals ( +24V Power)
RUN Multi- Digital Input Start
F/R Multi- Digital Input Reverse
GND Digital Ground (for 24V power)
RST Multi- Digital Input Reset
JOG Multi- Digital Input Jog

HLP-NV Series
HLP-NV Series - 15 -
3. Basic Connection Diagram
The wiring of the inverter is divided into two parts, main circuit terminal
connections and control circuit terminal connections. The user can
see the main circuit terminals and the control circuit terminals after
removing the cover of enclosure. The terminals must be connected
correctly as the following wiring circuit diagrams.
The following diagram shows the Default setting standard connection of
Model HLP-NV
Symbol Function Description Default setting
setting
EMS Multi- Digital Input Bit0
AO Multi- Analog Output 0/4-20mA
+10V Power Supply for Analog Setting +10V
VIN Multi- Analog input Voltage
GND Analog Ground
AIN Multi- Analog input 0/4~20mA
FA FB FC Multi- Digital Output (Relay) FA-FC:break
FA-FB:make
COM RS+ RS- RS485 Communication port COM:Common for
RS+ and RS-
AO
