Holman 1215H User manual

Retractable Hose Reel
Instruction Manual
15M/25M Models
Installation, Hose Replacement, Care & Troubleshooting
1215H – Product Dimensions(mm): W:430 H:370 L:180 Weight: 7.00kg
1225H – Product Dimensions(mm): W:440 H:410 L:220 Weight: 10.6kg

Glossary
Thank you for purchasing this HOLMAN Retractable Hose Reel. This product uses a 12mm
reinforced hose for added strength and durability, and includes a multi-function hose gun.
(Hose Gun styling is subject to change)
For your information, please read these installation instructions before using the
Retractable Hose Reel. Please keep all instructions and refer to them when necessary.
Introduction
180º Wall Bracket
Mounting Tube
Retractable Hose Reel 180º Swivel Bracket Tap to Reel Hose
12mm Reinforced Hose
Multi Function Gun
Wall Plugs / Hexagonal Coach Bolts (included)

max 2m
The Retractable Hose Reel should be installed
nearest to your chosen water source for
convenience of use. Check that the tap to reel
hose can reach the tap prior to mounting the
hose reel.
Take the mounting bracket and place against either a wall or
wooden post.
Mark the position of where you would like the screws to be
placed through the centre of the bracket holes to prepare for
drilling.
Retractable Hose Reel - Instruction Manual
max 2m distance
from tap
It is very important to use the correct size drill bit,
so a very secure t of the wall bracket is made
before installing the Retractable Hose Reel.
When ready drill all four holes, then hammer the
wall plugs gently into your wall (if attaching to a
wall).
distance from tap
IMPORTANT - DO NOT LEAVE TAP
ON. TURN TAP OFF AFTER USE..
Drill Bit Plug Bolt
Drill Bit
Drill Bit
Bolt
Plug
Please note that if you are attaching your hose reel to a wooden post, you will not
require the wall plugs as the coach bolts screw directly into wood.
Take the wall plugs (supplied with the hose reel) and measure the correct drill bit width
to use. It is recommended that you drill slightly undersize as masonry materials all have
dierent properties and this will ensure the wall plugs have a secure t.
8mm
10mm
11.7mm
15m/25m (1215H/1225H)

Place the bracket in position over the four wall plugs and
screw each hexagonal coach bolt into your wall or wooden
post. Screw in each bolt until all four have a secure hold on the
bracket against the surface.
Take your Retractable Hose Reel,
and remove the securing pin at the
base of the mounting tube. Remove
the mounting tube from the hose reel
and slot the hose reel around the wall
bracket, so the tting tube hole lines
up with the wall bracket hole.
Connect the tap to reel hose, to the
garden tap.
Retractable Hose Reel - Instruction Manual
Then replace the mounting tube into its hole to hold the hose
reel in place and replace the securing pin into the base of the
mounting tube.
max 2m
distance from tap

Retractable Hose Reel - Instruction Manual Hose Replacement - 1215H/1225H Models
Lift the viewing panel to see the locking bars in
a secure position, having pulled the hose out to
its limit (retraction wheel must lock so the hose
doesn’t auto retract).
Before placing the locking bars in the auto
wheel, remove the viewing panel for ease of
access.
Once the viewing panel is removed, place the
locking bars in the nearest secure holes on the
auto wheel.
Ensure that both locking bars (on each side) are
placed securely in the holes on the auto wheel
before proceeding.
Hose Replacement Guide

Hose Replacement - 1215H/1225H Models
Unscrew the clamp holding the hose in place on
the auto retraction wheel.
Ensure you fully unscrew both sides of the
clamp before proceeding.
Keep the clamp and screws together away from
the inside mechanism. Next remove the white
plastic clip from the internal hose connector.
Detach the hose connector from the ‘quick
release’ snap on connection.
Hose Replacement Guide

Unscrew the hose connector from the hose,
ensuring you keep all the parts together.
Pull the old hose back through the auto
retraction guide hole, ready to t the new hose.
Feed the new hose through the guide hole
ready to attach the hose connector.
Connect the clip back onto the tting and
attach it back onto the snap on adaptor.
Hose Replacement Guide
Hose Replacement - 1215H/1225H Models

Repeat the hose removal process in reverse.
Attach the hose connector, plug the hose
connector on to the white plastic adaptor and
screw the hose clamp back into position.
Gently pull the newly installed hose to release
the auto retraction hose reel for it to start
winding the hose back in to the unit. The image
above shows how the hose reel should look
once fully retracted, ready for storage.
Hose Replacement Guide - 15m & 25m only
Hose Replacement - 1215H/1225H Models
General Note: Once you have replaced your
hose, unscrew the brown plastic ‘hose stop’
from the old hose and screw onto the new
hose at the desired distance away from the
hose end, allowing the hose to stop at the
correct point when retracting.
Take the locking bars out of the retraction
wheel and secure them inside the hose
wheel unit.

Hose Replacement - 1215H/1225H Models Care & Troubleshooting
Locking bars in the CORRECT position,
clipped to the outer casing.
You will nd an indication sticker 1 metre before
the maximum length. Do not pull the hose past
this point (unless when replacing the hose).
When walking the hose back to the unit, turn
o the tap, press the lever on the watering
gun to release the water pressure in the hose.
This makes the retraction to the hose reel a lot
easier and prolongs the life of your hose reel.
If the hose retraction wheel is stuck and the
hose is fully extended, the wheel still has
movement past this point. Grip the hose close
to the guide hole and gently pull.
The retraction wheel will give you enough
movement to unlock itself before you slowly
allow the auto retraction wheel to wind the hose
back into the unit.
Fully Extended Hose
Not Retracting
Warnings
� Do not leave the water turned on with the hose under pressure when not in use.
� Always turn the water o and draw the water from the hose after use.
� Do not attempt to pull hose reel apart.

Spare Parts
To order spare parts please call our customer service team on 1300 716 188.
Hose stopperMounting Tube
Tap to reel hosePlastic wall bracket

Spare Parts Notes

Retractable Hose Reel - Warranty
Should you have any questions about this product or its operation please telephone
our customer service helpline on 1300 716 188 or visit www.holmanindustries.com.au
Holman oer a 2 year replacement warranty from the original date of purchase.
To claim warranty the product must be returned to the place of purchase with a copy
of the original receipt.
We will honour all statutory guarantees that this product is of acceptable quality
(including that it is t for purpose).
