Installation Guide
40370

For Technical Support Call: 800-343-7486, Monday-Friday, 7AM - 4 PM (PST) Page 1
Instructions –40370
PLEASE READ ALL INSTRUCTIONS AND WARNINGS PRIOR TO
ASSEMBLING, INSTALLING, AND USING THIS PRODUCT.
Warning
Always check for wires, fuel tanks and lines, brake lines and other important
vehicle functionality items prior to drilling and installing all products.
Tools Needed
Phillips driver
1/4” Drill bit (optional)
Drill (optional)
Table of Contents
Parts List ...........................................................................................................................................1
Hardware List ....................................................................................................................................1
Step 1 –Assembly.............................................................................................................................2
Step 2 –Installation ..........................................................................................................................2
Step 3 –Optional Installation.............................................................................................................3
Before You Begin
Read all instructions.
Ensure safety when drilling.
Parts
Hardware

For Technical Support Call: 800-343-7486, Monday-Friday, 7AM - 4 PM (PST) Page 2
Instructions –40370
Step 1 - Assembly
Bolt all three pieces together as
shown below.
Use #10 x 1/2” pan head screw to
bolt into #10 nuts.
Top tray, sits on top of each flange
on sides.
Snug tighten, but allow movement.
Step 2 - Installation
Place previously assembled bin holder onto desired location.
One can mount this part to multiple different places. These instructions show them being mounted
to Holman 46” Shelf unit.
Bolt through existing holes in shelf side panel using a 1/4” x 1/2” pan head screw.
Repeat on all four locations.

For Technical Support Call: 800-343-7486, Monday-Friday, 7AM - 4 PM (PST) Page 3
Instructions –40370
Step 3 –Optional Installation
Note: If desired, one can move location of where the unit is installed. Place assembly where
desired, mark through the four holes.
Drill through the previously marked holes, Replace assembly and bolt the same way as in step 2.
GO BACK AND TIGHTEN ALL HARDWARE.
INSTALLATION IS COMPLETE.
