Holmatro Foudry Wedge HFW Series Operating and maintenance instructions

[phone] |[email protected] |www.holmatro.com
916.001.339_001
1 2
Warning!
Make sure the pump is switched ‘OFF’.
START position.
OFF
Required materials:
article number
(Holmatro)
description example
150.581.093 Anti friction coating spray
100.581.082 Molykote BR-2 Plus Grease
150.583.142 Glue Permabond A130
180.000.029 2x T-grip
- Allen key 5 mm
1
MAINTENANCE INSTRUCTION |HFW
Cleaning and greasing of the wedge and wedge blades
Recommanded is monthly or after every 10 working hours to keep your Holmatro Foudry Wedge in
optimal condition. 10h

2
[phone] |[email protected] |www.holmatro.com
916.001.339_000
6 7
4
Remove the wedge blades.
4
Start the pump. Set the pump switch to it’s
‘MAINTENANCE’ position.
Press the button, until the wedge is
extended completely. And switch
the pump to it’s ‘OFF’ position.
OFF
Remove the top and bottom covers.
4
5
3
Fasten the tumbler with help of the T-grips.
MAINTENANCE INSTRUCTION |HFW

3
[phone] |[email protected] |www.holmatro.com
916.001.339_000
4
10
Then apply a good amount of
the Molykote BR-2 grease to the
sliding surfaces by using a brush.
4
11
Apply the anti-friction coating to
the sliding surfaces and let it set
for 3 minutes.
3 min
12
Start the pump, press the button,
until the wedge is fully retracted.
And switch the pump to it’s ‘OFF’
position.
OFF
13
Apply glue A130 to the bolts.
89
Clean the sliding surfaces of the wedge and
wedge blades.
Clean the plunger area.
MAINTENANCE INSTRUCTION |HFW

4
[phone] |[email protected] |www.holmatro.com
916.001.339_000
17
Start the pump, set the switch to it’s ‘OPERATION’
position.
18
Now your Holmatro Foundry Wedge is ready for
use.
16
Loosen the tumbler with help of the T-grips.
14
Mount the top and bottom covers using an allen
key 5 mm.
15
Place both wedge blades (new) back into the
wedge.
MAINTENANCE INSTRUCTION |HFW
