HOLMS KHV 280 SMS bracket Specifications

OPERATOR INSTRUCTION
Box 924 S-591 29 Motala Tel [phone] Fax [phone]
© HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 5/4/06
From serial no: 5306.
KHV 2,8 / 3,2 / 3,6
Vee-plow

2© HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 5/4/06
HOLMS INDUSTRI AB
MOTALA SWEDEN
KHV 2,8 / 3,2 / 3,6
CONTENT: PAGE
Product facts 3
Genneral information 4
Driver‘s instruction
and users tip-off 5
Service and maintenance 6
Important security aspects 6
Connecting selector valve
(extra equipment) 6
Foreword
This manual is intended to be a guide for correct use
and maintenance of the plough. Study the manual
before starting up and operating or before any
prevention maintenance is carried out.
Be confident with the equipment and all the
instructions and keep the manual so it will always be
used before taking the equipment into operation.
OBS! This manual is made to suit all our markets.
There might be somedifferences andif thisis the case
for you please do not take notice.
We are continuously working on improvements and
we reserv the right to make design changes and
improvements without notice.
The operator is obliged to:
• Look after ev. warning signs to be readable.
• See to that no unauthorized person uses the
equipment or is within the operating area during
work or maintenance work
• Check that the carrier is appropriate to the
attachment (hydraulic flow, stability etc.)
When ordering spare parts or by other contacts with
Holms or your local dealer, always inform about the
attachment type and series No. This number you will
find on the machine plate..

© HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 5/4/06
3
HOLMS INDUSTRI AB
MOTALA SWEDEN
KHV 2,8 / 3,2 / 3,6
Centre of gravity
Technical data KHV 280
SMS bracket KHV 280
4000 bracket KHV 320
4000 bracket KHV 360
4000 bracket
Width (m) 2,8 2,8 3,2 3,6 Operating width by 30° angling (m) 2,5 2,5 2,7 3,1 Weight (kg) 740 820 900 920 Centre of gravity, measure A on drawing 427 mm 483 mm 810 mm 850 mm Centre of gravity, measure B on drawing 134 mm 128 mm 140 mm 140 mm Max. height excluding hooks (m) 1,05 1,05 1,1 1,1 Number of cutting edges 4444 Max hydraulic pressure (bar) 210 210 210 210
A
B

4© HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 5/4/06
HOLMS INDUSTRI AB
MOTALA SWEDEN
KHV 2,8 / 3,2 / 3,6
General information
The snow plough KHV has two (2) individual adjustable half-blades
hydraulically controlled. The control is carried out by two (2) double-
acting hydr. functions or by an electrically operated selector valve for
turning the half-blades.
The KHV-plough is equipped with spring-loaded cutting edges which
are reversible.
Between the quick hitch attachment and the centre bracket the
pendulation unit (damping element) is mounted which allows the
plough to operate in floating position towards the ground. The unit will
also make the transport softer (plough lifted up by the loading arms).
The tilting indicator mounted on the right hand side of the plough will,
when the two yellow markers are aligned, ensure the right angle of the
plow to the ground.
Stepless adjustable support plates are standard and to be used by
snow removal on soft (no frozen) ground.
Selector valve
Damping element Tilting indicator
Support plate
Do not make any modifications, changes, rebuilt work etc. which
are not approved by Holms Industri AB. We also ask you to pay
attention to spare parts not approved by us.

5© HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 5/4/06
HOLMS INDUSTRI AB
MOTALA SWEDEN
KHV 2,8 / 3,2 / 3,6
Coupling
The snow plough is connected to two (2) double acting
hydraulic functions (see fig.) or one single function and
electrical connection for the selector valve.
Make sure the couplings are free from dust!
Setting
1. The plough is lifted and the attachment bracket is tilted
to about 90° to the ground.
2. Lower the loader arms until the plough contacts the
ground and the tilting indicator markers are aligned.
3. Now the ground pressure can be set by the tilting
function. Normally the plough shall be operated tilted
within its movement area. To check the middle of the
movement area tilt forwards and backwards.
4. Operating with the plough in the middle of the
movement area will give the best ground follow, but
temporarily the ground pressure can be raised or reduced
by tilting forewards (raised) or backwards (reduced).
5. Only the tilting function is to be used for adjusting the
ground pressure. By using the lifting function the plough
contact is adjusted, see picture .
6. Check that the plow is moving free in all positions from
the wheel loader wheels.
Tilt to increase
or decrease the
ground pressure.
Lift or sink to
obtain the
right angling
to the ground.
Connect to the 3:rd
Connect to the 4:th hydraulic function.
hydraulic function.

6© HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 5/4/06
HOLMS INDUSTRI AB
MOTALA SWEDEN
KHV 2,8 / 3,2 / 3,6
Service and maintenance
After every use of the plough, check the wear of the
cutting edges and the bushings.
Once a season, after winter season, check also hoses,
hydraulic valves and cylinders. Check eventual wear and
oil leakage.
Check the welded construction for eventual crack
formations.
The cylinders shall be protected from surface rust by
grease or other corrosion protection.
Important safety regulations
to be noticed
• Be sure the loader is designed to carry / operate this
attachment with this weight.
• Be sure that unqualified persons are not close the
operating area during work or maintenance.
• Always use the quick coupling plugs and put the hose-
ends into the holders, when the plough is disconnected to
avoid dirt coming into the hydraulic system and to protect
the hoses.
Connecting selector valve (extra equipment)
