Holzstar HBS Series User manual

HBS 400
Operating Instructions
HBS SERIES
Band Saw
HBS 400
HBS 471
HBS 473

Operator Safety: Required Reading
Important
Safety is the single most important consideration in the operation of this equipment.
The following instructions must be followed at all times.
There are certain applications for which this tool was designed. We strongly
recommend that this tool not be modified and/or used for any other application other
than that for which it was designed. If you have any questions about its application, do
not use the tool until you have written us and we have advised you.
General Safety Warnings
KNOW YOUR POWER TOOL. Read the owners man al caref lly. Learn the tools
applications, work capabilities, and the specific potential hazards pec liar to it.
DANGER! ALWAYS GROUND ALL TOOLS.
If yo r tool is eq ipped with a three-pronged pl g, yo m st
pl g it into a three-hole electric receptacle. If yo se an
adapter to accommodate a two-pronged receptacle, yo
m st attach the adapter pl g to a known gro nd. Never
remove the third prong of the pl g.
ALWAYS AVOID DANGEROUS ENVIRONMENTS.
Never se power tools in damp or wet locations. Keep yo r
work area well lighted and clear of cl tter.
DANGER! ALWAYS REMOVE THE ADJUSTING KEYS
AND WRENCHES FROM TOOLS AFTER USE.
Form the habit of checking to see that keys and adj sting
wrenches are removed from the tool before t rning it on.
ALWAYS KEEP YOUR WORK AREA CLEAN.
Cl ttered areas and benches invite accidents.
DANGER! ALWAYS KEEP VISITORS AWAY FROM
RUNNING MACHINES.
All visitors sho ld be kept a safe distance from the work
area.
ALWAYS MAKE THE WORKSHOP CHILDPROOF with
padlocks, master switches, or by removing starter keys.
1

DANGER! NEVER OPERATE A TOOL WHILE UN-
DER THE INFLUENCE OF DRUGS, MEDICATION, OR
ALCOHOL.
DANGER! ALWAYS WEAR PROPER APPAREL.
Never wear loose clothing or jewelry that might get ca ght
in moving parts. R bber-soled footwear is recommended
for the best footing.
DANGER! ALWAYS USE SAFETY GLASSES.
Also se a face or d st mask if the c tting operation is
d sty.
DANGER! NEVER OVERREACH.
Keep yo r proper footing and balance at all times.
DANGER! ALWAYS DISCONNECT TOOLS
before servicing and when changing accessories s ch as
blades, bits, and c tters.
ALWAYS AVOID ACCIDENTAL STARTING.
Make s re switch is in OFF position before pl gging in
cord.
NEVER LEAVE TOOLS RUNNING UNATTENDED.
DANGER! NEVER STAND ON TOOLS.
Serio s inj ry co ld occ r if the tool is tipped or if the
c tting tool is accidentally contacted.
DANGER! ALWAYS CHECK FOR DAMAGED PARTS.
Before initial or contin al se of the tool, a g ard or other
part that is damaged sho ld be checked to ass re that it
will operate properly and perform its intended f nction.
Check for alignment of moving parts, binding of moving
parts, breakage of parts, mo nting, and any other
conditions that may affect its operation. A g ard or other
damaged parts sho ld immediately be properly repaired or
replaced.
2

Special Safety Rules For Bandsaws
Always stop the bandsaw before removing scrap pieces from the table.
Always keep hands and fingers away from the blade.
Never attempt to saw stock that does not have a flat s rface, nless a s itable s pport is
sed.
Always hold material firmly and feed it into the blade at a moderate speed.
Always t rn off the machine if the material is to be backed o t of an ncompleted c t.
Adj st the pper g ide abo t 1/8" above the material being c t.
Check for proper blade size and type for the thickness and type of material being c t.
Make s re that the blade tension and blade tracking are properly adj sted.
Make relief c ts before c tting long c rves.
Release blade tension when the saw will not be sed for a long period of time.
User Responsibility / Warranty
This machine will perform in conformity with the description contained in the instr ctions
provided. This machine m st be checked periodically. Defective eq ipment (incl ding
power cable) sho ld not be sed. Parts that are broken, missing, obvio sly worn, distorted
or contaminated, sho ld be replaced immediately. Sho ld s ch repair or replacement
become necessary, it is recommended that only gen ine replacement parts are sed and
that s ch repairs are carried o t by q alified persons. This machine or any of its parts
sho ld not be altered or changed from standard specifications. The ser of this machine
shall have the sole responsibility for any malf nction that res lts from improper se or
na thorized modification from standard specifications, fa lty maintenance, damage or
improper repair by anyone other than a q alified person.
1.0
2.0
3.0
4.0
5.0
6.0
7.0
8.0
9.0
10.0
1.0 Specification
Throat width:
Sawblade length:
Sawblade width:
Sawblade tilt:
Max. c tting depth:
Sawtable size:
Sawblade speed:
Motor power:
3
Specification
Getting to know yo r bandsaw
Assembly
Adj stment
Operation
Maintenance
Wiring diagram
Tro bleshooting
Parts diagram
Parts list
Page 3
Page 4
Page 5
Page 6,7,8
Page 9
Page 9
Page 9
Page 10
Page 11,12,13
Page 14,15
Contents
18-3/8" (465mm)
136" (3454mm)
1/4"~1-1/2" (6~38mm)
-10o~45o
11-1/4" (285mm)
21"x19" (535mmx485mm)
50Hz--380m/min or 820m/min; 60Hz--460m/min or 980m/min
1 phase--2.1Kw S6 40%; 3 phases--2.5%Kw S6 40%

2.0 Getting to know your bandsaw
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
A. Hang Up Ring
B. Tension Indicator Window
C. Blade Tension Handwheel
D. Main Switch
E. Rip Fence
F. Speed Handwheel
G. Blade Guide
H. Guide ost Handwheel
I. Blade Tracking Window
J. Quick Release Lever
K. Guide ost Lock Knob
L. 4 Dust orts
M. Motor
N. Table Tilting Knob
O. Blade Tracking Knob
4

3.0 ssembly
The machine is s pplied partly assembled. Prior to
se, the following items have to be assembled;
working table, rip fence and crank handle.
WARNING! Use a 2,000kgs wrecker hang p this
bandsaw with Ring (Fig.1) to s itable place. To
ens re s fficient pright stability of this bandsaw
and safety, yo need to bolt this bandsaw to floor on
M10 screw.
Fitting W rking Table
With the help of another person, lift the working
table onto the tr nnion.
Mo nt the working table to the tr nnion sing the
s pplied (4) hex bolts and (4) washers (A--Fig. 2).
Using Hex socket screw, b shing, washer and
wingn t (B--Fig. 2) for the working table flatness.
Fitting Rip Fence
Install the rear fence rail to the table with (2)
M6-1.0 x 20 hex bolt and (2) flat washer M6 (Fig.3).
Install the front fence rail to the table with (4)
th mb screw and (4) flat washer M8 (Fig.3).
Make s re the end cap is locked into the rear fence
rail. Then set the fence on the front and rear rails.
Fitting Crank Handle
Attach the big crank handle (Fig.4) and small crank
handle (Fig.4) with 14mm and 10mm wrench
separately.
Ring
Fig.1
A B
Fig.2
Fig.3
Rear fence rail Bolt/washer
Front fence rail
Th mb screw/washer
Fig.4
Big crank handle
Small crank handle
5

4.0 djustment
Setting the Table Square t Saw Blade
The table may be set at 90o to the saw blade by
adj sting the table stop screw nder the table.
The table stop screw rests on the top of the lower
wheel bandwheel ho sing. By first slackening the
locking n t (A--Fig.5) and then adj sting the screw
(B--Fig.5), the table can be set correctly. Retighten
the locking n t (A--Fig.5) making s re that the
setting is maintained.
Tilting the Table
Loosen the lock handle (A--Fig.6) on the table
tr nnion.
T rn the table tilting knob (B--Fig.6) to adj st the
table to the desired angle. Use the angle indicator
scale on the tr nnion bracket to find the desired
angle.
Retighten the lock handle to sec re the table. Fig.6
Fig.5
Fig.7
AA
AA
ABB
BB
B
Tracking the Saw Blade
WARNING! Unpl g the bandsaw.
Firstly, make s re the pper and lower blade
g ides are adj sted away from the blade and the
tension scale reading corresponds to the width
blade yo are sing.
Then loosen the lock lever (Fig.7) by t rning it
co nterclockwise and t rn the blade tracking knob
(Fig.7) clockwise/co nterclockwise while t rning
the pper wheel by hand at least three rotations
ntil the blade tracks centered on the wheel.
Finally, tighten the lock lever and close the doors.
Lock Lever
Blade Tracking Knob
Adjusting the Blade Tensi n
To loosen the tension of the blade, t rn the blade
tension handwheel (Fig.8) co nter clockwise.
To tighten the tension of the blade, t rn the blade
tension handwheel.
Tension the blade ntil the tension readings
corresponds to the width blade yo are sing
thro gh the tension indicator window (Fig.8). Fig.8
Blade Tension Handwheel
Tension Indicator Window
6
A
B

Adjusting the Blade Guides
Upper G ides:
To adj st the pper blade g ides, first position the
roller g ides relative to the blade by slackening off
the hex n t (A--Fig.9) and moving the g ide carrier
ntil the roller g ides are approx. 1/16" behind the
g llets of the blade. Next set the roller g ides to
within 1/32" of the blade by releasing the screw (B--
Fig.9) on each side of the blade. Do not set the
g ides too close as this will adversely affect the life
of the blade. Finally, adj st the thr st bearing to be
j st clear of the back of the blade by nlocking the
hex n t (C--Fig.9). When the correct adj stment is
reached, lock the thr st bearing in position with the
hex n t (A--Fig.9).
Lower G ides
To adj st the lower blade g ides, first slacken off the
hex n t (A--Fig.10) then move the g ide carrier
casting to the approx. 1/16" behind the g llets of the
bandsaw blade and tighten the hex n t (A--Fig.10).
Next set the roller g ides to within 1/32" of the blade
by releasing the screw (B--Fig.10) on each side of
the blade. Finally, adj st the thr st bearing to be j st
clear of the back of the blade by nlocking the hex
n t (C--Fig.10).
Fig.9
Fig.10
AB
C
A
BCD
Fig.11
Fig.12
Adjusting the Cutting Height
Loosen the guide post lock knob (Fig.12) and turn the
guide post handwheel (Fig.12) to raise or lower the
guide post/upper blade guide assembly to the
desired height. Then tighten the guide post lock knob.
Note The bottom edge of the guide bearings are
approximately 1.4" above the top surface of the
workpiece.
Guide Post
Lock Knob
Guide Post
Handwheel
Adjusting the Rip Fence Guide Scale
Slide the rip fence against to blade along the rail.
and loosen the fixing screw (A--Fig.11). Then move
the scale (B--Fig.11) sideways and align the zero of
scale with the line on the magnifying window (C--
Fig.11). Retighten the fixing screw when the
adj stment is correct.
The adj stment may be checked by setting the rip
fence to a thickness and c tting a test piece.
When the adj stment is correct the thickness of the
test piece will correspond with the rip fence scale
setting.
7
ABC

Fig.13
AA
AA
ABB
BB
BCC
CC
C
Changing the Blade Speed
WARNING! Before changing the speed always
make s re the machine has been npl gged from
the electrical s pply.
This Bandsaw has two blade speeds, low speed
and high speed.
The lower bandwheel (A--Fig.13) has two, integral,
m lti-vee form p lleys and the motor shaft has a twin
m lti-vee form p lley (B--Fig.13).
The m lti-vee belt (C--Fig.13) passes aro nd the
bandwheel p lley and the motor p lley. The belt
tension is released and applied by sing the
cranked handle (D--Fig.13).
For the high speed, the belt sho ld be fitted to the
rear p lley on both the motor and bandwheel. As
shown in Fig.13.
For the low speed, the belt sho ld be fitted to the
front p lley on both the motor and bandwheel. As
shown in Fig.13.
ABC
D
High Speed
Low Speed
e) When fitting the new blade ens re the blade teeth are pointing downwards and towards
yo at the position where the blade passes thro gh the table.
f) Re-tension the new blade by rotating the q ick release lever (Fig.14) co nterclockwise and
check the blade tracking. The blade sho ld r n in the center of the bandwheel. Refer to
Tracking the Saw Blade on page 6 for more details.
g) Reset the blade g ides as described in the section Adj sting the Blade G ides on page
7.
h) Reset the blade tension as described in the section Adj sting the Blade Tension on page
6.
i) Replace the rip fence g ide, and retighten the 4 th mb screws (Fig. 3 on page 5).
j) Close and lock both the bandwheel doors before reconnecting the power s pply.
Replacing the Bandsaw Blade
WARNING! Unpl g the machine from the electrical s pply. This ens res that the Bandsaw
will not accidentally t rn on if the ON/OFF switch is b mped.
a) Open the top and bottom bandwheel doors by
t rning the door locking knobs.
b) Remove the rip fence rail from the front of the
table by releasing the 4 th mb screws (Fig. 3 on
page 5).
c) Release the blade tension by rotating the q ick
release lever (Fig.14) clockwise.
d) Remove the saw blade by feeding it thro gh the
slot in the table, pper and lower blade g ides and
the slot in the spine of the machine being caref l not
to c t yo rself. Wear gloves if necessary. Fig.14
Q ick Release Lever
8

5.0 Operation
The blade c ts on a contin o s downstroke.
With both hands, firmly hold the workpiece down on the table, and feed it towards
the blade slowly, keeping yo r hands away from the blade.
For best res lts the blade m st be sharp. A d ll blade will not c t correctly, especially
when straight c tting, and ca ses excess press re to be applied on the rear g ide
bearings.
Select the right blade for the job, depending on the thickness of the wood and the
c t to be made. The thinner and harder the wood, the finer the teeth of the blade.
Use a fine tooth blade for c tting sharp c rves.
The machine is especially s ited for c tting c rves, b t will also make straight c ts.
When c tting, follow the design marked o t by p shing and t rning the workpiece
evenly.
Do not attempt to t rn the workpiece witho t p shing it, as this may ca se the
workpiece to get st ck, or the blade to bend.
For straight c ts, se the fence provided to feed the workpiece along the blade
slowly and in a straight line.
6.0 Maintenance
CAUTION! BEFORE CLEANING OR CARRYING OUT MAINTENANCE WORK,
DISCONNECT THE MACHINE FROM THE POWER SOURCE (WALL SOCKET).
NEVER USE WATER OR OTHER LIQUIDS TO CLEAN THE MACHINE. USE A BRUSH.
REGULAR MAINTENANCE OF THE MACHINE WILL PREVENT UNNECESSARY
PROBLEMS.
Keep the table clean to ens re acc rate c tting.
Keep the o tside of the machine clean to ens re acc rate operation of all moving parts
and prevent excessive wear.
Keep the ventilation slots of the motor clean to prevent it from overheating.
Keep the inside (near the saw blade, etc.) clean to prevent acc m lation of d st.
7.0 Wiring diagram
WARNING! This machine must be gr unded.
Replacement of the power s pply cable sho ld only be done by a q alified electrician.
9
Main Switch
1phase
Motor
Power
Cord
Main Switch
Power
Cord
Sa ety
Switch
3 phases
Motor
Sa ety
Switch

8.0 Troubleshooting
WARNING: FOR YOUR OWN SAFETY, ALWAYS TURN OFF AND UNPLUG THE
MACHINE BEFORE CARRYING OUT ANY TROUBLESHOOTING.
10
TROUBLE
The machine does not
work when switched on.
The blade does not move
with the motor running.
The blade does not cut
in a straight line.
The blade does not cut,
or cuts very slowly.
Sawdust builds up inside
the machine.
Sawdust inside the
motor housing.
The machine does not
cut at 45o or 90o angles.
The blade cannot be
properly positioned on
the bandwheels.
PROBABLE CAUSE
. No power supply.
2. Defective switch.
. The quick release lever or
blade tension handwheel has
not been tightened.
2. The blade has come off one of
the wheels.
3. The saw blade has broken.
4. The drive belt has snapped.
. Fence for cutting not used.
2. Too fast feed rate.
3. The blade teeth are dull or
damaged.
4. Blade guides not suitably
adjusted.
. The teeth are dull, caused by
cutting hard material or long
use.
2. The blade was mounted in the
wrong direction.
. This is normal
. Excessive dust build-up on
the machine exterior
components.
. The table is not at right
angles to the blade.
2. The blade is dull or too much
pressure was put on the
workpiece.
. The wheels are not in
alignment. Defective bearing.
2. The blade tracking knob
hasnt been properly adjusted.
3. Inferior blade.
REMEDY
Check the cable for breakage.
Contact your local dealer for repair.
Switch off the motor, tighten the quick release
lever or blade tension handwheel.
Open the hinged door and check.
Replace the blade.
Replace the belt.
Use a fence.
Put light pressure on the workpiece & make
sure the blade does not bend.
Use a new blade.
Adjust the blade guides (see the section on
page 7).
Replace the blade, use a 6 T.P.I. blade for
wood and soft materials. Use a 4 T.P.I.
blade for harder materials. A 4 T.P.I. blade
always cuts slower due to the finer teeth and
the slower cutting performance.
Fit the blade correctly.
Clean the machine regularly. Open the hinged
door and remove the sawdust with a vacuum
cleaner.
Clean the ventilating slots of the motor with a
vacuum cleaner. From time to time remove
the sawdust to prevent it from being sucked
into the housing
Adjust the table.
Replace the blade or put less pressure on the
workpiece.
Contact your local dealer for repair.
Adjust the knob (see the section on page 6).
Replace the blade.

11
9.0 Parts diagram

12

13

14
10.0 Parts list
Part o. DESCRIPTIO Part o. DESCRIPTIO
1 Pan Head Bolt M4-0.7x35 48 Rivet
2 Flat Washer M4 49 Hex Bolt M6-1.0x20
3 Safety Switch Seat 50 Clear Window
4 Ring 51 Bushing
5 Frame 52 Safety Switch
6 Set Screw M6-1.0x10 54 Nut M4
7 Switch Cord 55 Upper Wheel Cover
8 Flat Washer M5 56 Hex Bolt M6-1.0x25
9 Power Cord 57 Flat Washer M6
10 Hex Nut M6-1.0 58 Brush
11 Pointer 59 Hex Bolt M6-1.0x25
12 Step Screw 60 Star Handle
13 Upper Shaft 61 Nylon Nut M6-1.0
14 Roll Pin 5x36 62 Strain Relief
15 Upper Wheel Shaft Hinge 63 Strain Relief Nut
16 Upper Wheel Shaft 64 Small Handwheel
17 Bushing 65 Thread Rod
18 Bearing 6204 66 Knob Bolt M10-1.5x20
19 Upper Wheel 67 Knob Bolt M10-1.5x53
20 Int Retaining Ring M47 68 Threaded Handle M10-1.5
21 Flat Wahser M8 69 Cam
22 Hex Bolt M8-1.25x30 70 Pillow Block
23 Saw Blade 71 Shaft End
24 Board 72 Rod
25 Hex Bolt M6-1.0x30 73 Safety Switch Cord
26 Tire 74 Shaft
27 Lower Wheel 75 Cap Screw M8-1.25x20
28 Idle Pulley 76 Shaft-V Belt Pulley
29 Hex Nut M27x2 77 V Belt Pulley
30 Lock Washer 27 78 Circlip Ring
31 Motor Cord 79 Set Screw M8-1.25x20
32 Spring 80 Hex Nut M8-1.25
33 Roll Pin 3x16 81 Lower Wheel Shaft
34 Block 82 Motor
35 Bearing 51201 83 Hex Bolt M6-1.0x25
36 Switch 84 Lock Washer M8
37 Big Handwheel 85 Tongue
38 Adjusting Rod 86 Cap Screw M8-1.25x20
39 Phlp HD SCR w/Flange M5-0.8x10 87 Strain Relief Plate
40 Star Washer M5 88 Phlp HD SCR w/Flange
41 Plug-Safety Switch 89 Sliding Cover
42 Phlp HD SCR w/Flange M5x12 90 Key 5x5x35
43 Switch Plate 91 Hex Bolt M8-1.0x20LH
44 Hex Bolt M8-1.25x16 92 Motor Pulley
45 Flat Washer M8 93 V-Belt
46 Upper Wheel Sliding Bracket 94 Hex Bolt M6-1.0x30
47 Hex Bolt M6-1.0x25 95 Lower Wheel Cover

15
Part o. DESCRIPTIO Part o. DESCRIPTIO
96 Small Wheel Cover 150 Adjust Bar
97 Bolt M12-1.75x40 151 Tube
98 Hex Bolt M12x35 152 Hex Bolt M6-1.0x25
99 Hex Nut M12-1.75 153 Upper Guide Support Block
100 Small Gear 154 Phlp HD SCR M5-0.8x10
101 Table Tilting Knob 156 Rack
102 Trummion Support Bracket 157 Upper Guide Hose
103 Lock Washer 12 158 Big Crank Handle
104 Flat Washer M10 159 Hex Bolt M6-1.0x20
105 Hex Bolt M6-1.0x20 160 Bushing
106 Hex Bolt M6-1.0x50 161 Bushing
107 Pollow Block 162 Cap Screw M8-1.25x20
108 Hex Nut M6-1.0 163 Spring Washer 8
109 Adjustment Bolt M6-1.0 164 Guide Bracket
110 Bearing 6201 165 Worm Cylinder
111 Cap Screw M8-1.25x25 166 Fixed Plate
112 Flat Washer M8 167 Gear
113 Flat Washer M8 168 Fixed Bolt
114 Phlp HD SCR M5-0.8x6 169 Cover
115 Gear Plate 170 Hex Bolt M8-1.25x16
116 Nylon Nut M8-1.25 171 Phlp M4-0.7x8
117 Phlp HD SCR M5-0.8x6 176 Bushing
118 Lock Handle 201 Front Fence Rail
119 Flat Washer M5 202 Adjustable Base
120 Pointer 203 Fixed Shaft
121 Trunnion Plate 204 Shaft
122 Small Crank Handle 205 Spring Piece
123 Hex Bolt M8-1.25x16 206 Bracket
124 Carriage Bolt M8-1.25x80 207 Support Tube
126 Table 208 Internal Sheath
127 Table Insert 209 Handle
128 Hex Socket Screw M6-1.0x50 210 End Cap
129 Hex Bolt M5-0.8x10 211 Convex Window
130 Left Cover 212 Cap Screw M6-1.0x55
131 Hex Bolt M8-1.25x45 213 Lock Mechanism
132 Lower Blade Guide Support 214 Rear Fence Rail
133 Lower Blade Guide Seat 215 Hex Nut M8-1.25
135 Right Cover 216 Bushing
136 Hex Bolt M5-0.8x10 220 Fixing Screw
137 Flat Washer M5 221 Scale
138 Protective Cover 222 Hex Nut M6-1.0
140 Step Screw 223 Wing Nut
141 Flat Washer 224 Cap Screw M6-1.0x16
142 Sliding Plate 225 Hex Bolt M6-1.0x20
143 Retaining Ring S15 226 Pan Head Screw M4-0.7x5
144 Bearing 6201 227 Flat Washer M6
145 Upper Blade Guide Support 228 Flat washer M8
146 Guide Ring 229 Thumb Screw
148 Carriage Bolt M8-1.25x85 230 Nut M8
149 Hex Bolt M6-1.0x15 231 Hex Bolt M8-1.25x55

Liability for defects (warranty)
HBS Series | Version 1.04
Liability for defects (warranty)
The legal regulations apply for our customers who are the con-
sumers. The customer has to give us the opportunity to con-
vince ourselves of the defect and to bring the product at our re-
quest and cost to one of our shops for examination. The
following points apply for our commercial customers:
(1) The customer has to check the delivered goods immedi-
ately upon delivery in particular on defects. He has to inform us
immediately about any determined apparent defects. He also
immediately has to inform the carrier about any transportation
damages and missing packages. If it is not possible to immedi-
ately detect the defects even though the goods are thoroughly
checked, he has to inform us immediately upon detection of the
defects in writing. In this case our customer immediately has to
stop the processing, machining and use of the ordered goods.
The customer has to give us the opportunity to convince our-
selves of the defect and to bring the product at our request and
cost to one of our shops for examination. After execution of an
agreed acceptance, the notice of defects which were identifia-
ble during acceptance shall be excluded. For commercial cus-
tomers, the legal term of liability for defects of 2 years is being
omitted.
(2) The term of liability for defects amounts to one year from the
passing of risk unless otherwise stated in the contract or law. If
the manufacturer of the delivered product grants a longer term
of liability for defects, we assign our rights hereof to the pur-
chaser/buyer already with the purchase of the product. We will
provide you a current list of the individual terms and conditions
of liability for defects of the manufacturers at any time upon
your request.
(3) In case of warranty we will provide rework or replacement in
consultation with the manufacturer at our choice. Necessary
expenses, in particular transportation, travel, labour and mate-
rial costs which are occurring since the purchased product
was transported to another place than the place of fulfilment,
do not imperatively have to be paid by us, unless it is pre-
scribed by the law. If reworks or replacements regarding a
defect demonstrably fail twice or would the repair of the defect
require a disproportionately high effort and the rework is there-
fore refused, the customer may request a reduction of the
reimbursement or an annulment of the contract. We point out to
our customers that there is no case of liability for defect in par-
ticular in case of defects which had been caused at the
premises of the customer due to misuse or improper use and
for defects which had been caused because the products
were exposed to damaging external influences (in particular
extreme temperatures, humidity, exceptional physical or elec-
trical stress, voltage fluctuations, lightning strikes, static elec-
tricity, fire) at the premises of the customer.
(4) If it results in the frame of an examination of the product due
to a notice of defects that the notice of defects was unjustified,
we are entitled to invoice a customary charge for the examina-
tion of the product as well as the transportation costs
(5) Our warranty does neither cover natural wear and tear,
improper use and storage, faulty installation nor damages
which are occurring after the passage of risk due to faulty or
negligent usage, excessive stress, improper operating equip-
ment or due to any other influences which are not provided
according to the contract.
(6) The claim for liability of defects due to an error is excluded
for any repair works performed by the purchaser/buyer or third
parties without our approval or improper repairs by a service
partner that is not authorised by the manufacturer.
(7) In cases of positive breach of contract, delay, impossibility,
unauthorised action as well as any other legal basis (except for
precontractual violations) we are only liable in case of intent or
gross negligence. In cases where culpable damage is caused
to live or health or bodily damage is caused, in cases of culpa-
ble negligence of cardinal contractual obligations (main con-
tractual obligations) or in the case of wilful deception as well as
in the event of a claim according to § 437 figure 2 Civil Law we
are liable to the statutory extent, whereby our liability for the
violation of cardinal obligations is limited to the amount of typi-
cally foreseeable damages. The term of cardinal obligations is
either used to denote a concretely described integral obliga-
tion jeopardising the attainment of the contractual purpose or
abstractly elucidated as a duty which must be fulfilled in order
that the contract can be duly and properly and on whose fulfil-
ment the customer may ordinarily rely. If we are in delay our
customer has either the right to demand damages or the right
to withdraw from the contract.
(8) In case of data losses we are only liable if our customer has
demonstrably saved the data stocks in regular intervals at least
once a day. The liability for data losses is limited to the restora-
tion cost if a backup copy is available, unless the data losses
were caused by us intentionally or grossly negligent. Other-
wise a liability is excluded except in cases of intent or gross
negligence.
(9) The scope of our liability according to the German Product
Liability Act remains unaffected.
Imprint
Product Identification
Band Saw Article Number
HBS 400 5900410
HBS 471 5900471
HBS 473 5900473
Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26
D-96103 Hallstadt
Hotline: [phone]
(0,49 €if calling from the German fixed
network)
Fax: [phone] - 55
E-Mail: [email protected]
Internet: www.holzstar.de
Indications regarding the operating instructions
Original Instructions
Edition: 18.09.2015
Version: 1.04
Language: English
Author: PS/MS
Indications regarding the copyright
Copyright © 2015 Stuermer Maschinen GmbH, Hall-
stadt, Germany.
The contents of these operating instructions is the sole
property of the company Stürmer Maschinen GmbH.
Passing on as well as copying of this document, the use
and distribution of its content are prohibited if not explic-
itly permitted. Contraventions are liable to compensa-
tion.
Subject to technical modifications and error.

www.holzstar.de
