HOMCOM 820-260V70 Manual

IN221000594V03 _UK_FR_ES_DE_IT
Electric oil filled heater

Buttons Body
Display panel
The power switch
Control box
Castor
Remove the product and all parts from the packaging box.
(1) Place the heater upside down, then place the castors onto the bottom using the wing nuts
and U-screw (fig. 2).
(2) Place the heater upright, so it is in the correct position.

Figure 2: Castor plate installation diagramme
2. What to check before using:
(1) Ensure the power cord is not damaged.
(2) Ensure the power source matches the electrical requirements stated on the heater
nameplate. Also make sure that it has safety grounding - if not, the outlet must be replaced.
Remote receiver
Display board
Boot
Increase
Decrease
Mode
Time
Temperature
If the display board is not showing anything, check the power cord and ensure the power
source is switched on.

1. Press the button to turn the appliance on. If there is no other operation, it will enter the
default mode, which is high grade (default temperature is 25°C). The mode button will light and
the middle display will show '3'. After three seconds, the display will show the temperature
setting.
2. Press the button again to put the product on standby.
3. Press and hold the power button to enter ' self test ' - the display screen will go off after two
seconds, whilst the high and low heating tubes will heat up for two seconds, then return to
standby.
4. When in its normal state, it will act as a switch. When turned off and then turned back on,
the product will remember the last mode used (the timer function is not memorised).
Mode button:
1. When plugged in, press the power button to turn the appliance on (default temperature is
25°C). The order is high, medium, low ECO and high. The middle display shows ‘3, 2, 1’ and
then ‘ECO 3’ in that order.
2 . When the mode is set, press the increase/decrease button to change the temperature.
3. When the mode is set, the indicator light in the middle of the mode button is highlighted.
The middle bit of the nixie tube shows the current setting, then it will show the set temperature
after three seconds.
4. The modes consist of low, medium and high. When in one of these modes, the temperature
can be set between 15-35°C. The current setting of the heating tube can be controlled
according to the set temperature and the temperature of the NTC probe. To do this, first press
the temperature button, then press the increase/decrease button to set the temperature – it
will automatically confirm after five seconds of no operation or directly press the temperature
button to confirm.
5. When in ECO mode, the temperature can be set between 15-35°C. The heater
automatically controls the switch of the heating tube according to the set temperature and
NTC probe temperature. The set temperature will automatically dop by 1°C every hour. It can
only be reduced manually by 5°C, with the minimum being 15°C.
Timing key:
1. Press the time button to set the timer – when it reaches zero, the appliance will turn off
automatically. The indicator light in the middle of the time button is highlighted –the time
content is shown on the three-digit digital tube. The first two parts show the hour and the last
part shows ‘h’.
2. Adjust the time by pressing the button – it will confirm automatically after five seconds of no
operation or press the time button to confirm(set between 0-24 hours).
3. No matter what mode the heater is in, a timer can be set to turn the appliance off
automatically.
4. Once the timer has been set, the indicator light in the middle of the time button is highlighted
(when the timer is set to 0, the indicator will turn off).

Temperature key:
1. Press the temperature button to adjust it – the light in the middle of the button will be
highlighted. The temperature is displayed using three digits – the first two digits show the
temperature and the last bit shows '°C'.
2. The default temperature is 25°C – change this by pressing the button. It will automatically
confirm after five seconds of no operation or confirm by pressing the temperature button
(temperature range: 15-35°C).
3. When on, hold the temperature button for five seconds – this will change the mode from
Celsius to Fahrenheit. When in Fahrenheit, hold the button for five seconds to switch back to
Celsius.
4. When in Fahrenheit, the default temperature is 77°F – the range is between 59-95°F.
5. The Celsius and Fahrenheit modes have a memory function. If there is a power outage, the
appliance will return to its previous settings when turned back on.
Increase/decrease buttons ▲/▼:
1. When there is not a mode, timer or temperature setting, the two corresponding lights will
be dim. There will be no response when pressing these buttons.
2. When setting a mode, timer or temperature, the two buttons will be active and the indicator
lights will be highlighted.
3. Press the temperature button to set the temperature.
Anti-tip function:
1. When the appliance is tilted, the digital tube flashes and displays ‘Eo’ – all functions will
turn off.
2. When the appliance is placed back to its upright position, the heater will resume to its
normal working function.
Anti-frost function:
1. When in standby, the mid-range heating will automatically turn on when the probe
temperature is lower than 5°C (41°F). When the probe temperature is higher than 7°C (45° F),
the heating will stop and return to standby.
2. When the frost protection is turned on, the LED will flash every two seconds – the digital
tube will show the current temperature (in degrees Celsius or Fahrenheit).
Note:
1. When on, if there is no operation after three minutes, the appliance will return to standby.
Press any button to return to its normal working state.
2. If there is a sensor short circuit, the letters ‘EH’ will flash. If there is a sensor open circuit,
the letter ‘EL’ will flash. If this happens, switch off the power and restart the appliance.

lll.Cleaning and maintenance
(1) When cleaning, avoid using abrasive substances or hard materials – this can damage the
coating and surface of the appliance.
(2) Use a soft and clean cloth to wipe the appliance.
IV.Notes
(1) Before using this heater, read and follow all instructions in this manual carefully.
(2) Do not cover the heater to prevent overheating.
(3) Do not place the heater directly below an electrical outlet or socket.
(4) Keep the heater away from humid environments, such as bathrooms. Do not immerse the
appliance in water or let liquid enter the body – this is an electrical hazard. Never use this
appliance near flammable or explosive materials.
(5) Never use this appliance if the power cord is damaged. It must be replaced by the
manufacturer, its service agent or a similarly qualified professional.
(6) The heater should be filled with a precise amount of professional HTF. Opening or repairing
the fins can only be done by the manufacturer or service personnel. If there is an oil leak, it must
be fixed by the manufacturer or service personnel.
(7) When throwing away your heater, check local regulations on how to safely dispose of the oil
inside the heater.
(8) Ensure the heater is placed on a smooth and even surface. Do not tilt or turn when in use.
(9) Do not place clothes, towels or other items directly on the heater – this is a safety
hazard that can cause overheating.
(10) After use or when left unattended, turn off and unplug the appliance. When unplugging,
grasp the plug and not the wire to avoid any damages.
(11) Before cleaning, turn off the appliance and wait for it to cool.
(12) When in use, keep the power cord away from the heater’s body.
(13) If, for any reason, the appliance does not work, turn off and unplug the appliance
immediately. Contact the manufacturer, its service agent or similarly qualified personnel for
inspection, repairs or replacements.
(14) Do not use other electric heaters or electrical appliances in the same outlet or circuit - this
can cause a circuit overload or fire.
(15) Do not use extension cords with this appliance.
(16) Do not use an automatic programme, timer or any other device to operate this heater.
(17) Do not insert hands, sticks or any other objects inside the heater.
(18) When in use, do not touch the heater’s surface with bare hands – this can cause burns. If
you need to move the heater, use the control panel as a handle.
(19) Keep combustible materials such as furniture, pillows, bedding, papers, clothes and
curtains at least 1m from the appliance.
(20)Do not place any objects on top of the heater.
(21)Children must be supervised to ensure that they do not touch or play with the appliance.
(22)When using the heater, keep doors and windows shut to get the maximum heating effect.
(23)Do not use the heater outdoors.
(24)Keep the product specification safe – do not discard it.
Only for UK:
A. Do not use two high-power appliances in the same socket
B. The plug needs to be plugged in fully
C. Product socket cannot use extension cord.
The socket need to be conformed to BS1363, The maximum withstand current value needs to
be greater than 13A.

Environment
NOTE:
This product should not be disposed of with household waste. Please recycle
where facilities exist.
Check with your local authority for recycling advice.
