Home Decorators Collection 13080 User manual

HOME
DECORATORS
COLLECTION
HDC# 13080 MFG# TW-19160WO
NAILHEAD CONSOLE TABLE 32"Hx48"Wx14"D WASHED OAK
ASSEMBLY INSTRUCTIONS
Note: 1. Before assembly, please be sure to work on a soft,
flat surface to avoid any damage to the finish.
2. You need at least 2 people to finish the assembly of
this product.
Made In China
P 1⁄3

BEFORE ASSEMBLY
IMPORTANT NOTE: READ CAREFULLY BEFORE ASSEMBLY TO PREVENT DAMAGE TO PARTS. FOLLOWING
INSTRUCTIONS LISTED BELOW IN THE PROPER SEQUENCE AS NUMBERED TO ASSURE FAST, EASY AND
CORRECT ASSEMBLY.
THANK YOU FOR PURCHASING THIS QUALITY PRODUCT. BE SURE TO CHECK ALL PACKING MATERTAL
CAREFULLY FOR SMALL PARTS, WHICH MAY HAVE CAME LOOSE INSIDE THE CARTON DURING
SHIPMENT. COUNT ALL PARTS AND MATERTAL HARDWARE, COMPARE WITH PARTS LIST TO BE SURE
ALL PARTS ARE PRESENT. IF ANY PARTS ARE MISSING OR DAMAGED, PHONE, FAX OR MAIL TO OUR
CUSTOMER SERVICE DEPARTMENT. FOR EFFICIENT AND SPEEDY SERVICE, PLEASE INDICATE THE
MODEL NUMBER AND CODE LETTER OF PART NEEDED.
HARDWARE LIST
ROUND HEAD BOLT ALLEN KEY
FLAT
WASHER
1PC
SPRING WASHER
8
SETS
A
OG
4
(2)
PARTS LIST
TOP FRAME LEG : LEG
1PC 1PC 1 PC
A B C
LEG BOTTOM
2 PCS 1 PC
D E
NOTE: THE SURFACE WITH THE STICKER IS THE BACK SIDE.
P 2/3

ASSEMBLE TOP FRAME (A), LEG (B & C & D) AND BOTTOM (Œ)
* INSERT THE LEGS (B & C & D) INTO THE 4 HOLES UNDER THE TABLE TOP.
e PUT BOTTOM (E) ONTO LEGS (B & C & D).
* USE ROUND HEAD BOLT, SPRING WASHER AND FLAT WASHER (1) TO ASSEMBLE TOP FRAME (A),
BOTTOM (E) AND LEGS (B & C & D) TOGETHER BY ALLEN KEY (2) AS SHOWN.
PLEASE ADJUST LEGS (B, C, & D) GENTLY. DO NOT FULLY TIGHTEN UNTIL BOTH SHELVES ARE IN
PLACE AND EVEN.
P 3/3
