Honeywell HF Series User manual

Local Air Conditioner
User Manual
Read and save these instructions before use
EN
Lokale Airconditioner
Gebruiksaanwijzing
Lees de gebruiksaanwijzing zorgvuldig en
bewaar deze goed
NL
Condizionatore d'aria Locale
Manuale Utente
Leggere attentamente le istruzioni prima
dell'utilizzo dell'apparecchio
IT
Lokale Klimaanlage
Benutzerhandbuch
Lesen sie die anleitung vor dem gebrauch
und heben sie sie auf
DE
Aire Acondicionado Local
Manual de Instrucciones
Lea y guarde estas instrucciones antes
de usar la unidad
ES
Climatiseur Local
Mode d'emploi
Lire ces instructions avant l'utilisation et
les conserver
FR
Model / Modèle / Modelo / Modello /
Model / Modelo / Modelo:
HF Series
www.honeywellportableac
[e-mail]
Ar Condicionado Local
Manual do Utilizador
Leia e guarde estas instruções antes da
utilização
PT

•
•
•
•
•
•
•
•
•
•
•
•
•
•
DO NOT operate the unit with a damaged plug or loose wall
outlet. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
DO NOT cover the air intake and exhaust when in use.
DO NOT place objects on or sit on the unit.
Always turn off and unplug the unit when cleaning or
servicing.
DO NOT use the appliance if it is damaged.
If service is needed contact an authorized service agent.
Unplug the unit when stored or not in use.
DO NOT pull or carry the appliance by the power cord.
DO NOT pinch the power cord in the door and DO NOT pull
it along edges or sharp corners.
DO NOT run the power cord under carpeting and rugs.
Use caution to prevent tripping on cord.
DO NOT use the device in the following cases:
- Near a fire source
- In areas where gasoline, paint or other flammable
goods are stored
- In an area where the water can be projected
DO NOT touch the plug or the device with wet hands.
Basic safety precautions should always be followed when
using electrical appliances.
SAFETY
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS. READ CAREFULLY AND
KEEP FOR FUTURE REFERENCE. IN CASE THERE IS ANY
INCONSISTENCY OR CONFLICT BETWEEN THE ENGLISH
VERSION AND ANY OTHER LANGUAGE VERSION OF THE
CONTENT OF THIS MATERIAL, THE ENGLISH VERSION
SHALL PREVAIL.
WARNING:
EN

SAFETY (CONTINUED)
This appliance has been manufactured for use in domestic
environments and should not be used for other purposes.
Only use the installation kit provided to install this unit.
DO NOT attempt to extend the hose or install this unit
using other methods other than that shown in this
manual. Improper installation will void any existing
warranties.
DO NOT use an extension cord with this unit.
This appliance can be used by children aged from 8 years
and above, and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
Never insert your fingers or rods into the air outlet. Take
special care to warn children of these dangers.
The manufacturer is not liable for injury caused to
persons or property damage due to non-compliance
with maintenance instructions and improper use of the
appliance.
The appliance shall be installed in accordance with national
wiring regulations.
The appliance is not to be used by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction.
Children should be supervised to ensure that they do not
play with the appliance.
•
•
•
•
•
•
•
•
•
EN

R290 SAFETY
SYMBOL NOTE EXPLANATION
WARNING
This symbol shows that this appliance uses a
flammable refrigerant. If the refrigerant is leaked and
exposed to an external ignition source, there is a risk
of fire.
CAUTION This symbol shows that the operation manual should
be read carefully.
CAUTION
This symbol shows that a service personnel should
be handling this equipment with reference to the
installation manual.
CAUTION This symbol shows that information is available such
as the operating manual or installation manual.
Read the instruction carefully before using the appliance.
R290 refrigerant gas complies with European environmental directives.
This appliance contains a certain number of grams (see rating label at the back of the unit) of
R290 refrigerant gas. The maximum refrigerant charge amount is 0.3 kg.
When defrosting or cleaning, do not use any method other than those recommended by the
manufacturer.
Do not place the appliance in a room with continuous sources of ignition (e.g. open flame,
operating gas appliance or working electrical heater).
Do not pierce and do not burn.
Do not perforate any part of the refrigerant circuit.
Refrigerant gas may be odorless.
The appliance must be installed, used and stored in an area that is greater than 12 m2.
Accumulation of possible refrigerant leaks in an unventilated room could lead to fire or explosion
should the refrigerant come in contact with electric heaters, stoves or other sources of ignition.
The appliance must be stored in a way to prevent mechanical damage.
Only individuals authorized by an accredited organization certifying their competence to handle
refrigerants in compliance with industry legislation should work on the refrigerant circuit.
Repair must be performed based on the recommendations from the manufacturer.
Maintenance and repair that requires the assistance of other qualified personnel must be
performed under the supervision of specialists in the use of flammable refrigerants.
Additional warnings for appliances with R290 refrigerant gas.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
EN

1
THANK YOU
Congratulations on your purchase of this Honeywell Local Air Conditioner.
Regarding the information pertaining to the installation, handling, servicing, cleaning and disposal
of the appliance, please refer to the below paragraph of the manual.
USER TIPS
Local Air Conditioners are ideal for spot cooling. The compressor, condenser and evaporator are
housed in a compact unit. The air is dehumidified and cooled while a flexible hose sends heat
outside. The Local Air Conditioner includes a window venting kit.
No permanent installation is needed. The unit is easy to move from room to room and offers a truly
flexible air conditioning solution.
Auto Evaporation System - The unit automatically evaporates the condensate through the hose.
There is no need to empty the drainage tank except in humid conditions. Read and follow the
instructions carefully.
To ensure optimal efficiency of the product, keep doors and windows closed when it is used as an air
conditioner or dehumidifier. If the product is being used with the fan function only, an open window
could improve air circulation.
EN
Important:
Before installing the unit, place it UPRIGHT for 1 hour before use to allow the refrigerant to stabilize.
Air outlet automatically opens when the unit is turned on, and automatically closes when the unit is
turned off. Manually adjust the air vent located at the top of the unit to adjust the direction of air flow.
Follow installation instructions to set up the unit.
Plug the unit into a properly grounded circuit. DO NOT plug into an extension cord.
•
•
Cooling and Dehumidifying
Operation Fan Operation

2
PARTS DESCRIPTION
EN
1) Control Panel 8) Upper Dust Filter
2) Air Outlet 9) Upper Rubber Drain Plug
(Dehumidifying Mode)
3) Handle 10) Lower Dust Filter
4) Casters 11) Drain Tube
(For Continuous Drain)
5) Remote Control 12) Drain Plug Cap
6) Hose Connector 13) Lower Rubber Drain Plug
(Air Conditioning Mode)
7) Cord Winder 14) Power Supply Cord
1
2
3
5
4
°F
°C
8
10
13
14
12
11
6
7
9

3EN
INSTALLATION
It is important that the installation instructions below are followed for successful installation of this
Local Air Conditioner. Please call Customer Support if you have any difficulties or queries
regarding these installation procedures.
Installation Kit:
Installation Steps:
Window bracket panel adapter, hose and hose connector are pre-assembled inside the package.1.
2. Adjust the window bracket as per width or height of your window and insert the plastic pin to
fix at the desired position. There is a hole where the hose will be inserted later. Make sure this
hole is not blocked.
Hole for Window Bracket
Panel Adapter and Hose
1. Window Bracket Kit (1 Set) 5. Hose (1 Piece)
2. Window Bracket Panel Adapter (1 Piece) 6. Foam Seal (adhesive) (2 Pieces)
3. Hose Connector (1 Piece) 7. Foam Seal (non-adhesive) (1 Piece)
4. Plastic Pin (2 Pieces)
4
x2
26.6", 36.2" to 52"
(67.5 cm, 92 cm to 132 cm)
Plastic Pin
1
x1
5
x1
x1
2 3
x1
6
x2 x1
7

4EN
INSTALLATION (CONTINUED)
3. Connect the hose to the rear exhaust outlet on the back of the unit. Slide-in the hose connector
then rotate clockwise until it is locked in place.
Note: After setting the window bracket to the size of your window, please remove it from the window
and follow the instructions below.
Hose:
Dia. 5.9" (15 cm)
Length: 10.6" to 59" (27 cm to 150 cm)
4. Connect the window bracket to the window bracket panel adapter. Ensure that all connections are
tight and installed properly.
Cut the Foam Seal (adhesive) to the proper length and attach them to the window sash
and frame.
5.
Horizontal Sliding Window Vertical Sliding Window

5EN
INSTALLATION (CONTINUED)
7. Cut the Foam Seal (non-adhesive) to the window length. Stuff the Foam Seal (non-adhesive)
between the inner window sash and the outer window glass to prevent air and insects from
getting into room.
Horizontal Sliding Window
Horizontal Sliding Window
Vertical Sliding Window
Vertical Sliding Window
Foam Seal
(adhesive)
Foam Seal
(non-adhesive)
Foam Seal
(non-adhesive)
Window
Sash Foam Seal
(adhesive)
Window
Sash
8. The Local Air Conditioner is now ready to use.
6. Connect the window bracket to the window.

6
INSTALLATION (CONTINUED)
IMPORTANT:
Do not replace or lengthen the hose as this could cause the unit to malfunction.
The supplied hose has a diameter of 5.9" (15 cm) and can be extended from
10.6" to 59" (27 cm to 150 cm).
Do not bend (to the extent shown below) the hose. A bent hose will block exhaust air
and cause the unit to malfunction or shut-off.
Make sure the back of the unit is at least 20" (50 cm) away from the wall. Do not place the unit in
front of curtains or drapes as this could obstruct the airflow.
•
•
•
WARNING: Any warranties included with this product will be voided if an extra extension hose is
added to the originally provided installation kit or if the installation is performed differently than the
manufacturer's instructions, without proper consultation. Please contact Customer Support for help
with installation procedures if needed.
Note: Due to the power input of the unit on start up, voltage drops may occur and this can influence
other equipment (e.g. dimming lights). Please make sure that the unit is connected to a supply with
a maximum permissible system impedance Zmax = 0.306 Ohm. If you require further clarification,
you may contact your local power supply authority.
Not Recommended Recommended
EN
20" (50 cm)
MIN 31 cm
MAX. 12" (31 cm)
MAX. 43" (110 cm)

7
USE AND OPERATION
CONTROL PANEL
FUNCTION BUTTONS
1) Indicator Lights 5) Timer / Temperature Set Controls
2) Power Control 6) Mode Control
3) Filter Reset 7) Timer Control
4) Fan Speed Control 8) Sleep Control
EN
The Power Control turns the unit on and off. When the unit is plugged into an appropriate
electrical outlet, the POWER indicator light will illuminate red indicating the unit is in a Standby
Mode, ready to be switched on at anytime. The air vent will automatically open when the unit is
turned ON and automatically close when unit is turned OFF.
POWER CONTROL
(6) (4) (3) (2)
(1)
(7)(8) (5)
When the operation has reached 250 hours, the Filter Reset light will illuminate.
Switch the Local Air Conditioner OFF and carefully remove filters from the unit and clean. Replace
filters and press the Filter Reset button, the Filter Reset light will turn off and the operation time will
be cleared.
FILTER RESET
4 settings: High, Medium, Low and Auto.
Note: Auto fan speed can be selected in cooling mode only.
FAN SPEED CONTROL

8
USE AND OPERATION (CONTINUED)
EN
FUNCTION BUTTONS (CONTINUED)
The default display is setting temperature.
In cooling mode, when or button is pressed, the set temperature is displayed and may be
adjusted.
Note: By pressing both or buttons at the same time, the display will toggle between Celsius
(°C) and Fahrenheit (°F).
•
•
TEMPERATURE CONTROL
MODE CONTROL
Air Conditioning Mode (COOL)
Adjust fan speed and air temperature to suit your desired comfort level.
Temperature setting range is 16°C - 32°C (60°F - 90°F).
Ambient temperature range is 16'C - 35'C (60'F - 95'F).
•
Settings: Air Conditioning, Dehumidifying, Fan, Auto.
The corresponding indicator light will illuminate to indicate the current mode setting.
Dehumidifying Mode (DRY)
Fan speed is preset to Low.
Note: If the unit will be used mainly as a dehumidifier, do not connect the hose. Continuous
drainage is then necessary (refer to Continuous Draining for Dehumidifier Mode).
IMPORTANT: The Dehumidifier mode is used to support moisture reduction but should not
be expected to dehumidify to the same degree as a standard dehumidifier-only appliance. The
built-in dehumidifier automatically adjusts dehumidification based on ambient room temperatures.
It is not possible to adjust to a desired humidity percentage. The front display only shows the
current and desired temperatures. It does not show humidity levels.
•
Fan Mode
For air circulation without air conditioner cooling.
Note: Auto fan speed cannot be selected in fan mode.
Auto Mode
Press the or button to select the temperature you want.
In this mode, the unit will automatically select cooling or fan only depends on the set temperature
and the room temperature. The Local Air Conditioner will control room temperature automatically
around the set temperature.
Note: Fan speed can't be adjusted in auto mode.
•
•

9
USE AND OPERATION (CONTINUED)
EN
FUNCTION BUTTONS (CONTINUED)
SLEEP MODE
The Timer is adjustable between 1 - 24 hours.
AUTO TURN OFF:
While unit is running, press the Timer button and the display will flash. While the display is
flashing, press the or button to select the number of hours you want the unit to turn OFF
automatically.
AUTO TURN ON:
When unit is in a standby mode (plugged in with power light on), press the Timer button
and the display will flash. While the display is flashing, press the or button to select the number
of hours until you want the unit to turn ON automatically.
TIMER CONTROL
When the Sleep Mode is activated in Air Conditioning mode, the set temperature will increase by 1°C
or 1°F after the first hour of cooling and will increase a further 1°C or 1°F after the second hour of
cooling. The unit will maintain this temperature for 5 hours. The set temperature will then reduce by
1°C or 1°F on the seventh hour and reduce a further 1°C or 1°F on the tenth hour. Sleep mode will
then deactivate automatically.
Note: The Sleep Mode can be deactivated during cooling mode by pressing any button at any time.
Condensation may accumulate in the unit.
If the internal tank is full, error code "P1" will be displayed and an alarm will beep for 30 seconds.
The unit will not operate until the water has been drained from the lower drain plug (refer to Water
Condensation Drainage).
After switching the Local Air Conditioner off, the compressor will not start immediately. You must
wait about 4 minutes before it switches back on again.
WATER FULL ALARM

10EN
USE AND OPERATION (CONTINUED)
REMOTE CONTROL
All key functions can be accessed from the remote control.
Use only two AAA or IEC R03 1.5V batteries.
Remove the batteries if the remote control is not in use for a month or longer.
All batteries should be replaced at the same time, do not mix with old batteries.
Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries.
Properly dispose of used batteries.
•
•
•
•
•
Caution:
°F
°C
Power Control
ON / OFF
Temperature Control
When the or key is pressed,
the set temperature is displayed
and may be adjusted
•
•
•
Sleep Control
Swing Control
In running mode: Auto switch off
In stand-by mode: Auto switch on
Press or button to adjust the
time setting for 1 hour intervals.
Timer setting is available from 1 - 24
hours by pressing the key or .
When timer is set, press the or
key will cancel the timer setting.
Mode Control • HIGH • MID • LOW • AUTO
ON / OFF
Press button to enable air outlet
louver swinging up and down. Press
button again to disable the swing
function. Swing can only be set from
the remote control.
Press button to change the
operation mode in the order of:
Fan Speed Control
Timer Control
Note:
Battery Installation: Remove the cover on the back of the remote control and insert two AAA
batteries with + and - pointing in the proper direction according to the polarity markings.
•
Air Conditioning Dehumidifying
Auto Fan

11
CLEANING AND MAINTENANCE
Appliance Maintenance:
Turn off the appliance before disconnecting the power supply.
Only clean the appliance with a soft dry cloth.
1.
2.
EN
Switch off and unplug the Local Air Conditioner from the
electrical outlet.
Remove the Upper Filter/ Grill, unscrew the Lower Filter/ Grill
and carefully remove.
Gently wash using water and/ or diluted liquid dishwashing
detergent. Rinse thoroughly and gently shake excess water
from the filters. Make sure the filters are dry before reinstalling.
Note: You may use a vacuum cleaner to remove dust.
Replace the Upper Grill onto the unit, and reinstall the Lower
Grill with the screw.
1.
2.
3.
4.
Dust Filter Maintenance:
The dust filter is to be cleaned every two weeks to maintain air cooling efficiency. Please follow the
below instructions for cleaning the dust filters:
WARNING: DO NOT power or operate the Local Air Conditioner when cleaning or when the Dust Filter
is removed from the unit, or if there is a loose-fitting Dust Filter. DO NOT attempt to handle or touch
any of the parts or wiring inside the Rear Grill after the Dust Filter has been removed from the unit.
Doing so can cause serious injury or electrical shock.
Rear
Grill
Upper
Dust Filter

12
Be sure to drain the left-over water condensation. Remove the lower drain plug and use a shallow
pan to collect the water (make sure to replace the deain plug cap when finished).
To dry excess moisture, run the unit in Fan only mode for 30 minutes before storing.
Turn off and unplug the Local Air Conditioner from the power supply.
Remove the dust filter and clean with water. Dry the dust filter and then reinstall.
Disconnecting the Window Installation Kit:
1.
2.
3.
4.
5.
Remove the Hose from the unit by rotating anti-clockwise then pulling away.
Remove the Foam Seal, Window Bracket, Window Bracket Panel Adapter and Hose Connector.
It is recommended to store the Window Kit parts in a bag together with the Remote Control,
Drain Tube and placing them together with the Local Air Conditioner unit.
If needed, you can clean the Window Kit with a damp cloth and water before storing.
Make sure all parts of the Window Kit are dry before storage.
•
•
•
•
Cover the Local Air Conditioner with a cloth/ plastic bag before storage, to protect from dust and
scratches collecting on the surface of the unit.
It is recommended to coil the power cord before storing to ensure the cord is protected from
bents and creases.
Store the Local Air Conditioner in a cool, dry place, away from direct sunlight.
6.
7.
8.
End of Season Storage and Maintenance:
If the appliance will not be used for a long time, follow these steps:
EN
CLEANING AND MAINTENANCE (CONTINUED)

13EN
WATER CONDENSATION DRAINAGE
When there is excess water condensation inside the unit, the Local Air Conditioner stops running
and shows an error code "P1" with an alarm. This indicates that the water condensation needs to be
drained using the following procedures:
Unplug the unit from power source.
Place a shallow pan under the lower rubber drain plug.
See diagram.
Remove the drain plug cap.
Water will drain out and collect in the shallow pan.
After the water is drained, replace the drain plug cap.
You can now turn on the unit.
1.
2.
3.
4.
5.
6.
Water may need to be drained in high humidity areas.
Lower
Rubber
Drain Plug
Shallow Pan
(not included)
Manual Draining in Cooling, Dehumidifying and Auto Modes
Unplug the unit from power source.
Remove the upper drain plug cap.
Some residual water may spill so please have a pan to
collect the water.
Connect the drain tube (included) to the upper drain
plug. See diagram.
The water can be continuously drained through the
drain tube into a floor drain or bucket.
Replace the drain plug cap.
You can now turn on the unit.
1.
2.
3.
4.
5.
6.
Continuous Draining for Dehumidifier Mode
Drain Tube (included):
Dia. 0.6" (1.6 cm)
Length: 23.6" (60 cm)
Upper Rubber
Drain Plug
While using the unit in dehumidifier mode, continuous drainage is recommended.

14
TROUBLESHOOTING GUIDE
The following troubleshooting guide addresses the most common problems. If problems persist, call
customer support. Unplug and disconnect the appliance from the power source before attempting
to troubleshoot.
EN
PROBLEM POSSIBLE CAUSE SOLUTION
The air
conditioning
unit does not
start
No electricity. Check for power.
Batteries in the remote
control need to be
replaced.
Change remote control batteries.
The power cord is not
properly plugged in. Remove and reconnect the power cord.
Runs a short
while only
The thermostat
temperature setting
is too close to room
temperature.
Lower the set temperature.
Air outlet is blocked. Make sure the hose is properly connected.
There are tight bends in
the air hose. Connect hose as per instructions on page 4.

15
TROUBLESHOOTING GUIDE (CONTINUED)
PROBLEM POSSIBLE CAUSE SOLUTION
Runs but not
cooling
A door or window is open. Make sure the window or door is closed.
The dust filter is dirty. Clean the dust filter.
The hose is detached. Reinstall hose properly
(refer to Installation section).
Temperature setting is
too high. Reduce temperature setting.
Air outlet or intake is
blocked. Remove blockage.
Room exceeds
recommended size. Move unit to smaller room.
Large size or number of
windows are decreasing
cooling effectiveness.
Cover windows with curtains or blinds.
Will not run and
error code "P1"
is displayed
Excess water
condensation inside
the tank.
Drain the water (refer to Water Condensation
Drainage).
EN

16
ERROR CODE GUIDE
ERROR CODE ERROR POSSIBLE CAUSE
"E1" Indoor temperature sensor failure (open circuit or short circuit).
"E3" Evaporator temperature sensor failure (open circuit or short circuit).
"P1" Water full alarm.
EN
