Honeywell Voyager 1602g User manual

Voyager 1602g
Wireless Area-Imaging Pocket Scanner
Quick Start Guide
Rev C
3/16
ʤʱʸʢʬʺʩʸʡʲʡʺʡʥʺʫʡʨʰʸʨʰʩʠʤʸʺʠʬʸʥʡʲwww.honeywellaidc.com.
ǀƸŮǍƯŽȚǀưƴŽwww.honeywellaidc.com ǟŽȘǚƲƄſȚ
Aller à www.honeywellaidc.com pour le français.
Vai a www.honeywellaidc.com per l'italiano.
Gehe zu www.honeywellaidc.com für Deutsch.
Ir a www.honeywellaidc.com para español.
Para Português, acesse www.honeywellaidc.com.br.
Перейти на русскоязычный сайт www.honeywellaidc.com.
Pro češtinu jdi na www.honeywellaidc.com.
Pre slovenčinu choďna www.honeywellaidc.com
日本語 : www.honeywellaidc.com をご覧ください。
查看中文简体版请登陆 www.honeywellaidc.com。
查看繁体版请登陆 www.honeywellaidc.com
한글 www.honeywellaidc.com 로이동합니다 .

Note: Refer to your User’s Guide for information about cleaning your
device.
Getting Started
The scanner’s battery must be fully charged before the first use. It
can be charged using a power supply or by connecting the USB
cable to a computer.
Charging via Power Supply:
Note: The power supply must be ordered separately, if needed.

Connecting the Scanner to a USB Port:
Turn off the computer’s power before connecting the scanner, then
power up the computer once the scanner is fully connected.
Note: If you are charging the scanner using the USB cable, the
current available for charging is reduced and charge times are
increased. Charging via the power supply is faster.

Battery Charge Indicator
When the battery is charging, the small LED at the top left of the
scanner flashes orange. When the battery is fully charged, this LED
is solid green.
Reading Techniques
The scanner projects an aiming
beam that should be centered over
the bar code, but it can be posi-
tioned in any direction for a good
read.
Hold the scanner over the bar code,
press the button, and center the
aiming beam on the bar code.
The aiming beam is smaller when
the scanner is closer to the code and larger when it is farther from
the code. Hold the scanner close to smaller bar codes, and farther
away from large bar codes to get a proper read.

If the bar code is highly reflective (e.g., laminated), you may need to
tilt the scanner at an angle so the bar code can be scanned.
Note: The scanner clicks while attempting to connect to the host. If
three beeps sound after the clicks, the link has not been
established. If the scanner beeps once, the link has been
established.
Standard Product Defaults

Scan the following bar code to reset the scanner to all standard
product default settings.
Note: PDF and 2D bar codes can only be read by Voyager model
1602g2D and cannot be read by model 1602g1D.
Pairing the Scanner
with Bluetooth Devices
The scanner can be used either with a Honeywell Access Point
(AP01-XXXBT) or with other Bluetooth devices. Those devices
include personal computers, laptops, tablets, and Apple®devices.
1. Scan the Bluetooth HID Keyboard Connect bar code below.
2. Set your personal computer, laptop, tablet, or Apple device so it
searches for other Bluetooth devices. (Refer to your device’s
User’s Guide for pairing instructions.)
Standard Product Defaults
Bluetooth HID Keyboard Connect

3. Once your personal computer, laptop, tablet, or Apple device has
located the scanner, select the Voyager 1602g scanner name
from the list displayed. Some personal computers, laptops, or
tablets will automatically pair with the scanner. If your device
automatically pairs with the scanner, it displays a successful
pairing message and you do not need to continue to the next
step.
4. If your personal computer, laptop, or tablet does not
automatically pair with the scanner, a PIN is displayed. This PIN
must be scanned within 60 seconds. You must quickly scan
Bluetooth PIN Code below, then scan the numeric bar code(s) for
the PIN code from the Programming Chart, then scan the Save
bar code.
Your personal computer, laptop, tablet, or Apple device should now
be paired with the scanner and be able to accept incoming data from
the Voyager 1602g. If you are using an Apple app to communicate
with the scanner using serial port protocol (SPP), refer to the Voy-
ager 1602g User’s Guide on our website, www.honeywellaidc.com.
Disconnect from Host and Connect to an
Access Point
If your scanner has been connected directly to an iPad, smart
phone, or laptop, you must disconnect it in order to communicate
with an Access Point. Scan the Bluetooth HID Keyboard Discon-
nect bar code to unlink the scanner from the currently linked host.
Scan the linking bar code on the Access Point to relink the scanner.
Bluetooth PIN Code
Bluetooth HID Keyboard Disconnect

Keyboard Country
Your keyboard layout default is a US keyboard. To change this lay-
out, scan the appropriate keyboard country code.
Belgium
Denmark
Finland
France
Germany/Austria
Great Britain
Italy
Norway
Spain

By default, national character replacements are used for the follow-
ing characters: #$@[\]^‘{|}~ Refer to the ISO 646 Character
Replacements chart in your User’s Guide to view the character
replacements for each country.
Note: For a complete list of country codes, see the User’s Guide for
your product at our website, www.honeywellaidc.com.
Suffix
If you want a carriage return after the bar code, scan the Add CR
Suffix bar code. To add a tab after the bar code, scan the Add Tab
Suffix bar code. Otherwise, scan the Remove Suffix bar code to
remove the suffixes.
Switzerland
USA
(Default)
Add CR Suffix
Add Tab Suffix
Remove Suffix

For additional prefix and suffix settings, see the User’s Guide for
your product at our website, www.honeywellaidc.com.
Add Code ID Prefix to all Symbologies
Scan the following bar code if you wish to add a Code ID prefix to all
symbologies at once.
Note: For a complete list of Code IDs, see the User’s Guide for your
product at our website, www.honeywellaidc.com.
Poor Quality 1D Bar Codes
This setting improves the scanner’s ability to read damaged or badly
printed linear bar codes. When Poor Quality 1D Reading On is
scanned, poor quality linear bar code reading is improved, but the
scanner’s snappiness is decreased, making it less aggressive when
reading good quality bar codes. This setting does not affect 2D bar
code reading.
Add Code ID Prefix To All Symbologies
(Temporary)
Poor Quality 1D Reading On
Poor Quality 1D Reading Off
(Default)

Beeper Volume - Good Read
The beeper volume codes modify the volume of the beep the scan-
ner emits on a good read.
Low
Medium
High
(Default)
Off

Data Format Editor Instructions
The following are abbreviated instructions for entering a data format.
For complete instructions refer to your User’s Guide, available at our
website, www.honeywellaidc.com.
1. Scan the Enter Data Format symbol.
2. Primary/Alternate Format: scan 0for Primary Format
3. Terminal Type: scan 099 for any terminal type
4. Code I.D.: scan 99 for any bar code type
5. Length: scan 9999 for any length bar code.
6. Editor commands: use the Programming Chart that follows.
7. Scan Save to save your entries.
Enter Data Format
Clear All Data Formats
Save

Programming Chart
0
1
2
3
4
5
6
7
8
9

A
B
C
D
E
F
Save

EZConfig-Scanning
To access additional features for the scanner use EZConfig-Scanning, an
online configuration software tool, available from our website at
www.honeywellaidc.com.
Technical Assistance
Contact information for technical support, product service, and repair can be
found at www.honeywellaidc.com.
Limited Warranty
For warranty information, go to www.honeywellaidc.com and select
Resources>Warranty.
Patents
For patent information, refer to www.hsmpats.com.
User Documentation
For localized versions of this document, and to download the User’s Guide,
go to www.honeywellaidc.com.
