Honeywell Genesis 7580G User manual

Genesis 7580g
Presentation Area Imager
Quick Start Guide
7580-QS Rev B
8/13
Aller à www.honeywellaidc.com pour le français.
Gehe zu www.honeywellaidc.com für Deutsch.
日本語 : www.honeywellaidc.com をご覧ください。
如要到中国 www.honeywellaidc.com（简体）。
查看繁体版请登陆 www.honeywellaidc.com
한글 www.honeywellaidc.com 로이동합니다 .

Note: Refer to your user’s guide for information about cleaning your
device.
For localized language versions of this document, go to
www.honeywellaidc.com.
Getting Started
Turn off computer’s power before connecting the scanner, then
power up the computer once the scanner is fully connected.
Power Supply Assembly (if included)
Note: The power supply must be ordered separately, if needed.

Connecting the Scanner
USB:
Keyboard Wedge:
Note: For Keyboard Wedge, only use the power supply if required.

RS232 Serial Port:
RS485:

EAS
USB:
RS232:

Reading Techniques
Present the bar code to the scanner. The aimer turns on and the
LEDs turn up to read the code. If the light level in the room is not high
enough, the code may not be read.
Standard Product Defaults
The following bar code resets all standard product default settings.
RS485 Interface
The RS485 interface defaults to port 5B. If you have an IBM POS
terminal using port 9B, scan the appropriate code below to program
the terminal, then power cycle the cash register. If you have an IBM
POS terminal using port 17, scan IBM Port 17 Interface bar code
below.
Note: For additional RS485 interface selections, see the User’s
Guide for your product at our website,
www.honeywellaidc.com.
Standard Product Defaults
IBM Port 9B HHBCR-1
Interface
IBM Port 9B HHBCR-2
Interface
IBM Port 17 Interface

USB PC Keyboard
Scan the following code to program the scanner for a USB PC
Keyboard.
USB Serial
Scan the following code to program the scanner to emulate a regular
RS232-based COM Port. Apple® Macintosh computers recognize
the scanner as a USB CDC class device and automatically use a
class driver.
Note: No extra configuration (e.g., baud rate) is necessary.
If you are using a Microsoft® Windows® PC, you must down-
load a driver from the Honeywell website
(www.honeywellaidc.com). The driver will use the next avail-
able COM Port number.
USB PC Keyboard
!
USB Serial

Keyboard Country
Scan the Program Keyboard Country bar code below, then scan
the numeric bar code(s) from page 13, then the Save bar code to
program the keyboard for your country. As a general rule, the
following characters are not supported by the scanner for countries
other than the United States:
@ | $ # { } [ ] = / ‘ \ < > ~
Note: For a complete list of country codes, see the User’s Guide for
your product at our website, www.honeywellaidc.com.
Country Code Scan Country Code Scan
Belgium 1 Italy 5
Denmark 8 Norway 9
Finland 2 Spain 10
France 3 Switzerland 6
Germany/Austria 4 USA (Default) 0
Great Britain 7
Program Keyboard Country
Save

Scan Modes
When in Presentation mode, the scanner is activated when it “sees”
a bar code.
When in Streaming Presentation mode, the scanner leaves the
scan illumination on all the time and continuously searches for bar
codes.
When in Presentation - Mobile Phone mode, your scanner is
optimized to read bar codes from mobile phone or other LED
displays.
Note: For additional scan modes, see the User’s Guide for your
product at our website, www.honeywellaidc.com.
Presentation Mode
Streaming Presentation Mode
Presentation - Mobile Phone

Suffix
If you want a carriage return after the bar code, scan the Add CR
Suffix bar code. To add a tab after the bar code, scan the Add Tab
Suffix bar code. Otherwise, scan the Remove Suffix bar code to
remove the suffixes.
Add Code ID Prefix to all Symbologies
Scan the following bar code if you wish to add a Code ID prefix to all
symbologies at once.
Note: For a complete list of Code IDs, see the User’s Guide for your
product at our website, www.honeywellaidc.com.
Add CR Suffix
Remove Suffix
Add Tab Suffix
Add Code ID Prefix To All Symbologies
(Temporary)

Function Code Transmit
When this selection is enabled and function codes are contained
within the scanned data, the scanner transmits the function code to
the terminal. Charts of these function codes are provided in your
User’s Guide. When the scanner is in keyboard wedge mode, the
scan code is converted to a key code before it is transmitted.
Enable
(Default)
Disable

Data Format Editor Instructions
The following are abbreviated instructions for entering a data format.
For complete instructions refer to your User’s Guide, available at our
website, www.honeywellaidc.com.
1. Scan the Enter Data Format symbol.
2. Primary/Alternate Format: scan 0for Primary Format
3. Terminal Type: scan 099 for any terminal type
4. Code I.D.: scan 99 for any bar code type
5. Length: scan 9999 for any length bar code.
6. Editor commands: use the Programming Chart that follows.
7. Scan Save to save your entries.
Enter Data Format
Clear All Data Formats
Save

Programming Chart
0
2
1
4
3
5
6
7

A
B
C
D
E
F
9
8
Save

EZConfig-Scanning
To access additional features for the scanner use EZConfig-
Scanning, an online configuration software tool, available from our
website at www.honeywellaidc.com.
Technical Assistance
Contact information for technical support, product service, and repair
can be found at www.honeywellaidc.com.
Limited Warranty
Refer to www.honeywellaidc.com/warranty_information for your
product’s warranty information.
Patents
For patent information, refer to www.honeywellaidc.com/patents.
User Documentation
For localized versions of this document, and to download the User’s
Guide, go to www.honeywellaidc.com.
Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make changes in
specifications and other information contained in this document without prior
notice, and the reader should in all cases consult HII to determine whether
any such changes have been made. The information in this publication does
not represent a commitment on the part of HII.
HII shall not be liable for technical or editorial errors or omissions contained
herein; nor for incidental or consequential damages resulting from the
furnishing, performance, or use of this material.
This document contains proprietary information that is protected by copyright.
All rights are reserved. No part of this document may be photocopied,
reproduced, or translated into another language without the prior written
consent of HII.
©2010-2013 Honeywell International Inc. All rights reserved.

Web Address: www.honeywellaidc.com
