MODEL NO: SOMAT39
802.11a/b/g/n/ac
+
BT4.2
System on Module

Table of Contents
Introduction..............................................................................1
Block Diagram..........................................................................3
Technical Specifications...........................................................4
Absolute Maximum Rating..............................................................4
Recommended Operating Condition...............................................4
Foot Print, Front & Back view...................................................5
Pin Configurations....................................................................6
Wireless Specifications ............................................................ 8
WLAN..............................................................................................8
BLUETOOTH..................................................................................8
WLAN Radio Specifications............................................................9
IEEE Specifications.......................................................................11
BLUETOOTH Radio Characteristics.............................................12
RF Layout, Soldering Guidelines............................................ 13
RF Layout & Design Guidelines....................................................13
Soldering Guidelines.....................................................................14
Agency Approvals..................................................................15
Industry Canada............................................................................16
MSL Level / Storage Conditions.............................................17

1
Introduction
This document specifies the details for a WiFi 802.11a/b/g/n/ac with BT4.1
RFSOM module called with Honeywell Part No.
50145732-001
RFSOM WBT, SOM MODULE, WIFI 802.11AC BT 4.2
uzon Module will use WM-BAC-AT-39 USI SiP module with Qualcomm
QCA6174A chip set which includes LNA, switch, and internal power amplifier
(iPA) for small form factor and optimum performance. All filters and diplexers
will be included in the module to ensure maximum power flatness and optimum
VSWR. The module will perform with all legacy hardware having data rates as low as
1Mbps. This chipset also supports concurrent operation of Bluetooth (Version 4.1) for
wireless connectivity during browsing or other device applications. Along with both
standard and high speed (HS) Bluetooth data rates, Bluetooth low energy modes are
also supported. Hardware WAPI acceleration engine, AES, TKIP, WPA and WPA2 are
supported to provide the latest security requirement on your network.
For placing the SOMAT39 onto the carrier board, the part number to be used is
50145748-001. The footprint details are available in
Global Library for using on the carrier board.
SOMAT39 is meant to be used inside Honeywell only. It
is not meant or designed to be sold independently outside Honeywell
Chapter
1
L
N O T E
Carrier Board Information

2
SOMAT39 –System on Module Features
•IEEE 802.11 a/b/g/n/ac WLAN
•Bluetooth 4.2 + HS
•Bluetooth-WLAN coexistence
•WiFi Wake on Wireless (WoW)
•20/40 MHz bandwidth at 2.4GHz
•20/40/80 MHz bandwidth at 5GHz
•Internal PA/LNA
•RF SOM Size: 15 mm x 15 mm, LGA Package
•802.11 k/v/r [will be available in next release]
•Low Current consumption in IEEE PS and Deep Sleep
•WiFi Security methods: OPEN, WEP, WPA2-PSK, WPA2-1X (PEAP-
MSCHAPV2, PEAP-TLS, EAP-TTLS)
•WiFi + BT Coexistence with simultaneous video streaming over WiFi and voice call
over BT.
•Weight of module ~ 1gram
Featuring integrated IEEE 802.11 a/b/g/n/ac + BT4.1.
60 pins LGA.
Future to support two streaming dual-band antennas.
Low power consumption & excellent power management performance extends battery
life.

3
Block Diagram
SOMAT39 module is designed based on Qualcomm QCA6174A chipset solution. It
supports generic SDIO, UART interface to connect the WLAN/BT to the host
processor. A simplified block diagram of the WM-BAC-AT-39 module is depicted in
above picture.
Currently ANT 0 is enabled for SOMAT39. Ant 1 is disabled.
Chapter
2
N O T E
ANT 1

4
Technical Specifications
Absolute Maximum Rating
Power Supply:
Max +3.6v
Storage Temperature:
- 40° to 125° Celsius
Voltage ripple:
± 2% (Max. Values not exceeding Operating voltage)
Maximum RF input
(reference to 50 Ω input):
0dBm
Digital I/O input voltage for
3.3 V I/O supply:
Vdd + 0.3 V
Digital I/O input voltage for
1.8 V I/O supply:
Vdd + 0.2 V
Recommended Operating Condition
Operating Temperature:
-20° to 65°C
Humidity
Max 85% (Non-condensing, relative humidity)
Voltage
VDD3P3: 3.3v +/- 0.1V
VDDIO: 3.3v +/- 0.1vV
(*1.8V for higher > 50MHz SDIO clock versions)
Current Consumption
Tx output power @ 19 dBm on 11b 1M (single
stream): 420mA (typ), 490mA (max)
**Tx output power @ 16 dBm on 11n MCS8_HT20
(dual stream): 620mA (typ), 720mA (max)
Tx output power @ 15 dBm on 11n MCS0_HT20
(single stream-5g): 470mA (typ), 540mA (max)
**Tx output power @ 13 dBm on 11n MCS0_VHT80
(dual stream-5g): 715mA (typ),820mA (max)
** Dual Streaming Current Consumption Data is for reference purpose only. Existing
capability for SOMAT39 is enabled for single streaming only.
NOTE: Peak current bursts of 1.1A is observed during tests. Power supply input to
RFSOM must support peak current of 1.1A.

5
Foot Print, Front & Back view
Note: Bottom View of RF SOM Module –LGA Package Footprint
Chapter
3

6
Pin Configurations
S.No
PINOUT
Signal Type
Signal Description
1
IO1
Input/Output
BT_DEV_WAKE
2
GND
Ground
Ground
3
RF_ANT1 (WiFi)
RF Output
RF Antenna 1 WiFi Output
4
GND
Ground
Ground
5
IO2
Input/Output
BT_HOST_WAKE
6
IO3
Input/Output
GPS_COEX_WOW
7
IO4
Input/Output
BT_PCM_OUT
8
IO5
Input/Output
BT_EN
9
IO6
Input/Output
WL_EN
10
GND
Ground
Ground
11
RF_ANT0
(WiFi/BT)
RF Output
RF Antenna 0 WiFi/BT Output
12
GND
Ground
Ground
13
IO7
Input/Output
LTE_SYNC_TMS
14
IO8
Input/Output
BT_PCM_IN
15
IO9
Input/Output
BT_PCM_CLK
16
IO10
Input/Output
BT_PCM_SYNC
17
IO11
Input/Output
PCIE_WAKE_L
18
IO12
Input/Output
PCIE_CLKREQ_L
19
IO13
Input/Output
PCIE_RST_L
20
IO14
Input/Output
LTE_PRI_TCK
21
IO15
Input/Output
USB_DN
22
IO16
Input/Output
USB_DP
23
VDD1
Power Supply
Power Supply for IO's
24
GND
Ground
Ground
25
PCIE_REFCLK_P
Clock Diff. Input +ve
PCIE Clock Diff. input Positive
26
PCIE_REFCLK_N
Clock Diff. Input -ve
PCIE Clock Diff. input Negative
27
GND
Ground
Ground
28
PCIE_TX_P
Transmit Diff. Output +ve
PCIE Transmit Diff. Output Positive
29
PCIE_TX_N
Transmit Diff. Output -ve
PCIE Transmit Diff. Output Negative
30
GND
Ground
Ground
31
PCIE_RX_N
Receive Diff. Input -ve
PCIE Receive Diff. Output Negative
32
PCIE_RX_P
Receive Diff. Input +ve
PCIE Receive Diff. Output Positive
33
GND
Ground
Ground
34
IO17
Input/Output
LTE_ACTIVE_TDI
35
IO18
Input/Output
SDIO_INT_TDO

7
S.No
RF SOM SOM
PINOUT
Signal Type
Signal Description
36
VDD2
Power Supply
Power Supply - SOM VDD3V3
37
VDD3
Power Supply
Power Supply - SOM VDD3V3
38
SDIO_DATA_0
Data Bidirectional output 0
Serial Data IO Data 0
39
SDIO_DATA_1
Data Bidirectional output 1
Serial Data IO Data 1
40
SDIO_DATA_2
Data Bidirectional output 2
Serial Data IO Data 2
41
SDIO_DATA_3
Data Bidirectional output 3
Serial Data IO Data 3
42
SDIO_CMD
SDIO Command input
SDIO Command input
43
SDIO_CLK
SDIO Clock input
SDIO Clock input
44
GND
Ground
Ground
45
IO19
Input/Output
BT_UART_TXD
46
IO20
Input/Output
BT_UART_RXD
47
IO21
Input/Output
BT_UART_CTS
48
IO22
Input/Output
BT_UART_RTS
49
GND
Ground
Ground
50
GND
Ground
Ground
51
GND
Ground
Ground
52
GND
Ground
Ground
53
GND
Ground
Ground
54
GND
Ground
Ground
55
GND
Ground
Ground
56
GND
Ground
Ground
57
GND
Ground
Ground
58
GND
Ground
Ground
59
GND
Ground
Ground
60
GND
Ground
Ground

8
Wireless Specifications
WLAN
The SOMAT39 module complies with the following features and standards;
Features
Description
WLAN Standards
IEEE 802 11a/b/g/n/ac
Antenna Port
Support 1 streaming with Ant 0 (Ant1 is disabled)
Frequency Band
2.400 GHz –2.484 GHz
4.900 GHz –5.845 GHz
Number of Sub
Channels
1~ 11Channels
36~ 48,52~ 64, 100~ 140, 149~ 165 Channels
Modulation
DSSS, CCK, OFDM, BPSK, QPSK,16QAM, 64QAM
Supported data rates
1, 2, 5.5, 11 (Mbps)
6, 9, 12, 18, 24, 36, 48, 54 (Mbps)
HT20_MCS0 ~ HT20_MCS7
VHT80_MCS0 ~ VHT80_MCS9
BLUETOOTH
The Radio specification is compliant with the Bluetooth 2.1 + EDR specification
Features
Description
Frequency Band
2400 MHz ~ 2483.5 MHz
Number of Channels
79 channels
Modulation
FHSS (Frequency Hopping Spread Spectrum), GFSK, DPSK
Antenna Port
Single Antenna for Wi-Fi and BT
Chapter
4

9
WLAN Radio Specifications
Mode
Data rate
(Mbps)
Channel
Frequency
(MHz)
Set Power
802.11b
1
2412
19
2442
19
2462
19
11
2412
19
2442
19
2462
19
802.11g
6
2412
19
2442
19
2462
19
54
2412
19
2442
18
2462
16
802.11n
MCS0_20
2412
19
2442
19
2462
16
MCS7_20
2412
19
2442
18
2462
16
802.11n
MCS0_40
2422
19
2442
16
2457
15
MCS7_40
2422
19
2442
16
2457
15
Above Set Power is based on Antenna Gain of 4.27dBi Maximum

10
Mode
Data
rate
Channel
Frequency
Set
Power
dBm
Mode
Data
rate
Channel
Frequency
Set
Power
dBm
Mode
Data rate
Channel
Frequency
Set
Power
dBm
802.11a
6Mbps
5180
16
802.11n
MCS0_40
5190
14
MCS9_20
5180
15
5240
16
5230
14
5240
15
5260
16
5270
14
5260
15
5320
16
5510
14
5320
15
5500
16
5590
14
5500
15
5600
16
5670
14
5600
15
5700
16
5755
14
5700
15
5745
16
5795
14
5745
15
5825
16
MCS7_40
5190
14
5825
15
54Mbps
5180
16
5230
14
MCS0_40
5190
14
5240
16
5270
14
5230
14
5260
16
5510
14
5270
14
5320
16
5590
14
5510
14
5500
16
5670
14
5590
14
5600
16
5755
14
5670
14
5700
16
5795
14
5755
14
5745
16
802.11ac
MCS0_80
5210
13
5795
14
5825
16
5290
13
MCS9_40
5190
14
802.11n
MCS0_20
5180
15
5530
13
5230
14
5240
15
5690
13
5270
14
5260
15
5775
13
5510
14
5320
15
MCS9_80
5210
13
5590
14
5500
15
5290
13
5670
14
5600
15
5530
13
5755
14
5700
15
5690
13
5795
14
5745
15
5775
13
5825
15
MCS0_20
5180
15
MCS7_20
5180
15
5240
15
5240
15
5260
15
5260
15
5320
15
5320
15
5500
15
5500
15
5600
15
5600
15
5700
15
5700
15
5745
15
5745
15
5825
15
5825
15
Above Power values are based on the Antenna Gain of 3.10dBi Maximum

11
IEEE Specifications
WiFi TX EVM follow the IEEE spec that as list in the table below:
Characteristics
IEEE Spec
Unit
RF Average Output EVM (11b)
@1 Mbps
35
%
@11 Mbps
35
%
RF Average Output EVM (11a/g)
@6 Mbps
-5
dB
@54 Mbps
-25
dB
RF Average Output EVM (11n)
@ MCS0
-5
dB
@ MCS7
-27
dB
RF Average Output EVM (11ac)
@ MCS0
-5
dB
@ MCS9
-32
dB
The SOMAT39 module 2.4GHz WiFi Sensitivity as list in the table below:
Receiver Characteristics
Typ.
Max.
Unit
PER <8%, Rx Sensitivity @ 1 Mbps
-97
-82
dBm
PER <8%, Rx Sensitivity @ 11 Mbps
-89
-76
dBm
PER <10%, Rx Sensitivity @ 6 Mbps
-91
-82
dBm
PER <10%, Rx Sensitivity @ 54 Mbps
-76
-65
dBm
PER <10%, Rx Sensitivity @ MCS0_HT20
-91
-82
dBm
PER <10%, Rx Sensitivity @ MCS7_HT20
-73
-64
dBm
The SOMAT39 module 5GHz WiFi Sensitivity as list in the table below:
Receiver Characteristics
Typ.
Max.
Unit
PER <10%, Rx Sensitivity @ 6 Mbps
-94
-82
dBm
PER <10%, Rx Sensitivity @ 54 Mbps
-78
-65
dBm
PER <10%, Rx Sensitivity @ MCS0_HT20
-93
-82
dBm
PER <10%, Rx Sensitivity @ MCS7_HT20
-75
-64
dBm
PER <10%, Rx Sensitivity @ MCS0_VHT80
-87
-76
dBm
PER <10%, Rx Sensitivity @ MCS7_VHT80
-62
-51
dBm

12
BLUETOOTH Radio Characteristics
Parameter
Conditions
Min.
Typ.
Max
Unit
Basic Rate
Output Power^
Average Power
7
10
13
dBm
Frequency Range*
2400
…
2483.5
MHz
Sensitivity (BER)
BER ≦0.1%
-92
-70
dBm
Maximum Input Level
BER ≦0.1%
-20
dBm
EDR
Relative Power*
π/4-DQPSK
-4
0
1.0
dBm
8DPSK
-4
0
1.0
dBm
EDR Sensitivity(BER)
π/4-DQPSK
…
-91
-70
dBm
BER ≦0.01%
8DPSK
…
-86
-70
dBm
BER ≦0.01%
EDR Maximum Input Level
π/4-DQPSK
…
…
-20
dBm
BER ≦0.01%
8DPSK
…
…
-20
dBm
BER ≦0.01%
BLE
BLE Output Power^
Average Power
-4
2
6
dBm
BLE Sensitivity (PER)
PER ≦30.8%
…
-95
-70
dBm
BLE Maximum Input Level
PER ≦30.8%
…
…
-10
dBm
+ The maximum output power is based on the Antenna Gain of 4.27 dBi.

13
RF Layout, Soldering Guidelines
RF Layout & Design Guidelines
I. Do not run antenna cables directly above or directly below the radio.
II. Do not run any high speed digital lines below the radio.
III. For applications using only 1X1, the second antenna port i.e RF_ANT1
to be terminated with a 50 ohm resistor close to the pin of SOMAT39.
IV. Isolate VDD2 & VDD3 (pin no 36 & 37) with a ferrite bead
(BLM15AG100SN1D) and decaps of 22uF and 0.1uF to be placed very
close to the pins.
V. 10uF and 0.1uF to be used at VDD1 i.e pin no 23 and the input power
supply which are to be placed very close to the pins.
VI. A 100K pull down resistors to be used for BT_DEV_WAKE, WL_EN
and BT_EN close to the pins of RF SOM.
VII. A series R (10E) and shunt capacitor (22pf) is recommended to reduce the
SDIO clock noise going to the input of SOMAT39 pin (pin no 43).
VIII. Use proper electro-static-discharge (ESD) procedures when installing the
SOMAT39 module.
Chapter
5

14
Soldering Guidelines
SOMAT39 is compatible with industrial standard reflow profile for Pb-free solders. The
reflow profile selection to be done based on the thermal mass of the entire populated
PCB, heat transfer efficiency of the oven and solder paste used.
I. Refer to technical documentations of solder paste for profile
configurations.
II. Avoid using more than one reflow cycle.
III. Aperture size of the stencil should be 1:1 with the pad size.
IV. For further recommendation, please refer to the JEDEC/IPC J-STD-020,
IPC-SM-782 and IPC 7351 guidelines.
Below is the overview of recommended Re-flow:
(1) Solder paste alloy: SAC305 (Sn96.5/Ag3.0/Cu0.5) (Lead Free solder paste.)
(2) A-B. Temp.: 150~200℃; soak time:60~120sec. (Base on Flux type, reference only)
(3) C. Peak temp: <245℃
(4) D. Time above 217 ℃: 40~90sec. (Base on SAC305)
(5) Suggestion: Optimal cooling rate is <1℃/sec. from peak to 217 ℃.
(6) Nine heater zones at least for Reflow equipment.
(7) Nitrogen usage is recommended and be controlled the value less than 1500 ppm.
Note: Need to inspect solder joint by X-ray post reflow

15
Agency Approvals
FCC:
Model: SOMAT39
FCC ID: HD5-HWUSIA
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy. However, there
is no guarantee that interference will not occur in a installation. If this equipment does
cause harmful interference to radio or reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference that my
cause undesired operation.
MODIFICATION: Any changes or modifications not expressly approved by the
grantee of this device could void the user’s authority to operate the device.
Chapter
6

16
This equipment should be installed and operated with minimum distance 20cm between
the radiator and your body.
Industry Canada
Model: SOMAT39
IC: 1693B-HWUSIA
This device complies with Industry Canada RSS standard(s). Operation is subject to the
following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Leprésent appareil est conforme aux CNR d'Industrie Canada applicable aux appareils
radio
Exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, meme si le brouillage est susceptible d'en
compromettre le fonctionnement."
Cet équipement doit être installé et utilisé avec une distance minimale de 20cm entre le
radiateur et votre corps.

17
MSL Level / Storage Conditions
Chapter
7
