Controller Failure Symptoms
Introduction
In addition to the error message prompts, there are failure symptoms that can be
identified by noting how the controller displays and indicators are reacting.
Symptoms
Compare your symptoms with those shown in Table-1.
Table-1 Controller Failure Symptoms
Upper
Display Lower Display Indicators Controller Output Probable Cause Trouble- shooting
Procedure
Blank Blank Off None Power Failure 0
OK OK
Current
Proportional
Output
0
OK OK
Position
Proportional or
TPSC Output
0
OK OK
Time Proportional
Output 0
OK
Displayed
Output
disagrees
with Controller
Output
OK
Controller
Output
disagrees
with Displayed
Output
Current/Time
Proportional
Output
0
OK OK OK
External Alarm
function does
not operate
properly
Malfunction in
alarm output 0
OK Displayed
Output
disagrees with
First Current
Output
OK Controller
Current Output
#1 disagrees
with Displayed
First Current
Output
First Current
Output 0
OK Displayed
Output
disagrees with
Second Current
Output
OK Controller
Current Output
#2 disagrees
with Displayed
Second Current
Output
Second Current
Output 0
OK Displayed
Output
disagrees with
Third Current
Output
OK Controller
Output
disagrees with
Displayed Third
Current Output
Third Current
Output 0
Page 1 of 16 Revision 1

U
U
UD
D
DC
C
C
3
3
35
5
50
0
00
0
0
A
A
Ap
p
pp
p
pl
l
li
i
ic
c
ca
a
at
t
ti
i
io
o
on
n
n
N
N
No
o
ot
t
te
e
e
Upper
Display Lower Display Indicators Controller Output Probable Cause Trouble- shooting
Procedure
Display does not change when a key is pressed Keyboard
Malfunction 0
Controller fails to go into “Slave” operation during communications Communications
Failure RS-485: 0
Ethernet: 0
Bad PV Reading Bad InX
Reading OK OK
Analog Input
Failure 0
Other symptoms
If a set of symptoms or prompts other than the one you started with appears while
troubleshooting, re-evaluate the symptoms. This may lead to a different troubleshooting
procedure.
If the symptom still persists, refer to the installation section in this manual to ensure
proper installation and proper use of the controller in your system.
Troubleshooting Procedures
Introduction
The troubleshooting procedures are listed as they appear in Table-1. Each procedure
describes what to do if you have that particular failure and how to do it or where to find
the data needed to accomplish the task.
WARNING—SHOCK HAZARD
TROUBLESHOOTING MAY REQUIRE ACCESS TO HAZARDOUS LIVE
CIRCUITS AND SHOULD ONLY BE PERFORMED BY QUALIFIED SERVICE
PERSONNEL. MORE THAN ONE SWITCH MAY BE REQUIRED TO DE-
ENERGIZE UNIT BEFORE SERVICING.
Equipment needed
You will need the following equipment in order to troubleshoot the symptoms listed:
• Multimeter – Capable of measuring millivolts, volts, milliamps and resistance.
• Calibration sources – T/C, mV, Volt, etc.
