Honeywell HY-200 Series User manual

IMPORTANT SAFETY
INSTRUCTIONS
READ AND SAVE THESE SAFETY
INSTRUCTIONS BEFORE USING
THIS FAN
When using electrical appliances, basic
precautions should always be followed to
reduce the risk of fire, electric shock, and
injury to persons, including the following:
FOR US MODELS ONLY – This product em-
ploys overload protection (fuse). A blown fuse
indicates an overload or short-circuit situation.
If the fuse blows, unplug the product from
the outlet. Replace the fuse as per the user
servicing instructions (follow product marking
for proper fuse rating) and check the product.
If the replacement fuse blows, a short-circuit
may be present and the product should be
discarded or returned to an authorized service
facility for examination and/or repair.
1. Use this fan only as described in this manual.
Other use not recommended as it may cause
fire, electric shock or injury to persons.
2. This product is intended for household
use ONLY and not for commercial, industrial or
outdoor use.
3. To protect against electric shock, do not place
fan in window, immerse unit, plug or cord in
water or spray with liquids.
Owner’s Manual
The Honeywell trademark is used by Kaz USA, Inc. under license from Honeywell International Inc.
Honeywell International Inc. makes no representation or warranties with respect to this product.
The Febreze trademark is used by Kaz USA, Inc. under license from The Procter and Gamble Company.
4. This appliance has a polarized plug (one blade
is wider than the other). To reduce the risk
of shock, this plug is intended to fit only one
way in a polarized outlet. If the plug does not
fit fully in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician.
DO NOT attempt to defeat this safety feature.
5. Close supervision is necessary when any
appliance is used by or near children.
6. Turn the fan OFF and unplug the fan from
the outlet when not in use, when moving the
fan from one location to another and before
cleaning.
7. To disconnect the fan, first turn the unit OFF,
grip the plug and pull it from the wall outlet.
Never pull the plug by the cord.
8. Do not operate the fan in the presence of
explosive and/or flammable fumes.
9. Do not place the fan or any parts near an open
flame, cooking or other heating appliance.
10. Do not operate the fan with a damaged cord or
plug or if the product malfunctions, is dropped
or damaged in any manner (see warranty).
11. Avoid contact with moving fan parts.
12. The use of attachments not recommended by
the manufacturer may be hazardous.
13. Place the fan on a dry level surface.
HONEYWELL WITH
FEBREZE FRESHNESSTM
COOL & REFRESH
MINI TOWER FANS
HY-200 Series

- 2 -
14. Do not hang or mount fan on a wall
or ceiling.
15. Do not operate if the fan housing is damaged.
16. A loose fit between the AC outlet (receptacle)
and plug may cause overheating and a
distortion of the plug. Contact a qualified
electrician to replace loose or worn outlet.
17. Do not operate any fan with a damaged cord
or plug. Discard any damaged fan, return
the fan to the retailer where the fan was
purchased, or request a return authorization
to return to Kaz USA, Inc. for examination
and/or repair.
USER SERVICING INSTRUCTIONS
• Grasp plug and remove from the receptacle or other outlet device.
Do not unplug by pulling on cord.
• If your fan loses power and you suspect that the fuse on your fan
has blown, you should first remove the spare fuse holder attached
to the cord plug (Fig. 1). Remove the spare fuse from the plastic
spare fuse holder, and set the spare fuse aside (Fig. 2).
• You can gain access to the blown fuse by sliding open the door
found on the side of the plug. Slide the door outward until the
blown fuse is fully visible (Fig. 3).
• Carefully remove the blown fuse and snap the replacement fuse
into place. Risk of fire. Replace fuse only with 2.5 Amp, 125 volt
fuse (provided with product). Fully close the fuse door by sliding
back into place. Discard the blown fuse. The plug should now be
ready for normal use.
• Risk of fire. Do not replace attached plug. Contains a safety device
(fuse) that should not be removed. Discard product if the attached
plug is damaged.
• If you need further information on how or when to replace the
fuse in the safety plug, please contact Kaz Consumer Relations
Department by visiting our website at www.kaz.com or calling
1-800-477-0457.
Thank you for your purchase.
This fan features a fused safety plug which is designed to cut off electric current to the fan if an
electrical fault occurs. Please see below for more information on how to properly use your fan and
replace the safety plug fuse, if needed.
FUSED SAFETY PLUG - FOR US ONLY
Fig. 1
Fig. 2
Fig. 3
18. Do not run fan cord under carpeting. Do
not cover cord with throw rugs, runners, or
similar coverings. Do not route cord under
furniture or appliances. Arrange cord away
from traffic areas and where it will not be
tripped over.
WARNING: To Reduce The Risk of Fire or
Electric Shock, Do Not Use This Fan With
Any Solid-State Speed Control Device,
other than the one supplied.

- 3 -
FAN OPERATION
On/Off
& Speed
Control
Oscillation
Button
Scent
Control
Dial
Scent
Cartridge
Compartment
On/Off
To turn fan on, turn the fan Speed Control Knob
located on the bottom of the control panel
clockwise.
Speed Control
Turn the fan Speed Control Knob clockwise to
set the Fan at High( ) or Low ( )
Oscillation
To activate the Oscillation feature, press the
Oscillation button ( ) once.
Press the Oscillation button again to turn the
Oscillation feature off.
Once a Febreze® Set&Refresh®
scent cartridge has been inserted,
fresh Febreze® scent is released
into the Scent Path and travels to
the interior region of the fan.
At this point, the fresh Febreze®
scent combines with the air being
drawn into the fan by the fan motor.
The fan then pushes a stream of
Febreze® scented air out through
the front fan grilles to cool and
freshen your entire room.
The Scent Control Dial allows you to
control the level of scent output.
To operate the fan without scent,
simply remove the Febreze®
Set&Refresh® scent cartridge.
HOW IT WORKS
Set&Refresh®
Scent Cartridge
Scent Path
Air In
Air In
Freshened Air Out
Freshened Air Out
1. Remove the fan from the plastic bag and carton.
2. Place the fan on a dry level surface.
3. Plug the fan into a 120 volt outlet.
See the next two pages for instructions on installing the Febreze® Set&Refresh® scent cartridge.

- 4 -
FAN OPERATION
INSTALL FEBREZE® SET&REFRESH® SCENT CARTRIDGE
If you would like to use the scent distribution feature on your fan, you need to install and activate
a Febreze® Set&Refresh® scent cartridge.
Your Honeywell with Febreze Freshness™ Cool & Refresh Fan package contains one Febreze®
Set&Refresh® Advanced Odor Eliminator scent cartridge at the time of purchase.
Fragrance is intended for use with Kaz fan models HY-200, HY-201 and HY-204 Series.
Make sure your fan is
turned OFF.
1 - Turn Fan Off
Remove the Set&Refresh®
scent cartridge from the
enclosed packaging. Do not
peel or cut the cartridge
Open the door to the Scent
Cartridge Compartment
located in the center of the
fan control panel.
Hold the Set&Refresh®
scent cartridge so that the
curved side is facing
upward.
Line the cartridge up with
the slot inside the Scent
Cartridge Compartment.
Slide the scent cartridge into
the slot until it is firmly in
place.
Close the door to the Scent
Cartridge Compartment.
2 - Remove Cartridge 3 - Open Cartridge Door
4 - Position Cartridge 5 - Insert Cartridge 6 - Close Cartridge Door

- 5 -
Once the Febreze® Set&Refresh® scent cartridge is properly
installed, use the Febreze® Scent Control Dial located on the
top of the Fan control panel (Fig. 4), to control the amount of
scent released into the air.
Turn the Febreze® Scent Control Dial clockwise to release
increasing amounts of Febreze® scent into the air.
Keep the Scent Control Dial in the LOW position if you want the
minimum amount of Febreze® scent to be released into the air
and circulated by your fan.
Turning the Febreze® Scent Control Dial all the way to the right (MAXIMUM) will release the
maximum amount of Febreze® scent into your room.
PLEASE NOTE:
The speed at which you run your Honeywell with Febreze Freshness™ Cool & Refresh Fan
does affect the length of time your Set&Refresh® scent cartridge will last.
An installed and activated Set&Refresh® scent cartridge will empty faster if you run your
fan at HIGH speed instead of LOW speed.
If you regularly run your fan at LOW speed while a Set&Refresh® scent cartridge is
installed and activated, the Set&Refresh® scent cartridge will last longer.
To operate the fan without any scent, simply remove the scent cartridge from the fan.
Febreze® Set&Refresh® scent cartridges are available in a variety of scents wherever
Set&Refresh® products are sold. Click on the ‘Buy Now’ link on www.Febreze.com to locate a
retailer near you.
CAUTION: EYE IRRITANT. Avoid contact with eyes. Do not put fingers into product vent. Wash
hands after handling perfume cartridge.
KEEP OUT OF REACH OF CHILDREN AND PETS. FIRST AID TREATMENT: Contains fragrance
oils. If eye contact occurs, rinse with plenty of water for 20 minutes. If eye irritation persists,
consult a physician.
IF SWALLOWED; do not induce vomiting, call a physician or poison control center immediately.
CONTROLLING THE FEBREZE® SCENT
Fig. 4
Scent Control

- 6 -
Should I remove the foil from the back of the Set&Refresh® scent cartridge?
No, do not remove the foil from the cartridge. Simply remove the cartridge from its packaging
and place it into the slot in the Scent Cartridge Compartment on the top of the unit. By inserting
the cartridge properly in the fan, the scent cartridge foil will automatically be pierced to release
the Febreze® scent.
How do I insert the scent cartridge?
Hold the scent cartridge so that the curved side is facing upward.
Align the cartridge with the slot inside the Scent Cartridge
Compartment on top of the unit. Slide the cartridge into the slot
until it feels secure.
Why isn’t my fan producing scent anymore?
It may be due to an empty Set&Refresh® scent cartridge. Check the cartridge in the unit; if it is
empty and no longer releasing any scent, it is time to replace the cartridge.
Where can I get additional Febreze® Set&Refresh® scent cartridges?
You can purchase Febreze® Set&Refresh® scent cartridges wherever Set&Refresh® products are
sold. Click on the ‘Buy Now’ link on www.Febreze.com to locate a retailer near you.
My Honeywell with Febreze Freshness™ Cool & Refresh Fan came with an Advanced
Odor Eliminator Set&Refresh® scent cartridge. Is Advanced Odor Eliminator the only
Set&Refresh® scent cartridge that I can use in my fan?
No - you can use any of the variety of scents available in the Febreze® Set&Refresh®
scent cartridge assortment. See www.Febreze.com for more information on which scents are
available.
How long will a Set&Refresh® scent cartridge last in my fan?
A single Set&Refresh® scent cartridge may last between 2-4 weeks depending on a variety of
factors, including: · Fan speed used while the scent cartridge is inserted
· Room Size
· Amount of air flow in the room where the fan is operating
NOTE: Operating the fan at higher speeds while a Set&Refresh® scent cartridge is installed will
cause the scent cartridge to empty faster. Similarly, operating the fan at lower speeds while a
Set&Refresh® scent cartridge is inserted will enable the scent cartridge to last for a longer period
of time.
Can my fan be operated without a Set&Refresh® scent cartridge?
Yes, your fan is fully operational as a fan only, without the scent cartridge.
FREQUENTLY ASKED QUESTIONS

- 7 -
CONSUMER RELATIONS
Mail questions or comments to:
Kaz USA, Inc.
Consumer Relations Dept.
250 Turnpike Road
Southborough, MA 01772
Please be sure to specify a model number.
NOTE: IF YOU EXPERIENCE A PROBLEM, PLEASE CONTACT CONSUMER RELATIONS FIRST
OR SEE YOUR WARRANTY. DO NOT RETURN TO THE ORIGINAL PLACE OF PURCHASE. DO
NOT ATTEMPT TO OPEN THE MOTOR HOUSING YOURSELF, DOING SO MAY VOID YOUR
WARRANTY AND CAUSE DAMAGE TO THE FAN OR PERSONAL INJURY.
USER SERVICING INSTRUCTIONS
CLEANING AND STORAGE
• Ensure the fan is turned off and unplugged.
• Remove the Set&Refresh® scent cartridge and discard.
• Use only a soft cloth to gently wipe the outer surfaces of the fan clean.
• To clean between the grills and fan blade area, we recommend using a pipe cleaner,
flexible dust wand, vacuum cleaner or compressed air to gently remove the dust.
• To clean the rear grill use a soft dry cloth.
• DO NOT immerse the fan in water and never allow water to drip into the motor housing.
• DO NOT use gasoline, paint thinner or other chemicals to clean the fan.
• For storage, you may leave the fan assembled and covered to protect it from dust.
Store the fan in a cool, dry place.
Call us toll-free at: 1-800-477-0457
E-mail: [e-mail]
Or visit our website at: www.kaz.com

- 8 -
You should first read all instructions before
attempting to use this product.
A. This 1 year limited warranty applies to
repair or replacement of product found to be
defective in material or workmanship. This
warranty does not apply to damage resulting
from commercial, abusive, unreasonable use
or supplemental damage. Defects that are
the result of normal wear and tear will not
be considered manufacturing defects under
this warranty. KAZ IS NOT LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES
OF ANY NATURE. ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE ON THIS PRODUCT IS
LIMITED IN DURATION TO THE DURATION OF
THIS WARRANTY. Some jurisdictions do not
allow the exclusion or limitation of incidental or
consequential damages or limitations on how
long an implied warranty lasts, so the above
limitations or exclusions may not apply to you.
This warranty gives you specific legal rights,
and you also may have other rights which vary
from jurisdiction to jurisdiction. This warranty
applies only to the original purchaser of this
product from the original date of purchase.
B. At its option, Kaz will repair or replace this
product if it is found to be defective in material
or workmanship. Defective product should
be returned to the place of purchase in
accordance with store policy. Thereafter, while
within the warranty period defective product
may be returned to Kaz.
C. This warranty does not cover damage resulting
from any unauthorized attempts to repair
or from any use not in accordance with the
instruction manual.
D. Return defective product to Kaz USA, Inc. with
a brief description of the problem. Include proof
of purchase and a $10 US/$15.50 CAN check
or money order for handling, return packing
and shipping charges. Please include your
name, address and a daytime phone number.
You must prepay shipping charges. We suggest
having tracking or delivery confirmation.
Send to:
In U.S.A.:
Kaz USA, Inc.
Attn: Returns Department
4755 Southpoint Drive
Memphis, TN 38118
USA
In Canada:
Kaz Canada, Inc.
Attn: Returns Department
510 Bronte Street South
Milton, ON L9T 2X6
Canada
Please go to www.kaz.com and register your
product under the Customer Care Center and
receive product information updates and new
promotional offers.
1 YEAR LIMITED WARRANTY

Guide d’utilisation
La marque de commerce Honeywell est utilisée par Kaz USA, Inc. avec l’autorisation de Honeywell International, Inc.
Honeywell International Inc. ne fait aucune assertion et n’offre aucune garantie en ce qui concerne ce produit.
Kaz USA, Inc. utilise la marque de commerce Febreze avec l’autorisation de la société Procter & Gamble.
INSTRUCTIONS
DE SÉCURITÉ
IMPORTANTES
LISEZ CES CONSIGNES DE SÉCURITÉ
AVANT L’EMPLOI ET GARDEZ-LES
L’utilisation d’appareils électriques exige
l’observation de précautions fondamentales
pour réduire les risques d’incendie, de choc
électrique et de blessures corporelles, y
compris des suivantes:
MODÈLES ÉTATSUNIENS SEULEMENT – Cet
appareil présente une protection (fusible)
contre les surcharges. Un fusible grillé signale
une surcharge ou un court-circuit. Si le
fusible saute, débrancher l’appareil à la prise.
Remplacer le fusible selon les instructions
d’entretien fournies (le calibre du fusible
requis est donné sur le produit) et vérifier
l’appareil. Si le fusible de rechange grille,
un court-circuit peut en être la cause; en ce
cas, l’appareil doit être jeté ou retourné à un
centre de services agréé pour vérification et/
ou réparation.
1. N’employez le ventilateur que tel que décrit
dans ce manuel. Tout autre usage non conseillé
pourrait entraîner incendie, choc électrique et
blessures corporelles.
2. Ce ventilateur est UNIQUEMENT destiné
à l’usage domestique et non à l’emploi
commercial, industriel ou en plein air.
3. Afin de prévenir les chocs électriques, ne placez
pas le ventilateur dans une fenêtre, n’immergez
ni l’appareil, ni sa fiche, ni son cordon et ne les
éclaboussez pas de liquide.
4. Cet appareil comprend une fiche polarisée (une
branche est plus large que l’autre). Pour réduire
les risques de choc électrique, la fiche n’enfonce
que dans un sens dans les prises polarisées.
Si elle ne pénètre pas totalement dans la prise,
inversez-la. Si elle ne rentre toujours pas, faites
appel à un électricien. NE neutralisez PAS ce
dispositif de sécurité.
5. Surveillez assidûment l’appareil s’il est utilisé par
des enfants ou près d’eux.
6. ÉTEIGNEZ le ventilateur et débranchez-le entre
utilisations, pour le déplacer ainsi qu’avant de
le nettoyer.
7. Pour le débrancher, ÉTEIGNEZ-LE puis tenez la
fiche entre le pouce et l’index pour la tirer hors
de la prise. Ne tirez jamais sur le cordon d’un
coup sec.
8. Ne faites pas fonctionner le ventilateur
en présence de vapeurs explosives ou
inflammables.
9. Ne placez ni le ventilateur ni de ses pièces près
de flammes nues ou près d’appareils de cuisson
ou de chauffage.
10. Ne vous servez pas du ventilateur si son cordon
ou sa fiche est abîmé, s’il a mal fonctionné, a été
échappé ou endommagé d’une façon quelconque
(voyez la garantie).
11. Évitez tout contact avec les pièces mobiles.
VENTILATEURS MINI-
COLONNES HONEYWELL
FRAIS ET RÉGÉNÉRANTS,
À FEBREZE FRESHNESSMC
Série HY-200

- 10 -
FICHE DE SÉCURITÉ AVEC FUSIBLE - ÉTATS-UNIS SEULEMENT
Merci d’avoir acheté cet appareil.
Ce ventilateur comprend une fiche de sécurité avec fusible conçue pour couper le courant au
ventilateur en cas de défaillance électrique. Voyez, ci-dessous, comment utiliser correctement le
ventilateur et remplacer le fusible de la fiche de sécurité, si nécessaire.
Fig. 1
Fig. 2
Fig. 3
12. L’emploi d’accessoires non recommandés par
le fabricant peut se révéler dangereux.
13. Posez l’appareil sur une surface plane et sèche.
14. N’accrochez pas le ventilateur au mur ou au
plafond.
15. Ne vous en servez pas si le boîtier est abîmé.
16. Une fiche mal assujettie dans la prise de
courant peut surchauffer et se déformer.
Demandez à un électricien de remplacer toute
prise de courant usée.
17. Ne faites pas fonctionner un ventilateur
dont le cordon ou la fiche est endommagé.
Mettez tout ventilateur abîmé au rebut,
retournez-le au lieu d’achat ou demandez
l’autorisation de le renvoyer à Kaz USA, Inc. pour
le faire vérifier et réparer au besoin.
18. N’acheminez pas le cordon sous de la moquette.
Ne le recouvrez pas de carpettes, tapis de
corridor ou revêtement de sol de ce genre. Ne
passez pas le cordon sous des meubles ou des
appareils. De plus, éloignez-le du passage afin
qu’il ne risque pas de faire trébucher.
AVERTISSEMENT : Pour réduire le risque
d’incendie ou de choc électrique, ne faites
pas fonctionner le ventilateur avec une
commande de vitesse transistorisée autre
que celle qui est fournie.
INSTRUCTIONS D’ENTRETIEN DESTINÉES À L’UTILISATEUR
• Saisissez la fiche pour la tirer hors de la prise de courant, ou autre.
Ne donnez pas un coup sec sur le cordon pour le débrancher.
• Si le ventilateur perd de sa puissance ou bien si vous soupçonnez que le
fusible est grillé, commencez par séparer le porte-fusible de rechange de
la fiche (fig. 1). Sortez le fusible de rechange de son logement en
plastique et mettez ce fusible de côté (fig. 2).
• Pour accéder au fusible grillé, faites coulisser le volet qui se trouve sur le
côté de la fiche. Faites glisser le volet vers l’extérieur jusqu’à ce que le
fusible grillé soit totalement visible (fig. 3).
• Retirez soigneusement le fusible grillé et mettez le fusible de rechange à
sa place. Risque d’incendie. Ne remplacez le fusible que par un fusible de
2,5 ampères et 125 volts (fourni avec le produit). Refermez complètement
le volet en le faisant coulisser en place. Jetez le fusible grillé. La fiche
devrait alors fonctionner normalement.
• Risque d’incendie. Ne remplacez pas la fiche. Elle contient un dispositif de
sécurité (fusible) qui ne doit pas être enlevé. Jetez l’appareil si sa fiche est
abîmée.
• S’il vous faut de plus amples renseignements en ce qui concerne le
remplacement du fusible de la fiche de sécurité, veuillez communiquer
avec le Service à la clientèle de Kaz, visiter notre site Web: www.kaz.com
ou appeler le 1-800-477-0457.
