INSTALLATION MANUAL
KRA 405B
RADAR ALTIMETER
MANUAL NUMBER 006-10536-0010
REVISION 10 OCTOBER, 2005

WARNING
The enclosed technical data is eligible for export under License Designation NLR and is to be
used solely by the individual/organization to whom it is addressed. Diversion contrary to U.S. law
is prohibited.
COPYRIGHT NOTICE
©1997, 1999, 2001, 2003, 2005 Honeywell International Inc.
REPRODUCTION OF THIS PUBLICATION OR ANY PORTION THEREOF BY ANY MEANS
WITHOUT THE EXPRESS WRITTEN PERMISSION OF HONEYWELL IS PROHIBITED,
EXCEPT TO THE EXTENT REQUIRED FOR INSTALLATION OR MAINTENANCE OF THE
RECIPIENT’S EQUIPMENT. FOR FURTHER INFORMATION CONTACT THE MANAGER,
TECHNICAL PUBLICATIONS, HONEYWELL, ONE TECHNOLOGY CENTER, 23500 WEST
105th STREET OLATHE KS 66061 TELEPHONE: [phone].

N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page RH-1
006-10536-0010 Rev. 10 Oct/2005
REVISION HIGHLIGHTS
006-10536-0010 Rev. 10
Oct/2005
This is a full reprint of the KRA 405B Installation Manual. Discard the previous
manual revision in its entirety. Specific changes to content are denoted by
change bars.
Revision highlight(s) include the updating the environmental qualification forms
to revision AF.

N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page RH-2
006-10536-0010 Rev. 10 Oct/2005
THIS PAGE IS RESERVED

N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page TC-1
006-10536-0010 Rev. 10 Oct/2005
TABLE OF CONTENTS
ITEM PAGE
SECTION I
GENERAL INFORMATION
1.0 INTRODUCTION ............................................................... 1-1
1.1 DESCRIPTION OF EQUIPMENT ................................................... 1-2
1.2 ACRONYMS AND ABBREVIATIONS ................................................. 1-3
1.3 TECHNICAL CHARACTERISTICS .................................................. 1-4
A. KRA 405B RADAR ALTIMETER SYSTEM ............................................ 1-4
B. KRA 405B RECEIVER/TRANSMITTER TSO .......................................... 1-4
C. KRA 405B RECEIVER/TRANSMITTER .............................................. 1-4
D. KNI 415/416 INDICATOR ...................................................... 1-7
E. KA 54A ANTENNA ............................................................. 1-8
F. KA 54 ANTENNA (RETROFIT ONLY) .............................................. 1-9
1.4 UNITS AND ACCESSORIES SUPPLIED (KRA 405B SYSTEM COMPONENTS) ................ 1-9
A. RADAR ALTIMETER (Receiver/Transmitter) ..................................... 1-9
B. RADAR ALTIMETER INDICATOR - Honeywell KNI 415 or KNI 416 .................. 1-10
C. RADAR ALTIMETER ANTENNAS (2 each) ......................................... 1-10
D. KRA 405B INSTALLATION KIT ................................................. 1-10
E. KNI 415/416 INDICATOR INSTALLATION KIT .................................... 1-11
F. KA 54A RADAR ALTIMETER ANTENNA INSTALLATION KIT ........................... 1-11
1.5 ACCESSORIES REQUIRED BUT NOT SUPPLIED ..................................... 1-11
1.6 OPTIONAL ACCESSORIES RECOMMENDED BUT NOT SUPPLIED ......................... 1-12
A. CM 2000 CONFIGURATION MODULE KIT P/N 050-03380-0000. ...................... 1-12
B. KPA 900 CONFIGURATION MODULE PROGRAMMER KIT ............................... 1-13
1.7 LICENSE REQUIREMENTS ...................................................... 1-14
1.8 INSTRUCTIONS FOR CONTINUED AIRWORTHINESS .................................. 1-14
SECTION II
INSTALLATION
2.1 GENERAL INFORMATION ........................................................ 2-1
2.2 UNPACKING AND INSPECTING EQUIPMENT ......................................... 2-1
2.3 EQUIPMENT INSTALLATION ..................................................... 2-1

N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page TC-2
006-10536-0010 Rev. 10 Oct/2005
ITEM PAGE
2.4 CONFIGURABLE PARAMETERS .................................................... 2-2
A. ALTITUDE TRIP POINTS ....................................................... 2-2
B. ZERO FEET OFFSET ........................................................... 2-4
C. KPA 900 CONFIGURATION MODULE PROGRAMMER KIT ................................ 2-6
D. DH AUDIO OUTPUT ............................................................ 2-6
2.5 KRA 405B SYSTEM INSTALLATION ............................................... 2-6
A. KRA 405B RECEIVER/TRANSMITTER .............................................. 2-6
B. KNI 415/416 INDICATOR ...................................................... 2-8
C. ANTENNAS ................................................................... 2-9
D. PLANNING THE ANTENNA INSTALLATION ......................................... 2-10
E. IMPLEMENTING THE ANTENNA INSTALLATION ..................................... 2-12
F. ANTENNA CABLES ............................................................ 2-13
G. WIRING HARNESS ............................................................ 2-14
H. CONFIGURATION MODULE INSTALLATION ......................................... 2-14
2.6 POST INSTALLATION ......................................................... 2-15
A. POST INSTALLATION CALIBRATION ............................................. 2-15
B. GENERAL ................................................................... 2-17
C. KRA 405B RADAR ALTIMETER POST INSTALLATION TEST PROCEDURE ................. 2-17
D. TEST PROCEDURE ............................................................ 2-20
2.7 REMOVAL AND REPLACEMENT ................................................... 2-22
A. KRA 405B RECEIVER/TRANSMITTER ............................................. 2-22
B. KNI 415/416 INDICATOR ..................................................... 2-23
C. ANTENNAS .................................................................. 2-24
2.8 HONEYWELL MAINTENANCE RECOMMENDATIONS ..................................... 2-24
SECTION III
OPERATION
3.1 GENERAL .................................................................... 3-1
3.2 NORMAL OPERATION ........................................................... 3-2
A. PREFLIGHT .................................................................. 3-2
B. TAXI ....................................................................... 3-2
C. IN FLIGHT OPERATION ........................................................ 3-3

N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page TC-3
006-10536-0010 Rev. 10 Oct/2005
ITEM PAGE
D. APPROACH ................................................................... 3-3
E. PUSH-TO-TEST MODE .......................................................... 3-3
3.3 SELF-TEST DIAGNOSTICS ...................................................... 3-4
TSO APPENDIX

N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page TC-4
006-10536-0010 Rev. 10 Oct/2005
THIS PAGE IS RESERVED

N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page TC-5
006-10536-0010 Rev. 10 Oct/2005
ITEM PAGE
FIGURE 2-1 KRA 405B DEFAULT TRIP POINT SETTINGS ............................. 2-3
FIGURE 2-2 KRA 405B TRIP POINT EDITING WINDOW ............................... 2-3
FIGURE 2-3 KRA 405B ZERO POINT OFFSET ....................................... 2-5
FIGURE 2-4 KRA 405B POST INSTALLATION CALIBRATION SWITCH ................... 2-16
FIGURE 2-5 KNI 415/416 INSTALLATION DRAWING ................................ 2-25
FIGURE 2-6 KRA 405B INSTALLATION DRAWING ................................... 2-27
FIGURE 2-7 DUAL RADAR ALTIMETER SYSTEM TYPICAL ANTENNA INSTALLATIONS ....... 2-29
FIGURE 2-8 KA 54 ANTENNA OUTLINE AND MOUNTING DRAWING ...................... 2-33
FIGURE 2-9 UBC TYPE AD 43013-1 AND COMANT TYPE 01-34-04531 ................. 2-35
FIGURE 2-10 DORNE MARGOLIN TYPE DMPN 3-4/A ANTENNA .......................... 2-37
FIGURE 2-11 KA 54A ANTENNA .................................................. 2-39
FIGURE 2-12 HONEYWELL GT 7003586 (SENSOR SYSTEMS TYPE S67-2002-4 ANTENNA) ... 2-41
FIGURE 2-13 TNC COAX/CONNECTOR ASSEMBLY (RG 393/U) .......................... 2-43
FIGURE 2-14 CONNECTOR PIN LOCATIONS ......................................... 2-44
FIGURE 2-15 KRA 405B TEST EQUIPMENT SETUP ................................... 2-45
FIGURE 2-16 EXTERNAL SONALERT ............................................... 2-46
FIGURE 2-17 KRA 405B RADAR ALTIMETER SYSTEM INTERCONNECT .................... 2-47
FIGURE 2-18 CM 2000 CONFIGURATION MODULE MOUNTING DRAWING ................... 2-49
FIGURE 3-1 KNI 415 CONTROL FUNCTIONS ........................................ 3-5
FIGURE 3-2 KNI 416 CONTROL FUNCTIONS ........................................ 3-6

N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page TC-6
006-10536-0010 Rev. 10 Oct/2005
THIS PAGE IS RESERVED

N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page TC-7
006-10536-0010 Rev. 10 Oct/2005
ITEM PAGE
TABLE 1-1 KNI 415/416 INDICATOR AVAILABILITY .............................. 1-10
TABLE 1-2 CABLE INSTALLATIONS ............................................. 1-11
TABLE 2-1 TSO CERTIFIED ANTENNAS ........................................... 2-9

N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page TC-8
006-10536-0010 Rev. 10 Oct/2005
THIS PAGE IS RESERVED

N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page 1-1
006-10536-0010 Rev. 10 Oct/2005
SECTION I
GENERAL INFORMATION
1.0 INTRODUCTION
This manual contains information relative to the physical, mechanical, and
electrical characteristics of the BENDIX/KING KRA 405B. Installation and
operating procedures are also included. Information relative to the
maintenance and procurement of replacement parts may be found in the KRA
405B Maintenance Manual Part Number 006-15536-00XX (XX = Highest
Revision).
NOTE: The KRA 405B System consists of four modules: the Radar Altim-
eter (Receiver/Transmitter), the Radar Altimeter Indicator, the
Radar Altimeter Antennas (2 each), and the CM 2000 Configuration
Module (optional). The system is positioned as a replacement
for the KRA 405 Radar Altimeter System.
The preferred configurations utilize the following components:
COMPONENT UNIT PART NUMBER CHARACTERISTIC
RADAR ALTIMETER KRA 405B 066-01153-0101 STANDARD
KRA 405B 066-01153-0202 ARINC 552A
KRA 405B 066-01153-2001/-4001 ENHANCED DIGITAL AC-
CURACY
CONTROLLER/DISPLAY KNI 415 066-3031-00 5 VOLT BLK
KNI 415 066-3031-01 28 VOLT BLK
KNI 415 066-3031-02 5 VOLT GRY
KNI 415 066-3031-03 28 VOLT GRY
KNI 415 066-3031-04 28 VOLT BLK NIGHT VI-
SION
KNI 416 066-3044-00 5 VOLT BLK
KNI 416 066-3044-01 28 VOLT BLK
KNI 416 066-3044-02 5 VOLT GRY
KNI 416 066-3044-03 28 VOLT GRY
KNI 416 066-3044-04 28 VOLT BLK NIGHT VI-
SION
ANTENNA KA 54A 071-1501-00 WHITE (2 EACH)
ANTENNA (OPTIONAL) KA 54A 071-01501-0100 BLACK (2 EACH)
CONFIGURATION MODULE CM 2000 071-00097-0100 OPTIONAL

N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page 1-2
006-10536-0010 Rev. 10 Oct/2005
Some part numbers may not be currently available. Consult the current
Honeywell catalog or contact a Honeywell representative for equipment
availability. The KRA 405B System also may consist of previously TSO
certified components from the following list. However the use of any
configurations other than the preferred configuration will result in
reduced functionality of the system.
Upon use of the above antennas or any other configurations, the STC
certification will be the sole responsibility of the customer and/or the
installing agent. Please contact a field representative for additional
information.
1.1 DESCRIPTION OF EQUIPMENT
The KRA 405B Radar Altimeter System provides the pilot with dependable,
accurate AGL (altitude above ground level) information during the approach
phase of a flight. The system has the capability of alerting the pilot
when a predetermined altitude (decision height) is reached. The system
also provides altitude information to the flight control system during the
approach.
The KRA 405B Radar Altimeter (P/N 066-01153-0202), in addition to
providing an ARINC 552A output for Auxiliary Out 2, has the ability to
take a DH input from an EFIS or KNI 415/416 and generate an audio signal
(refer to section 1.3. C. KRA 405B RECEIVER/TRANSMITTER for tone generator
circuit specifications).
The KRA 405B Radar Altimeter (P/N 066-01153-2001/-4001) provides enhanced
accuracy (±2 feet) below 100 feet using the digital 429 Buss labels 164
and 165.
Both KRA 405B versions P/N 066-01153-0101 and P/N 066-01153-0202 with
software 01/04, 02/04 or higher will not report negative values of
altitude on the ARINC 429 digital bus unless expressly configured to do
so. This feature is required for installations with Honeywell EFIS 40/
50. One of these two unit versions (-0101 or -0202) must be used when
interfacing the digital output of the KRA 405B to equipment which expect
non-negative values.
The KRA 405B determines the altitude above ground level (AGL) by
transmitting a signal to the ground then processing the reflected signal.
The altimeter outputs the altitude information as analog voltages and in
ARINC 429 digital format.
MODEL KA 54
DESCRIPTION RETROFIT ANTENNA

N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page 1-3
006-10536-0010 Rev. 10 Oct/2005
The KRA 405B Radar Altimeter System consists of the KRA 405B Receiver/
Transmitter, the KNI 415 or KNI 416 Indicator, and two (2) KA 54A Antennas.
The entire system is solid state except for a servo mechanism and relay
in the Indicator.
The KRA 405B Radar Altimeter replaces the KRA 405 altimeter. The KRA 405B
is electrically compatible with the same indicators and antennas as the
KRA 405.
NOTE: The connectors for KRA 405 and KRA 405B are not compatible.
1.2 ACRONYMS AND ABBREVIATIONS
ACRONYM MEANING
AGL Above Ground Level
ARINC Aeronautical Radio Incorporated
EUROCAE The European Organization for Civil Aviation Electronics
FAA Federal Aviation Administration
FCC Federal Communications Commission
FTZ Fernmeldetechischeszentralamt (German)
Hz Hertz
IF Intermediate Frequency
kHz kilohertz
GHz Gigahertz
MHz Megahertz
PEO Precision Equipment Output
P/N Part Number
RTCA Requirements and Technical Concepts for Aviation
R/T Receiver/Transmitter
TSO Technical Standing Order
VSWR Voltage Standing Wave Ratio
XX Part numbers ending in XX denotes the highest revision available (Example: 006-
10536-00XX)

N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page 1-4
006-10536-0010 Rev. 10 Oct/2005
1.3 TECHNICAL CHARACTERISTICS
A. KRA 405B RADAR ALTIMETER SYSTEM
B. KRA 405B RECEIVER/TRANSMITTER TSO
C. KRA 405B RECEIVER/TRANSMITTER
SYSTEM ALTITUDE ACCURACY: ±5 ft (1.5 m) or ±5% (whichever is greater)
at 0 to 500 feet and ±7% at 500 to 2,500 feet
SYSTEM ANTENNA CABLES (2 Required):
Length: See 1.5 ACCESSORIES REQUIRED BUT NOT SUPPLIED
Cable Type: See TABLE 1-2 CABLE INSTALLATIONS
SYSTEM POWER REQUIREMENTS: 27.5 Vdc ±20% at 2 Amperes maximum
SYSTEM WEIGHT (less cables): 5.1 lbs (2.31 kg)
TSO COMPLIANCE: C87/ETSO-2C87 (See TSO APPENDIX)
ALTITUDE: 55,000 ft (16,764 m)
OPERATIONAL TEMPERATURE RANGE: -55°C to +70°C
NON TSO’D FUNCTIONS NONE
PHYSICAL CHARACTERISTICS:
Length:
Width:
Height:
See FIGURE 2-6 KRA 405B INSTALLATION DRAWING
WEIGHT: KRA 405B
With Mtg rack (optional)
See FIGURE 2-6 KRA 405B INSTALLATION DRAWING
POWER REQUIREMENTS:
Nominal Current
Maximum Current
27.5 Vdc ±20% at 850 mA
18 Vdc @ 1.2 Amperes (emergency)
ALTITUDE RANGE:
Tracked: -20 to 2,500 feet (-6.1 to 762.0 m)
ALTITUDE TRIPS (selectable):
Adjustment Range #1, 2, and 3: (Con-
figuration Module
Programmable)
Factory Settings:
0-2500 feet (0-762.00 m)
Trip #1 200 feet (60.90 m)
Trip #2 500 feet (152.40 m)
Trip #3 1200 feet (365.76 m)
ALTITUDE ACCURACY:
066-01153-0101,-0202,-2001/-4001
(All Analog and Digital Altitude Outputs except
066-01153-2001/-4001 Digital Outputs)
3 ft (0.91 m) or ±3% (whichever is greater)
at 0 to 500 feet and ±5% at 500 to 2,500 feet
ALTITUDE ACCURACY:
066-01153-2001/-4001
ARINC 429 Outputs Labels 164 and 165
±2 ft (0.61 m) below 100 feet,
±3% at 100 feet to 500 feet, and
±5% at 500 to 2,500 feet

N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page 1-5
006-10536-0010 Rev. 10 Oct/2005
C. KRA 405B RECEIVER/TRANSMITTER (cont.)
ALTITUDE OUTPUT:
Slope:
Precision Equipment: -20 to 2,500 ft (-6.1 to 762.0 m) -10 mV/ft (32.81 mV/m); Zero
ft = 0.000 volts
Auxiliary Out #1: -20 to 500 feet (-6.1 to 152.4 m) +20 mV/ft (+65.62 mV/m); 500
to 2,500 feet (152.4 to 762 m) +3 mV/ft (9.84 mV/m); Zero ft
= +0.400 volts
Auxiliary Out #2:
(-0101, -2001/-4001)
-20 to 2,500 feet (-6.1 to 762.0 m) -4 mV/ft (13.12 mV/m);
Zero feet = 0.000 volts
Auxiliary Out #2:
(-0202)
-20 to 480 feet (-6.1 to 146.3 m) +20 mV/ft (+65.62 mV/m); 480
to 2,500 feet (146.3 to 762 m) 10 x logn [e(h+20)/500](10 x
logn [e(h+6.1/152.4)]m); Zero ft = +0.400 volts
Analog Altitude: -20 to 500 feet (-6.1 to 152.4 m) +20 mV/ft (+65.62 mV/m); 500
to 2,500 feet (152.4 to 762 m) +3 mV/ft (9.84 mV/m); Zero ft
= +0.400 volts
Arinc 429 Out: Shall meet all ARINC 429 electrical
specifications.
The following are serial digital outputs from the KRA 405B:
LABEL INFORMATION CONTAINED IN LABEL FORMAT SPEED
164 Radio Height BNR Low Speed
165 Radio Height BCD Low Speed
371 GA Equipment Code BCD Low Speed
377 Equipment Identifier Word BCD Low Speed

N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page 1-6
006-10536-0010 Rev. 10 Oct/2005
C. KRA 405B RECEIVER/TRANSMITTER (cont.)
Load Capability: 4 loads, @ 2 kΩper load
Off Scale Voltage:
Precision Equipment Output: -28.0 ±1.5 Vdc
Auxiliary Out #1: +17.3 ±0.5 Vdc
Auxiliary Out #2: -11.2 ±0.6 Vdc (-0101)
Auxiliary Out #2: 27.5 ±1.5 Vdc (-0202)
Time Constant:
Precision Equipment Output: 0.1 second maximum
TRANSMITTER OUTPUT:
Power: 160 mW nominal, FMCW
Center Frequency: 4300 ±15 MHz
Modulation Frequency:
Primary: 100 Hz nominal
Secondary: 105 Hz nominal (in dual installation)
TRANSMITTER OUTPUT: (cont.)
FM Deviation P-P: 100 MHz
Type of Service: Continuous
WARNING SYSTEM:
FCS Warn:
Normal Operation: +18 to +32 Vdc at less than 250 mA
Warn Condition: Less than 10 μA
Altimeter Valid:
Normal Operation: +18 to +32 Vdc at less than 250 mA
Warn Condition: Less than 10 μA
Rad_Alt Valid:
Normal Operation: +18 to +32 Vdc at less than 250 mA
Warn Condition: Less than 10 μA
ALTITUDE TRIPS:
Tripped (Locked R/T): +0.5 Vdc maximum at less than 250 mA
Untripped (Unlocked R/T): 10 μA maximum at less than +30 Vdc
TONE GENERATOR CIRCUIT:
DH Tone Enable Active Level: Low: < 3.5 Vdc
Inactive Level: High: > 17 Vdc
Tone Active Time: 2.5 seconds ±.5 seconds
Output Frequency: 587 HZ ±20 Hz (music tone D)
Output Level (-0202): 30mW ±10 mW into a 500 Ωload
Noise Level: 60 dB min below rated level

N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page 1-7
006-10536-0010 Rev. 10 Oct/2005
D. KNI 415/416 INDICATOR
TSO COMPLIANCE: C87/ETSO-2C87 DO-138
Env. Cat GAPAAAXXXXXX
PHYSICAL DIMENSIONS: See FIGURE 2-5 KNI 415/416 INSTALLATION DRAWING
Length:
Width:
Height:
WEIGHT: See FIGURE 2-5 KNI 415/416 INSTALLATION DRAWING
ALTITUDE: 55,000 feet (16,764 m)
OPERATIONAL TEMPERATURE RANGE: -20°C to +70°C
POWER REQUIREMENTS:
Primary Power: 27.5 Vdc ±20% @ 850 mA
Panel Lamp Power: (28 volt units) 28 Vdc ±10% or 26 Vac ±10% @ 120 mA
Panel Lamp Power: (5 volt units) +5 Vdc ±10% or 5 Vac ±10% @ 575 mA
ALTITUDE RANGE DISPLAYED: -20 to 2,000 feet (-6.1 to 609.60 m)
ALTITUDE ACCURACY:
0 to 500 ft: ±4 feet (1.22 m) or ±4% (whichever is great-
er)
500 to 2,000 ft: ±5%
DECISION HEIGHT:
Altitude Range:
(pilot adjustable)
0 to 2,000 feet (0 to 609.60 m)
Accuracy: ±5 feet (1.27 m) or 5%, whichever is greater
EXTERNAL DECISION HEIGHT OUTPUT: Isolated pair of relay contacts for switching
external circuit. 110 mA at 28 Vdc, 3 watts
maximum continuous contact load.
VISUAL WARNING SYSTEM:
Pilot Display Warning Flag:
Normal Operation: Flag hidden from view
Flag Condition: Power failure or altitude error
Indicator Needle:
Over Altitude: Needle hidden from view

N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page 1-8
006-10536-0010 Rev. 10 Oct/2005
E. KA 54A ANTENNA
TSO COMPLIANCE: C87/ETSO-2C87 DO-160A
Env. Cat. D2AJXWFD
PHYSICAL CHARACTERISTICS: See FIGURE 2-11 KA 54A ANTENNA
Length:
Width:
Height:
WEIGHT: (2 required) See FIGURE 2-11 KA 54A ANTENNA
ALTITUDE: 60,000 ft (18,281 m)
OPERATIONAL TEMPERATURE RANGE: -54°C TO +85°C
BEAMWIDTH:
E-Plane: 45°min.
H-Plane: 40°min.
SIDELOBES: Greater than -40 dB down
VSWR: 4240 - 4360 MHz: 1.5:1 Maximum
GAIN: 10 dBi (above isotopic)
POLARIZATION: Linear
POWER HANDLING: 1 watt average, 10 watts peak
CROSS COUPLING: 20 in spacing - 88 dB max
36 in spacing - 95 dB max
INPUT IMPEDANCE: 50 ohms nominal
