Honeywell Dolphin 70e Black User manual

Dolphin™ 70e Black
with Windows
®
Embedded Handheld 6.5
User’s Guide

Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other
information contained in this document without prior notice, and the reader should in all cases consult HII
to determine whether any such changes have been made. The information in this publication does not
represent a commitment on the part of HII.
HII shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or
consequential damages resulting from the furnishing, performance, or use of this material.
This document contains proprietary information that is protected by copyright. All rights are reserved. No
part of this document may be photocopied, reproduced, or translated into another language without the
prior written consent of HII.
Web Address: www.honeywellaidc.com
Trademarks
Dolphin is a trademark or registered trademark of Hand Held Products, Inc. in the United States and/or
other countries.
Microsoft, Windows, Windows Mobile, Windows Phone, Windows Embedded Handheld, Windows CE,
Windows 98 Second Edition, Windows NT, Windows 2000, Windows ME, Windows XP, Windows 7,
Windows Vista, ActiveSync, Outlook, and the Windows logo are trademarks or registered trademarks of
Microsoft Corporation.
The Bluetooth trademarks are owned by Bluetooth SIG, Inc., U.S.A. and licensed to Honeywell.
Qualcomm is a registered trademark of Qualcomm Incorporated.
Other product names mentioned in this manual may be trademarks or registered trademarks of their
respective companies and are the property of their respective owners.
Patents
For patent information, please refer to www.honeywellaidc.com/patents.
©2013 Honeywell International Inc. All rights reserved.

Table of Contents
iii
Chapter 1 - Dolphin 70e Black Terminal Agency Information
Label Locations....................................................................................................................1-1
LED Safety...........................................................................................................................1-1
LED Safety Statement....................................................................................................1-1
UL and C-UL Statement.......................................................................................................1-2
Approvals by Country...........................................................................................................1-2
R&TTE Compliance Statement—802.11a/b/g/n, Bluetooth, and/or GSM............................1-2
FCC Requirements ..............................................................................................................1-3
Dolphin RF Terminal—802.11a/b/g/n, Bluetooth, and/or GSM ......................................1-3
Canadian Compliance..........................................................................................................1-3
RF Exposure Information (SAR) ..........................................................................................1-4
For European Community Users .........................................................................................1-5
Waste Electrical and Electronic Equipment Information ......................................................1-5
China RoHS .........................................................................................................................1-5
Pacemakers, Hearing Aids and Other Electrically Powered Devices ..................................1-6
Hearing Aid Compatibility (HAC)..........................................................................................1-6
Microwaves ..........................................................................................................................1-6
Chapter 2 - Getting Started
Out of the Box ......................................................................................................................2-1
Initial Setup for Dolphin 70e Black Terminals ......................................................................2-1
Using the USB Charge/Communication Cable (Model 70e-USB ADAPTERKIT) ..........2-3
The Home Screen................................................................................................................2-5
Title Bar..........................................................................................................................2-5
Icons in the Title Bar ......................................................................................................2-5
Horizontal Scroll .............................................................................................................2-8
Tile Bar...........................................................................................................................2-8
Virtual Keyboard ..................................................................................................................2-8
The Start Menu ..................................................................................................................2-10
Navigating the Start Menu............................................................................................2-10
Pop-Up Menus ...................................................................................................................2-10
File Explorer.......................................................................................................................2-11
File Provisioning on the Dolphin 70e Black........................................................................2-12
Search................................................................................................................................2-12
Turning Power On/Off ........................................................................................................2-13
Suspend Mode .............................................................................................................2-13
Replacing the Main Battery................................................................................................2-13
Resetting the Terminal.......................................................................................................2-14
Chapter 3 - Hardware Overview
Standard Configurations for the Dolphin 70e Black .............................................................3-1
Peripherals for the Dolphin 70e Black..................................................................................3-2
Accessories for the Dolphin 70e Black ................................................................................3-3

iv
Features of the Dolphin 70e Black ...................................................................................... 3-4
Front, Bottom, and Right Panels.................................................................................... 3-4
Back, Top, and Left Panels............................................................................................ 3-7
The I/O Connector ............................................................................................................. 3-10
Battery ............................................................................................................................... 3-10
Charging Options......................................................................................................... 3-11
Charging Times ........................................................................................................... 3-11
Important Charging Guidelines.................................................................................... 3-11
Battery Error Notification.............................................................................................. 3-13
Storing Batteries .......................................................................................................... 3-13
Guidelines for Battery Pack Use and Disposal............................................................ 3-13
Managing Battery Power ............................................................................................. 3-14
Checking Battery Power .............................................................................................. 3-15
System Resets .................................................................................................................. 3-15
Hardware Maintenance ..................................................................................................... 3-15
Installing a SIM Card and/or Memory Card ....................................................................... 3-15
Chapter 4 - Using the Scan Image Engine
Overview.............................................................................................................................. 4-1
LED Safety .......................................................................................................................... 4-1
Image Engine Specifications ............................................................................................... 4-1
Field of View .................................................................................................................. 4-1
Depth of Field ................................................................................................................ 4-1
Supported Bar Code Symbologies ..................................................................................... 4-2
Decoding ............................................................................................................................. 4-3
Using the Scan Demo to Decode a Bar Code ............................................................... 4-3
The Aiming Beam .......................................................................................................... 4-3
Capturing Images Using the Imaging Demo........................................................................ 4-4
Taking an Image............................................................................................................ 4-5
Uploading Images.......................................................................................................... 4-5
Chapter 5 - Using the Color Camera
Overview.............................................................................................................................. 5-1
Taking a picture using the Camera Demo tool .................................................................... 5-1
Taking a picture using the Windows Embedded Handheld 6.5 Camera tool ...................... 5-4
Recording Video using the Windows Embedded Handheld 6.5 Camera tool ..................... 5-6
Uploading Pictures and Videos ........................................................................................... 5-6
Chapter 6 - System Settings
Overview.............................................................................................................................. 6-1
Clock & Alarms .................................................................................................................... 6-2
Lock ..................................................................................................................................... 6-3
Personal Menu .................................................................................................................... 6-4
Buttons........................................................................................................................... 6-5
Voice Command ............................................................................................................ 6-8

v
System Menu....................................................................................................................... 6-9
About ...........................................................................................................................6-11
Audio Panel ................................................................................................................. 6-11
Backlight ...................................................................................................................... 6-12
Battery .........................................................................................................................6-14
Certificates................................................................................................................... 6-16
Encryption.................................................................................................................... 6-16
Error Reporting ............................................................................................................ 6-17
External GPS............................................................................................................... 6-17
HSM SystemInfo.......................................................................................................... 6-17
SIP Config.................................................................................................................... 6-18
Smart Sensor............................................................................................................... 6-19
Proximity Sensor Settings............................................................................................ 6-21
Managed Programs ..................................................................................................... 6-22
Memory........................................................................................................................ 6-22
Power...........................................................................................................................6-23
Regional Settings......................................................................................................... 6-24
Remove Programs....................................................................................................... 6-25
RIL ............................................................................................................................... 6-26
Screen ......................................................................................................................... 6-26
Task Manager.............................................................................................................. 6-27
Chapter 7 - Communication
Connections Menu............................................................................................................... 7-1
Microsoft Connections Application ...................................................................................... 7-2
Dolphin Wireless Manager .................................................................................................. 7-5
Dolphin Wireless Manager Window............................................................................... 7-5
Enabling the Radios....................................................................................................... 7-6
Accessing Radio Configuration Utilities......................................................................... 7-7
USB to PC ........................................................................................................................... 7-8
Network Cards..................................................................................................................... 7-8
Connecting and Synchronizing the Terminal and Workstation............................................ 7-9
Installing Additional Software ............................................................................................ 7-11
Adding Programs Using ActiveSync or Windows Mobile Device Center..................... 7-11
Connecting the Terminal to a Wireless Network.......................................................... 7-12
Adding Programs Using the Internet............................................................................ 7-12
Software Upgrades............................................................................................................ 7-13
Dolphin 70e Black COM Port Assignment Table............................................................... 7-13
Chapter 8 - Working with Wireless Wide Area Networking (WWAN)
Overview.............................................................................................................................. 8-1
Requirements ................................................................................................................ 8-1
Antenna Band................................................................................................................ 8-1
Signal Strength .............................................................................................................. 8-2
Voice and Data Communication .................................................................................... 8-2
Enabling the WWAN Radio ................................................................................................. 8-3
Audio Modes........................................................................................................................ 8-4
Volume Control.............................................................................................................. 8-4

vi
Voice Communication.......................................................................................................... 8-4
Accessing the Dialer Window ........................................................................................ 8-4
Accessing Voice Mail..................................................................................................... 8-5
Customizing the Phone.................................................................................................. 8-6
Data Communication ........................................................................................................... 8-9
System Requirements ................................................................................................... 8-9
Establishing Data Communication................................................................................. 8-9
Manual Network Selection (GSM/UTMS) .................................................................... 8-11
Dolphin Connection Manager ............................................................................................ 8-12
Chapter 9 - Working with the Bluetooth Radio
Enabling the Bluetooth Radio .............................................................................................. 9-1
Pairing and Trusted Devices ............................................................................................... 9-2
Connecting to Other Bluetooth Devices .............................................................................. 9-2
Transferring Files using Beam File...................................................................................... 9-5
Making the Terminal Discoverable ...................................................................................... 9-6
Enabling the Terminal to Receive Incoming Beams............................................................ 9-6
Selecting COM Ports ........................................................................................................... 9-6
Chapter 10 - Working with GPS
Overview............................................................................................................................ 10-1
Assisted GPS Support....................................................................................................... 10-1
Powering the GPS Module ................................................................................................ 10-1
Communication Ports ........................................................................................................ 10-1
Selecting the Port ........................................................................................................ 10-1
COM7 .......................................................................................................................... 10-2
GPS Intermediate Driver.............................................................................................. 10-2
GPS Demo ........................................................................................................................ 10-2
Chapter 11 - Dolphin 70e Black HomeBase Device (Model 70e-HB)
Overview............................................................................................................................ 11-1
Unpacking the HomeBase........................................................................................... 11-1
Charging Overview ...................................................................................................... 11-1
Communications.......................................................................................................... 11-1
Convenient Storage..................................................................................................... 11-2
Capacity....................................................................................................................... 11-2
Dimensions.................................................................................................................. 11-2
Weight..........................................................................................................................11-2
Parts and Functions........................................................................................................... 11-3
Front Panel ................................................................................................................. 11-3
Back Panel .................................................................................................................. 11-4
Bottom Panel ............................................................................................................... 11-5
Power ................................................................................................................................ 11-5
Connecting Power to the HomeBase........................................................................... 11-5
Charging the Main Battery................................................................................................. 11-6
To Power a Terminal and Charge its Main Battery...................................................... 11-6
Charging a Spare Battery in the Auxiliary Battery Well ............................................... 11-6

vii
Communication.................................................................................................................. 11-7
Requirements .............................................................................................................. 11-7
Setting Up and Connecting the Dolphin Terminal to the HomeBase........................... 11-7
Mounting the HomeBase ................................................................................................... 11-7
Desk Mounting............................................................................................................. 11-7
Chapter 12 - Dolphin 70e Black ChargeBase Device (Model 70e-CB)
Overview............................................................................................................................ 12-1
Unpacking the ChargeBase......................................................................................... 12-1
Charging Overview ...................................................................................................... 12-1
Convenient Storage..................................................................................................... 12-1
Capacity....................................................................................................................... 12-1
Dimensions.................................................................................................................. 12-2
Weight..........................................................................................................................12-2
Parts and Functions........................................................................................................... 12-2
Front Panel .................................................................................................................. 12-2
Back Panel................................................................................................................... 12-3
Bottom Panel ............................................................................................................... 12-3
Power ................................................................................................................................ 12-3
Connecting Power to the ChargeBase ....................................................................... 12-4
Charging the Main Battery................................................................................................. 12-4
To Power a Terminal and Charge its Main Battery...................................................... 12-4
Mounting the ChargeBase................................................................................................. 12-5
Chapter 13 - Customer Support
Product Service and Repair............................................................................................... 13-1
Technical Assistance......................................................................................................... 13-1
Warranty Disclaimer: Proper Use of a Touch Screen Mobile Device ................................ 13-1
Limited Warranty ............................................................................................................... 13-1
How to Extend Your Warranty ..................................................................................... 13-3

viii

1 - 1
1
Dolphin 70e Black Terminal Agency Information
Dolphin 70e Black mobile computers meet or exceed the requirements of all applicable standards
organizations for safe operation. However, as with any electrical equipment, the best way to ensure safe
operation is to operate them according to the agency guidelines that follow. Read these guidelines
carefully before using your Dolphin terminal.
This documentation is relevant for the following Dolphin models: 70eL00, 70eLGN, 70eLG0, and
70eL0N.
CAUTION - Read the Guidelines for Battery Pack Use and Disposal on page 3-13 and all cautionary
markings on the battery, charging peripheral, or device using the battery before attempting to install, use, or
charge the battery. Risk of fire and burns if improperly handled. Do not open, crush, heat above 60°C
(140°F), or incinerate.
Label Locations
Model Number, Serial Number and IMEI Labels
The model (item) number, serial number, and international mobile equipment identity (IMEI) number for
the terminal are located on labels affixed to the bottom of the battery well.
Warning! To prevent possible hearing damage, do not listen at high volume levels for long periods.
LED Safety
LED Safety Statement
LEDs have been tested and classified as “EXEMPT RISK GROUP” to the Standard: IEC 62471:2006.
Caution! Do not view directly with optical instruments.
!
Back Panel of the terminal
with the battery door and
battery removed.
Compliance Labels and Marks
!

1 - 2
UL and C-UL Statement
UL and C-UL listed: UL60950-1 2nd Edition, and CSA C22.2 No. 60950-1-07 2nd Edition.
Underwriters Laboratories Inc. (UL) has not tested the performance or reliability of the global positioning
system (GPS) hardware, GPS operating software or other GPS-related aspects of this product. UL has
only tested for the explosion, fire, shock, and casualty hazards required by the applicable hazardous
locations standards. UL certification does not cover the performance or reliability of the GPS hardware,
GPS operating software, or other GPS-related aspects of this product. UL makes no representations,
warranties, or certifications whatsoever regarding the performance or reliability of any GPS-related
functions of this product.
Approvals by Country
R&TTE Compliance Statement—802.11a/b/g/n, Bluetooth, and/or GSM
Dolphin RF terminals are in conformity with all essential requirements of the R&TTE Directive
(1999/5/EC).
This product is marked with according to article 12 of the R&TTE Directive. In addition, this
product complies to 2006/95/EC Low Voltage Directive when supplied with the recommended power
supply. Honeywell shall not be liable for use of our product with equipment (i.e., power supplies, personal
computers, etc.) that is not CE marked and does not comply with the Low Voltage Directive.
The equipment is intended for use throughout the European Community; PAN European Frequency
Range: 2.400–2.4835 GHz.
5Ghz band: UNII (Unlicensed National Information Infrastructure) or band1 (5.150 to 5.350 GHz) is
restricted to indoor use only. Any other use will make the operation of the device illegal.
Country EMC, Radio, & SAR Safety
U.S.A. FCC Part 15, Subpart B
FCC Part 15, Subpart C, 15.247
FCC Part 15, Subpart E
FCC Part 22H, FCC Part 24E
FCC SAR OET 65 Supplement C
UL60950-1, 2nd Edition
Canada ICES-003 (Class B), RSS 132, RSS 133, RSS 210 CSA C22.2 No. 60950-1-07, 2nd Edition
European
Community/CE
EN 302 291-1&2: V1.1.1,
EN 301 489-1: V1.9.2, EN 301 489-3: V1.4.1,
EN 301 489-7: V1.3.1, EN 301 489-17: V2.2.1,
EN 301 489-24: V1.5.1,
EN 301 511: V9.0.2,
EN 301 893: V1.6.1,
EN 301 908-1&2: V5.2.1,
EN 300 440-1: V1.6., EN 300 440-2: V1.4.1,
EN 300 328: V1.7.1, EN 300 330-1: V1.7.1,
EN 300 330-2: V1.5.1
EN 50360: 2001, EN 50360: 2001/AC:2006
EN 50364: 2010,
EN 62209-1: 2010, IEC 62209-2: 2010
EN 60950-1: 2006/A11:2009+A1:2010+A12:2011
EN 60825-1: 2007 (2nd Edition)
2006/95/EC - Low Voltage Directive
2011/65/EU-RoHS (recast)
International IEC 60950-1 2nd Edition
IEC 60825-1 2nd Edition
IEC 62471

1 - 3
High power radars are the primary users of 5250-5350 MHz and 5650-6850 MHZ bands. This may
cause interference to Wireless Local Area Network devices.
European Contact:
Hand Held Products Europe B.V.
Nijverheidsweg 9-13
5627 BT Eindhoven
The Netherlands
FCC Requirements
Dolphin RF Terminal—802.11a/b/g/n, Bluetooth, and/or GSM
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
If necessary, the user should consult the dealer or an experienced radio/television technician for
additional suggestions. The user may find the following booklet helpful: “Something About Interference.”
This is available at FCC local regional offices. Our company is not responsible for any radio or television
interference caused by unauthorized modifications of this equipment or the substitution or attachment of
connecting cables and equipment other than those specified by our company. The correction is the
responsibility of the user. Use only shielded data cables with this system.
5Ghz band: UNII (Unlicensed National Information Infrastructure) or band1 (5.150 to 5.250 GHz) is
restricted to indoor use only. Any other use will make the operation of the device illegal.
Caution! - Any changes or modifications not expressly approved by the grantee of this device could void the user’s
authority to operate the equipment.
Canadian Compliance
This Class B digital apparatus complies with Canadian ICES-003 and RSS210. Operation is subject to
the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired
operation.

1 - 4
5Ghz band: UNII (Unlicensed National Information Infrastructure) or band1 (5.150 to 5.250 GHz) is
restricted to indoor use only. Any other use will make the operation of the device illegal.
For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines for
use with the following body worn accessory: Holster-1. Use of other accessories may not ensure
compliance with FCC RF exposure guidelines.
Caution! - Any changes or modifications not expressly approved by the grantee of this device could void the user’s
authority to operate the equipment.
Conformité à la règlementation canadienne
Cet appareil numérique de la Classe B est conforme à la norme NMB-003 et RSS210 du Canada. Son
fonctionnement est assujetti aux conditions suivantes:
1. Cet appareil ne doit pas causer de brouillage préjudiciable.
2. Cet appareil doit pouvoir accepter tout brouillage reçu, y compris le brouillage pouvant causer un
fonctionnement indésirable.
Bande 5 Ghz: UNII (Infrastructure Nationale d'Information Sans Permis) ou Bande1 (5.150 à 5.250 GHz)
est limitée à l'usage intérieur seulement. Toute autre utilisation rendra l'opération de l'appareil illégal.
For body worn operation, ce téléphone a été testé et respecte les directives d'exposition RF de la FCC
pour une utilisation avec l'accessoire body worn: Holster-1. L'utilisation de d'autres accessoires risque
de ne pas assurer la conformité avec les directives d'exposition RF de la FCC.
Mise en garde! - Tout changement ou modification non expressément approuvées par le bénéficiaire de cet
appareil peut annuler l'autorisation d'utiliser l'équipement.
RF Exposure Information (SAR)
This mobile phone meets the government's requirements for exposure to radio waves. This phone is
designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF)
energy set by the Federal Communications Commission of the U.S. Government.
The exposure standard for wireless mobile phones employs a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/Kg and for Europe 2W/Kg.
Although the SAR is determined at the highest certified power level, the actual SAR level of the phone
while operating can be well below the maximum value. This is because the phone is designed to operate
at multiple power levels so as to use only the poser required to reach the network. In general, the closer
you are to a wireless base station antenna, the lower the power output.
The highest reported SAR values for head, body-worn accessory and simultaneous transmission use
conditions are: 0.45 W/kg (1g), 0.96 W/kg (1g) and 1.33 W/kg (1g).
The highest reported CE SAR values for head, body-worn accessory and simultaneous transmission
use conditions are: 0.59 W/kg (10g), 1.0 W/kg (10g), 1.15 W/kg (10g).
While there may be differences between the SAR levels of various phones and at various positions, they
all meet the government requirement.
The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone
is on file with the FCC and can be found under the Display Grant section of www.fcc.gov/oet/ea/fccid
after searching on FCC ID: HD570eLGN, HD570eLG0 and HD570eL00.

1 - 5
For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines for
use with the following body worn accessory: Holster-1. Use of other accessories may not ensure
compliance with FCC RF exposure guidelines.
For European Community Users
Honeywell complies with Directive 2002/96/EC OF THE EUROPEAN PARLIAMENT AND OF THE
COUNCIL of 27 January 2003 on waste electrical and electronic equipment (WEEE).
Waste Electrical and Electronic Equipment Information
This product has required the extraction and use of natural resources for its production. It may contain
hazardous substances that could impact health and the environment, if not properly disposed.
In order to avoid the dissemination of those substances in our environment and to diminish the pressure
on the natural resources, we encourage you to use the appropriate take-back systems for product
disposal. Those systems will reuse or recycle most of the materials of the product you are disposing in a
sound way.
The crossed out wheeled bin symbol informs you that the product should not be disposed of along
with municipal waste and invites you to use the appropriate separate take-back systems for product
disposal. If you need more information on the collection, reuse, and recycling systems, please
contact your local or regional waste administration. You may also contact your supplier for more
information on the environmental performances of this product.
China RoHS
有毒有害物质名称及含量 (Names and Content of Hazardous Substances or Elements)
部件名称 (Parts Name) 有毒有害物质或元素 (Toxic and Hazardous Substances or Elements)
铅(Pb) 汞(Hg) 镉(Cd) 六价铬 (Cr6+)多溴联苯 (PBB) 多溴二苯醚 (PBDE)
成像式条码 读器 (Imager) oooooo
印刷电路板 (PCB) oooooo
主机及基座外壳 (Housing) oooooo
连线 (Cables) oooooo
液晶显示器 (LCD) oooooo
液晶显示器框架 (LCD Frame) oooooo
相机模组 (Camera) oooooo
按键 (Key) oooooo
电池 (Battery) oooooo
电源供应器 (Power Adapter) oooooo
o: 表示该有毒有害物质在该部件所有均质材料中的含量均在SJ/T11363-2006标准规定的限量要求以下 (Indicates that this toxic or hazardous substance contained in all of the homogeneous
materials for this part is below the limit requirement in China’s SJ/T11363-2006.)
x: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求 (Indicates that this toxic or hazardous substance contained in at least one of the
homogeneous materials for this part is above the limit requirement in China’s SJ/T11363-2006. )

1 - 6
Pacemakers, Hearing Aids and Other Electrically Powered Devices
Most manufacturers of medical devices adhere to the IEC 601-1-2 standard. This standard requires
devices to operate properly in an EM Field with a strength of 3V/m over a frequency range of 26 to
1000MHz. The maximum allowable field strength emitted by the Dolphin terminal is 0.3V/m according to
Subpart B of Part 1 of the FCC rules. Therefore, the RF from the Dolphin terminal has no effect on
medical devices that meet the IEC specification.
Hearing Aid Compatibility (HAC)
Dolphin 70e Black models 70eLGN and 70eLG0 have been tested for hearing aid compatibility. These
devices have an M4 and T4 rating. For additional HAC information, including the HAC rating for this
product, please refer to www.honeywellaidc.com.
When some wireless devices are used near some hearing devices such as hearing aids and implants,
users may detect a buzzing or humming noise. Some hearing devices are more immune than others to
this interference noise. Wireless devices may also vary in the amount of interference they generate.
The ratings for compatibility of digital wireless devices with hearing aids are described in the American
National Standards Institute (ANSI) C63.19 standard:
M-Rating: Phones rated M3 or M4 meet FCC requirements and are likely to generate less interference
with hearing devices than phones that are not labeled. M4 is the superior/higher of the two ratings.
T-Rating: Phones rated T3 or T4 meet FCC requirements and are likely to be more usable with hearing
devices' telecoil than unrated phones. T4 is the superior/higher of the two ratings.
The more immune the hearing aid device is, the less likely one is to experience interference noise from
the wireless phone. Hearing aid devices may also be rated. Adding the ratings of the hearing aid and the
phone would determine probable usability:
• Any combined rating equal to or greater than six offers the best use.
• Any combined rating equal to five is considered normal use.
The ratings are not guarantees. Results will vary depending on the user's hearing device and hearing
loss. If your hearing device happens to be vulnerable to interference, you may not be able to use this
device successfully. Trying out this device with your hearing device is the best way to evaluate it for your
personal needs.
This device has been tested and rated for use with hearing aids for some of the wireless technologies
that it utilizes. However, there may be some newer wireless technologies used in this phone that have
not been tested yet for use with hearing aids. It is important to try the different features of this phone
thoroughly and in different locations, using your hearing aid or cochlear implant, to determine if you hear
any interfering noise. Consult your service provider or the manufacturer of this phone for information on
hearing aid compatibility.
Microwaves
The radio in the Dolphin RF terminal operates on the same frequency band as a microwave oven.
Therefore, if you use a microwave within range of the Dolphin RF terminal you may notice performance
degradation in your wireless network. However, both your microwave and your wireless network will
continue to function.

2 - 1
2
Getting Started
Out of the Box
Verify that the carton contains the following items:
• Dolphin 70e Black mobile computer (terminal)
• 3.7V Li-ion rechargeable battery
• USB charge/communication cable
• Power adapter with regional plug adapters
• Quick start guide
• Compliance Regulatory Sheet
If you ordered accessories for your terminals, verify that they are also included with the order. Be sure to
keep the original packaging in the event that the Dolphin terminal should need to be returned for service.
Note: Your Dolphin model may differ from the model illustrated in this guide; however, the features noted are
standard for all Dolphin 70e Black models with Windows® Embedded Handheld unless otherwise indicated.
Initial Setup for Dolphin 70e Black Terminals
Step 1. Install the Battery
Note: Before installing the main battery, read the Guidelines for Battery Pack Use and Disposal on page 3-13.
Dolphin 70e Black model terminals are designed for use with battery part numbers BAT-STANDARD-01
(Li-ion 3.7V, 6.179 watt hour) and BAT-EXTENDED-01 (Li-ion 3.7V, 12.358 watt hour) manufactured for
Honeywell International Inc.
The terminal is shipped with the battery packaged separate from the unit. Perform the steps illustrated
below to install the battery. For information on how to remove the battery, see Replacing the Main Battery
on page 2-13.
Ensure all components are dry prior to placing the battery in the terminal. Mating wet components may cause
damage not covered by the warranty.
How to Install the Battery
!
2
1
345

2 - 2
Step 2. Charge the Battery
The power source for the Dolphin terminal is the 3.7V Li-ion rechargeable battery located under the
battery door on the back panel of the device. See Battery on page 3-10 for additional information on
battery storage, use, and disposal.
Important: Removing the battery from the terminal erases all non-persistent memory. Always place the terminal in
Suspend mode before removing the battery. For information on how to remove the battery from the terminal, see
Replacing the Main Battery on page 2-13.
Before Initial Use
Dolphin terminals ship with the battery significantly discharged of power. After installing the battery in the
terminal, charge the battery with a Dolphin 70e Black charging peripheral for a minimum of 4 hours for
the standard battery pack or 6 hours for the extended battery pack. When using the 70e-USB Charge/
Communication cable to charge from a 500mA USB port on a host device, charge the battery for a
minimum of 6 hours for the standard battery and 8 hours for the extended battery.
Note: Inadequate source current may interfere with effective battery charging; see Important Charging
Guidelines on page 3-11 for additional information.
We recommend use of Honeywell peripherals, power cables, and power adapters. Use of any non-Honeywell
peripherals, cables, or power adapters may cause damage not covered by the warranty.
Dolphin 70e Black model terminals are designed for use with the following charging devices and cables:
70e-HB, 70e-CB, and 70e-USB ADAPTERKIT. See pages 3-2 and 3-3 for additional information on
Dolphin 70e Black peripherals and accessories.
Ensure all components are dry prior to mating terminals/batteries with peripheral devices. Mating wet
components may cause damage not covered by the warranty.
7
6
98
!
!

2 - 3
Using the USB Charge/Communication Cable (Model 70e-USB ADAPTERKIT)
Dolphin 70e Black terminals ship with a USB Charge/Communication Cable and a power adapter with
regional plug adapters. The USB Charge/Communication cable provides two options for charging the
terminal. Use the cable in conjunction with the provided power supply adapter and plug adapter to
charge the terminal from a power outlet or connect the cable to a high-power USB port to charge from a
host device.
Warning - The terminal shall only be connected to CTIA certified adapters, products that bear the USB-IF logo
or products that have completed the USB-IF compliance program when using the micro USB port as a
charging source.
Option 1: Charging from a power outlet
Use only a UL Listed power supply, which has been qualified by Honeywell with an output rated at 5VDC
and 1A with the device.
Option 2: Charging from a high power USB port on a host device (PC)
Charging the battery through a USB port takes more time than direct charging using the provided power
supply. Inadequate source current may lengthen the charge time or prevent the battery from charging if
the terminal is drawing more current than supplied by the USB port. The maximum current supplied by a
USB Host can vary from 100mA to 500mA. Do not attempt to charge the terminal from a 100mA source.
An active Dolphin terminal uses more current than supplied by a 100mA source causing the terminal to
continue to draw power from the battery. See Important Charging Guidelines on page 3-11 for additional
information.
Note: Placing the terminal in Suspend mode while charging reduces the current draw of the terminal and shortens
the charging time of the battery.
Tou ch > Settings > System > Power to view the battery charge status.
To access detailed information on the battery, touch > Settings > System > Battery.
!
USB Door
Plug Adapter
1
3
42
Micro USB Port
Power
Adapter
5Right Side Panel of Dolphin 70e Black
USB Charging/
Communication Cable

2 - 4
Step 3. Boot the Terminal and Access the Home Screen
The terminal begins booting as soon as power is applied. Do not press any keys or interrupt the boot
process. When the boot process is complete, the Home screen appears.
Note: During the initial charging stage, the terminal display may dim to conserve battery power due to inactivity.
Touch the display to turn on the backlight.
USB Door
USB Port on Host Device
1
3
2Micro USB
Port
USB Charge/
Communication Cable
Right Side Panel of Dolphin 70e Black

2 - 5
The Home Screen
After the Dolphin terminal initializes, the Home screen appears.
Title Bar
The Title bar, located at the top of the screen, displays the active program, the status of various system
functions, and the current time. Touching on the title bar provides access to the Horizontal Scroll. The
scroll provides access to additional programs and application screens. For additional information, see
Horizontal Scroll on page 2-8.
Icons in the Title Bar
Indicator Meaning
Synchronizing data
Touch to access
the Start menu.
Touch a menu item to
access additional screens.
Title Bar (page 2-5)
Touch to access the Clock &
Alarms settings screen.
Tile Bar (page 2-8)
Swipe up or down with your
finger or stylus to scroll through
the menu items.
Touch to access the
Contacts screen.
Text here indicates
the active program. Icons here indicate the status of various system
functions.

2 - 6
The terminal could not synchronize data with the workstation via ActiveSync.
New e-mail
New text message
New voicemail
New instant message
Vibrate on
Ringer off
Speaker phone on
Voice call in progress
Calls are forwarded
Call on hold
Missed call
Data call in progress
A battery error has occurred. Replace the main battery with a Honeywell Li-ion battery pack.
Battery is has a full charge
Battery has a high charge
Battery has a medium charge
Battery has a low charge
Battery has a very low charge and requires charging
Terminal is running on external power. If a battery pack is installed, the battery is charging in the
background.
The terminal is not connected to external power. A battery is installed, but is defective; specifically,
its charge level cannot be measured.
Icons in the Title Bar
Indicator Meaning
