Honeywell CW45 Series User manual

CW45
powered by Android™
Quick Start Guide
CW45-A-ES-QS-01-AG Rev A
10/22


DRAFT

1
Agency Models
CW45-X0N
Out of the Box
Make sure that your shipping box contains these items:
• CW45 mobile computer
•Armmount
• Rechargeable Li-ion battery
• Product documentation
Note: Arm strap (CW45-STRAP) sold separately.
If you ordered accessories for your mobile computer, verify that
they are also included with the order. Be sure to keep the original
packaging in case you need to return the mobile computer for
service.
DRAFT

2
Computer Features
Speaker
Touch Panel
I/O Connector
Battery Status/
Notification LED
Front Camera
F1
Function
Button
(Volume
Up*)
Microphone
Camera Lens
and Flash
F2 Function
Button
(Volume
Down*)
Power Button
Battery Latch
F3 Function
Button
(Scan*/Enter)
*Out of the box configuration.
DRAFT

3
Battery Latch
Mount Slot
Battery
I/O Connector
DRAFT

4
Mount Features
Arm Strap
Attachment
Clips
Mount Attachment
Arm Strap
Attachment
Clips
Mount
Release Latch
Comfort Pad
DRAFT

5
About the Battery
The mobile computer ships with either a standard 3.6 VDC,
12.24 watt-hour Li-ion standard battery or an extended
3.6 VDC, 24.48 watt-hour Li-ion battery manufactured for
Honeywell International Inc.
Before you attempt to use, charge or replace the
battery in the device, carefully read all labels,
markings and product documentation provided in the
box or online at sps.honeywell.com. To learn more
about Battery Maintenance for Portable Devices, go
to honeywell.com/PSS-BatteryMaintenance.
Avant d’essayer d’utiliser, de charger ou de remplacer
la batterie de l’appareil, lisez attentivement toutes les
étiquettes, marquages et documentation du produit
fournis dans la boîte ou en ligne à sps.honeywell.com.
Pour en savoir plus sur l’Entretien de Batteries pour
Appareils Portables, consultez-le honeywell.com/
PSS-BatteryMaintenance.
We recommend use of Honeywell Li-ion battery
packs. Use of any non-Honeywell battery may result
in damage not covered by the warranty.
Nous recommandons l’utilisation de batteries Li-ion
de la marque Honeywell. L’utilisation d’une batterie
d’un autre fabricant est susceptible de provoquer des
dommages non couverts par la garantie.
Ensure all components are dry prior to placing the
battery in the computer. Mating wet components
may cause damage not covered by the warranty.
Assurez-vous que tous les composants sont secs avant
d’insérer la batterie dans l’ordinateur. L’insertion de
composants humides risque de provoquer des
dommages non couverts par la garantie.
DRAFT

6
Install the Battery
Note: Battery can be installed with or without the mount in place.
Assemble the Mount and Arm Strap
1 2 3
CW45-STRAP
(sold separately)
1
Attachment
Hook
Mount
DRAFT

7
2
3
CW45
DRAFT

8
. .
4
5
Strap
Adjustment
Dial
Left Arm Setup Right Arm Setup
6
DRAFT

9
Remove Mount Assembly
7
8
1
DRAFT

10
Charge the Mobile Computer
The mobile computer ships with a partially charged battery.
Charge the standard (12.24 Wh) battery with a CW45 charging
device for a minimum of 3 hours. Charge the extended (24.48
Wh) battery a minimum of 6 hours.
Note: Using the computer while charging the battery increases
the time required to reach a full charge. If the mobile
computer is drawing more current than supplied by the
charging source, charging will not take place.
We recommend the use of Honeywell accessories and
power adapters. Use of any non-Honeywell
accessories or power adapters may cause damage not
covered by the warranty.
Nous recommandons d’utiliser des accessoires et des
adaptateurs secteur de marque Honeywell.
L’utilisation de tout accessoire ou adaptateur secteur
d’une autre marque est susceptible de provoquer des
dommages non couverts par la garantie.
2
DRAFT

11
CW45 series mobile computers are designed for use with CW45
charging accessories. For more information, see the CW45
Accessories User Guide available for download at
sps.honeywell.com.
Turn Power On/Off
The first time you power on the computer, a Welcome screen
appears. You can either scan a configuration barcode or use the
Wizard to manually set up the computer. Once setup is
complete, the Welcome screen no longer appears on startup
and Provisioning mode is automatically turned off (disabled).
To turn the computer on:
•PressandholdthePower button for approximately 3 seconds
and then release.
To turn the computer off:
1. Press and hold the Power button until the options menu
appears.
2. Touch Power Off.
Ensure all components are dry prior to mating the
computers and batteries with peripheral devices.
Mating wet components may cause damage not
covered by the warranty.
Assurez-vous que tous les composants sont secs
avant de raccorder les ordinateurs et les batteries à
des périphériques. L’insertion de composants
humides risque de provoquer des dommages non
couverts par la garantie.
DRAFT

12
Battery Replacement
Hot Swap
You can replace the battery on demand provided the following
conditions are met:
• The computer has been powered on for at least 4 minutes.
AND
• You insert a new battery within 60 seconds.
Swap Battery Mode
Swap Battery mode places the computer in a low power state so
that the battery can be removed for a short time.
To activate Swap Battery mode:
1. Press and hold the Power button until the options menu
appears.
2. Touch Swap Battery and follow the on-screen instructions.
3. Once you replace the battery, press the Power button.
DRAFT

13
Remove the Battery
Press and hold the battery latches and lift the battery out of the
computer.
Screen Timeout
The screen timeout (sleep mode) automatically turns the touch
panel display off and locks the computer to save battery power
when the computer is inactive for a programmed period of time.
• Press and release the Power button to wake the computer.
Adjust the Screen Timeout
To adjust the amount of time before the display sleeps after
inactivity:
1. Swipe up on the touch screen.
2. Select Settings > Display > Screen Timeout.
3. Select the amount of time before the display goes to sleep.
DRAFT

14
About the Home Screen
Notification /
Status Bar
Search Bar
Favorites
Tray
Navigation
Buttons
Home Screen
Panel
DRAFT

15
Navigation and Function Buttons
For button locations, see Computer Features on page 2.
Button Description
Back Return to the previous screen.
Home Return to the Home screen.
Recent Apps View and switch between recently
used apps.
Power • Turn Power On/Off
•Enter/ExitScreen Timeout (sleep).
• Access options menu, including:
Power off, Restart, and Swap
Battery Mode.
VOL_UP Programmable function button.
Default is Volume Up.
VOL_DOWN Programmable function button.
Default is Volume Down.
ENTER/
SCAN*
Programmable function button.
Default is Enter.
*Out of the box, the F3 button is
assigned to Scan (see next section).
F1
F2
F3
DRAFT

16
F3 Button
Out of the box, the F3 button has been remapped to Scan so
that you can use a configuration barcode during setup. To clear
the remapping and return the F3 button to its default (Enter),
scan the barcode below or use Keyremap. (Refer to the CW45
User Guide for more information about Keyremap.)
Note: Performing a Factory Reset will remap the F3 key back to
Scan.
About Provisioning Mode
After completing the out-of-box set up process, Provisioning
mode is automatically turned off. Scanning a barcode to install
applications, certificates, configuration files, and licenses on
the computer is restricted unless you enable Provisioning mode
in the Settings app. To learn more, see the user guide.
DRAFT

17
Scan a Barcode with the Scan Demo
For optimum performance, avoid reflections by scanning the
barcode at a slight angle.
1. Swipe up on the screen.
2. Select Demos > Scan
Demo.
3. Point the computer at
the barcode.
4. Touch Scan on the
screen.
The decode results appear
on the screen.
Note: In the Scan Demo app, not all barcode symbologies are
enabled by default. If a barcode does not scan, the correct
symbology may not be enabled. To learn how to modify the
default app settings, see the user guide.
Sync Data
To move files between your CW45 and a computer:
1. Connect the CW45 to your computer using a
communication accessory.
2. On the CW45, swipe down from the top of the screen to see
the notifications panel.
3. Touch the Android System notification twice to open the
options menu.
DRAFT

18
4. Select either File Transfer or PTP.
5. Open the file browser on your computer.
6. Browse to the CW45. You can now copy, delete, and move
files or folders between your computer and CW45 as you
would with any other storage drive (e.g., cut and paste or
drag and drop).
Note: When Provisioning mode is turned off, some folders are
hidden from view in the file browser.
Restart the Mobile Computer
You may need to restart the mobile computer to correct
conditions where an application stops responding to the system
or the computer seems to be locked up.
1. Press and hold the Power button until the options menu
appears.
2. Select Power > Restart.
To restart the computer if the touch panel display is
unresponsive:
•PressandholdthePower button for approximately 8 seconds
until the computer restarts.
Note: To learn about advanced reset options, see the user guide.
Compliance Version
To view compliance marks for the mobile device, select Settings
> About phone > Compliance Information.
DRAFT

19
Support
Go to sps.honeywell.com and select Support to search our
knowledge base for a solution or to log into the Technical
Support portal.
Documentation
Product documentation is available at sps.honeywell.com.
Limited Warranty
For warranty information, go to sps.honeywell.com and then
select Support > Warranties.
Patents
For patent information, see www.hsmpats.com.
Trademarks
Android is a trademark of Google LLC.
Other product names or marks mentioned in this document may
be trademarks or registered trademarks of other companies and
are property of their respective owners.
Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make
changes in specifications and other information contained in
this document without prior notice, and the reader should in all
cases consult HII to determine whether any such changes have
been made. HII makes no representation or warranties
regarding the information provided in this publication.
HII shall not be liable for technical or editorial errors or
omissions contained herein; nor for incidental or consequential
damages resulting from the furnishing, performance, or use of
