Honeywell PC42E-T User manual

User Guide


PC42E-T
Desktop Printer

Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in
this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes
have been made. HII makes no representation or warranties regarding the information provided in this publication.
HII shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential
damages resulting from the furnishing, performance, or use of this material. HII disclaims all responsibility for the
selection and use of software and/or hardware to achieve intended results.
This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this
document may be photocopied, reproduced, or translated into another language without the prior written consent of HII.
Copyright 2023 Honeywell Group of Companies. All rights reserved.
Web Address: sps.honeywell.com
Trademarks
Microsoft® Windows® and the Windows logo are trademarks or registered trademarks of Microsoft Corporation.
Wi-Fi is a registered certification mark of the Wi-Fi Alliance.
Bluetooth is a trademark of Bluetooth SIG, Inc., U.S.A.
Google™, Android™ and Google Play Store™ are registered trademarks of Google, LLC.
Zebra and Eltron® is a trademark or registered trademark of Zebra Corporation.
Other product names or marks mentioned in this document may be trademarks or registered trademarks of other
companies and are the property of their respective owners.
Patents
For patent information, refer to www.hsmpats.com.

PC42E-T Desktop Printer User Guide iii
Customer Support
Technical Assistance
To search our knowledge base for a solution or to log into the Technical Support
portal and report a problem, go to honeywell.com/PSSTechnicalsupport.
Product Service and Repair
Honeywell International Inc. provides service for all of its products through service
centers throughout the world. Go to sps.honeywell.com and select Support to find
a service center near you or to get a Return Material Authorization number (RMA #)
before returning a product.
Limited Warranty
For warranty information, go to sps.honeywell.com and select Support >
Warranties.

iv PC42E-T Desktop Printer User Guide
Safety Warnings
Warning: Moving parts are exposed when the cover is open.
Make sure the cover is closed before you operate
the printer.
Warning: The printhead/motor may be hot. Allow the
printhead/motor to cool.
Warning: Do not put your fingers inside the print
mechanism when the power is on.
Warning: The tear bar contains sharp edges. Keep fingers
and other body parts away from the tear bar.
Caution: Read and review the warnings in this manual
carefully before connecting the printer.
Caution: Observe all safety and accident prevention
regulations applicable to your specific region and
application.
Caution: Do not spray the printer with water. If you are using
a host to clean the premises in an industrial
environment, remove the printer or protect it
carefully from spray and moisture.
Caution: You must implement both hardware and software
safety precautions to prevent the possibility of
undefined system states.
Caution: You must make sure that dangerous conditions
cannot occur under any circumstances, even for a
brief period of time.
Caution: Carefully read the warning text on the envelope
before using a cleaning card.
Caution: To reduce the risk of electric shock or fire, keep the
cover closed and turn off the printer when not in
use. No user-serviceable parts inside.

PC42E-T Desktop Printer User Guide iii
TABLE OF CONTENTS
Customer Support ........................................................................................................................ iii
Technical Assistance ............................................................................................................. iii
Product Service and Repair ................................................................................................ iii
Limited Warranty .................................................................................................................... iii
Safety Warnings ...................................................................................................................... iv
Chapter 1 - About the Printer features.........................................................1
About the Printer ............................................................................................................................ 1
Printer Features .............................................................................................................................. 2
About the Print Button ................................................................................................................. 3
About the ECO Button.................................................................................................................. 3
About the Status LED ................................................................................................................... 4
About Media ..................................................................................................................................... 4
Load Tear-Off Media .............................................................................................................. 5
Load External Media ........................................................................................................... 10
Load Ribbon .................................................................................................................................. 10
Connect the Printer to Power ................................................................................................. 16
About Printer Command Languages .................................................................................. 16
Autosense ................................................................................................................................ 17
Direct PDF Printing.............................................................................................................. 17
Direct Protocol ....................................................................................................................... 17
DPL............................................................................................................................................. 17
ESim........................................................................................................................................... 17
Fingerprint............................................................................................................................... 17
IPL............................................................................................................................................... 18

iv PC42E-T Desktop Printer User Guide
ZSim............................................................................................................................................18
How to Set the Printer Command Language....................................................................18
Set the Command Language with the Print Button................................................18
Set the Command Language from the Printer Web Page ....................................19
Set the Command Language from PrintSet 5 ...........................................................19
About Test Labels ........................................................................................................................19
Print a Test Label When You Turn on the Printer......................................................20
Print a Test Label When the Printer is Ready to Print.............................................20
Chapter 2 - Connect the Printer.................................................................. 21
Printer Drivers ...............................................................................................................................21
Install Honeywell Windows Driver ..................................................................................21
How to Connect the Printer to Your PC ...............................................................................22
Connect the Printer with a USB Cable ..........................................................................22
Connect the Printer with a USB-to-Serial Cable.......................................................22
Connect the Printer to Your Network ...................................................................................22
Connect the Printer to an Ethernet Network..............................................................22
Connect the Printer via Wi-Fi ...........................................................................................23
Configure Bluetooth Communication.................................................................................25
Configure Bluetooth Communication from the Web Page ..................................25
Configure Bluetooth Communication from PrintSet 5 ..........................................25
USB Host Port ...............................................................................................................................25
Connect a USB Device.........................................................................................................26
Configure the Printer..................................................................................................................26
Configure the Printer from the Printer Web Page ....................................................26
Configure the Printer with PrintSet 5 ..................................................................................27
Upgrade the Firmware ...............................................................................................................27
Download the Printer Firmware Update.......................................................................27
Upgrade Firmware from the Printer Web Page .........................................................28
Upgrade Firmware from PrintSet 5................................................................................28
Upgrade Firmware from a USB Storage Device ........................................................28

PC42E-T Desktop Printer User Guide v
Chapter 3 - Troubleshoot and Maintain the Printer ................................29
Locate the Printer Configuration and Serial Numbers.................................................29
Printer Problems and Possible Solutions...........................................................................29
How to Restore Default Settings............................................................................................30
Restore Default Settings with the Print Button................................................................30
Restore Default Settings from the Printer Web Page..............................................31
Restore Default Settings with PrintSet 5......................................................................31
Clean the Printhead ....................................................................................................................31
Replace the Printhead................................................................................................................32
Clean the Platen Roller ..............................................................................................................34
Clean the Interior of the Printer..............................................................................................36
Clean the Exterior of the Printer.............................................................................................36
Appendix A - Specifications ..........................................................................37
Specifications and Resources.................................................................................................37
Media Specifications ..................................................................................................................37
Print Sensors..................................................................................................................................38
Fonts..................................................................................................................................................38
Resident Fonts........................................................................................................................38
Downloadable Fonts.............................................................................................................39
Supported Font Types..........................................................................................................39
Printed Barcode Symbologies ..........................................................................................39
Graphic File Types.................................................................................................................41
Appendix B - Default Settings ......................................................................43
Default Configuration ................................................................................................................43
Ethernet Settings...................................................................................................................43
Media Settings........................................................................................................................44
Print Quality Settings...........................................................................................................47
General System Settings ....................................................................................................47
Manage I/O Settings............................................................................................................48
Manage Services Settings .................................................................................................49

vi PC42E-T Desktop Printer User Guide
DNS Network Services.........................................................................................................49
Net1 Network Services........................................................................................................50
Email Server ............................................................................................................................50
WINS Network Services.......................................................................................................51
Web Server Network Services...........................................................................................51
Connectivity Agent ...............................................................................................................51
XML Printing ...........................................................................................................................52
Device Management............................................................................................................52
Appendix C - Print Labels with INPrint...................................................... 53
The INPrint Page..........................................................................................................................53
Print INPrint Labels..............................................................................................................53
Appendix D - Installing Accessories ........................................................... 55
Cutter Module ...............................................................................................................................55
Out of the Box .........................................................................................................................55
Installation...............................................................................................................................55
Peel-Off Module...........................................................................................................................58
Out of the Box .........................................................................................................................58
Installation...............................................................................................................................58
Bluetooth Module and Bluetooth/Wi-Fi Module............................................................62
Out of the Box .........................................................................................................................62
Installation...............................................................................................................................62

CHAPTER
1
PC42E-T Desktop Printer User Guide 1
ABOUT THE PRINTER FEATURES
This chapter introduces the PC42E-T printer. It includes descriptions of the printer
features and basic operation.
About the Printer
The PC42E-T printer is a lightweight, reliable printer that is easy to use. It is
designed to print up to 1500 labels a day. Printer features include:
• 203 dpi (6 ips) or 300 dpi (5 ips) printing.
• USB host port for connecting storage devices, scanners, or keyboards.
• USB device port for connecting to a desktop PC.
• Honeywell PrintSet 5 support.
• Support for printer programming languages, including Datamax Printer
Language (DPL), Direct PDF Printing, Direct Protocol (DP), Eltron Simulation
(ESim), Fingerprint (FP), Intermec Printer Language (IPL), and Zebra Simulation
(ZSim).
• Optional Ethernet interface.

2 PC42E-T Desktop Printer User Guide
Printer Features
Use these illustrations to locate printer features.
Front
Rear
Status LED
Latch
Print Button
ECO Mode Button
Media Window
Tear Bar
External Media
Feed Slot
Ethernet Port
USB Host Port
USB Device Port
Power Port
Power Switch
Module Door

PC42E-T Desktop Printer User Guide 3
About the Print Button
Use the next table to understand the functions of the Print button.
About the ECO Button
Use the next table to understand the functions of the ECO button.
Press the ECO button to turn ECO mode on and off.
Print Button
Action Description
Press and hold the
Print button (while
the printer is starting
up)
The printer calibrates the media, prints a
configuration label, and then lets you select the
printer command language. Press the Print
button when the printer command language you
want to use prints out.
Press and hold the
Print button for two
seconds and then
release (when the
printer is idle)
The printer prints out several labels to calibrate
the media sensor (testfeed).
Press and hold the
Print button for six
seconds (when the
printer is idle)
The printer prints out several labels (testfeed) and
then prints the configuration label.
Press and release the
Print button
If the printer is idle, the printer advances media to
the beginning of the next label.
If the printer is printing, the printing pauses.
If the printer has been paused, printing resumes.
Press and hold the
Print button for three
seconds
If the printer is paused, the print job is canceled
and any print jobs inside the printer are
discarded. The printer returns to the idle state.
ECO Button
Action Description
Green (on) ECO mode is on. The fast media calibration
feature is active and the printer media calibration
process will use a minimal length of labels. Use
ECO mode to conserve media.
Blank (off) ECO mode is off. The slow media calibration
feature is active and the printer media calibration
process will use the length of multiple labels. Use
slow calibration if the printer has trouble
identifying gaps or marks in media.

4 PC42E-T Desktop Printer User Guide
About the Status LED
The status LED turns green, orange, or red to indicate the current status of the
printer. Use the next table to understand the states of the status LED.
About Media
The printer can print on labels, tags, and continuous (receipt and linered) media.
The printer supports both direct thermal and thermal transfer media. To use
thermal transfer media, you also need thermal transfer ribbon. The printer
supports media from 1 to 4.5 inches (25 to 114 mm) wide.
LED State Description
Off Power is turned off.
Green (solid) The printer is idle and waiting for the next print
job.
Green (blink from
start up)
The printer is experiencing a memory error. You
need to upgrade the firmware. For help, see
Upgrade the Firmware on page 27.
Green (blink) The printer is starting up.
Printing is paused. Press the Print button to
resume printing or press and hold the Print
button for three seconds to cancel the print job.
Green (fast blink) The printer is communicating.
The simulator (ZSim and ESim) is starting up.
Green (slow blink) In peel off mode, a printed label is available in the
output slot. The printer will not print another label
until the label in the output slot is removed.
Orange (solid) The printhead is too hot. Wait for the printhead to
cool down to an acceptable temperature before it
can resume printing.
Orange (blink) The printer is upgrading its firmware from an
inserted USB flash drive. Remove the USB flash
drive after the LED turns solid green.
Orange (slow blink) The print job includes a font that is not installed
or includes a location that is outside the available
print area.
Red (blink) The printer is in Error mode. The printer may be
out of ribbon, have ribbon installed when
configured for direct thermal, be out of media,
have the printhead lifted, have a label
obstructing the printing path, or you may not
have performed a testfeed (hold Print button
until several labels print).
After you have fixed the error, press the Print
button to restart printing.
Red and green
(alternating blink)
The printer is experiencing a hardware issue.
Return the printer to Honeywell for service. For
help, see Product Service and Repair on page iii.

PC42E-T Desktop Printer User Guide 5
Load Tear-Off Media
In tear-off printing mode, you manually tear off the media upward against the tear
bar.
1. Press in on the cover latches on both sides of the printer and open the cover.
Media Path
Caution: Open the cover completely to ensure that it does not close shut
while you are loading media.

6 PC42E-T Desktop Printer User Guide
2. Pull up the lock on the left media hub and slide the media hubs to
accommodate the width of the media roll.
3. Insert the media roll between the media hubs as shown.

PC42E-T Desktop Printer User Guide 7
4. Make sure the media hubs are snug against the sides of the media roll, and
then press the locking tab down to lock the media hubs in place.
5. Press in both locking buttons to open the print and ribbon mechanism.

8 PC42E-T Desktop Printer User Guide
6. Adjust the media sensor according to type of media: black mark, gap, or cloth
tag and other media. Slide the tab in the middle of the sensor to the location of
the media type.
5. Feed the media underneath the print and ribbon mechanism and to the front of
the printer.
6. Place the media between the media holders, and adjust the media holders to
the width of the media. Ensure the media lays flat.
Sensor tab
Cloth tag and
other media
Gap
Black mark

PC42E-T Desktop Printer User Guide 9
7. Ensure that the media extends beyond the cutter area in front of the printer.
Lower the print and ribbon mechanism and press down until both locking tabs
snap into place.
8. Close the cover.
9. Make sure you configure these printer settings:
• Thermal transfer or direct thermal printing
• Media type
• Media width and length
10. Press and hold the Print button to print a test label. For help, see About Test
Labels on page 19.

10 PC42E-T Desktop Printer User Guide
Load External Media
You can place the media supply, such as fanfold tickets or tags, behind the printer.
You need to purchase an external media holder separately.
Note: Protect the media from direct sunlight and from dust, dirt, or other foreign particles
that can impair the printout quality or cause unnecessary wear to the printhead.
1. Place the media behind the printer.
2. Feed the media into the printer through the external media feed slot.
3. Thread the media through the printer and adjust the media holders and sensor
as you would for media that loads inside the printer.
Load Ribbon
You must use thermal transfer ribbon to print on thermal transfer media. Make
sure to select ribbon that matches the face materials of the media to obtain the
best durability and print quality.
External Media
Feed Slot
Ribbon Path

PC42E-T Desktop Printer User Guide 11
Note: The printer can only use ribbon that is “ink out,” which means that the ribbon is loaded
with the inked side (dull side) facing out.
1. Press in on the cover latches on both sides of the printer and open the cover.
2. Adjust the ribbon core switches according to the diameter of the ribbon core:
• For 1/2 inch ribbon cores, the ribbon core switch must be in the outward
position. Hold the ribbon turnplate for the switch and use a Phillips
screwdriver to push in and turn the switch counter clockwise.
• For 1 inch ribbon cores (or if you are using the ribbon adapter), the ribbon
core switch must be in the inward position. Hold the ribbon turnplate for the
switch and use a Phillips screwdriver to push in and turn the switch
clockwise.
Caution: Open the cover completely to ensure that it does not close shut
while you are loading the ribbon.

12 PC42E-T Desktop Printer User Guide
3. Press in both locking buttons to open the print and ribbon mechanism.
Ribbon turnplate
Ribbon core switch
Button Inside
1.0”
Ribbon Core
0.5”
Ribbon Core
0.5” 1.0”
Button Outside
