Honeywell 2450Cm Series User manual

Mounting surface
Mounting template
Anchors
Camera assembly
Self-tapping screws
Dome cover
Locking screw
Allen Key
H4W2PER3 WDR 1080P IR Dome Camera
Quick Installation Guide
Thank you for purchasing a Honeywell Performance
Series IP camera. Follow the instructions in this guide to
install and log in to your camera. For instructions on
configuring the camera, refer to the user guide on the CD
that came with your camera. If you require additional
assistance, call the number listed for your region on the
back cover.
Warnings and Cautions
WARNING To ensure compliance with electrical safety standards, this product is
intended for use with a Listed Power Adapter marked “Limited Power Source” or “LPS” on
the unit, output rated to 12 VDC, minimum 0.33 A, TMA=60 deg C, or from Power over
Ethernet (PoE) provided by Listed Information Technology Equipment meeting IEEE
802.3af PoE standard.
CAUTION The Ethernet connection is not intended to be connected to exposed (outside
plant) networks. Do not connect two power sources to the camera at the same time.
CAUTION Invisible LED radiation (850 nm). Avoid exposure to beam.
Important Safeguards
• Read and keep these instructions
• Confirm the installation surface can support at least three times the weight of the camera.
• Do not apply power to the camera before completing installation.
• Do not aim the camera toward a bright light source for extended periods to prevent damage to
the imager.
• Avoid operating the unit under or close to unstable light sources (may cause flickering), or close
to fluorescent lamps or objects reflecting light.
• Do not touch the camera lens.
• Do not drop the camera or subject it to physical shock.
• Do not use a strong or abrasive detergent when cleaning the camera.
• Avoid operating or storing the unit in extremely humid, dusty, hot/cold environments, where the
operating temperature is outside the recommended range of -22°F to 140°F (-30°C to 60°C).
Before You Begin
Before you begin, check that you have received all the parts listed below. If any parts are
missing or damaged, contact your dealer immediately.
• Camera
• Installation CD
• Quick installation guide
• Allen key (L-wrench)
• Self-tapping screws (×4)
• Plastic anchors (×4)
• Mounting template
CAUTION Installation and servicing should be performed only by qualified and
experienced technicians to conform to all local codes and to maintain your warranty
CAUTION
THIS SYMBOL INDICATES THAT
DANGEROUS VOLTAGE
CONSTITUTING A RISK OF
ELECTRIC SHOCK IS PRESENT
WITHIN THE UNIT.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE THE COVER.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
THIS SYMBOL INDICATES THAT
IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS
ACCOMPANY THIS UNIT.
RISK OF ELECTRIC
SHOCK
DO NOT OPEN

© 2018 Honeywell International Inc. All rights reserved. No part of this publication may be reproduced by any means without written permission from Honeywell. The information in this publication is believed to be accurate in all respects. However, Honeywell
cannot assume responsibility for any consequences resulting from the use thereof. The information contained herein is subject to change without notice. Revisions or new additions to this publication may be issued to incorporate such changes.
Preparing the Mounting Surface
1. Apply the mounting template to the mounting surface.
2. Using the mounting template as a guide, drill three pilot holes in the mounting surface,
then hammer the supplied anchors into the holes.
3. Drill a cable entry hole in the mounting surface, then pull the required cables through the hole.
Mounting and Aiming the Camera
1. Remove the dome cover from the camera assembly using the supplied Allenkey.
2. If you are using a microSD card with the camera, install it before continuing. See below for
details.
1. Push and
slide metal
shell to unlock
position.
2. Open
metal shell.
3. Insert microSD
card.
4. Close metal
shell and slide to
lock position.
3. Connect the Ethernet cable to the RJ-45 port on thecamera.
4. If the other end of the Ethernet cable is not connected to a PoE (Power-over-Ethernet)
switchor NVR, connect the power connector of the camera to a 12 VDC power source.
5. Fix the camera assembly to the mounting surface using the supplied screws.
6. Aim the camera lens in the desired direction, then tighten the screws on the cameraassembly.
7. Reattach the dome cover.
Logging On to the Camera
If the camera is connected to the PoE port of a Honeywell Embedded NVR, it can be configured
using the NVR.
To log on remotely from a PC, install the Honeywell Config Tool from the software and
documentation CD, find the camera on the network, and then open the web browser with the
Honeywell Config Tool. The default user name is admin (case-sensitive) and the default password
is 1234.
Note
•Only Internet Explorer 11 (or later) is supported.
•IP address of the device is assigned automatically by DHCP server. If the DHCP
server is not available, the device will acquire 192.168.1.108 as the default IP
address.
Recommended Recorders
HEN*4
8/16/32/64-channel Focus 4K NVRs (H.264 and H.265)
HEN*3 4/8/16/32-channel Performance Series NVRs (H.264 and H.265)
HEN*2 4/8/16-channel Performance Series NVRs (H.264)
HRHT4* 4/8/16-channel 4 MP HQA/IP/CVBS Hybrid DVRs (H.264)
Regulatory Statements
FCC Compliance
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the interference at his
own expense.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
This Class A digital apparatus complies with Canadian ICES-003.
Manufacturer’s Declaration of Conformance
North America The equipment supplied with this guide conforms to UL 60950-1 and CSA C22.2 No. 60950-1.
Europe The manufacturer declares that the equipment supplied is compliant with the European Parliament
and Council Directive on the restriction of the use of certain hazardous substances in electrical and electronic
equipment (2011/65/EU), General Product Safety Directive (2001/95/EC), and the essential requirements of
the EMC directive (2014/30/EU), conforming to the requirements of standards EN 55032 for emissions, EN
50130-4 for immunity, and EN 62368-1 for electrical equipment safety.
CAUTION This is a Class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
WEEE (Waste Electrical and Electronic Equipment)
Correct disposal of this product (applicable in the European Union and other European countries with
separate collection systems). This product should be disposed of, at the end of its useful life, as per
applicable local laws, regulations, and procedures.
2700 Blankenbaker Pkwy, Suite 150
Louisville, KY, 40299, USA
www.honeywell.com/security
[phone]
(North America only)
Aston Fields Road, Whitehouse Industrial
Estate Runcorn, Cheshire, WA7 3DL, UK
www.honeywell.com/security/uk
[phone]
(Europe only)
Building #1, 555 Huanke Road, Zhang
Jiang Hi-Tech Park
Pudong New Area, Shanghai, 201203,
China www.asia.security.honeywell.com
[phone]
(Asia Pacific only)
Document 800-24597 – Rev A – 08/2018
