1/3" HIGH RESOLUTION FULLY FEATURED COLOUR CAMERA
HCC484TPX
The Honeywell Systems HCC484TPX 1/3"CCD high resolution colour camera is
the premier choice for any surveillance application. One of Honeywell Video
Systems Series high-end camera line, the sophisticated HCC484TPX delivers
superior low light performance to satisfy even the most stringent viewing
requirements. The HCC484TPX features a high resolution of 480 TV lines and
Digital Signal Processing (DSP) for clean, sharp images.
Adaptable to varying light levels, the HCC484TPX features a high sensitivity of
0.1 lux @ F1.2 and 0.001 lux with digital slow shutter for unprecedented
sensitivity in extremely low light conditions. Three user-selectable BLC windows
provide the flexibility to view high contrast scenes from almost any angle. The
camera features Black Mask BLC, which reduces bright glaring light from a scene
(for example, removes the glare from car headlights for license plate identification).
The HCC484TPX offers quick and easy setup via the On-screen Display (OSD)
menu or via RS-485 remote control. The camera can be installed using
conventional coax or unshielded twisted pair (UTP) with its built-in NVT
transceiver. UTP provides the ultimate in flexibility and offers a significant
advantage in labour and material savings. Installers can back focus the camera
quickly and easily using its convenient thumbwheel. The HCC484TPX mounts
using a 1/4"-20 UNC mounting shoe. Also, the camera has an auto sensing
12 VDC/24 VAC power supply feature for multiple camera connection.
Market Opportunities
The HCC484TPX is one of Honeywell Video Systems Series products that deliver
increased flexibility, superior performance, and advanced technologies for today's
most demanding applications, including parking garages, office buildings and
educational institutions. This full featured camera is ideal for use with Honeywell
Video Systems Series of Digital Video Recorders.
Features
• Ultra low light 0.001 lux with Digital
Slow Shutter
• Powerful back light compensation
through 3 modes BMB™
(Black Mask BLC) control
• OSD menu control/camera
title setting
• High resolution 480 TVL picture
quality through DSP
• Remote control through RS-485

Honeywell Security
Aston Fields Road
Whitehouse Industrial Estate
Runcorn
Cheshire WA7 3DL
Tel: [phone]
Fax: [phone]
www.honeywell.com/security/uk
SPECIFICATIONS
HVSHCC484TPX01EN0706DSXX
July 2006
©2006 Honeywell International Inc.
HCC484TPX
Operational
Video Standard PAL
Scanning System 625 lines (PAL)
Image Sensor 1/3" CCD, 470K pixels (PAL)
Number of Pixels
(H x V) 752 x 582 (PAL)
Minimum
Illumination
0.1 lux @ F1.2 (30 IRE)
0.001 lux @ F1.2 (128X DSS)
Horizontal
Resolution 480 TVL
Video Output 1.0 Vp-p @ 75 Ohms
Sync System Internal/Line lock
S/N Ratio More than 50 dB (AGC off)
Auto Gain Control Off/On switch (4 - 38 dB)
ALC Auto iris: Video drive/DC drive
Automatic
Electronic Shutter 1/50 – 1/15,000 sec (PAL)
White Balance ATW/AWC/Indoor/Outdoor/Fluorescent/
Manual/One Push WB
Line Lock Phase
Adjustment Adjustable AC line lock, ±90°
BLC On/Off (3 modes)
BMB™
(Black Mask BLC) On/Off (3 modes)
OSD Camera title setting/Menu control
Remote Control RS-485
Electrical
Input Voltage 24 VAC/12 VDC (Non polarised)
Input Tolerance 17 - 28 VAC, 10 - 16 VDC
Surge Suppression 1.5 kW transient
Power
Consumption 4 W (max)
Mechanical
Dimensions
(W x H x D)
2.68" x 2.2" x 4.72"
68 mm x 56 mm x 120 mm
Weight 0.84 lb (380 kg)
Construction Housing: Aluminium
Finish: Light grey
Camera Mount 1/4-20 UNC mounting shoe
Lens Mount C/CS adjustable top or bottom
thumbwheel
Connector Video Output: BNC, UTP Push terminal
Lens: 4-pin connector
Power Input Push terminal block
Ordering
HCC484TPX 1/3" High Resolution Colour Camera with DSP, BMB control, 480 TVL, 24 VAC/12 VDC, PAL
NOTE: Honeywell reserves the right, without notification, to make changes in product design or specifications.
Regulatory
Emissions FCC, CE (EN55013)
Immunity CE (EN50130-4)
Safety EU: 73/23/EEC LVD
Environmental
Temperature Operating: 14°F to 122°F (-10°C to 50°C)
Storage: -4°F to 158°F (-20°C to 70°C)
Relative
Humidity 0 to 90% non-condensing
Accessories
Lenses
HLD28V8F95L 2.8 - 8 mm, F0.95, DC Auto Iris
HLD5V50F13L 5.0 - 50 mm, F1.3, DC Auto Iris
Housings and Mounts
HHC12 Series Housings with optional heater/blower and
mounts
MC1600WT Camera wall mount
