Honeywell H4L6GR2 User manual

equIP® Series Cameras
ULTRA HD IP CAMERA
H4L6GR2/ HBL6GR2 /HM4L8GR1/HMBL8GR1
USER GUIDE

i
Revisions
Issue Date Revisions
A 07/2017 New document.

ii
Cautions and Warnings
CAUTION To ensure compliance with electrical safety standards, CSA
Certified/UL Listed LPS or Class 2 power adapters are required. Power over
Ethernet (PoE) shall be provided by listed information technologyequipment
meeting the IEEE 802.3af PoE standard. The PoE is not intended to be
connected to exposed (outside plant) networks.
CAUTION To comply with EN50130-4 requirements, a UPS should be
employed when powering on the camera from 24 V AC.
CAUTION Installation and servicing should be performed only by
qualified and experienced technicians to conform to all local codes and to
maintain your warranty.
CAUTION This is a Class A product. In a domestic environment this
product may cause radio interference in which case the user may be required
to take adequate measures. Note: Only for H4L6GR2, HM4L8GR1 and
HMBL8GR1.
Regulatory Statements
FCC Compliance Statement
Information to the User: This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
Note Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Canadian Compliance Statement
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la Classe A est conforme à la norme NMB-003 du Canada.

iii
Manufacturer’s Declaration of Conformity
North America
The equipment supplied with this guide conforms to UL 60950-1 and CSA C22.2 No.
60950-1-07.
Europe
The manufacturer declares that the equipment supplied is compliant with the European
Parliament and Council Directive on the Restrictions of the Use of Certain Hazardous
Substances in Electrical and Electronic Equipment (2011/65/EU), General Product Safety
Directive (2001/95/EC), and the essential requirements the EMC directive 2014/30/EU,
conforming to the requirements of standards EN 55032 for emissions, EN 50130-4 for
immunity, and EN 60950-1 for electrical equipment safety and EN 50581 for RoHS.
Waste Electrical and Electronic Equipment (WEEE)
Correct Disposal of this Product (applicable in the European Union and other
European countries with separate collection systems).
This product should be disposed of, at the end of its useful life, as per applicable
local laws, regulations, and procedures.
Safety Instructions
Before installing or operating the unit, read and follow all instructions. After
installation, retain the safety and operating instructions for future reference.
1. HEED WARNINGS - Adhere to all warnings on the unit and in the operating
instructions.
2. INSTALLATION
•Install in accordance with the manufacturer’s instructions.
•Installation and servicing should be performed only by qualified and experienced
technicians to conform to all local codes and to maintain your warranty.
•Do not install the unit in an extremely hot or humid location, or in a place subject to
dust or mechanical vibration. The unit is not designed to be waterproof. Exposure
to rain or water may damage the unit.
•Any wall or ceiling mounting of the product should follow the manufacturer’s
instructions and use a mounting kit approved or recommended by the
manufacturer.
3. POWER SOURCES - This product should be operated only from the type of power
source indicated on the marking label. If you are not sure of the type of power supplied
to your facility, consult your product dealer or local power company.
4. HEAT- Situate away from items that produce heat or are heat sources such as radiators,
heat registers, stoves, orotherproducts(includingamplifiers).
5. WATER AND MOISTURE - (Indoor models only) Do not use this unit near water or in an
unprotected outdoor installation, or any area classified as awet location.

iv
6. MOUNTING SYSTEM - Use only with a mounting system recommended by the
manufacturer, or sold with the product.
7. ATTACHMENTS - Do not use attachments not recommended by the product
manufacturer as they may result in the risk of fire, electric shock, or injury to persons.
8. ACCESSORIES- Only use accessories specified by the manufacturer.
9. CLEANING - Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
10. SERVICING - Do not attempt to service this unit yourself as opening or removing covers
may expose you to dangerous voltage or other hazards. Refer all servicing to qualified
service personnel.
11. REPLACEMENT PARTS - When replacement parts are required, be sure the service
technician has used replacement parts specified by the manufacturer or have the same
characteristics as the original part. Unauthorized substitutions may result infire, electric
shock or other hazards. Using replacement parts or accessories other than the original
manufacturersmayinvalidate the warranty.
12. DAMAGE REQUIRING SERVICE - Unplug the unit from the outlet and referservicing to
qualified servicepersonnelunder the followingconditions:
•When the power supply cord or plug is damaged.
•If liquid has been spilled, or objects have fallen into the unit.
•If the unit has beenexposed to rain or water.
•If the unit does not operate normally by following the operating instructions. Adjust
only those controls that are covered by the operating instructions as an improper
adjustment of other controls may result in damage and will often require extensive
work by a qualified technician to restore the unit to its normal operation.
•If the unit has been dropped or the enclosure has been damaged.
•When the unit exhibits a distinct change in performance - this indicates a need for
service.
13. SAFETY CHECK - Upon completion of any service or repairs to this unit, ask the service
technician to perform safety checks to determine that the unit is in proper operating
condition.
Warranty and Service
Subject to the terms and conditions listed on the Product warranty, during the warranty period
Honeywell will repair or replace, at its sole option, free of charge, any defective products
returned prepaid.
In the event you have a problem with any Honeywell product, please call Customer Service at
1.800.323.4576 for assistance or to request a Return Merchandise Authorization (RMA)
number. Be sure to have the model number, serial number, and the nature of the problem
available forthetechnicalservice representative.
Prior authorization must be obtained for all returns, exchanges, or credits. Items shipped to
Honeywellwithout a clearly identified Return Merchandise Authorization (RMA) number
may berefused.

v
List of Symbols
The following table contains a list of symbols that may appear on the camera:
The WEEE symbol.
This symbol indicates that when the end-user wishes to discard this product,
it must be sent to separate collection facilities for recovery and recycling. By
separating this product from other household-type waste, the volume of waste
sent to incinerators or landfills will be reduced, and thus natural resources will
be conserved.
The UL compliance logo.
This logo indicates that the product has been tested and is listed by UL
(formerly Underwriters Laboratories).
The FCC compliance logo.
This logo indicates that the product conforms to Federal Communications
Commission compliance standards.
The direct current symbol.
This symbol indicates that the power input/output for the product is direct
current.
The alternating current symbol.
This symbol indicates that the power input/output for the product is
alternating current.
The RCM compliance logo.
This logo indicates that the product conforms with Australian RCM guidelines.
The CE compliance logo.
This logo indicates that the product conforms to the relevant
guidelines/standards for the European Union harmonization legislation.
The caution symbol.
This symbol indicates important information.
The protective earth (ground) symbol.
This symbol indicates that the marked terminal is intended for connection to
the protective earth/grounding conductor.
Symbol Explanation

vi
Table of Contents
About This Document.......................................................................................................................................................................1
Overview of Contents ..................................................................................................................................................................................1
Related Documents .....................................................................................................................................................................................2
1. Accessing the Camera ...........................................................................................................................................................3
Installing the IPC Tool Utility...................................................................................................................................................................3
Discovering Your Camera on the Network .......................................................................................................................................3
Assigning a New IP Address to Your Camera..................................................................................................................................4
Upgrading the Camera’s Firmware ......................................................................................................................................................4
Accessing the Camera from a Web Browser....................................................................................................................................5
2. Logging In and Viewing Live Video...................................................................................................................................6
Logging In to the Web Client...................................................................................................................................................................6
Overview of the Live Interface.................................................................................................................................................................7
Configuring the Live Interface................................................................................................................................................................8
Working in the Live Interface...................................................................................................................................................................9
Setting Up Live Video Streaming .......................................................................................................................................................10
Setting the Stream Type .....................................................................................................................................................................10
Setting the Stream Protocol ..............................................................................................................................................................10
Logging Out of the Web Client............................................................................................................................................................10
3. Playing Back Recorded Video...........................................................................................................................................11
Overview of the Playback Interface ...................................................................................................................................................11
Playback Controls .................................................................................................................................................................................12
Video Clip Controls ...............................................................................................................................................................................12
Timeline ...................................................................................................................................................................................................13
Playing Back Recorded Video ..............................................................................................................................................................13
Downloading Recorded Video .............................................................................................................................................................14
Viewing Snapshots ....................................................................................................................................................................................15
4. Configuring Video and Audio Settings..........................................................................................................................16
Configuring Video Settings...................................................................................................................................................................16
Configuring Camera Settings ...........................................................................................................................................................16
Managing Profiles ................................................................................................................................................................................19
Configuring Streaming Settings ......................................................................................................................................................19
Configuring Snapshot Settings ........................................................................................................................................................21
Configuring Privacy Masks ................................................................................................................................................................22
Configuring the Channel Title ..........................................................................................................................................................23
Configuring the Time Title .................................................................................................................................................................23
Configuring Customized Text Overlays .........................................................................................................................................24
Configuring Picture Overlays ............................................................................................................................................................24
Configuring Regions of Interest .......................................................................................................................................................24
Configuring Zoom and Focus Settings ..........................................................................................................................................25
Configuring Audio Settings...................................................................................................................................................................26
5. Configuring Network Settings .........................................................................................................................................27
Configuring TCP/IP ..................................................................................................................................................................................28
IPv4 Address Configuration ..............................................................................................................................................................28
IPv6 Address Configuration ..............................................................................................................................................................29
ARP/Ping .................................................................................................................................................................................................29
Configuring Network Connections....................................................................................................................................................30
Configuring ONVIF....................................................................................................................................................................................31
Configuring PPPoE Settings................................................................................................................................................................31
Configuring DDNS Settings..................................................................................................................................................................32
Filtering IP/MAC Addresses..................................................................................................................................................................33
Adding IP/Mac Addresses to the List of Approved Users ........................................................................................................33
Editing IP/Mac Addresses .................................................................................................................................................................34
Deleting IP/Mac Addresses from the List of Approved Users ................................................................................................34
Configuring Email Settings...................................................................................................................................................................35

vii
Configuring UPnP Port Mapping.......................................................................................................................................................36
Configuring SNMP Settings.................................................................................................................................................................37
Configuring Bonjour.................................................................................................................................................................................37
Configuring Multicast Settings...........................................................................................................................................................38
Configuring 802.1X Settings ...............................................................................................................................................................38
Configuring QoS Settings......................................................................................................................................................................39
Working with Certificates.......................................................................................................................................................................39
6. Configuring Event Settings ..............................................................................................................................................41
Configuring Alarm Events......................................................................................................................................................................41
Configuring System Events ..................................................................................................................................................................43
Configuring SD Card Event Settings ..............................................................................................................................................43
Configuring Network Event Settings ..............................................................................................................................................43
Configuring Illegal Access Event Settings ....................................................................................................................................44
Configuring Motion Detection Events ............................................................................................................................................45
Configuring Camera Tampering Events.........................................................................................................................................47
Configuring Scene Change Events...................................................................................................................................................48
Configuring Audio Events......................................................................................................................................................................49
Accessing Extensional Smart Function..........................................................................................................................................50
Configuring Face Detection Events..................................................................................................................................................52
Configuring People Counting Events..............................................................................................................................................53
People Counting................................................................................................................................................................................53
Report .....................................................................................................................................................................................................53
7. Configuring Recording Settings .....................................................................................................................................55
Configuring Recording Schedules ....................................................................................................................................................55
Configuring Storage Settings ..............................................................................................................................................................56
Configuring Storage Paths ................................................................................................................................................................57
Configuring the Local SD Card for Storage ..................................................................................................................................57
Configuring an FTP Server for Storage ..........................................................................................................................................58
Configuring an NAS Disk for Storage .............................................................................................................................................58
8. Configuring System Settings ...........................................................................................................................................60
Configure Multi Sensor...........................................................................................................................................................................62
9. Technical Specifications....................................................................................................................................................73

About This Document
1
About This Document
This manual is intended for system installers, administrators, and users of Honeywell’s
equIP® Series 4K Ultra HD network cameras and contains instructions for accessing,
configuring, and operating the cameras.
Overview of Contents
This manual contains the following chapters and appendixes:
•Chapter 1, Accessing the Camera, describes how to access the camera remotely from a
web browser.
•Chapter 2, Logging In and Viewing Live Video, describes how to log in to the camera and
how to use the Live interface.
•Chapter 3, Playing Back Recorded Video, describes how to play back and export
recorded video andsnapshots.
•Chapter 4, Configuring Video and Audio Settings, describes how to set up video and
audio streams.
•Chapter 5, Configuring Network Settings, describes how to set up the camera on a
network. (For advanced usersonly.)
•Chapter 6, Configuring Event Settings, provides instructions for configuring alarm
inputs/outputs, motion detection, audio detection, tampering detection, and system
event settings.
•Chapter 7, Configuring Recording Settings, describes how to set up a recording
schedule and how to manage recording and storage settings.
•Chapter 8, Configuring System Settings, provides instructions for configuring language
and date and time options, managing user accounts and permissions, setting
maintenance tasks, upgrading firmware, and resetting a camera to its factory defaults.
•Chapter 9 Technical Specifications, lists camera specifications.
•Index, provides a searchable list of key terms used in the manual.

ULTRA HD IP Camera User Guide
2
Related Documents
For more information relating to equIP Series Ultra HD cameras, refer to the following
documents:
Document Title Part Number
equIP Series Network Security Guide 800-23224
equIP Series Outdoor Bullet Multi-Imager HMBL8GR1 Quick
Installation Guide
800-23101
equIP Series Outdoor Dome Multi-Imager HM4L8GR1 Quick
Installation Guide
800-23102
equIP Series Outdoor Bullet HBL6GR2 Quick Installation Guide 800-23103
equIP Series Outdoor Dome H4L6GR2 Quick Installation Guide 800-23104
You can find these and other documents on the product webpages:
•HMBL8GR1 http://www.honeywellvideo.com/products/video-systems/video-
redefined/equIP-family/1324366.html
•HM4L8GR1 http://www.honeywellvideo.com/products/video-systems/video-
redefined/equIP-family/1324368.html
•HBL6GR2 http://www.honeywellvideo.com/products/video-systems/video-
redefined/equIP-family/1324369.html
•H4L6GR2 http://www.honeywellvideo.com/products/video-systems/video-
redefined/equIP-family/1324370.html

Accessing the Camera
3
1. Accessing the Camera
This chapter contains the following sections:
•Installing the IPC Tool Utility, page 3
•Discovering Your Camera on the Network, page3
•Assigning a New IP Address to Your Camera, page 4
•Upgrading the Camera’s Firmware, page4
•Accessing the Camera from a Web Browser, page 5
Installing the IPC Tool Utility
To install the IPC Tool utility and create a desktop shortcut:
1. Insert the included Software and Document disc into your PC’s disc drive.
2. Install the IPC Tool utility to your PC. The shortcut is added to thedesktop.
Discovering Your Camera on the Network
To discover your network camera(s), open the IPC Tool utility , enter your user name and
password, and then click Connect. Cameras that are online have a green connected icon
next to them. Cameras that are offline have a gray X next to them. To refresh the list, click
Refresh.

Ultra HD IP Camera User Guide
4
Assigning a New IP Address to Your Camera
The current IP address of your camera appears in the IP column of the devices list. If you
want, you can assign a new static IP address to the camera.
To change the IP address of a single camera:
1. Select the camera that you want to configure from the devices list.
2. Click the Network tab.
3. Clear the DHCP check box.
4. Enter the new IP settings in the IP Address, Subnet Mask, and Default Gateway fields.
5. Click Apply to apply the settings.
To change the IP addresses of multiple cameras at the same time:
1. In the left-most pane of the IPC Tool utility, click Batch Setting.
2. Select all of the cameras that you want to configure from the devices list.
3. Click the Network tab.
4. Do one of the following:
•To assign dynamic IP addresses, select the Set all to DHCP check box, and then
click Apply.
•To assign static IP addresses, enter the settings in IP Range, Subnet Mask, and
Default Gateway fields, and then click Apply.
Upgrading the Camera’s Firmware
Before you begin using your camera, make sure you have the latest firmware installed. You
can upgrade a single camera or multiple cameras at the same time.
To upgrade a single camera:
1. Select the camera that you want to upgrade from the devices list.
2. Click the Upgrade tab.
3. Click Browse, navigate to the directory that contains the firmware file (.bin), select the
file, and then click Open. The firmware file appears in the Target File field.
4. Click Upgrade. When the upgrade is complete, the camera will reboot.
To upgrade multiple cameras at the same time:
1. In the left-most pane of the IPC Tool utility, click Batch Setting.
2. Select all of the cameras that you want to upgrade from the devices list.
3. Click the Upgrade tab.
4. Click Browse, navigate to the directory that contains the firmware file (.bin), select the
file, and then click Open. The firmware file appears in the Target File field.
5. Click Upgrade. When the upgrade is complete, the cameras will reboot.

Accessing the Camera
5
Accessing the Camera from a Web Browser
To access the camera from a web browser:
1. Select the camera that you want to access from the devices list. The camera must be
online .
2. On the Device Information tab, click Web Page. The web client opens in your default
browser.

Ultra HD IP Camera User Guide
6
2. Logging In and Viewing Live
Video
This chapter contains the following sections:
•Logging In to the Web Client, page6
•Overview of the Live Interface, page 7
•Configuring the Live Interface, page8
•Working in the Live Interface, page 9
•Logging Out of the Web Client, page10
Logging In to the Web Client
If this is your first time logging in to the web client, on the login page, enter the default user
name (admin) and password (1234), and then click Login.

Logging In and Viewing Live Video
7
For security purposes, we strongly recommend that you create a new secure password.
The password must be at least 8 characters long and contain at least one lowercase letter,
one number, and one special character. The password cannot be blank.
Overview of the Live Interface
Figure 2-1 shows the layout of the web client’s Live interface.
Figure 2-1 Live Interface

Ultra HD IP Camera User Guide
8
Configuring the Live Interface
Note The first time you log into the web client, follow the on-screen instructions to
download and install the web browser plug-in.
You can configure the Live interface using the configuration controls located in the lower left
corner of the screen, immediately below the video window (Figure 2-2).
Figure 2-2 Live Configuration Toolbar
Table 2-1 Live Configuration Controls
Adjustment
Opens the Image Adjustment panel.
Move the sliders to adjust the image
brightness, contrast, hue, or saturation.
Click the – and + signs to make fine
adjustments. To restore the settings to
their default values (64), click Reset.
Note These settings only apply to the
client end. To change the settings at the camera end, go to
Setup > Camera Setup > Conditions > Picture.
Original Size Displays the video at actual size (the exactdimensions are
determined by the stream resolution).
Full Screen Displays the video in full-screen mode. Double-click (or press Esc)
to exit full-screen mode.
Width:Height
Ratio
Displays the video in its original size (Original) or fitted to your
screen (Adaptive).
Fluency Sets the video fluency level (Realtime, Normal, or Fluency).
Select a fluency level based on the capabilities of your network.
For example, if your connection is slow, selecting Fluency will
prioritize smoothness over image quality.
Rules Info Tracks movement in the video window when intelligent video
surveillance (IVS) isenabled.
Zoom and Focus Note: Only for H4L6GR2 and HBL6GR2.
Opens the Zoom and Focus panel.
Move the sliders to adjust the zoom and
focus settings. Click the – and + signs to
make fine adjustments. The Step
number determines the magnitude of
the adjustment. To set the focus
automatically, click Auto Focus. To
restore the default zoom and focus
settings, click Restore All. To focus on a
specific region, click Regional Focus,
and then drag your mouse over the area
in the video window.

Logging In and Viewing Live Video
9
Working in the Live Interface
The toolbar in the upper left corner of the screen, immediately above the video window,
provides quick access to commonly used controls (Figure 2-3).
Figure 2-3 Quick Access Toolbar
Table 2-2 Quick Access Controls
Easy Focus Note: Only for H4L6GR2 and HBL6GR2.
Displays the current video definition (AF Peak) and target video
definition (AF Max). For auto focus to work, the AF Peak and AF
Max values must be close together. If the values are far apart,
the camera must be re-aimed or focused manually.
Record Click to start or stop recording video. The icon appears red when
video is being recorded, gray when video is not being recorded.
The recorded video is saved to the location specified in Setup >
Storage Setup > Destination > Path > Live Record.
Setup > Storage Setup > Destination > Path > Live Snapshot.
Destination > Path > Live Snapshot.
Digital Zoom When this function is enabled, you can drag your mouse over an
area of the video to enlarge that area. Right-click to return to the
previousmagnification.
Help
Displays online help for the Live interface.
Snapshot
Click to take a snapshot of the current video. The snapshot is
saved to the location specified in Setup > Storage Setup >
Audio
Click to enable or disable the audio input stream.
Talk
Click to enable or disable bidirectional talk (audio must also be
enabled).
Triple Snapshot Click to take three snapshots in quick succession(1 per
second). The snapshots are saved to the location specified in
Alarm Output
Click to generate or cancel an alarm output. The icon appears
red when the alarm is active, gray when the alarm is inactive.

Ultra HD IP Camera User Guide
10
Setting Up Live Video Streaming
In the upper right corner of the screen, immediately above the video window, you can set the
stream type and protocol for live video streaming.
Setting the Stream Type
To set the stream type, in the Stream Type list, select Main Stream, Sub Stream 1, or Sub
Stream 2.
Main Stream Delivers high definition video for real-time monitoring, recording, and storage.
Uses the most bandwidth.
Sub Stream 1 Delivers low/standard definition video, typically for remote monitoring in lower
network bandwidth environments.
Sub Stream 2 Delivers low, standard, or high definition video.
The properties for each stream type are configured on the Setup > Compression Setup >
Video page (see Configuring Streaming Settings on page 19).
Setting the Stream Protocol
To set the stream protocol, in the Protocol list, select TCP, UDP, or Multicast.
TCP Provides most reliable data transmission. Higher latency and bandwidth use
than UDP.
UDP Provides fastest data transmission. Lower latency and bandwidth use than
TCP but allows some data loss (such as droppedframes).
Multicast Provides the most efficient use of bandwidth if large numbers of clients are
viewing the videosimultaneously.
Logging Out of the Web Client
To log out of the web client, in the upper right corner of the screen, click Logout.
