Honeywell HCX13MW User manual

Honeywell’s HCX series of megapixel cameras offers world-class video and
leading-edge IP networking technologies. When object recognition is needed over
a vast field of view, one megapixel camera can often do the same job as several
standard analog cameras. Megapixel technology increases the effectiveness of
your security system by providing greater detailed images while saving on
installation and equipment costs.
The HCX13MW is a megapixel color network camera that offers up to 1.3 MP
(1280 X 1024) with frame rates up to 30 frames per second. It adapts to varying
lighting conditions to ensure the highest picture quality even in low-light conditions
down to 0.2 lux. User selectable exposure windows optimize video performance in
the areas of interest. More detailed viewing can be performed using the digital PTZ
control.
The HCX13MW network camera includes advanced bandwidth management tools
to optimize performance over any network. A built-in Web server provides
password protected access to video and network setup. Setup is quick and easy
and can be customized through a Web client or from an NVR multi-zone motion
detection to trigger motion-based video streaming and privacy zones for blocking
portions of the scene that are not to be recorded. An analog output facilitates
setup of zoom and focus of the lens using spot monitors and allows easy
integration with public view monitors. Choose between 12 VDC/24 VAC power
input or PoE 802.3 af for additional installation flexibility.
Market Opportunities
The HCX13MW provides optimum performance for both indoor and outdoor
applications requiring higher resolution over a larger field of view than is available
from a high resolution analog camera. Retail and banking industries greatly benefit
from using megapixel cameras. When properly positioned, both the full transaction
as well as a person’s identifying features can be zoomed in to analyze transactions
or identify fraud. Other applications include multi-lane driveways, wide lobbies,
gated entrances and loading docks.
Features
www.honeywellvideo.com
HCX13MW Camera
• 1280 X 1024, HD, XGA, SVGA, 4CIF,
VGA, 320 X 256 resolutions
• Excellent low light performance, down
to 0.2 lux.
• Up to 30 fps at 4CIF1
20 fps at HD
15 fps at 1.3 MP
• Includes 4.0 mm to 10 mm F1.8 lens
• Analog video output for setup of lens
• MJPEG compression
• Multi-zone motion detection
• User selectable exposure window
• Password protection prevents
unauthorized users from altering
system settings
• Web server for remote setup of
camera video and network parameters
• 12 VDC/24 VAC or PoE 802.3 af
choice of power inputs
1.3 MEGAPIXEL COLOR NETWORK CAMERA
1with image cropping

NOTE: Honeywell reserves the right, without notification, to make changes in product design or specifications.
L/HCX13MWD/D
September 2009
© 2009 Honeywell International Inc.
Honeywell Security & Data Collection
Honeywell
2700 Blankenbaker Pkwy, Suite 150
Louisville, KY 40299
1.800.796.CCTV (2288)
www.honeywell.com
HCX13MW Camera www.honeywellvideo.com
SPECIFICATIONS
Operational
Image Sensor 1/3" CMOS imager, progressive scan
Minimum
Illumination 0.2 lux color
S/N Ratio 50 dB or more (AGC off)
Auto Gain Control Peak detect, dark detect, clip average,
average
Automatic
Electronic Shutter 1/5–1/10,000 sec
Gamma 0.45
White Balance Automatic
Digital Slow
Shutter 1X – 4X
Analog Output NTSC/PAL (operational when Ethernet not
connected)
Analog Video
Output 1.0 Vp-p @ 75 Ohms
Motion Detection Multi-zone Include/Exclude
Exposure Window Include, variable size
Privacy Zones Multiple exclude zones
Electrical
Input Voltage 12 VDC/24 VAC, PoE 802.3af
Input Range 12-24 VDC, 22-26 VAC
Surge
Suppression 1.5 kW transient
Power
Consumption 2.5 W (max)
Mechanical
Dimensions See Diagram
Weight 0.4 lb (0.16 kg) camera only
Construction Housing: Aluminum
Finish: Gray Painted
Connector Video Output:RCA connector
Power Input: Removable screw terminal
block
Network: RJ45 connector
Environmental
Temperature Operating: 32°F to 104°F
(0°C to 40°C)
Storage: -4°F to 140°F
(-20°C to 60°C)
Relative Humidity 0% to 85%, non-condensing
Regulatory
Emissions FCC, CE (EN55022)
Immunity CE (EN55024)
Safety LVD 2006/95/EC
IP Specifications
Resolutions 1280 X 1024, HD, XGA, SVGA, 4CIF, VGA,
320 x 256
Frame Rate1Up to 15 fps @ 1.3 MP
20 fps @ HD
30 fps @ 4CIF
Video Streaming MJPEG controllable frame rate and
bandwidth. Constant and variable bit rate
Security Multiple user access levels with password
protection
Users 3 simultaneous unicast
Video Access
From Web
Browser
Camera live view for up to 3 clients. Full
control of all camera settings available to
administrator.
Minimum Web
Browsing
Requirements
Pentium IV CPU 3.0 GHz or equivalent AMD,
512 MB RAM, AGP graphics card (32 MB
RAM)
Windows XP, 2000, Internet Explorer 6.x or
later
Supported
Protocols IPv4, HTTP, TCP UDP, FTP, SMTP, ICMP DHCP, ARP, DNS
Environmental
Housings and Mounts
HBC5WT Wall/ceiling mount bracket
HHC12 Series Environmental housing
System Compatibility
The Megapixel Series is supported by a comprehensive line of
video management systems and accessories. Visit the
Megapixel Series product pages on www.honeywellvideo.com
for up-to-date information on system compatibility.
Ordering
HCX13MW 1/3" CMOS 1.3 MegaPixel Color Network Camera, 12 VDC/24 VAC or PoE 802.3 af, 4.0 mm to
10 mm VFMI F1.8 lens included
2.91”
73.9 mm
1.65”
41.8 mm
1.74”
44.1 mm
.89”
22.5 mm
2.91”
73.9 mm
3.47”
88.1 mm
25.4°
1.43”
36.5 mm
1.89”
48.0 mm
