equIP® SERIES SD INDOOR AND OUTDOOR PTZ
NETWORK CAMERAS WITH WIDE DYNAMIC RANGE
HDZ SERIES – STANDARD DEFINITION IP PTZ DOMES
Honeywell’s HDZ PTZ series are True Day/Night, wide dynamic network cameras.
They provide extremely crisp video that provide up to 570k effective pixels and up to
36x zoom for continuous surveillance in outdoor and indoor applications.
HDZ provides consistently high coverage to capture video images of interest. Its
360° continuous rotation function and zoom lens (30x indoor, 36x outdoor) with up
to 550 TVL (PAL) gives you the flexibility to view a target area with desired width and
depth. Electronic image stabilisation is also available for improved image quality in
unstable mounting conditions. Both HDZ indoor model has support for Power over
Ethernet (PoE+/PoE++) and installing either model is simple, saving you time on
site or allowing more domes to be commissioned per day. For critical infrastructure
requirements and in the event of a network failure, the, HDZ will continue to record
captured video to the Micro SDHC (if fitted) providing an additional level of security
for the user.
HDZ is also equipped with Wide Dynamic Range (WDR), which is ideal for
environments with high contrast and changing light conditions.
The camera in the outdoor version is housed by an IP66 rated tamper-resistant
dome to prevent the camera from damage by ingress of dust and heavy rain.
HDZ supports quad video streams and adopts multiple compression formats
(H.264 / MJPEG) with rates up to 60 frames per second (50 fps for PAL systems).
The digital compression parameters for the two video streams are independently
configurable.
Market Opportunities
The combination of the latest digital technology and advanced video processing
makes HDZ ideally suited for large-scale surveillance in cities, roads, airports,
government facilities, schools and campuses, industrial environments and anywhere
detailed surveillance is essential.
Features
• 36x (outdoor) 30x (indoor) optical
zoom and 12x digital zoom
• On board - camera storage – Micro
SDHC card support (up to 32GB)
• 60 fps (50 fps PAL) interlace scan
• Wide Dynamic Range
• ONVIF Profile S compatible
• Supports both dynamic and static
IP addresses
• Wide range of mounting options
available (1.5” NPT)
• Supports Electronic Image
Stabiliser (EIS)
• 550 TVL Horizontal resolution
• High preset speed up to 400°/sec
• Selectable compression formats
• Choice of 24 VAC/PoE power inputs
- Indoor: 24 VAC/PoE+ power inputs
- Outdoor: 24 V AC / PoE++
power inputs
• Vandal Proof Acrylic (Using IK10
Acrylic accessory satisfies IK10
Impact standard for HDZ unit)
SD

SYSTEM DIAGRAM AND DIMENSIONS
System Diagram
Monitor
Monitor
Monitor
Hybrid DVR
NVR
NETWORK
Keyboard
HDZ
tAnalogue ou
Dimensions
HDZ SERIES – STANDARD DEFINITION IP PTZ DOMES
Outdoor Pendant
Using In-Ceiling Bracket
Indoor Pendant
mm
mm
mm
mm
mm
123,00 mm
136,00 mm
155,89 mm
231,46 mm
190,00 mm
Ø254,00
123,00 mm
136,00 mm
155,89 mm
231,46 mm
190,00 mm
Ø254,00
Ø193.96 Ø192.00

SPECIFICATIONS
HDZ Indoor HDZ Outdoor
Camera
Scanning System NTSC/PAL
Image Sensor 1/4" Sony CCD
Optical Zoom 30x 36x
Digital Zoom 12x
Effective
Pixels
NTSC 480K
PAL 570K
Horizontal Resolution 550 TVL
Wide Dynamic Range On/Off
S/N Ratio > 50 dB (AGC Off)
Minimum Illumination
0.08 lux (Colour), 0.005 lux (B/W) @ F1.6
30IRE. Max. Aperture Ratio: F1.6 (Wide),
F4.5 (Tele)
Focal Length 3.4 to 102 mm 3.4 to 122.4 mm
Focus Mode Manual/Auto (Continuous/PTZ trigger/
Zoom Trigger Focus
White Balance Auto/Indoor/Outdoor/ATW/Manual
Iris Control Auto/Manual
Electronic Shutter 1/1~1/10k sec.
AGC Control Auto/Manual
Back Light Compensation On/Off
Operational
Multi-Language GUI
English, French, German, Italian, Russian,
Spanish, Portuguese, Dutch, Czech, Polish,
Tranditional Chinese, Simple Chinesse and
Japanese
Pan Travel 360° endless
Tilt Travel -10° to 190°
Manual Speed Manual pan Speed 0.5° to 200°/s
Manual tilt Speed 0.5° to 84°/s
Presets 256
Preset Accuracy 0.225°
Maximum Preset Speed Up to 400°/s
Preset Tours 8
Auto Pan 4
Mimic Tours 8
Privacy Mask 16
Proportional Pan and Tilt On/Off (Pan and tilt speed proportional to
zoom ratio)
Auto Resume After
Power Failure Yes
Home Function Preset, Preset tour, Auto pan, Mimic tour
Auto Flip*Mechanical/Digital/Off
Digital Slow Shutter On/Off
Motion Detection On/Off
Wide Dynamic Range On/Off
Day/Night: IR Cut Filter On/Off
Image Freeze On/Off
Image Rotation Flip/
Mirror/Inverse/Portrait On/Off
Noise Reduction 2D On/Off
3D On/Off
Electronic Image
Stabiliser On/Off
HDZ Indoor HDZ Outdoor
Electrical
Power Source 24 VAC ± 10% and
PoE+ , 21W
24 VAC ± 10%and
PoE++, 57W
Power Consumption 20 W 57 W (with heater)
Mechanical
Dimensions ø192 x 275.07mm ø193.96 x 270.49mm
(with sunshield)
Weight 2.2 kg (3.1 kg with
in-ceiling bracket)
2.6 kg
(with sunshield)
Environmental
Operating Temperature* 0°C to 40°C -40°C to 50°C*
Relative Humidity 10% to 90%, non-condensing
Waterproof Standard IP66 standard (HDZ Outdoor)
Impact Rating IK10 - when using HDZIK10AC
IP Specifications
Video Compression H.264 (High Profile, Main Profile, Baseline
Profile) /MJPEG.
Video Streaming Quad streaming
Video Resolution D1: NTSC 720x480/PAL 720x576
CIF: NTSC 352x240/PAL 352x288
Frame Rate Up to 60/50 fps @ D1 resolution
Audio Compression G.711/G.726 ADPCM/AAC
Audio Stream Full-duplex, Simplex
Interface RJ-45, 10/100 Mbps Ethernet
Supported Protocols**
IPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP,
HTTPS, ICMP, FTP, SMTP, DHCP, PPPoE,
UPnP, IGMP, SNMP, IEEE 802.1x, QoS,
ONVIF
Simultaneous Users 5 at D1 (720x576 (PAL), 720x480 (NTSC))
Security User account and password protection
HTTPS, IP Filter, IEEE 802.1x
Alarm Inputs x4
Outputs x2
Alarm Reaction Preset, Preset tour, Auto pan, Mimic tour
Event Notification HTTP, FTP, SMTP
Micro SD Support for Micro SDHC up to 32GB
Micro SD Function
Event trigger recording
Continuous and scheduled recording
Automatic recording when network fails
Supported Web Browsers Internet Explorer (8.0+)
Supported OS Windows 7 32bit/64bit
Communication ONVIF Profile S Support
Regulatory
EMC
Emissions North America: FCC part 15B, ICES-003
EU: EN55022
Immunity EN50130-4
Safety
North America: UL/CSA 60950-1,
UL/CSA 60950-22 (outdoor models)
EU: EN60950-1, EN60950-22
(outdoor models)
RoHS EN50581
HDZ SERIES – STANDARD DEFINITION IP PTZ DOMES
Notes:
*Protecting the dome from direct sunlight in high temperature environments is advised
**Some development may be required in specific user cases to support some of these
protocols in the field as naturally the protocols will mature over time.

ACCESSORIES, SYSTEM COMPATIBILITY AND ORDERING
Accessories
HDVWM1 Indoor Only Wall Mount HDXPMA2 Pole Mount Adapter for HDXWM2
HDXWM2 Indoor and Outdoor Wall Mount HDXCMA1 Corner Mount Adapter for HDXWM2
HDXSM1 Half Swan Neck Pole Mount HDZVRSMKAC Smoked Polycarbonate Vandal
Proof Acrylic for HDZ Series
HDPRM2 Parapet and Roof Mount HDZINBKT In-Ceiling Bracket for HDZ Series
HDCM1 Ceiling mount for Indoor Pendant
(Not for outdoor use) HDZIK10AC Clear IK10 VP Acrylic for HDZ
517082-7130 In-Ceiling PTZ Support Plate
System Compatibility
(Note: For latest system compatibility information, visit www.honeywell.com/security/uk)
Open IP Integration
ONVIF support for interoperability between Honeywell and other manufacturer’s IP-enabled security devices.
Honeywell Device Integration
Hybrid DVR
Fusion Full featured hybrid Digital Video Recorder, version 3.6 or higher
NVRs
Fusion NVR 8, 16 and 32 Channel Network Video Recorders
MAXPRO®NVR Family Entry to Enterprise Level Network Video Recorders
HUS Honeywell Universal Surveillance (HUS) Integration Platform
Ordering
HDZ30X Network True Day/Night Standard Definition PTZ Dome, Indoor Pendant, Clear, 30X, H.264, PAL
HDZ36EX Network True Day/Night Standard Definition PTZ Dome, Outdoor Pendant, Clear, 36X, H.264, PAL
HDZ30 Network True Day/Night Standard Definition PTZ Dome, Indoor Pendant, Clear, 30X, H.264, NTSC
HDZ36E Network True Day/Night Standard Definition PTZ Dome, Outdoor Pendant, Clear, 36X,
H.264, NTSC
HVS-HDZSD-04-UK(0414)DS-E
April 2014
© 2014 Honeywell International Inc.
Note: ‘ONVIF’ and are trademarks of ONVIF Inc.
