Honeywell IS312B User manual

ES SEFR NL IT RU UK
IS312
B
Passive Infrared Motion Sensor
with Swivel
Bracket
-
Quick Installation Guide
1
IS312QIG-001-V0
[EN]
≤80 lbs / 36 kg
2.1 - 2.7 m
(6' 9" - 8' 9")
2.3m
(7' 6")
[E ] = installation agréé / instalación homologado / godkänd installation / goedgekeurde installatie / installazione
corretta / xopoшee MECTO / approved installation
2
312B-QIG-011-V0
3
[A]
312B-010-V0
#6 x 1"
(3.5 mm x 25 mm)
[B]
312B-012-V0
4
IS312QIG-002-V0
[EN]
* Non inclus / * No Incluido / * Ingår ej / * Niet inbegrepen / * Non Incluso / * Не входит в комплект / * Not included
5
IS312QIG-003-V0
6
IS312QIG-004-V0
2
1
7
IS312B-QIG-014-V0
0.2-0.52mm
(24-20 AWG)
8
9
IS312QIG-015-V0
CNC V+V-T1T2
ON
OFF
ON
OFF
LED
Immunité aux petits animaux
Inmunidad para mascotas
Husdjursimmunitet
Immuniteit voor huisdieren
Immunità agli animali domestici
Игнорирование животных
Pet Immunity
90 mA, 18 VDC
*Réglage usine / *valores de fábrica / *Fabriksinställning / * Fabrieksinstellingen /
* Programmazione di fabbrica / *Заводские настройки / *Factory Default
*Enabled
Disabled
*LED Enabled
LED Disabled
1
2
3
4
5
6
IS312B-QIG-008-V0
100 mA, 30 VDC
T2 NC V-V+ T1 C
Ground +12V
Zone
#
Zone
COM
Zone
#
Zone
COM
Panel
Sensor
PI =
9 mA typ.,11 mA max., 9-15 VDC

7
PLAN VIEW
ALL ZONES
A B C D
2.3m
(7.5ft)
0m
(0ft)
4m
(13ft)
0m
(0ft)
2m
(7ft)
4m
(13ft)
6m
(20ft)
8m
(27ft)
10m
(33ft)
12m
(40ft)
2m
(7ft)
0ft
(0m)
2m
(7ft)
4m
(13ft)
6m
(20ft)
6m
(20ft)
8m
(27ft)
10m
(33ft)
8m
(27ft)
10m
(33ft)
Vue de dessus
Vista Desde Arriba
Sett ovanifrån
Bovenaanzicht
Vista in pianta
Вид сверху
Top View
Vue de coté
Vista Lateral
Sett från sidan
Zijaanzicht
Vista in sezione
Вид сбоку
Side View
Approval Listings:
EN50131-2-2:2008, Security Grade 2, Environmental Class II.
Suitable for connection to an EN 60950 Class II Limited
Power Source.
Note: In EN 50131-2-2 compliant installations, mount the sensor at 2.3m, and
lock the sensor housing with the cover screw (see “[EN]” where noted in Steps
1, 4 and 12).
IMPORTANT : Le détecteur doit être testé au moins une fois par an.
Importante: El sensor debe comprobarse al menos una vez al año.
Viktigt! Detektorn ska testas minst en gång per år.
Belangrijk: De sensor dient minstens één keer per jaar getest te worden.
Importante È necessario sottoporre il sensore a test almeno una volta l’anno.
Важное замечание:Датчик следует проверять минимум раз вгод ежегодно.
IMPORTANT: The sensor should be tested at least once each year.
INCERT B-893-0016
PD6662:2010
NF&A2P 2 boucliers (référentiel NF324-H58)
et conforme aux normes EN50131-2-2 et
RTC50131-2-2 ; IP30 IK04
N°de certificat: 2821420019
Organisme de certification:
CNPP Cert. : www.cnpp.com et
AFNOR Cert.: www.marque-nf.com
Honeywell Security Group - BP1219
1198 avenue du docteur Maurice Donat
Sophia Antipolis
06254 Mougins Cedex
TEL: [phone]
FAX: [phone]
Pour toutes informations supplémentaires, se référer svp à notre site Web :
Para cualquier información adicional, por favor visite nuestra Website:
Mer information finns på vår webbplats:
Voor verdere informatie, bezoek aub onze website op:
Per ogni ulteriore informazione, si prega di fare riferimento al nostro sito Web:
Дополнительную информацию см. на нашем веб-сайте:
For any additional information, please refer to our Website:
http://www.honeywell.com/security/uk/hscdownload/
O u contacter : / o contacte con: / Eller kontakta: / of neem
contact op met: / o contattare: / Или обратитесь / or contact:
Honeywell Security Group
Newhouse Industrial Estate
Motherwell
Lanarkshire ML1 5SB
United Kingdom
To protect the environment, a detailed installation
guide is available on the Honeywell website – Please
consider before printing the document!
Power: 9.0 - 15 VDC; 9 mA typical, 11 mA maximum.
Contacter un revendeur Honeywell autorisé pour obtenir des informations sur la garantie de ce produit
Por favor contacte con su distribuidor Honeywell Security para información sobre la garantía del producto
Kontakta den lokala auktoriserade representanten för Honeywell för produktgarantiinformation
Voor informatie over de productgarantie kunt u het beste contact opnemen met de lokale Honeywell vertegenwoordiging
Contatti il suo rappresentante Honeywell per ulteriori informazioni su prodotti e garanzia
Чтобы получить информацию о гарантии на продукцию, обратитесь к местному авторизованному представителю Honeywell
Please contact your local authorized Honeywell representative for product warranty information
 2014 Honeywell International Inc
Honeywell is a registered trademark of
Honeywell International Inc All other
trademarks are the properties of their
respective owners All rights reserved
800-18734-04 Rev. D
