ADEMCO VISTA-48LA
Security System
Programming Guide
K0749-6ENPR 5/05 Rev. A

– 2–
FIRST STEP: SELECT THE LANGUAGE
When programming the system, you should first select the appropriate language by doing the following:
1. Enter Programming mode.
2. Press [∗] + 28 (Language Select data field).
3. Press the number corresponding to the desired language: 0 = English, 1 = Spanish, 2 = Portuguese
4. Continue programming the system as desired.
TO START PROGRAM MODE, use method A or B (must use alpha keypad connected to keypad terminals):
A. POWER UP, then press both [✱] and [#] at same time within 50 seconds of powering up.
(if
✱98 was used to exit Program mode, this is the only method that can be used to start Program mode again)
B. Initially, key: Installer Code (4 + 1 + 1 + 2) plus 8 + 0 + 0.
Data Field Programming Procedures
Task Procedure
Go to a Data Field Press [∗] + [Field Number], followed by the required entry.
Entering Data When the desired field number appears, simply make the required entry. When the last entry for a field
is entered, the keypad beeps three times and automatically displays the next data field in sequence.
If the number of digits that you need to enter in a data field is less than the maximum digits available
(for example, the phone number fields *41, *42), enter the desired data, then press [∗] to end the entry.
Review a Data Field Press [#] + [Field Number].
Data will be displayed for that field number. No changes will be accepted in this mode.
Deleting an Entry Press [∗] + [Field Number] + [∗]. (Applies only to fields ∗40–*43, *45, *94, and pager programming
fields)
Menu Mode Programming (∗
∗∗
∗56, 57, ∗
∗∗
∗58, ∗
∗∗
∗79, ∗
∗∗
∗80, ∗
∗∗
∗81, ∗
∗∗
∗82, ∗
∗∗
∗83)
Press [✱] + [Interactive Mode No.] (for example, ✱56). The alpha keypad displays the first of a series of prompts.
Interactive Mode Used to Program
✱56 Zone Programming Zone characteristics, report codes, alpha descriptors, and serial numbers for 5800 RF
transmitters.
✱57 Function Key Programming Unlabeled keypad keys (known as ABCD keys) for special functions
✱58 Zone Programming Same options as *56 mode, but with fewer prompts. Intended for those familiar with
(Expert mode) this type of programming, otherwise *56 mode is recommended.
✱79 Output Device Mapping Assign module addresses and map individual relays/powerline carrier devices
✱80 Output Programming 4229 or 4204 Relay modules, 6164 output relay, Powerline Carrier devices, or on-
board triggers
✱81 Zone List Programming Zone Lists for relay/powerline carrier activation, chime zones, pager zones, etc.
✱82 Alpha Programming Zone alpha descriptors
✱83 Configurable Zone type Prog Attributes for configurable zone types
INITIALIZE DOWNLOAD and RESET DEFAULTS
✱96 Initializes download ID and subscriber account number.
✱97 Sets all data fields to original factory default values.
The control has two unique sets (tables) of default entries.
Press ∗97 while in Program Mode, then press 1 or 2 to load the desired set of factory defaults. This resets all data
fields to the respective default table values. Default values are listed next to the data field entry boxes on the
Program Form with unique table 1 and table 2 values indicated where applicable (DT1 = default table 1; DT2 =
default table 2).
User Code Defaults: To reset only the user codes to default values, press ∗97, then press 3.
TO EXIT PROGRAMMING MODE:
✱98 Exits programming mode and
prevents re-entry by: Installer Code + 8 + 0 + 0. If ✱98 is used to exit programming
mode, system must be powered down, and method 1 above used to enter the programming mode.
✱99 Exits programming mode and
allows re-entry by: Installer Code + 8 + 0 + 0 or method 1 above.
Special Messages
OC = OPEN CIRCUIT (no communication between keypad and Control).
EE or ENTRY ERROR = ERROR (invalid field number entered; re-enter valid field number).
After powering up, AC, dI (disabled) or Busy Standby and NOT READY will be displayed after approximately 4 seconds.
This will revert to a “Ready”message in approximately 1 minute, which allows PIRS, etc. to stabilize. You can bypass this
delay by pressing [#] + [0].
If E4 or E8 appears, more zones than the expansion units can handle have been programmed. Correct the programming
and then completely de-power and re-power the control to clear this indication and remove the disable indication.

– 3–
PROGRAMMING FORM
Entry of a number other than one specified will give unpredictable results. Default values are shown in brackets, with unique table 1 and
table 2 values indicated where applicable (fields *28 and *35; DT1 = default table 1; DT2 = default table 2).
∗20 Installer Code [4112] | | |
0–9 = 4 digit installer code
∗21 Quick Arm Enable [1,1,1]
0 = no quick arm; 1 = allow quick arm Part. 1 Part. 2 Part. 3
∗22 RF Options [0,0]
Entry 1 - 0 = no RF Jam detection; 1 = detect RF Jam
Entry 2 –supervision interval; 0 = 12 hour (must use “0”when used in
Latin America); 1 = 2 hour; 2 = 20 min if disarmed/2 hrs if armed;
3 = 12 hrs for burg zones/3 hrs for fire zones
∗
∗∗
∗23 Quick (Forced) Bypass [1,1,1]
0 = no quick bypass Part. 1 Part. 2 Part. 3
1 = allow quick bypass (code + [6] + [#])
∗
∗∗
∗24 RF House ID Code [00,00,00] | | |
00 = disable all wireless keypad usage Part. 1 Part. 2 Part. 3
01–31 = house ID for 5827, 5827BD keypad or 5804BD/5804BDV
keyfob (does not apply to 5839/5839EU/5839H)
∗
∗∗
∗25 Arming Prevention Override [0,0]
If no override is selected, system will not arm when there is either a
supervision failure, system low battery, AC loss, or a tamper.
Entry 1 0 = no arming prevention override
1 = allow system to arm with an RF Trouble failure (RF supv,
RF low bat, or RF jam)
2 = allow system to be armed with an AC Mains Loss
4 = allow system to be armed with a system low battery
E.g., To select “RF Trouble Fail”and “system low batt”, enter 5 (1 + 4);
Entry 2 0 = no tamper override (see field *175 for more tamper options)
1 = allow system to be armed with a tamper fault
2 = allow system to be armed with a tamper fault once
NOTE: If tamper option 1 or 2 is selected, field *175 digit 2 must be “0.”
∗
∗∗
∗26 Chime By Zone [0]
0 = no; 1 = yes, select chime zones on zone list 3, using *81 Menu mode
∗
∗∗
∗27 Powerline Carrier (X–10) House Code [0]
0 = A; 1 = B, 2 = C, 3 = D, 4 = E, 5 = F, 6 = G, 7 = H, 8 = I, 9 = J,
#10 = K, #11 = L, #12 = M, #13 = N, #14 = O, #15 = P
∗
∗∗
∗28 Language Select [DT1:1; DT2: 2]
0 = English, 1 = Spanish, 2 = Portuguese
∗
∗∗
∗29 ECP Contact ID Output for ACM [0]
0 = no; 1 = use Contact ID output on ECP terms. (e.g. TCP-IP Ethernet
or cellular radio)
∗
∗∗
∗30 Make Partition 3 a Common Area Part. [0]
0 = no (must be 0 if system uses zone type 82 - Blockschloss)
1 = yes, make partition 3 a common area partition
∗
∗∗
∗31 Single Alarm Sounding Per Zone [0]
0 = no
1 = yes, only one alarm sounding per armed period per zone
∗
∗∗
∗32 Fire Alarm Sounder Timeout [0]
0 = sounder stops at timeout
1 = no sounder timeout
∗
∗∗
∗33 Bell (Siren) Timeout [2]
0=none; 1 =1 min; 2 =2 min; 3 =3 min; 4 =4 min; 5 =8 min; 6 =16 min
∗
∗∗
∗34 Exit Delay [60, 60, 60]
00 to 96 = 00 to 96 seconds respectively Part 1 Part 2 Part 3
97 = 120 seconds
∗
∗∗
∗35 Entry Delay #1 (zone type 01)
[30, 30, 30] Part 1 Part 2 Part 3
00 to 96 = 00 to 96 seconds respectively
97 will = 120 seconds; 98 will = 180 seconds; 99 will = 240 seconds
∗
∗∗
∗36 Entry Delay #2 (zone type 02)[30, 30, 30]
See *35 for entries. Part 1 Part 2 Part 3
∗
∗∗
∗37 Audible Exit Warning [0, 0, 0]
0 = no; 1 = yes Part. 1 Part. 2 Part. 3
∗
∗∗
∗38 Confirm. Arming Ding | | |
First entry for each partition selects Part. 1 Part. 2 Part. 3
whether arming from wired keypads causes bell ding: [00, 00, 00]
0 = no; 1 = yes, 1-second ding
Second entry for each partition selects whether arming from remote
RF devices causes bell ding and/or activates trigger 2 output; also selects
bell ding/trigger activation duration (arm = 2 dings of selected duration
with 1 second off between; disarm = 1 ding of selected duration).
Enter 0-15 from table.
Entry Ding at Siren Trigger 2 Output
0 none none NOTE:
1 none 250mS If using trigger 2
2 none 1 second output for arming
3 none 4 seconds ding, do not assign
4 250mS none any other functions
5 250mS 250mS to trigger 2.
6 250mS 1 second
7 250mS 4 seconds
8 1 second none
9 1 second 250mS
#+10 1 second 1 second
#+11 1 second 4 seconds
#+12 4 seconds none
#+13 4 seconds 250mS
#+14 4 seconds 1 second
#+15 4 seconds 4 seconds
∗
∗∗
∗39 Power-Up In Previous State [1]
0 = always power-up disarmed; 1 = yes
For dialer fields ∗40 –∗42, enter the number of digits shown. Do not fill
unused spaces. Enter 0–9; #+11 for '∗'; #+12 for '#'; #+13 for a 2-second
pause. If fewer than the maximum digits entered, exit the field by pressing [✶].
The next data field is displayed.
∗
∗∗
∗40 PABX Access Code | | | | |
Enter up to 6 digits. If fewer than 6 digits are entered, exit by pressing
[✶]. To clear entries from field, press ∗40∗
∗
∗∗
∗41 Primary Phone No.
| | | | | | | | | | | | | | | | | | | | | | | | | | | | |
∗
∗∗
∗42 Second Phone No.
| | | | | | | | | | | | | | | | | | | | | | | | | | | | |
Enter up to 30 digits for each phone number. To clear entries, press
∗41∗or ∗42∗respectively.
For fields *43, *44 , *45, *46, *51 and *52, enter 4, 6 (Robofon 8), or 10
digits, depending on selection in *48 Report Format. Enter 0–9; #+11 for B;
#+12 for C; #+13 for D; #+14 for E; #+15 for F. To clear entries from field,
press *43*, *44*, *45*, *46*, *51* or*52* respectively. Examples: For Acct.
1234, enter 1 | 2 | 3 | 4 ; For Acct. B234, enter #+11| 2 | 3 | 4

– 4–
∗
∗∗
∗43 Primary Subscriber ID # (Part.1)
| | | | | | | | |
∗
∗∗
∗44 Secondary Subscriber ID # (Part.1)
| | | | | | | | |
∗
∗∗
∗45 Primary Subscriber ID # (Part. 2)
| | | | | | | | |
∗
∗∗
∗46 Secondary Subscriber ID # (Part. 2)
| | | | | | | | |
∗
∗∗
∗47 Phone System [1]
If Cent. Sta. IS NOT on a satellite link: 0=Pulse Dial; 1=Tone Dial;
if Cent. Sta. IS on a satellite link: 2 = Pulse Dial ; 3 = Tone Dial
∗
∗∗
∗48 Report Format [77]
0 = 3+1,4+1, ADEMCO L/S STANDARD prim. second
1 = 3+1,4+1, RADIONICS STANDARD
2 = 4+2, ADEMCO L/S STANDARD NOTE: To enable
3 = 4+2, RADIONICS STANDARD the audio “beeps”
5 = CID w/10-digit subscriber account (ID) no. format (Follow-Me
6 = 4+2, ADEMCO EXPRESS feature), refer to the
7 = CID w/4-digit subscriber account (ID) no System Features
8 = 3+1,4+1, ADEMCO L/S EXPANDED section of the
9 = 3+1,4+1, RADIONICS EXPANDED Installation Instr.
#+10 = ROBOFON 8 (6-digit subs account no.) and the User Guide
#+11 = ROBOFON Contact ID
∗
∗∗
∗49 Split/Dual Reporting [0]
0 = Disable (standard/backup reporting only)
Primary Phone No. Second Phone No.
1 = Alarms, Restore, Cancel Others
2 = All except Open/Close, Test Open/Close, Test
3 = Alarms, Restore, Cancel All
4 = All except Open/Close, Test All
5 = All All
∗
∗∗
∗50 Dialer Delay (Burg) [1]
0 = none; 1 = 15 seconds
2 = 30 seconds; 3 = 45 seconds
∗
∗∗
∗51 Primary Subscriber ID # (Part. 3)
| | | | | | | | |
∗
∗∗
∗52 Secondary Subscriber ID # (Part. 3)
| | | | | | | | |
Fields *51 and *52 see box above ∗43 for entries.
∗
∗∗
∗53 SESCOA / Radionics [0]
0 = Radionics (0-9, B-F); 1 = SESCOA (0-9 reporting only)
∗
∗∗
∗54 Dynamic Signaling Delay [0]
Delay selectable from 0 to 225 secs in 15-sec increments.
0 = no delay (both signals sent); 1 = 15 secs; 2 = 30 secs, etc.
∗
∗∗
∗55 Dynamic Signaling Priority [0]
0 = Primary Dialer first; 1 = ECP Contact ID first (e.g., TCP-IP ethernet)
TO PROGRAM SYSTEM STATUS, & RESTORE REPORT CODES:
For 3+1 or 4+1 Standard Format: Enter a code in the first box: 1–9, #+10 for
0, #+11 for B, #+12 for C, #+13 for D, #+14 for E, #+15 for F.
A 0 ( not #+10) in the first box will disable a report. A 0 ( not #+10) in the
second box will result in automatic advance to the next field.
For Expanded or 4+2 Format: Enter codes in both boxes (1st and 2nd digits)
for 1–9, 0, or B–F, as described above.
A 0 ( not #+10) in the second box will eliminate the expanded message for
that report. A 0 ( not #+10) in both boxes will disable the report.
For Ademco Contact ID® Reporting: Enter any digit (other than 0) in the first
box, to enable zone to report (entries in the second boxes are ignored).
A 0 ( not #+10) in the first box disables the report.
∗
∗∗
∗59 Exit Error Report Code [0]
∗
∗∗
∗60 Trouble Report Code [00] |
∗
∗∗
∗61 Bypass Report Code |
∗
∗∗
∗62 AC Loss Report Code |
∗
∗∗
∗63 Low Bat Report Code |
∗
∗∗
∗64 Test Report Code |
Use Scheduling mode to schedule periodic test reports.
∗
∗∗
∗65 Open Report Code [0,0,0]
Part. 1 Part. 2 Part 3
∗
∗∗
∗66 Arm Away/Stay Rpt Code
[0,0,0,0,0,0]
AWAY STAY AWAY STAY AWAY STAY
Part. 1 Part. 2 Part 3
∗
∗∗
∗67 RF Trans. Low Bat Report Code |
∗
∗∗
∗68 Cancel Report Code |
∗
∗∗
∗69 Alarm Restores [0]
Send restore code (if fault cleared):
0 = at siren timeout (if restored) or at disarm (whether restored or not)
1 = dynamically as the fault clears
2 = only after a disarm
∗
∗∗
∗70 Alarm Restore Rpt Code [0]
∗
∗∗
∗71 Trouble Restore Rpt Code |
∗
∗∗
∗72 Bypass Restore Rpt Code |
∗
∗∗
∗73 AC Restore Rpt Code |
∗
∗∗
∗74 Low Bat Restore Rpt Code |
∗
∗∗
∗75 RF Low Battery Restore Rpt Code |
∗
∗∗
∗76 Test Restore Rpt Code |
∗
∗∗
∗77 Summer Time Start\End Month [3][10] |
0 = Disabled; 1-12 = month (1 = January, 2 = February, etc)
#+10 = October; #+11 = November; #+12 = December
∗
∗∗
∗78 Summer Time Start\End Weekend [5][5] |
0 = disabled; 1 = first; 2 = second; 3 = third
4 = fourth; 5 = last; 6 = next to last; 7 = third to last
∗
∗∗
∗84 Auto Stay Arm [0]
0 = none; 1 = partition 1; 2 = partition 2; 4 = partition 3
Add the values for multiple partitions.
∗
∗∗
∗85 Linked Zone Verification Timer/ [0,0]
Up and About Timer Linked Up/about
Linked Zone: Assign linked zones on zone list 4, with *81 Menu mode.
0 = 15 seconds 4 = 90 seconds 8 = 4 min #+12 = 8 min
1 = 30 seconds 5 = 2 minutes 9 = 5 min #+13 = 10 min
2 = 45 seconds 6 = 2-1/2 min #+10 = 6 min #+14 = 12 min
3 = 60 seconds 7 = 3 min #+11 = 7 min #+15 = 15 min
Up and About Timer: 1-15 hours (also need to program up and about
schedule for time window that up and about feature is active; value set
in this field is time within the schedule that activity must occur)
∗
∗∗
∗86 Cancel Verify Keypad Display [0]
0 = no “alarm canceled”display
1 = display “Alarm Canceled”when system is disarmed after an alarm
has occurred. (To clear the “ALARM CANCELED”display, the
user must enter the security code + OFF again.)
∗
∗∗
∗87 Misc. Fault Delay Time [0]
(for Configurable Zone Type zones - alarm/trouble processing option)
0 = 15 seconds 4 = 90 seconds 8 = 4 min #+12 = 8 min
1 = 30 seconds 5 = 2 minutes 9 = 5 min #+13 = 10 min
2 = 45 seconds 6 = 2-1/2 min #+10 = 6 min #+14 = 12 min
3 = 60 seconds 7 = 3 min #+11 = 7 min #+15 = 15 min

– 5–
∗
∗∗
∗88 Exit Options [0]
0 = all intrusion zones must be intact before arming (must be 0 if
system uses zone type 82 - Blockschloss)
1 = All intrusion zones except in exit path (zone list 12) must be
intact before arming. Exit path zones cause alarm if not restored
at end of exit time
2 = All intrusion zones except in exit path (zone list 12) must be
intact before arming. Exit path zones are bypassed if not restored
at end of exit time
3 = Final contact set, infinite exit delay, terminates when exit door is
closed for 5 seconds, else restarts (use zone list 8 to assign exit
door zone number)
∗
∗∗
∗89 Event Log Full Report Code [00] |
See box above ∗59 for entries.
∗
∗∗
∗90 Event Log Enables [15]
0 = None; 1 = Alarm/Alarm Restore; 2 = Trouble/Trouble Restore;
4 = Bypass/Bypass Restore; 8 = Open/Close.
Example: To select “Alarm/Alarm Restore”, and “Open/Close”, enter
9 (1 + 8); To select all, enter #15.
NOTE: System messages are logged when any non-zero entry is made.
∗
∗∗
∗91 Miscellaneous Options [0]
0 = None; 4 = Audio Alarm Verification (AAV)
8 = Exit Delay Restart
# + 12 = AAV (4) + Exit Delay restart (8)
∗
∗∗
∗92 Telecom Monitor Enable [0,0]
Entry 1: 0 = disabled 1 2
1-15 = enabled, after 1 15 min. line outage
(#+10 = 10 min; #+11 = 11 min; #+12 = 12 min;
#+13 = 13 min; #+14 = 14 min; #+15 = 15 min)
Entry 2: 0 = keypad display when line is faulted
1 = keypad display plus keypad trouble sound
2 = Same as “1”, plus programmed output device STARTS. If
any partition is armed, external sounder also activates.
NOTE: Output Device must either be programmed to be STOPPED
in field ∗80 or STOPPED by Code + # + 8 + output number.
∗
∗∗
∗93 No. of Reports in Armed Period [0]
Per Zone (Intermittent Sensor)
0 = Unlimited Reports
1-6 = 1 to 6 report pairs
∗
∗∗
∗94 Download Phone No.
| | | | | | | | | | | | | | | | | | | | | | | | | | | | |
Enter up to 30 digits, 0–9; #+11 for '∗'; #+12 for '#'; #+13 for a 2-
second pause. Do not fill unused spaces. If fewer than 30 digits, exit
field by pressing ∗. To clear entries from field, press ∗94∗.
∗
∗∗
∗95 Ring Count For Downloading [15]
0 = Disable Monitoring Station Initiated Download;
1–14 = number of rings (1–9, # +10 =10, # +11 =11, # +12 =12,
# +13 =13, # +14 =14);
15 = Answering machine/fax defeat (# +15 =15).
∗
∗∗
∗160 Pager 1 Phone No.
| | | | | | | | | | | | | | | | | | |
Enter up to 20 digits, 0–9; #+11 for '∗'; #+12 for '#'; #+13 for a 2-
second pause. Do not fill unused spaces. If fewer than 20 digits, exit
field by pressing ∗. To clear entries from field, press ∗160∗.
∗
∗∗
∗161 Pager 1 Characters
| | | | | | | | | | | | | | |
Enter the optional prefix characters, up to 16 digits.
0–9; #+11 = '∗'; #+12 = '#'; #+13 = 2-second pause.
∗
∗∗
∗162 Pager 1 Reporting Options
For each partition, select from: [0,0,0] Part. 1 Part. 2 Part 3
0 = no reports sent; 1 = Open/close all users; 4 = All alarms and troubles
5 = All alarms / troubles, and open/closes for all users
12 = Alarms / troubles for zones entered in zone list 9
13 = Alarms / troubles for zones entered in zone list 9, and
opens/closes for all users
∗
∗∗
∗163 Pager 2 Phone No. (See field *160 for entries.)
| | | | | | | | | | | | | | | | | | |
∗
∗∗
∗164 Pager 2 Characters (See field *161 for entries.)
| | | | | | | | | | | | | | |
∗
∗∗
∗165 Pager 2 Reporting Options
See field *162 for entries. [0,0,0] Part. 1 Part. 2 Part 3
Use zone list 10 if using options 12 or 13.
∗
∗∗
∗166 Pager Delay Option For Alarms [3]
0 = none, 1 = 1 minute, 2 = 2 minutes, 3 = 3 minutes
This delay is for ALL pagers in the system. The delay does not reset
for new alarms occurring while an existing pager delay is in progress.
∗
∗∗
∗173 RF Reporting Options [3]
0 = none; 1 = RF Tamper reports during disarm
2 = RF keyfobs send low battery
3 = RF Tamper reports during disarm and RF keyfobs send low battery
∗
∗∗
∗175 Tamper Options [0,0]
(see field *25 for tamper override options when arming) 1 2
Entry 1: 0 = standard tamper protection
1 =detect tamper from bypassed zones
2 = detect tamper when in Test mode
3 = detect tamper when in Test mode and from bypassed zones
Entry 2: 0 = all users can clear a tamper (must be “0”if field *25 digit
2 set to 1 or 2)
1 = only the installer can clear a tamper
∗
∗∗
∗176 Bell (Siren) Options [0,0]
Entry 1: 0 = external bell (siren); 1 = self-activated ext. bell 1 2
Entry 2: 0 = disable (entry 2 is ignored if entry 1 not set to external bell)
1 = enable 30 second ext. siren and dialer delay during entry
delay period when armed AWAY (if entry delay is active
and an instant zone is faulted, the siren is delayed 30
seconds, and the report is delayed 30 secs. unless field
*50 is set for a greater delay)
2 = when armed in the Stay mode and an alarm event occurs,
the siren output will be delayed by the amount of time that
the entry delay 1 is set for.
∗
∗∗
∗177 Device Duration 1, 2 [0,1]
(used in *80 Menu mode-Device Actions 5/6) 1 2
Duration 1 – Device Action 5 Timer
0 = 15 seconds 4 = 90 secs 8 = 4 min #+12 = 8 min
1 = 30 seconds 5 = 2 min 9 = 5 min #+13 = 10 min
2 = 45 seconds 6 = 2-1/2 min #+10 = 6 min #+14 = 12 min
3 = 60 seconds 7 = 3 min #+11 = 7 min #+15 = 15 min
Duration 2 – Device Action 6 Timer (Strobe Timer)
1 –7 = 1 to 7 days
∗
∗∗
∗178 RF Supervision and RF Jam Option [0]
0 = Basic RF supervision and RF jam detection
1 = Report RF supervision failure as tamper alarm when armed
2 = Report RF Jam as tamper alarm when armed
3 = Report RF Jam & RF supervision failure as tamper alarm when armed
∗
∗∗
∗180 Zone Bypass Limit [0]
0 = unlimited zone bypasses in each partition
1-7 = number of zone bypasses allowed in each partition
(each partition individually uses this entry)
∗
∗∗
∗181 50/60 Hertz AC Operation (for real-time clock) [5]
Use the following table to select the desired options for real-time
clock synchronization (50Hz, 60Hz, Crystal), AC Loss display
(independent of AC Loss report enabled in *62), and clock display
(time displayed on bottom line of alpha keypads).
X10 NOTE: “X10”(powerline carrier devices) use the selected AC
frequency to communicate with the control.
Entry AC Freq. Crystal for AC Loss disp Clock disp
0 60Hz clock backup no no
1 50Hz clock backup no no
2 60Hz clock no no
3 50Hz clock no no
4 60Hz clock backup yes no
5 50Hz clock backup yes no
6 60Hz clock yes no
7 50Hz clock yes no
8 60Hz clock backup no yes
9 50Hz clock backup no yes
#+10 60Hz clock no yes
#+11 50Hz clock no yes
#+12 60Hz clock backup yes yes
#+13 50Hz clock backup yes yes
#+14 60Hz clock yes yes
#+15 50Hz clock yes yes

– 6–
∗
∗∗
∗182 Summer Time Switchover Day [0]
0 = switch on Sunday morning; 1= switch on Saturday morning
2 = switch on Friday morning
∗
∗∗
∗183 Date/Time Format [3]
0 = 12-hour time/MMDDYY date 2 = 24-hour time/MMDDYY date
1 = 12-hour time/DDMMYY date 3 = 24-hour time/DDMMYY date
∗
∗∗
∗185 Downloader Suppression Options [0]
0 = no suppression; 1 = suppress user code viewing
2 = suppress commands and program download when armed
3 = suppress user code viewing, commands, and program download
when armed
∗
∗∗
∗186 Display Options [0,0]
Entry 1: Latch the first alarm in the display: 0 = disable; 1 = enable
Entry 2: Turn off the display (except for AC loss) except during exit
delay. Turns off when exit delay expires, or 30 seconds
after disarm; 0 = disable; 1 = enable
∗
∗∗
∗187 Sounder Mimic on Trigger 1 [0]
0 = no sound output on trigger 1
1 = mimic keypad 1, address 16 5 = mimic keypad 5, address 20
2 = mimic keypad 2, address 17 6 = mimic keypad 6, address 21
3 = mimic keypad 3, address 18 7 = mimic keypad 7, address 22
4 = mimic keypad 4, address 19 8 = mimic keypad 8, address 23
NOTE: If used, do not assign any other functions to trigger 1.
∗
∗∗
∗188 Keypad Sabotage Options [0,0]
Entry 1: Keypad Lockout: 0 = disable; 1 = enable 15 minute lockout
Entry 2: Keypad Supervision and Tamper Fault Detection:
0 = no, 1 = yes
∗
∗∗
∗189 AUI Device 1 and 2 Enable [0,0]
(for Touch Screen Style Keypads) AUI 1 AU2
System supports up to two touch screen style keypads (e.g., Symphony
Advanced User Interface, and 6270 Touch Screen Keypad).
AUI Compatibility Note: To ensure proper AUI device operation, use
AUI devices with the following rev levels: 6270 series use version
1.0.9 or higher; 8132/8142 (Symphony) series use version 1.1.175 or
higher.
Touch Screen (AUI) device 1: Must set AUI device address to 1
Touch Screen (AUI) device 2: Must set AUI device address to 2
Enter each AUI’s home partition.
0 = disabled
1 = partition 1; 2 = partition 2; 3 = common partition
KEYPAD OPTIONS
NOTES: 1. Keypad 1 (addr 16) options are factory set and cannot be changed.
2. Each keypad must be assigned a unique address. Keypads
programmed with the same address will give unpredictable results.
∗
∗∗
∗190 Keypad 2 Device Address 17 [0] [0]
Partition: 0 = keypad disabled; 1-3 = part. no. Part. Sound
Sound: 0 = no suppression
1 = suppress arm/disarm and E/E beeps
2 = suppress chime beeps only
3 = suppress arm/disarm, E/E, & chime beeps
Fields*191-*196 see field ∗190 for entries. Part. Sound
∗
∗∗
∗191 Keypad 3 Device Address 18 [0] [0]
∗
∗∗
∗192 Keypad 4 Device Address 19 [0] [0]
∗
∗∗
∗193 Keypad 5 Device Address 20 [0] [0]
∗
∗∗
∗194 Keypad 6 Device Address 21 [0] [0]
∗
∗∗
∗195 Keypad 7 Device Address 22 [0] [0]
∗
∗∗
∗196 Keypad 8 Device Address 23 [0] [0]
∗
∗∗
∗197 Exit Time Display Interval [0]
0 = no display; 1-5 = seconds between display refresh
∗
∗∗
∗198 Display Partition Number [0]
0 = no; 1 = yes (partition number displays on alpha keypads)
∗
∗∗
∗199 ECP Device Fail Display [0]
0 = 3-digit display (“1”+ device address); for 6139, 6148, 6164
1 = 2-digit fixed-display as “91;”for 6128 series keypads

– 7–
*56 ZONE PROGRAMMING WORKSHEET [default values shown in brackets]
Zone Zn Type Partition Report Basic Wired Type Response Time Location
1 [01] [1] [EOL] [1]
2 [04] [1] [EOL] [1]
3 [03] [1] [EOL] [1]
4 [03] [1] [EOL] [1]
5 [03] [1] [EOL] [1]
6 [03] [1] [EOL] [1]
7 [03] [1] [EOL] [1]
8 [03] [1] [EOL] [1]
Zone Zn Type Partition Report Input Type Loop Serial Number Location
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49 [1] [BR]
50 [1] [BR]
51 [1] [BR]
52 [1] [BR]
53 [1] [BR]
54 [1] [BR]
55 [1] [BR]
56 [1] [BR]
57 [1] [BR]
58 [1] [BR]
59 [1] [BR]
60 [1] [BR]
61 [1] [BR]
62 [1] [BR]
63 [1] [BR]
64 [1] [BR]
91 [05] N/A N/A N/A N/A Addressable Device Report
92 N/A N/A N/A N/A N/A Duress Report
95 [00] N/A N/A N/A keypad [1] / [∗]
96 [00] N/A N/A N/A keypad [3] / [#]
99 [06] N/A N/A N/A keypad [∗] / [#]
NOTES:
Zone Type: see chart on
next page
Basic wired Type (zns 1-8):
0 = EOL
1 = NC
2 = NO
3 = zone doubling (2-8)
4 = double-balanced
(2-8)
Input Type:
2 = AW (zones 9-48)
3 = RF (zones 9-48)
4 = UR (zones 9-48)
5 = BR (zones 49-64)
7 = RM (zones 9-48)
NOTE: Zones 10-16 not
available depending on
whether zone doubling
enabled on zones 2-8.
Response Time:
0 = 10msec
1 = 400msec
2 = 700msec
3 = 1.2 sec
NOTE: If zone doubling is
selected, the response
time selected for the basic
zone automatically applies
to the associated doubled
zone.
Reserved Zones
91 = addressable device
report enable/disable
default zone type =
[05].
92 = Duress report
enable/disable

– 8–
∗
∗∗
∗56 ZONE PROGRAMMING MENU MODE (press *56 while in Program mode)
SET TO CONFIRM?
0 = NO 1 = YES
0 = no
1 = yes (prompt appears after entering the serial and loop numbers to confirm each transmitter)
We recommend that you confirm the programming of every transmitter.
Enter Zn Num.
(00 = Quit) 10
Enter the zone number being programmed:
wired zones 01-48; wireless zones 09-48; RF button zones 49-64
91 = addr. device report enable (Enter a report code for zone 91 to enable addressable device reporting.
92 = duress report enable (Enter a report code for zone 92 to enable duress reporting)
95, 96, 99 =emergency zones
00 to quit; [∗] to continue
Zn ZT P RC In: L
10 00 1 10 RF: 1
Summary Screen
[∗] to continue; “IN: L”= input type and loop; “IN: AD”= wired expansion module address
“HW: RT”= basic wired zone configuration (EOL, NO, NC, zone doubling, double-balanced) and response
time
10 Zone Type
Perimeter 03
Enter the desired zone type from the list below. If 00 is entered, Delete Zone ? is displayed.
00 = Not used 07 = 24-Hr Audible 21 = Arm–AWAY*
01 = Entry/exit #1 08 = 24-Hr Aux 22 = Disarm*
02 = Entry/exit #2 09 = Fire 23 = No Alarm Resp
03 = Perimeter 10 = Interior w/Delay 24 = Silent Burglary
04 = Interior Follower 12 = Monitor Zone 77 = Keyswitch
05 = Trouble Day/Alarm Night 14 = Gas 81 = AAV Monitor Zone
06 = 24-Hr Silent 16 = Fire w/Verify 82 = Blockschloss Keyswitch
*5800 button-type transmitters only 20 = Arm–STAY* 90-93 = Configurable
10 Partition
1
Enter the desired partition for this zone
1-3 = partition
[∗] to continue
10 Report Code
1st 01 2nd 00 10
Enter the report code for this zone, which consists of 2 hexadecimal digits, each in turn consisting of 2
numerical digits. For example, for a report code of “10,”enter 01 and 00.
For Contact ID®, entering any non-zero entry as the first digit enables the report code for this zone.
1-9, 10 for 0, 11 for B, 12 for C, 13 for D, 14 for E, 15 for F
00 to disable; [∗] to continue
02 HARDWIRE TYPE
EOL 0
This prompt appears only for zone numbers 02-08. Zone 1 is automatically set for EOL operation.
Enter the desired basic wired type:
0 = EOL; 1 = NC; 2 = NO; 3 = zone doubling (ZB); 4 = double-balanced (DB)
[∗] to continue
02 Response Time
1
This prompt appears only for basic wired zones 01-08 (zone 02 is used as an example in display).
0 = 10mSec; 1 = 400mSec; 2 = 700mSec; 3 = 1.2 seconds
[∗] to continue
10 INPUT TYPE
RF TRANS 3
This prompt is skipped for zones 1-8, and for zones 10-16 if zone-doubling enabled at “Hardwire Type”
prompt.
All of the RF transmitters have one or more unique input loops (see list below). Each of the input loops
requires its own programming zone (e.g., a 5804's four inputs requires four zones).
2 = AW (Aux wired zone)
3 = RF (supervised RF transmitter; sends fault, restore, and low-battery signals, and sends periodic check-
in signals; transmitter must stay within receiver's range)
4 = UR (unsupervised RF transmitter; sends fault, restore, and low-battery signals, but periodic check-in
signals are not supervised; transmitter may be carried off-premises)
5 = BR (unsupervised button type RF transmitter; sends fault and low battery signals when activated, does
not send restore or check-in signals; transmitter may be carried off-premises)
7 = RM (supervised RF motion detector; sends fault and low battery signals, and sends periodic check-in
signals; panel ignores detector restore signals but automatically restores the zone to “ready”after a few
seconds; transmitter must stay within receiver's range)
[∗] to continue
NOTES:
•For the built-in basic wired zones, the Input Type is automatically displayed as HW and cannot be edited.
•To change the input type of a previously programmed wireless device (type RF, UR, BR, RM) to a wired
zone (type AW), you must first delete the transmitter’s serial number.
10 INPUT S/N: L
A022-4064 1
For wireless transmitters, enroll the serial number and loop number as follows:
1. a. Transmit two open/close sequences. If using a button-type transmitter, press and release the button
twice, but wait about 4 seconds before pressing the button the second time.
OR
b. Manually enter the 7-digit serial number printed on the label of the transmitter.
Press the [∗] key to move to the “L”position, then enter the loop number.
If desired, you can press the [C] key to copy the previously enrolled serial number (used when
programming a transmitter with several input loops). The cursor moves to the loop number position.
c. To delete an existing serial number, enter 0 in the loop number field. The serial number will change to
0's. If 0 was entered in error, simply re-enter the loop number or press [#], and the serial number will
return to the display.
2. Press [∗] to continue. The system now checks for a duplicate serial/loop number combination.

– 9–
10 INPUT S/N L
A022-4064 1
If the serial/loop number combination is not a duplicate in the system, a display showing the serial number
and loop number entry appears.
[∗] to continue
XMIT TO CONFIRM
PRESS ✱TO SKIP
This prompt will only appear if you answered “Yes”at the first prompt in this section.
The system will enter a confirmation mode so that the operation of the actual programmed input can be
confirmed.
Activate the loop input or button that corresponds to this zone.
[∗] to continue
Entd A022-4063 1
Rcvd A022-4064 1
If the serial/loop number transmitted does not match the serial number entered, a display showing the
entered and the received serial/loop numbers appears.
If so, activate the loop input or button on the transmitter once again. If a match is not obtained (i.e.,
summary display does not appear), press the [#] key twice and then enter (or transmit) the correct serial
number.
[∗] to continue
Zn ZT RC In: L
10 03 10 RF: 1s
If the serial number transmitted matches the serial number entered, the keypad will beep 3 times and
a summary display will appear, showing that zone's programming. An “s”indicates that a
transmitter’s serial number has been enrolled.
[∗] to accept the zone information and continue
PROGRAM ALPHA?
0 = NO 1 = YES 0
If you want to program descriptors for zones now, enter 1 (Yes) and refer to the *82 Descriptor Programming
section for procedures. To program descriptors later, enter 0 (no).
[∗] to continue
ENTER ZN NUM.
(00 = QUIT) 11
If 0 (No) was entered at the Program Alpha prompt, the system will return you to the ENTER ZN NUM.
prompt for the next zone.
When all zones have been programmed, enter 00 to quit.
∗
∗∗
∗58 Expert Programming Mode Procedures (press ∗
∗∗
∗58 while in Data Programming mode)
SET TO CONFIRM?
0 = NO 1 = YES
0 = no
1 = yes (prompt appears after entering the serial and loop numbers to confirm each transmitter)
We recommend that you confirm the programming of every transmitter.
Zn ZT P RC HW: RT
01 09 1 10 EL 1
Zn ZT P RC IN: L
10 –––: –
A summary screen will appear, showing zone 1’s currently programmed values.
Enter the zone number being programmed, then press [∗]. In this example, zone 10 is being entered.
01-64 = zone number
[D] = for assigning wireless key programming templates (see Wireless Key Programming Templates section
in i/i); lets you choose from a series of preset templates for easy programming of wireless key zones
00 = quit (when all zones have been programmed, press “00”to quit this menu mode)
[∗] to continue
Zn ZT P RC IN: L
10 00 1 10 RF 1
A summary screen with the selected zone’s current programming appears.
Begin programming zone information as follows:
Enter Zone Type (ZT; see Zone Type chart shown in *56 Menu Mode “Zone Type”prompt), Partition (P),
Report Code (RC, 0-9 only; see *56 mode for hex codes), and Input Device Type (IN)* sequentially (Loop
Number (L) is entered at the next prompt).
•Use the [A] (Advance) and [B] (Back) keys on the keypad to move the cursor within the screen.
•Use the [C] key to copy the previous zones attributes.
* If HW (basic wired) or AW (Auxiliary) is entered for Input Device Type, the display will be similar to the
prompt shown, except that HW or AW will be under “IN”.
Press [∗] to save the programming and continue. If needed, press the [#] key to back up without saving.
For wireless devices (input types RF, UR, BR, RM), continue to the serial number/loop number prompt.
For wired devices, return to the initial summary screen prompt to begin programming the next zone.
10 INPUT S/N: L
AXXX-XXX –
Zn ZT P RC In L
10 03 1 10 RF: 1s
Manually enter the serial number (found on the transmitter label), by entering the digits in the “X”locations,
using the [A] (advance) or [B] (back) keys as required.
OR
Transmit two open/close sequences. If using a button-type transmitter, press and release the button twice,
but wait about 4 seconds before pressing the button the second time.
If you want to copy the previous zone’s serial number, press the [C] key.
Press [∗] to advance to the loop number, then enter loop number.
Press [∗] to accept the existing serial and loop number and continue to the “Confirm”prompt described in *56
Menu mode above.
If necessary, press [#] to back up and re-enter or edit the serial number.
If the serial number transmitted matches the serial number entered, the keypad will beep 3 times and a
summary display will appear, showing the programmed information for that zone.
Press [∗] to begin programming the next zone. See first “Summary Screen”prompt paragraph on previous
page.

– 10 –
Wireless Key Programming Templates (press the [D] key from *58 Menu mode Summary Screen display)
This procedure programs the wireless keys, but a key is not active until it is assigned to a user number (see System Operation section,
assigning attributes command in the Installation Instructions).
TEMPLATE ?
1–6 1
Enter desired template number 1–6 (see chart below).
Press [#] if you want to return to *58 Menu mode Summary Screen.
If necessary, press [#] to back up and re-enter template number.
Press [∗] to continue to template display.
L 01 02 03 04
T 23 22 21 23
When [∗] is pressed, the selected template will be displayed.
Top line of display represents loop numbers, bottom line represents zone type assigned for each loop.
Press [∗] to accept template and continue.
PARTITION
1
Enter the partition in which the key is to be active.
1 = partition 1; 2 = partition 2; 3 = partition 3 (or common area partition)
Press [∗] to continue.
ENTER START ZONE
00 = QUIT 36
The system will search for the highest available consecutive 4-zone group (the four zones in the case of the
5804 and 5804BD/5804BDV), and display the lowest zone number of the group.
If you want to start at a different zone, enter the zone desired, and press [∗]. If that zone number is
displayed, the system has the required number of consecutive zones available, beginning with the zone you
entered. If not, the system will again display a suggested zone that can be used.
If the required number of consecutive zones is not available at all, the system will display “00”.
Press [∗] to accept and continue.
INPUT S/N L
AXXX-XXXX –
Manually enter the serial number printed on the label for the wireless key or press and release the button to
transmit its serial number.
Press [∗] to accept the serial number. The system will check for duplicate.
If necessary, press the [#] key to back up without saving, and re-enter the serial number.
Use the [A] key to move forward within the screen, and the [B] key to move backward.
XMIT TO CONFIRM
PRESS ✱TO SKIP
If “Yes”was entered at the SET TO CONFIRM? prompt (first prompt following entry into the ∗58 Expert
Programming Mode), the display on the left will appear.
Confirm serial and loop numbers by activating the wireless key. Refer to the “Confirm”prompt described in
*56 Menu mode above for more information on confirming the serial number.
If the serial number transmitted matches the serial number entered, the keypad will beep 3 times and will
return you to the ENTER START ZONE NUMBER prompt to enter the starting zone for the next wireless key.
IMPORTANT: When confirmed, the key is not active until it is assigned to a user number (using the
assigning attributes command, attribute “4”). See System Operation section in Installation Instructions.
[∗] to skip confirm.
Wireless Key Predefined Default Templates
5804 Loop Function Zone Type 5804BD/5804BDV Loop Function Zone Type
TEMPLATE 1 1 No Response 23 TEMPLATE 4 1 No Response 23
2 Disarm 22 2 No Response 23
3 Arm Away 21 3 Arm Away 21
4 No Response 23 4 Disarm 22
TEMPLATE 2 1 No Response 23 TEMPLATE 5 1 No Response 23
2 Disarm 22 2 Arm Stay 20
3 Arm Away 21 3 Arm Away 21
4 Arm Stay 20 4 Disarm 22
TEMPLATE 3 1 24-hour audible 7 TEMPLATE 6 1 24-hour audible 7
2 Disarm 22 2 Arm Stay 20
3 Arm Away 21 3 Arm Away 21
4 Arm Stay 20 4 Disarm 22
5800 Series Transmitter Input Loop Identification
All of the transmitters illustrated below have one or
more unique factory assigned input (loop) ID codes.
Each of the inputs requires its own programming
zone (e.g., a 5804's four inputs require four
programming zones).
Note: For information on any transmitter not shown,
refer to the instructions accompanying that
transmitter for details regarding loop
numbers, etc.
5802MN2/5802H
ENROLL AS
"UR" OR "RF"
LOOP
1
VISTA48D-001-V0
5817
ENROLL AS "RF"
5890/5888H
ENROLL AS
"RF" OR "RM"
LOOP 1
5808LST/5808H
ENROLL AS "RF"
LOOP 1
5809
ENROLL AS "RF"
5852/5852H
ENROLL AS "RF"
(Green)
(Red)
(Yellow)
5804BD
ENROLL AS "BR"
LOOP 4
YOU MUST
ENROLL
THIS BUTTON
SET
HOUSE
CODE
LOOP 3
LOOP 1
LOOP 2
5804/5804H
ENROLL AS "BR"
OFF
ON
5816MN
ENROLL AS "RF"
LOOP 1
(TERMINALS)
ALTERNATE
POSITION
FOR LOOP 2
LOOP 2
(REED)
5816/5816H
ENROLL AS "RF"
LOOP 1
(TERMINALS)
ALTERNATE
POSITION
FOR LOOP 2
LOOP 2
(REED)
LOOP 3
(TERMINALS)
5819WHS/5819SH
ENROLL AS "RF"
LOOP 1
(INTERNAL
SHOCK
SENSOR
LOOP 2
(REED)
5819
ENROLL AS "RF"
LOOP 2
(REED)
LOOP 3
(TERMINALS)
LOOP 1
(TERMINALS)
5801
ENROLL AS
"UR" OR "RF"
LOOP 3
LOOP 1
LOOP 2
LOOP 4
YOU MUST
ENROLL
THIS
BUTTON
LOOP 1
LOOP 2
LOOP 4
YOU MUST
ENROLL
THIS
BUTTON
LOOP 3
LOOP 1
LOOP 2
(AUX.
CENTER)
LOOP 1
(PRIMARY)
LOOP 3
(AUX.
RIGHT)

– 11 –
Table of Device Addresses
Address Report†Device Programmed by…
00 100 RF Receiver *56 zone programming: input device type entry;
03 103 Alternative Communication Media (ACM) automatic if ECP Contact ID Output for ACM field *29 enabled
17-23 117-123 Telecommand Voice Module same as keypad enables; see below
Zone Expanders (4219/4229)/6164 Keypad: *56 zone programming: input device type entry, then:
07 107 module 1 zones 09 - 16 / 6164 zones 9-12 •automatic if zone no. 9-16 entered as AW type or relay assigned
08 108 module 2 zones 17 - 24 / 6164 zones 17-20 •automatic if zone no. 17-24 entered as AW type or relay assigned
09 109 module 3 zones 25 - 32 / 6164 zones 25-28 •automatic if zone no. 25-32 entered as AW type or relay assigned
10 110 module 4 zones 33 - 40 / 6164 zones 33-36 •automatic if zone no. 33-40 entered as AW type or relay assigned
11 111 module 5 zones 41 - 48 / 6164 zones 41-44 •automatic if zone no. 41-48 entered as AW type or relay assigned
Relay Modules (4204)/6164 Keypad with Relay: *79 output device programming: device address prompt:
12 112 module 1 / 6164 using relay only (no zones) •entered at device address prompt
13 113 module 2 / 6164 using relay only (no zones) •entered at device address prompt
14 114 module 3 / 6164 using relay only (no zones) •entered at device address prompt
15 115 module 4 / 6164 using relay only (no zones) •entered at device address prompt
Keypads: data field programming as listed below:
16 n/a keypad 1 •always enabled for partition 1, all sounds enabled.
17 n/a keypad 2 •data field *190
18 n/a keypad 3 •data field *191
19 n/a keypad 4 •data field *192
20 n/a keypad 5 •data field *193
21 n/a keypad 6 •data field *194
22 n/a keypad 7 •data field *195
23 n/a keypad 8 •data field *196
28 n/a 5800TM Module automatic
†Addressable devices are identified by “1”plus the device address when reporting. Enter report code for zone 91 to enable addressable device
reporting (default = reports enabled). See field *199 for addressable device (ECP) 3-digit/2-digit identification keypad display options.
*57 FUNCTION KEY PROGRAMMING
Option Function A
P1 P2 P3
B
P1 P2 P3
C
P1 P2 P3
D
P1 P2 P3
Comments
01 Paging
02 TimeDisplay
03 ArmAWAY
04 ArmSTAY
05 ArmNIGHT-STAY
06 StepArming
07 DeviceActivation Device:
08 Comm.Test
09 Macro Key 1 Assign each macro key to only a single partition. †
10 Macro Key 2 Assign each macro key to only a single partition. †
11 Macro Key 3 Assign each macro key to only a single partition. †
12 Macro Key 4 Assign each macro key to only a single partition. †
00 Emergency Keys: zone 95 zone 99 zone 96 paging
Personal Emergency n/a
SilentAlarm n/a
Audible Alarm n/a
Fire n/a
Emergency Keys: A = paired keys [1] / [∗] (zone 95); B = paired keys [∗] / [#] (zone 99); C = paired keys [3] / [#] (zone 96)
†There are only four macros system-wide.
Start Function Key Programming mode by pressing ∗
∗∗
∗57 while in Data Programming mode.
Press Key to Pgm
0 = Quit 0
Press the desired function key, A-D.
NOTE: A key programmed as a function key is no longer available to
be used as an end-user macro key or panic key.
[∗] to continue
321
654
987
#0
*
READY
INSTANT
MAX
OFF
CODE
AWAY
TEST
CHECK
STAY
BYPASS
A
B
C
D
keypad_keys-00-001-V0
Partition
1
1 = function key active in partition 1
2 = function key active in partition 2
3 = function key active in partition 3
[∗] to continue
Key "A" Func
Zone 95 00
Enter the desired function for this key:
00 = For the Function key selected, the function will be as follows (system default):
If A selected = Zone 95 (emergency key, same as [1] [∗] pair)
If B selected = Zone 99 (emergency key, same as [∗] [#] pair)
If C selected = Zone 96 (emergency key, same as [3] [#] pair)
If D selected = Single-button paging
01 = Single-button paging (sends a 999-9999 message to pager)
02 = Display time
03 = Arm AWAY (reports as User 00 if closing reports are enabled)
04 = Arm STAY (reports as User 00 if closing reports are enabled)
05 = Arm NIGHT-STAY (reports as User 00 if closing reports enabled)
06 = Step Arming (arms STAY, then NIGHT-STAY, then AWAY)
07 = Output Device Command (for device programmed as system operation type 66 in *80 Menu Mode)
08 = Communication Test (sends Contact ID code 601)
09 -12= Macro Keys 1-4 respectively (defined by [#] [6] [6] command)
[∗] to continue; returns to key number prompt with the next function key letter displayed.

– 12 –
OUTPUT RELAYS/POWERLINE CARRIER DEVICES WORKSHEET FOR ∗
∗∗
∗79, ∗
∗∗
∗80 and ∗
∗∗
∗81.
For keypad activated devices, use *79 Menu mode to assign a system output number and associate its corresponding device.
For automatic activation, use *79 Menu mode as above, and use *80 Menu mode to define the system condition that will
activate/deactivate the device(s).
∗
∗∗
∗79 RELAY/POWERLINE CARRIER DEVICE MAPPING (Must program before using *80)
OUTPUT TYPE OUTPUT TYPE
Relay X10
Relay X10
Output
No.
Module
Addr.
Pos
(1-4)
Unit
No.
Description Output
No.
Module
Addr.
Pos
(1-4)
Unit
No.
Description
01 09
02 10
03 11
04 12
05 13
06 14
07 15
08 16
17 On-Board Trigger 1 Postive\Negative Trigger
To Activate/Deactivate Devices in Normal Operating Mode:
Code + # + 7 + NN Key Entry starts Device NN.
Code + # + 8 + NN Key Entry stops Device NN. 18 On-Board Trigger 2 Postive\Negative Trigger
Start Output Device Mapping by pressing *79 while in Data Programming Mode.
ENTER OUTPUT NO.
00 = QUIT xx
Enter the logical (or reference) relay number as used in the system.
01-16 = relays/X-10
17-18 = on-board triggers (can be programmed for inverted output; see next prompt)
[∗] to continue
17 OUT NORM LOW
0 = NO 1 = YES 0
This prompt appears only for triggers 17 and 18.
0 = no (standard default); sets the trigger output level normally high
1 = yes; sets the trigger output normally low (can be used for resetting 4-wire smoke detectors by connecting
trigger wire to the negative power terminal of the smoke detector, selecting 1 at this prompt, and setting
as zone type 54, fire zone reset, in *80 Menu mode)
[∗] to return to Output Number prompt
XX OUTPUT TYPE
DELETE? 0
Select whether this is a relay or a Powerline Carrier (X-10) device.
0 = delete this output number
1 = relay on 4204/4229 module, 6164 keypad (skip to “B”prompt)
2 = Powerline Carrier device (go to “A”prompt)
[∗] to continue
“A”
XX UNIT No.
yy
Enter the device’s unit code (set at the device)
01-16 = predefined address
[∗] to return to the Output Number prompt
“B”
XX MODULE ADDR
07-15 yy
Enter the module’s predefined address (set the module’s DIP switches to the selected address, or key the
6164 address)
07-15 = predefined address (see table of device addresses)
[∗] to continue
XX REL POSITION
1-4 zz
Enter the actual (or physical) relay number with respect to the Relay Module upon which it is located. For
4204 modules, relay numbers are 1-4. For 4229 modules, relay numbers are 1-2. For 6164 keypad, relay
number is 1.
1-4 = relay position
[∗] to return to the Output Number prompt for programming the next device

– 13 –
✱80 OUTPUT DEFINITIONS
NOTES: 1. For Relays, 4229, 4204, and 6164 devices are programmed in *79, *80, and *81 modes.
2. For Powerline Carrier devices (plcd), field ✱27 must be programmed with a House Code.
3. Tampers of expansion units cannot be used to operate devices.
Zone Types:
00 = Not used 07 = 24-Hr Audible 21 = Arm–AWAY*
01 = Entry/exit #1 08 = 24-Hr Aux 22 = Disarm*
02 = Entry/exit #2 09 = Fire 23 = No Alarm Resp
03 = Perimeter 10 = Interior w/Delay 24 = Silent Burglary
04 = Interior Follower 12 = Monitor Zone 77 = Keyswitch
05 = Trouble Day/Alarm Night 14 = Gas 81 = AAV Monitor Zone
06 = 24-Hr Silent 16 = Fire w/Verify 82 = Blockschloss Keyswitch
20 = Arm–STAY* 90-93 = Configurable *5800 button-type transmitters only
Choices for System Operation are: ** Use 0 (Any) for Partition No. (P) entry.
20 = Arming–Stay 38 = Chime 58 = Duress *** Or at Disarming, whichever occurs earlier.
21 = Arming–Away 39 = Any Fire Alarm 60 = AAV Trigger
22 = Disarming (Code + OFF) 40 = Bypassing 66 = Function key (use *57 Menu Mode to assign the function key, function “07,”)
31 = End of Exit Time 41 = **AC Mains Failure 67 = Siren Failure
32 = Start of Entry Time 42 = **System Battery Low 68 = Telecom Line Fault
33 = Any Burglary Alarm 43 = Communication Failure 78 = Keyswitch red LED (device action not used for this option)
36 = **At Siren Timeout*** 52 = Kiss off 79 = Keyswitch green LED (device action not used for this option)
54 = Fire Zone Reset 80 = any tamper in the system
OUTPUT DEFINITION WORKSHEET
Activation Type and Detail Event (for zone list/activated by)Output
Function
Number
(1-48)
Activated by
0=delete
1=zn list
2=zn type
3=zn no.
Zone List
(ZL)
1-8 = list
Zone Type
(ZT)
(see table
below)
Zone No.
(ZN)
00=none
01-64
Partition
Number
(P)
(if using ZT trig)
0 = any
1 = partition 1
2 = partition 2
3 = partition 3
By Zone List
0 = restore
1 = alarm
2 = fault
3 = trouble
By Zone No.
0 = restore
1 = alarm
2 = fault
3 = trouble
4 = off-normal
Action
0 = off
1 = close 2
secs
2 = stay closed
3 = pulse
4 = toggle
5 = duration 1††
6 = duration 2††
Output
Number
1-18= dev
Device
Type
R = relay
T = trigger
X = X10
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
†† Duration is set in program field *177. Duration 1 (action 5) is from 15 seconds to 15 minutes. Duration 2 (action 6) is from 1 day to 7 days.

– 14 –
Start Output Definition mode by pressing ∗
∗∗
∗80 while in Data Programming mode.
Output Funct. #
(00 = Quit) 01
Enter the output function number to be defined
01-48 = output function number
[∗] to continue
00 = exit
01 A E P Trig
?00 0 0 –ZL=1
This screen displays a summary of the current output programming
A = Output Action; E = Triggering event; P = Partition; Trig = Trigger type
Question mark indicates the device shown has not been mapped. Use *79 Menu mode to map the device.
[∗] to continue
01 Activated By:
Zone List
Select where the initiating event for this output definition is to occur.
0 = delete (deletes the output function and any previous programming)
Delete? To delete this output definition, press 1.
0 = NO, 1 = YES If you do not want to delete this output,. press 0.
1 = zone list (go to “A”prompt)
2 = zone type (go to “B”prompt)
3 = zone number (go to “C”prompt)
[∗] to continue
“A”
01 Zn List
1
If zone list was selected, this screen appears. Otherwise skip to the next row.
Enter the desired zone list number associated with this output number:
01-12 = zone list (Do not use zone lists 09-11 in output definitions if they are being used for paging)
Enter the zone list event that will activate this output:
Enter Event 0 = restore; 1 = alarm;
Alarm 1 2 = fault; 3= trouble
[∗] to continue
NOTE: For alarm, fault, and trouble, an event on ANY zone in the list activates the output, but ALL zones in
the list must be restored before the output is restored.
Press [∗] to continue and skip to the “Output Action”prompt.
“B”
01 Enter Zn type
Perimeter 03
If zone type was selected, this screen appears. Otherwise skip to the next row.
Enter the desired zone type for this output number. See list above *80 Worksheet for zone types.
Enter the partition in which this zone type will occur.
01 Partition 0 = any partition; 1 = partition 1;
Any partition 0 2 = partition 2; 3 = partition 3
Press [∗] to continue and skip to the “Output Action”prompt.
“C”
01 Enter Zn No.
12
If zone number was selected, this screen appears.
Enter the desired zone number associated with this output number.
Press [∗] to continue.
Enter the zone event that will activate this output.
01 Enter Event 0 = restore; 1 = alarm/fault/trouble
Restore 0
Press [∗] to continue to the “Output Action”prompt
01 Output Action
Close for 2 sec 1
Enter the desired device action as listed below.
0 = off 4 = Change Device State
1 = Close for 2 seconds 5 = Duration 1 (see data field *177 entry 1, from 15 secs to 15 minutes)
2 = Close and Stay Closed 6 = Duration 2 (see data field *177 entry 2, from 1 to 7 days)
3 = Pulse 1 sec ON, 1 sec OFF
Press [∗] to continue.
Enter Output No.
R02 02
Enter the device output number (programmed in *79 Menu Mode) you want associated with this output.
01-16 = output no.
17-18 = on-board triggers
Press [∗] to continue.
02 A E P TRIG
R02 1 1 3 ZL=1
A summary screen appears showing the programmed settings.
Press [∗] to return to output function number prompt.

– 15 –
✱81 ZONE LISTS
List No. Used For… Contains These Zones…
01 General Purpose (GP)
02 General Purpose
03 Chime-by-Zone or GP
04 Linked Zones
05 Night-Stay Zones or GP
06 General Purpose
07 General Purpose
08 Final Contact Set Zones or G P
09 Zones activating pager 1 or G P
10 Zones activating pager 2 or G P
11 General Purpose
12 Exit Zones (*88) or GP
NOTES:
•Any list may include any or all of the system's zone numbers.
•A zone list can be assigned to more than one output relay.
•When creating zone list 4 for cross zoning, include only zones assigned to zone types 3, 4, or 5. Do not include zones that have delays
(entry/exit zones, interior w/delay) or 24-hour zones, as these zone types may produce unpredictable operation and may not function as
intended.
Start Zone List Program Mode by pressing ∗
∗∗
∗81 while in Data Programming mode.
Zone List No.
(00 = Quit) 01
Enter the Zone List Number to program (or 00 to end these entries).
01-12 = zone list number
[∗] to continue
01 Enter Zn Num.
(00 = Quit) 00
Enter each zone number to add to the zone list.
01-64 = zone numbers followed by [∗] to accept each zone
00 to continue
IMPORTANT: Do not include fire zones in zone lists that are used to STOP device actions.
01 Del Zn List?
0 = No 1 = Yes 0
0 = don’t delete list; current zone list remains saved
1 = delete this zone list; All zones in the zone list will be deleted automatically and the system returns to the
Zone List No. prompt.
[∗] to continue
01 Delete Zone?
0 = No 1 = Yes 0
0 = don’t delete zones; save zone list and return to the Zone List No. prompt.
1 = go to next prompt to delete zones
[∗] to continue
01 Zn to Delete?
(00 = Quit) 00
Enter each zone to be deleted from the list
01-64 = zones to be deleted from list followed by [∗] to accept each zone
00 when done to return to the Zone List No. prompt

– 16 –
*82 DESCRIPTOR PROGRAMMING
Start Zone Descriptor Programming mode by pressing *82 while in Data Programming mode.
Program Alpha ?
0=No, 1=Yes 00
The “Program Alpha ?”prompt appears.
1 = program zone descriptors, partition descriptors, or reminder words
0 = exit
[∗] to continue
Sel Zone Des=0
Part/Rmndr=1
This prompt selects whether you are entering zone descriptors or entering partition descriptors and/or
“reminder”words (for Scheduling mode). NOTE: Do not assign reminder words if using fixed-word keypads.
0 = create zone descriptors (see Zone No? prompt below)
1 = create partition descriptors or reminder words
[∗] to continue
If “1”selected, the following prompt appears.
Enter the 2-digit custom word number (08-13) to be programmed, then press [∗].
PART/REMIND? 00 08-10 = “reminder”words used with scheduling mode, event “10”
11 = partition 1 descriptor; 12 = partition 2 descriptor; 13 = partition 3 descriptor
Enter the descriptor as described in steps 1-3 in the Zone Number section below.
Zone No.? 00
Enter the zone number for the descriptor you are programming.
Press [∗] to continue. Acursor appears at the beginning of the second line.
Special Keys:
[6] = accept character and move cursor to next position to right
[4] = move cursor to left
[8] = save descriptor
1. Refer to the Character Chart below.
Press [#], followed by the 3-digit entry for the first letter you want to display (e.g., # 0 6 5 for “A”).
Press [6] to move the cursor to the right, in position for the next character.
2. Repeat Step 1 to enter the next characters until the desired descriptor is entered. You can use the [4]
key to move the cursor to the left, if necessary.
Zone descriptors can be a maximum of 16 characters.
Reminder words/Partition descriptors can be a maximum of 10 characters.
3. When done, press the [8] key to save the descriptor and return to the “Zone No. ?”prompt. To enter a
descriptor for the next zone,
4. Enter the zone number for the next descriptor, press [∗], and repeat steps 1-3.
To change a custom word, simply overwrite it.
To exit, enter zone number “00.”
CHARACTER (ASCII) CHART (For Creating Zone/Partition Descriptors and Reminder Words)
032 (space)
033 = !
034 = "
035 = #
036 = $
037 = %
038 = &
039 = '
040 = (
041 = )
042 = *
043 = +
044 = ,
045 = –
046 = .
047 = /
048 = 0
049 = 1
050 = 2
051 = 3
052 = 4
053 = 5
054 = 6
055 = 7
056 = 8
057 = 9
058 = :
059 = ;
060 = <
061 = =
062 = >
063 = ?
064 = @
065 = A
066 = B
067 = C
068 = D
069 = E
070 = F
071 = G
072 = H
073 = I
074 = J
075 = K
076 = L
077 = M
078 = N
079 = O
080 = P
081 = Q
082 = R
083 = S
084 = T
085 = U
086 = V
087 = W
088 = X
089 = Y
090 = Z
091 = [
092 = ¥
093 = ]
094 = ^
095 = _
096 = `
097 = a
098 = b
099 = c
100 = d
101 = e
102 = f
103 = g
104 = h
105 = i
106 = j
107 = k
108 = l
109 = m
110 = n
111 = o
112 = p
113 = q
114 = r
115 = s
116 = t
117 = u
118 = v
119 = w
120 = x
121 = y
122 = z
123 = {
124 = |
125 = }
126 = →
127 = ←

–17 –
*83 CONFIGURABLE ZONE TYPE PROGRAMMING
CONFIGURABLE ZONE TYPE WORKSHEET
Option ZT 90 ZT 91 ZT 92 ZT 93 Option Selections
Zone Attributes
Bypass Option
Response to Short
Response to Open
Vent Zone
Zone Processing
Sound on Trouble
Sound on Alarm
Dial Delay
Display Options
Contact ID Code
Zone Attributes
0 = none
1 = exit delay only
2 = entry/exit 1
3 = entry/exit 2
4 = follows entry/exit
5 = has verification†
6 = resettable
Bypass Option
0 = cannot be bypassed
1 = auto bypassed when
armed STAY
Response to Short/Open
0=none 2=trouble
1=Alarm 3=fault
Vent Zone
0=no; 1=yes
Zone Processing
0=none
1 = Zone type has
automatic restore
2 = zone type uses Misc.
Fault Delay Time and
automatic restore
Sound on Trouble
0=none
1=1 beep every minute
2= fast beeps normal
Sound on Alarm
0=none
1= keypad sound only
2= steady siren sounding
3= pulsing siren (temporal)
Dial Delay
0=no; 1=yes
Display Options
0=no display
1=display only
2 = chime only
3 = chime & disp.
Contact ID Code
000-999
Start Configurable Zone Type Programming Mode by pressing ∗
∗∗
∗83 while in Data Programming mode.
Enter Zone Type
(00=quit) 90
Enter the configurable zone type number being programmed.
90-93
[∗] to continue
90 Zn Attributes
0
Enter the desired zone attributes.
0 = none 4 = follows entry/exit
1 = exit delay only 5 = has verification (resets power upon event and when code + OFF to clear
2 = entry/exit 1 condition. If condition persists, zone activates)
3 = entry/exit 2 6 = resettable (upon code + OFF)
[∗] to continue
90 Bypass Option
0
Enter the desired bypass option.
0 = zone type cannot be bypassed
1 = auto bypassed when armed in stay mode
[∗] to continue
90 Resp to Short
Armed 0 DArmd 0
Select the type of response when zones assigned to this zone type are shorted when the system is armed.
0=none 2=trouble NOTE: •For double-balanced zones, this entry must be 0.
1=alarm 3=fault •For zone-doubled zones, both zones of the doubled pair must
[∗] to continue be assigned the same response to a short.
90 Resp to open
Armed 0 DArmd 0
Select the type of response when zones assigned to this zone type are opened when the system is armed.
0 = none 2 = trouble
1 = alarm 3 = fault
[∗] to continue
90 Vent Zone
0 = No, 1 = Yes
If selected, the system can be armed even if zones assigned to this zone type are faulted.
NOTE: After arming, faults on these zones will be ignored until the zone is restored.
0=no; 1=yes; [∗] to continue
90 Alm/Trbl Proc
0
Select desired actions for zones assigned to this zone type.
0=none; 1=Zone type has automatic restore; 2=zone type uses Misc. Fault Delay Time (selected in field *87)
and automatic restore; [∗] to continue
90 TRBL SOUND
0
Select type of sounding upon trouble conditions on zones assigned to this zone type.
0=none; 1=one beep every minute; 2= normal trouble sound (fast beeps)
[∗] to continue
90 ALARM SOUND
0
Select type of sounding upon alarm conditions on zones assigned to this zone type.
0=none; 1= keypad sound only; 2= steady siren sounding; 3= pulsing siren (temporal)
[∗] to continue
90 Dial Delay
0=No, 1=Yes
If selected, faults on zones assigned to this zone type will delay reporting for whatever length of time that is
selected in dial delay (*50)
0=no; 1=yes; [∗] to continue
90 Disp Option
1
Select whether faults on zones assigned to this zone type are displayed at the touch pad and/or cause a
chime sound.
0=no display; 1=display only; 2 = chime only; 3 = chime & display; [∗] to continue
Alarm ID: 000
Trouble ID: 000
Enter the desired 3-digit (000-999) Contact ID report codes for faults and troubles occurring on zones
assigned to this zone type.
[∗] to continue; returns to Enter configurable zone type number prompt.
IMPORTANT:
•Make sure the code does not conflict with existing, predefined Contact ID report codes. See the
System
Communication
section in the Installation Instructions for a list of standard Contact ID codes.
•Zone alarm report code (prompt in *56 Zone Programming) and Trouble report code (*60) and relevant
restore codes (*70, *71) must be enabled in order for the Configurable Zone Type codes to be reported.

–18 –
Schedules (installer code + [#] + [6] [4]; master code can only access schedules 01-24 and events 00-08 )
Sched
No.
Event
(see list
below)
Device No.
for event
“01”:
relays = 01-
16
triggers = 17,
18
User
Group
for event
“02”:
enter 1-8
Partition
for events
“04-06”:
enter 1, 2,
or 3
Start Time/ Days
select days by
entering“1”under
each desired
HH:MM SMTWTFS
Warning
Delay
Time
01-15 =
minutes
Stop Time/ Days
select days by
entering“1”under
days desired
HH:MM SMTWTFS
Repeat
enter
0-4
(see list
below)
Random
0 = no
1 = yes
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
Events: Master/Installer Installer Only Repeat Options:
00 = clear event 05 = forced AWAY arm 10 = display reminder words 8-10 0 = no repeat
01 = device on/off 06 = auto disarm 11 = periodic test report 1 = repeat weekly
02 = user access 07 = display “reminder”12 = up and about 2 = repeat every other week
03 = child not home report 08 = disarm time window 3 = repeat every 3rd week
04 = forced STAY arm 4 = repeat every 4th week
Start Scheduling mode by entering installer code + [#] + [6] [4] while in normal operating mode.
NOTE: The master code can only access schedules 01-24 and events 00-08.
ENTER SCHED NO.
00=QUIT 00
Enter the desired schedule number.
01-24 = end-user schedules
25-32 = installer-only schedules
[∗] to continue
ENTER EVENT
NOTE: Events 07 and 10
cause the keypad to beep
every 30 seconds when
messages are displayed.
Stop the beeps by user code
+ OFF.
Enter the desired event number for event you want to occur at a specified time.
00 = clear event
01 = Relay On/Off
02 = User Access
03 = Child Not Home Report to Pager (sent to all pagers in the user’s partition; message sent is 777-7777;
user must be enabled for paging)
04 = Forced Stay Arming (Forced bypass is automatically enabled regardless of setting in field *23)
05 = Forced Away Arming (Forced bypass is automatically enabled regardless of setting in field *23)
06 = Auto Disarm
07 = Display “Reminder”
08 = Disarm Time Window (system can be disarmed only during this time period. Exception: If a burglary
alarm occurs, the system can be disarmed outside the scheduled time window.
10 = Display Custom Words (installer only; if selected, system displays custom words 8, 9, and 10 at defined
time. Can be used as installer’s reminder message to the end user)
11 = Periodic Test Report (installer only)
12 = Up and About (This selection defines the large time window within which the time window selected in
data field *85 will be monitored)
[∗] to continue

–19 –
DEVICE NUMBER
XX
This prompt appears if event “1”(relay on/off) was selected, otherwise it is skipped.
Enter the physical device number as programmed in ∗79 Menu Mode, then press [*] to continue to the “Start”
prompt.
Device numbers 17 and 18 designate built-in triggers 1 and 2 respectively.
01-18 = device number
[∗] to continue
GROUP NUMBER
X
This prompt appears if event “2”(user access) was selected. Otherwise it is skipped.
1-8 = group number
[∗] to continue to the “Start”prompt.
PARTITION
X
This prompt appears if events “3-7, or 10”were selected. Otherwise it is skipped.
0 = all partitions; 1 = partition 1; 2 = partition 2; 3 = partition 3
[∗] to continue
START SMTWTFS
HH MMAM 0010000
Enter the event’s start time and days of the week to occur.
To select days, position the cursor under the desired days using the [∗] key to move forward, then press “1”
to select the day.
01-12 (00-23) = hour (use 00-23 if 24-hour time is enabled)
00-59 = minute
0 = AM; 1 = PM
Days = place “1”under days
[∗] to continue
WARNING DLY TIME
00
This prompt appears if events “4 or 5”were selected.
Enter the desired amount of time the system should warn of impending arming. The system will beep once
every 30 seconds to alert users that arming will soon occur. Otherwise, this prompt is skipped.
01-15 = minutes of arm warning delay time
[∗] to continue
STOP SMTWTFS
HH MMAM 0010000
Enter the event’s stop time and days of the week to occur.
To select days, position the cursor under the desired days using the [∗] key to move forward, then press “1”
to select the day.
This entry applies only to the following events: 1 (relay on/off); 2 (user access); 3 (child-not-home report)
01-12 (00-23) = hour (use 00-23 if 24-hour time is enabled)
00-59 = minute
0 = AM; 1 = PM
Days = place “1”under days
[∗] to continue
REPEAT OPTION
0-4 X
Enter the desired repeat option for this schedule.
e.g., To make a schedule that happens everyday you would select all days with a repeat count of 1. To make
a schedule that runs for one week then stops, select everyday with a repeat count of 0.
0 = do not repeat
1 = repeat schedule weekly
2 = repeat schedule biweekly (every other week)
3 = repeat schedule every third week
4 = repeat schedule every fourth week
[∗] to continue
RANDOMIZE
0=NO 1=YES X
If selected, the scheduled start and stop times will vary within 60 minutes of the “hour”time. For example, if a
schedule is set to start at 6:15pm, it will do so the first time 6:15pm arrives, but on subsequent days it will
start anytime between 6:00 and 6:59 p.m.
NOTE: Do not use the random option if the start and stop times are within the same “hour”setting, otherwise
unpredictable results may occur (e.g., the randomized stop time may occur before the start time).
0 = no
1 = yes
[∗] to continue

–20 –
–NOTES –
