Honeywell Galaxy 2 Series User manual

Galaxy 2 Series
Installation Manual
Honeywell Security

Galaxy 2 Series Installation Manual
i
Table of Contents
Contents
SECTION 1: INTRODUCTION .................................................................... 1
Optional Peripherals ............................................................................................. 1
Features.................................................................................................................. 2
RF ........................................................................................................................................... 2
Groups................................................................................................................................... 2
Dialler ..................................................................................................................................... 2
SMS Text Messaging............................................................................................................ 2
ProxKeypads ........................................................................................................................ 2
Remote Servicing ................................................................................................................. 2
SECTION 2: QUICK GUIDE ........................................................................ 3
How to Boot up ...................................................................................................... 3
Default Codes......................................................................................................... 3
Menu Access Operation/Navigation .................................................................... 3
How to get in and out of Engineer Mode ............................................................ 3
How to Set/Unset.................................................................................................... 3
How to Restore an Alarm ...................................................................................... 4
SECTION 3: SYSTEM ARCHITECTURE .................................................... 5
SECTION 4: SYSTEM WIRING................................................................... 6
General Information .............................................................................................. 6
Siting ...................................................................................................................................... 6
Ventilation.............................................................................................................................. 6
Cabling .................................................................................................................................. 6
Mains Cable Type ................................................................................................................. 6
Zone and Data Cable Type.................................................................................................. 7
Mains Supply Connection................................................................................................... 7
Equipment Electrical Rating................................................................................. 8
Batteries ................................................................................................................................ 8
Fuses ..................................................................................................................................... 8

Galaxy 2 Series Installation Manual
ii
Table of Contents
Connecting the Galaxy 2 Series to the PSTN ..................................................... 9
Private Branch Exchange (PBX) Approval ........................................................................ 9
REN and SEN Numbers...................................................................................................... 10
SECTION 5: HARDWARE ......................................................................... 11
PCB Layout (2–44+) ............................................................................................. 11
PCB Layout (2–20) ............................................................................................... 12
Zones................................................................................................................................... 13
Zone Links .................................................................................................................................................13
Wiring Zones .............................................................................................................................................14
Wiring Keyswitches ................................................................................................................................... 14
Wiring Push-Set Buttons ............................................................................................................................ 14
Zone Addresses ................................................................................................................. 15
Zone Numbering System ..........................................................................................................................15
Outputs................................................................................................................................16
Trigger Header.................................................................................................................... 16
Trig 1-8 ....................................................................................................................................................... 16
Inputs .........................................................................................................................................................17
Supply .......................................................................................................................................................17
Data Buses .......................................................................................................................... 17
RS485 Wiring Configurations ..................................................................................................................... 17
RS485 Wiring Recommendations ............................................................................................................. 18
ECP Bus (2–44+ Only) .............................................................................................................................. 19
Built-in Dialler/Modem........................................................................................................ 19
LED’S.................................................................................................................................... 19
Audio Header (2–44+ Only) ............................................................................................... 19
GSM Interface (2–44+ Only)............................................................................................... 19
Panel Mounting (Plastic Box)............................................................................. 20
Installation Kit ..................................................................................................................... 20
Removing the Enclosure Lid ............................................................................................ 20
Installing the Enclosure Lid .............................................................................................. 20
Removing and Replacing the Galaxy 2 Series PCB ...................................................... 20
Remove the PCB ......................................................................................................................................21
Replace the PCB.......................................................................................................................................21
Mounting the Plastic Enclosure Base ............................................................................. 21
Fitting the Tamper Spring ................................................................................................. 21
Panel Mounting (Metal Box) ............................................................................... 22
Installation Kit ..................................................................................................................... 22
Removing and Installing the Enclosure Lid ................................................................... 22
Removing and Replacing the Galaxy 2 Series PCB ...................................................... 23
Mounting the Metal Enclosure Base................................................................................ 23

Galaxy 2 Series Installation Manual
iii
Table of Contents
Peripherals - Installation, Wiring & Addressing............................................... 24
Configuring ......................................................................................................................... 24
General ................................................................................................................................24
Mk7 LCD Keypad/Keyprox ................................................................................................ 25
Keypad/Keyprox Installation ..................................................................................................................... 25
Mk7 Keypad/Keyprox Addressing ........................................................................................................... 26
Adding a Mk7 Keypad/Keyprox to the System ........................................................................................26
Remote Input Output (RIO)................................................................................................ 27
Addressing the RIO ................................................................................................................................... 27
Connecting the RIO ................................................................................................................................... 27
Configuring the RIO ...................................................................................................................................28
Zones.........................................................................................................................................................28
Outputs ...................................................................................................................................................... 28
Power Supply Unit.............................................................................................................. 29
Configuration ..............................................................................................................................................29
Installation Instructions ............................................................................................................................... 30
Battery........................................................................................................................................................31
Battery Test ................................................................................................................................................ 31
Specifications ............................................................................................................................................31
EN50131 Compliance ................................................................................................................................ 31
ECP Zone Expander (2–44+ Only).................................................................................... 32
Zone Expander Outputs ............................................................................................................................32
Addressing the ECP Zone Expander .......................................................................................................33
5800H RF Receiver (2–44+ Only) ...................................................................................... 33
Installation ..................................................................................................................................................33
Wiring......................................................................................................................................................... 33
Addressing ................................................................................................................................................ 33
G2 RF Portal ........................................................................................................................ 34
Mounting the Plastic Base .........................................................................................................................34
Attaching the PCB......................................................................................................................................35
Addressing the RF Portal ..........................................................................................................................35
Connecting the RF Portal ..........................................................................................................................36
Configuring the RF Portal ..........................................................................................................................36
Attaching the Plastic Box Lid.....................................................................................................................36
Specifications ............................................................................................................................................36
EN50131 Compliance ................................................................................................................................ 36
6160 Keypad/Keyprox/RFH (2–44+ Only)........................................................................ 37
Installation and Wiring ................................................................................................................................37
Addressing the 6160 Keypad ...................................................................................................................38
Addressing the 6160 Keyprox ..................................................................................................................38
Addressing the 6160 RFH .........................................................................................................................38
2-Way Audio (2–44+ Only) ................................................................................................. 39
Operation of 2-Way Audio .........................................................................................................................40
GSM Module (2–44+ Only) ................................................................................................. 41
Characteristics ...........................................................................................................................................42
Compliance ............................................................................................................................................... 42

Galaxy 2 Series Installation Manual
iv
Table of Contents
SECTION 6: GENERAL OPERATION ...................................................... 43
Galaxy 2 Series Users ......................................................................................... 43
Users.................................................................................................................................... 43
Engineers ............................................................................................................................ 43
General Menu Operation..................................................................................... 43
Full Setting .......................................................................................................................... 44
Part Setting.......................................................................................................................... 44
Night Setting ....................................................................................................................... 45
Cancelling the Setting ....................................................................................................... 45
Unsetting the System ........................................................................................................ 45
Cancelling Alarms and Alerts ........................................................................................... 45
Alert Indication ................................................................................................................... 45
Restoring alarms ................................................................................................................46
Overriding of Faults and Tampers................................................................................... 46
Setting and Unsetting with Keyfobs ................................................................................ 47
Setting and Unsetting with Keytags or Cards ................................................................ 48
Text Programming.............................................................................................................. 49
Additional Functions ......................................................................................................... 50
Code Tampers ...........................................................................................................................................50
Hot Keys ....................................................................................................................................................50
SECTION 7: MENU OPTIONS .................................................................. 51
Menu 10 - Setting Options................................................................................................. 51
Option 11 - Omit Zones.............................................................................................................................. 51
Option 12 - Timed Set ............................................................................................................................... 51
Option 13 - Part Set ................................................................................................................................... 51
Option 14 - Night Set .................................................................................................................................51
Option 15 - Chime...................................................................................................................................... 51
Menu 20 - Display Options ................................................................................................ 52
Option 21 - Zone Status ............................................................................................................................. 52
Option 22 - View Log.................................................................................................................................52
Option 23 - System Version ......................................................................................................................53
Option 24 - Print ......................................................................................................................................... 53
Menu 30 - Test Options...................................................................................................... 54
Option 31 - Walk Test ................................................................................................................................54
Option 32 - Output Test ..............................................................................................................................54
Menu 40 - Modify Options ................................................................................................. 55
Option 41 - Time/Date................................................................................................................................ 55
Option 42 - Users ......................................................................................................................................55
Adding Keyfobs (ECP) .......................................................................................................................................... 57
Adding Keyfobs (RS485) ...................................................................................................................................... 57
Removing Keyfobs ............................................................................................................................................... 57
Adding Keytags or Cards - Mk7 485 Keyprox only ............................................................................................... 58
Adding Keytags or Cards - 6160 Keyprox only ..................................................................................................... 58

Galaxy 2 Series Installation Manual
v
Table of Contents
Removing Keytags or Cards - Mk7 485 Keyprox only ......................................................................................... 58
Removing Keytags or Cards - ECP 6160 Tags only ............................................................................................ 58
Option 44 - Mobile Nos .............................................................................................................................59
Option 47 - Remote Access ......................................................................................................................60
Option 48 - Level 3 Access .......................................................................................................................60
Menu 50 - Engineer 1 Options .......................................................................................... 61
Option 51 - Parameters .............................................................................................................................61
Option 52 - Zones ......................................................................................................................................73
Option 53 - Outputs....................................................................................................................................79
Option 56 - Comms ................................................................................................................................... 82
Option 57 - System Print ........................................................................................................................... 94
Menu 60 - Engineer 2 Options .......................................................................................... 95
Option 61 - Diagnostics ............................................................................................................................. 95
Option 62 - Full Test...................................................................................................................................96
Option 63 - Options ................................................................................................................................... 97
SECTION 8: RF HINTS AND TIPS ............................................................ 99
How to Install RF................................................................................................................. 99
RF Zones ............................................................................................................................. 99
RF Stop Set ......................................................................................................................... 99
RF Diagnostics ................................................................................................................... 99
SECTION 9: FINAL COMMISSIONING ................................................... 100
Final system Test ............................................................................................................. 100
User Information............................................................................................................... 100
SECTION 10: REMOTE SERVICING ...................................................... 101
Telephone Line Set-Up .................................................................................................... 101
Direct Wire Set-Up ............................................................................................................ 101
Remote Programming ..................................................................................................... 101
SECTION 11: FLASH UPGRADE ........................................................... 102
SECTION 12: PRINTER CONNECTION ................................................. 103
SECTION 13: BELL-BOX CONNECTIONS ............................................ 104
SECTION 14: EVENT LOG LIST ............................................................ 105

Galaxy 2 Series Installation Manual
vi
Table of Contents
SECTION 15: SPECIFICATIONS ............................................................ 108
SECTION 16: COMPLIANCE AND APPROVALS................................... 110
EN50131 Compliance....................................................................................................... 110
Public Switched Telephone Network (PSTN) Approval ............................................... 110
HONEYWELL SECURITY LIMITED WARRANTY ....................................111
Appendix A: Point ID Comms Triggers................................................ A-1

1
Galaxy 2 Series Installation Manual
SECTION 1: INTRODUCTION
The Galaxy 2 Series is a 12-zone intruder alarm control panel. There are 2 variants. The 2-44+ is the full
function version which is expandable to 44 zones. The 2-20 is an entry level version which is expandable to
20 zones. This manual covers both versions. However, certain features are not available on the 2-20 variant.
The following table gives the general specification for both variants.
Table 1. General Specifications
The Galaxy 2 Series requires at least one external keypad for programming and general operation. There are
two main types of keypad available.
Galaxy Mk7 LCD Keypad: This keypad has a 2 x 16 character display and operates on the RS485 data
bus. Optionally, a keyprox version is available. This is a standard Mk7 keypad with a proximity card reader
built in to the lower right-hand corner. The keyprox is for set/unset only.
6160 Full Text Keypad: This keypad has a 2 x 16 character display and operates on the ECP data bus.
Optionally versions are available with built-in prox reader and wireless receiver.
Optional Peripherals
Zone Expander: This gives eight extra hardwire zones and four programmable outputs.Alternatively four
extra hardwire zones and no outputs.
Introduction
SpecificationFeature
Galaxy 2-20 Galaxy 2-44+
Zones 12 expandable to 20 12 expandable 44
Outputs 4+8 expandable to 16 4+8 expandable to 28
Databuses RS485 Only RS485 and ECP
PSU 1A (0.6A @ Grade 2) 1.4A (1A @ Grade 2)
Alphanumeric LCD Keypads/
Alphanumeric LCD KeyProx
4 4
RIO (8 zones/4 outputs) 1 4
RF Receiver 2 2
User Codes (PIN and Card) 23 23
Groups 3+1 common group 3+1 common group
Part Set 2 Part Sets 2 Part Sets
Silent Night Set Yes Yes
Zone Types 18 18
O/P Types 23 23
Event Log 384 384
Multi-Users 4 4
Printer Module Optional Optional
PSTN Communicator/Modem On-Board On-Board
GSM Comunicator/Modem - Plug on Option
Serial Port 1 on-board 1 on-board
2-way Voice - Optional

2
Galaxy 2 Series Installation Manual
RF Radio Receiver: This allows the control panel to receive signals from wire-free detectors and radio
keyfobs. One radio receiver will allow the panel to assign wire-free detectors to any or all of the 44 detection
zones. However, two receivers can be used to increase coverage.
Proximity Card Reader: This allows users to set/unset simply by swiping a card or tag in front of the reader.
The proximity card readers are built into the housing of the keypads.
RIO/ PSU Control: Up to four RIO’s or PSU’s can be added to the RS485 Bus. Each RIO/ PSU Control
expands the system by eight zones and four outputs.
GSM Module: This module provides mobile telecommunications between the panel and theAlarm Receiving
Center (ARC).
Features
RF
The system operates with the 5800 receivers on ECP and/or the RF Portal on RS485.Amaximum of two RF
receivers can be fitted to the system (two on the ECP bus, two on the RS485 bus or one on each bus), to
support up to 44 zones. The RF receivers are in addition to the prox keypads on RS485 but in place of ECP
prox keypads.
Groups
Group functionality allows the system to be split into three individual sub-systems that can be set and unset
independently.Additionally there is a fourth common group which will set automatically when all the other
groups have set. It is unset as soon as any one group has been unset by a user. Zones are assigned users to a
single group only. Users are assigned to one or more groups.
Dialler
The system can have two active comms devices configured, chosen from:
• On-board PSTN/Modem
• Plug-on GSM Module
These are used for Dial-up primary and secondary signalling, as well as remote servicing and two-way audio.
SMS Text Messaging
This is a secondary alarm notification to keyholders. Text messages are sent to GSM mobile phones, giving
information on panel events.
ProxKeypads
These are standard keypads with an added proximity card reader, combined into one housing. This allows
dual function setting/unsetting ability from the one station without the need for a separate card reader. They
are primarily intended for use in situations where a PIN card is needed to set and unset the intruder alarm
system.
Remote Servicing
The Galaxy 2 series control panel can be remotely and/or locally serviced by a Personal computer (PC). This
is accomplished when the Remote Servicing Software is installed on the PC.
Introduction (cont’d)

3
Galaxy 2 Series Installation Manual
SECTION 2: QUICK GUIDE
How to Boot up
Wire up the keypads, address them (see Peripherals - Installation, Wiring andAddressing), then apply power
to the system. The keypads will configure and show the default banner display.
Default Codes
Default User Code: 1234
Default Engineer code: 112233
Menu Access Operation/Navigation
Only valid codes can access the Galaxy 2 Series menu options.
Type the code then press ent to access the menu.
Data entry, on both ECP and RS485 keypads, is via the 0-9 function keys and the *, #on the keypad.
The A> and <B keys are curser or scroll keys and are used to scroll through options in menus.
The ent key is used to enter a PIN code and to accept screen information.
The esc key is used to cancel or exit from the current operation.
NOTE: Users cannot view or access options for which they are not authorised.
How to get in and out of Engineer Mode
Entry to engineer mode is authorised by a user in menu option 48 = Level 3Access. Following this the
engineer will have five minutes in which to enter his code. When the engineer code is entered four things
happen:
• All system tampers become isolated.
• All fault signalling is suppressed, and indications are silent.
• The engineer is given access to the full menu.
• The banner message is changed to indicate engineer mode.
To bring the system back out of engineer access mode and reinstate all the tampers from the banner, the
engineer enters his code but presses the esc key rather than the ent key.
How to Set/Unset
To Full Set the system, the user types their code then presses the Akey.
To Part Set the system, the user types their code, presses the B key then presses the [1] key.
To Night Set the system, the user types their code, presses the Bkey then presses the [2] key.
To Unset the system, the user types their code then presses ent.
GalaxyGalaxy
GalaxyGalaxy
Galaxy 44 V1.044 V1.0
44 V1.044 V1.0
44 V1.0
09:51 SAT 01 JAN09:51 SAT 01 JAN
09:51 SAT 01 JAN09:51 SAT 01 JAN
09:51 SAT 01 JAN
Quick Guide

4
Galaxy 2 Series Installation Manual
How to Restore an Alarm
Alarms, faults and tampers will be restored provided:
1. The cause has cleared
2. An authorised user PIN code or anti-code has been entered.
3. The conditions have been viewed on the keypad display after steps 1 and 2 above.
If a user cannot restore all the conditions, a temporary banner is displayed to indicate that a manager or
engineer is required to restore the system. This lasts for 30 seconds before the normal banner is displayed.
Quick Guide (cont’d)

5
Galaxy 2 Series Installation Manual
SECTION 3: SYSTEM ARCHITECTURE
Figure 1. Galaxy 2 Series System Configuration
Architecture
12 on-board zones
Galaxy 2-44
PCB
Trigger
Header
12-way ribbon cable External
Communicator
ECP BUS (2 44+ only)
4 outputs
Phone line
Serial Port to PC
Maximum cable length
from panel to last module
on line is 100m
6160 keypad (4)
(optionally with
built-in
receiver/keyprox)
Note: maximum of
2 receivers/keyproxes
ECP zone expander
8 zone, 4 output (3)
5800 RF
receiver (2)
Standard 4-core cable
spurred or T wired
Note: A maximum of 4 keypads
(including keyprox) can be
connected to the RS485 line.
GALAXY 44 V1.0
09:51 01/08/04
123
A
456
B
789
ent
*
0
#
esc
Mk7 LCD
Keypad/Keyprox
(4)
RF Portal (2)
8 zones
4 outputs
8 zones
4 outputs
Power Unit (4) P025
or
Power RIO (4) P026
RIO (4)
C072
OR
RS485 BUS
Twisted pair screened cable
Belden 8723 equivalent.
Daisy chain configuration only.
Maximum cable length
from panel to last module
on line is 1km
MODULE TOTAL
QTY
ADDRESSES
AVAILABLE ECP RS485 PLUG-ON
Keypads 4 0,1, 2, 3 4 4
Keyprox 4 0,1, 2, 3 2 2
Expanders*4 on RS485
or
3 on ECP
2, 3, 4, 5 3 4
RF Receivers 2 4, 5 2 2
PSU Control/RIO 4 2, 3, 4, 5 - 4
GSM (2-44+ only) 1 ---1
2-way Voice (2-44+ only 1 ---1
* Only the first expander can be used on the 2-20

6
Galaxy 2 Series Installation Manual
System Wiring
SECTION 4: SYSTEM WIRING
General Information
It is essential that this product is installed correctly, in particular with respect to a person’s safety and connec-
tion to the mains electricity supply. This product is not suitable for installation, maintenance or connection by
the user.Acompetent, qualified engineer, with for example NACOSS approval, must carry out installation and
maintenance.
Siting
The control panel enclosure (plastic box or metal box), must be sited indoors in a secure area where it cannot
be readily interfered with. There must be adequate ventilation, ample light and easy access for servicing and
maintenance. It is not suitable for siting externally or in harsh environments where it could be subject to high
humidity, extremes of temperature, chemical atmospheres, high dust levels, or in a position where it may be
subject to being dripped on, or splashed by, water or other fluids.
The enclosure base must be securely fixed to a vertical, smooth, solid surface that is a part of the fabric of the
building. The position chosen must allow the cabinet lid to be removed and allow unhindered access for
installation and maintenance.
Ventilation
While the control panel has been designed so that no part attains an unsafe temperature it is important that
adequate ventilation is provided around the cabinet, therefore the cabinet must not be positioned close to
heat-radiating equipment or other sources of heat.
Cabling
The panel has high voltage barriers between the a.c. mains supply and the alarm wiring terminals. It is essential
that these barriers be maintained in the way the cables enter the cabinet, are routed inside the cabinet, and are
routed externally.
Additional holes must not be cut in the enclosure, rear entry points are provided for cables.Alarm system
cables must be neatly trimmed and not allowed to loop inside the cabinet.
Cables external to the cabinet must be either firmly affixed to the fabric of the building using suitable clips or
saddles, or mechanically protected in conduit or trunking. It must not be possible to put strain on the wiring
within the control cabinet by pulling on cabling external to the cabinet.
It must not be possible to push a finger or similar size object or instrument into any hole or cable entry point.
Mains Cable Type
The conductors of the mains supply cable must have a minimum cross-sectional area of 0.75 mm and the
insulating material on each conductor must be a minimum of 0.4 mm thick Polyvinyl Chloride (pvc). Flexible
cables must conform to the requirements of BS6500 and IEC Publication 227. Non-flexible electrical installa-
tion cables must conform to BS6004.

7
Galaxy 2 Series Installation Manual
NOTE: Connections shown as dashed lines
are factory made. The metal box
must be earthed.
Figure 2. Mains Connection to the Galaxy 2 Series
The outer covering insulation must be clamped under the cable clamp. It is important that this cable enters the
control panel enclosure through the mains entry hole next to the mains terminal block, is not looped within the
control panel enclosure and does not run close to other system cables inside or external to the enclosure.
WARNING: The control panel enclosure must not be opened before isolating the mains supply.
Illumination of the green power LED 2 indicates the presence of a.c. mains supply. The
cover of the Galaxy 2 Series enclosure must be replaced whenever any connection to the
BT master socket is completed to prevent exposure to potentially lethal voltages from the
PSTN.
System Wiring (cont’d)
Zone and Data Cable Type
Zone cables and all cables between the panel, keypads and expansion modules must be as follows:
RS485 Bus: Twisted pair screen cable Belden 8723 equivalent. For systems with less than 100m cable run
in total, standard 4-core alarm cable may be used in most normal environments.
ECP Bus and Zone Cables: Standard 4-core alarm cable.
Zones: Standard 4-core alarm cable.
Mains Supply Connection
The connection to the a.c. mains supply must be made by a competent, qualified person, for example NICEIC
approved, in accordance with the current IEE and local supply regulations.
Warning: A means of isolation from the mains supply must be provided within two metres of the
control panel. Where live and neutral supplies can be identified, a fused spur with a 3A
fuse, must be fitted on the live circuit. Where live and neutral circuits cannot be reliably
identified, 3A fuses must be fitted to both circuits.
Where a flexible cable is connected to the control having cores coloured brown and blue it is important to
connect the wires to the mains terminal block as follows:
• Blue (Neutral) – connect to terminal N
• Green/Yellow (Earth) – connect to terminal E
• Brown (Live) – connect to terminal L
From a.c. mains input
(entering next to terminal block)
Brown Wire
Blue Wire
Galaxy 2 Series PCB
Mains Transformer
Primary Side
Mains Transformer
Secondary Side
200 mA
mains fuse
TB2
Batt+ Batt-
AC Power

8
Galaxy 2 Series Installation Manual
Equipment Electrical Rating
The control equipment is designed to operate on a mains supply of 230 Volts a.c. (230 V +10% -15%) at a
frequency of 50 Hz. It is not suitable for other types of supply. The maximum current consumption in normal
use is 200 mA.
Batteries
The battery used with the control panel must be a 12 V sealed lead-acid rechargeable battery of up to 7Ahr
(plastic box) or 17Ahr (metal box) capacity on the 2-44+ and 12 Ahr on the 2-20. The battery must be
positioned on the battery shelf. Wire in battery leads to panel terminals (red lead to Batt+, black lead to
Batt-). The battery leads must be connected to the battery observing terminal polarity and not left hanging
near the mains terminal block.
Fuses
The mains supply must be disconnected before opening the cabinet and changing the fuse. Replace the mains
fuse with the same type and rating. Refer to SECTION 15: SPECIFICATIONS.
System Wiring (cont’d)

9
Galaxy 2 Series Installation Manual
Connecting the Galaxy 2 Series to the PSTN
The Telecommunications Network Voltage (TNV) port (terminalsAand B on TB1) must be permanently
connected (hard-wired) to the PSTN via a BT master socket, refer to Figure 3.
Note: If the BT master socket is the newer type (NTE5/CTE5), then the connection can be carried out by the
installation engineer. If the BT master socket is not an NTE5/CTE5, then the network operator must make the
connection.
Figure 3. Connecting the Galaxy 2 Series to the PSTN
NOTES: 1. Terminals 2 and 5 on the BT Master Socket must be hard-wired to theAand B terminals
(TB1)on the Galaxy 2 Series PCB. The connection is polarity independent.
2. It is strongly recommended that the Galaxy 2 Series panel is the only device on the line.
3. If another device is to be connected to the line, connect the PHONE terminals on the PCB
to terminals 2 and 5 on a second BT Master Socket and connect the additional devices to
the second socket.
Using cable suitable for connection to 2.8 mm diameter screw terminals, strip back approximately 20 mm of
the outer sheath and then remove approximately 4 mm of the insulation from the wires to be connected to the
Galaxy 2 Series.
Connect terminals 2 and 5 on the BT Master socket across theA and B terminals (TB1) on the Galaxy 2
Series, see Figure 3.
Private Branch Exchange (PBX) Approval
The Galaxy 2 Series may be used with some analogue PBX exchanges. The correct operation of the Galaxy
2 Series cannot be guaranteed under all possible conditions of connection to compatible PBXs.
System Wiring (cont’d)
Incoming
PSTN Line
A B
Galaxy 2 Series PCB
PHONE
TB5
2
5
2
5
BT Master socket ( NTE5 / CTE5 ). BT Master socket (
NTE5 / CTE5 ).

10
Galaxy 2 Series Installation Manual
REN and SEN Numbers
It is possible to simultaneously connect a number of items to one line of the PSTN. The limit is determined by
summing the Ringer Equivalence Number (REN) shown on each item of apparatus, ensuring that the sum of
RENs is not more than four.
The REN of the Galaxy 2 Series is one (1).
Assume that all British Telecom equipment has a REN of one unless otherwise marked.
More than one item of series apparatus may be connected to the Galaxy 2 Series ports marked phone. This is
limited by summing the Series Equivalence Number (SEN) shown on each item of series connected apparatus,
ensuring that the sum of the SENs is not more than one (1). The total series resistance, including cabling, must
not exceed 50 Ohms.
• The SEN of the Galaxy 2 Series is 0.3.
• Nominal series resistance is 90 milli-ohms.
• Nominal insertion loss is 0.1 dB.
It is recommended that the PSTN should have the following facilities:
• Outgoing calls only (when used as dialler only).
• Direct exchange.
• Tone dialling.
System Wiring (cont’d)

11
Galaxy 2 Series Installation Manual
SECTION 5: HARDWARE
PCB Layout (2–44+)
Figure 4. Galaxy 2–44+ PCB Layout
PCB Layout
AC power Zone Terminals
COM N/O TRIG
N/C
BELL +12v
0v T
SAB Connections
Loudspeaker
DI
DO AUX+
AUX-
A
B
AUX+
AUX+
LED2
BELL FUSE
AUX FUSE
F3
F2
F1
BATTERY FUSE
Program Header
Processor
Alternative Phone Socket
B
A
B
LINE IN
A
Extension
Phone Output
Phone Line
Input
Data in
Data out
12V Aux
Output
RS 485 peripherals
BATT + BATT
-
Trigger Header Audio
Connector
LK1
RELAY
Engineer Header
Battery Terminals
For ECP peripherals
see Note
Note: If Relay is fitted the TRIG terminal is used as N/C for Relay. If Relay is not fitted the COM & N/O terminals are not fitted.The TRIG N/C terminal is the transistorised output.
HEATSINK
Tamper Spring and switch SW1 (plastic box only)
Note: Switch SW1 and the tamper spring are for the plastic box only. The metal box has a 2-way terminal for connection to the lid tamper microswitch.
RIO 0 RIO 1
12
0v 34
0v 56
0v 78910
0v 0v 11 12
0v
LED 1
Telecoms
2-way header RS485 termination
TAMPER

12
Galaxy 2 Series Installation Manual
PCB Layout (2–20)
Figure 5. Galaxy 2–20 PCB Layout
X1
B
A
LINE IN
B
A
910 11 12
12345678
COM N/O BELL
+12v
0V T
TRIG
(N/C)
LS
B
A
+
+
AUX
-
-
BATT +
BATT -
F1 (1 amp) BATT
F2 (0.5 amp)
F3 (0.5 amp)
AUX
BELL
PROG HEADER
Power
LED
AC Power
Input
Battery
Terminals
12 Volt
Auxilliary
Output
Loudspeaker
Negative
Trigger
Output
SAB
Connections Zone Terminals
Extension
Phone
Output
Phone
Line
Input
Alternate
Phone
Socket
Trigger
Header
RS 485
lines
Note: Switch SW1 and the
tamper spring are for the
plastic box only.
The metal box has a 2-way
terminal for connection to
the lid tamper microswitch.
Note: If Relay is fitted the TRIG terminal
is used as N/C for Relay.
If Relay is not fitted the COM & N/O terminals
are not fitted.The TRIG N/C terminal is
the transistorised output.
2-way header
RS485 termination
2-way
connector
