INSTALLATION INSTRUCTIONS
62-0208—3
H7625A, H7635A
Humidity/Temperature Sensors
WALL-MOUNT MODELS
APPLICATION
The H7625A, H7635A Wall-Mount Humidity/Temperature
Sensors are universal Relative Humidity transmitters that
can be powered with either a +18 to 36 Vdc or 24 Vac
supply. The sensors use a half-wave bridge rectifier to
convert AC power to a usable DC voltage. The device
also includes a 20K ohm temperature sensor for optional
use.
The humidity sensors are designed with a field selectable
4 to 20 mA, 0 to 5 Vdc, or 0 to 10 Vdc output signal
equivalent to 0 to 100% RH. All units are shipped from
the factory with a default setting to accept AC power with
three-wire, 0 to 10 Vdc loop-powered output.
INSTALLATION
When Installing this Product...
1. Read these instructions carefully. Failure to follow
them could damage the product or cause a
hazardous condition.
2. Check ratings given in instructions and on the
product to ensure the product is suitable for your
application.
3. Installer must be a trained, experienced service
technician.
4. After installation is complete, check out product
operation as provided in these instructions.
CAUTION
Electrical Shock or Equipment Damage
Hazard.
Can shock individuals or short equipment
circuitry.
Disconnect power supply before installation.
CAUTION
Equipment Damage Hazard.
Improper wiring can damage the sensor
beyond repair.
Follow the wiring instructions carefully.
Location
Install the device where it cannot be affected by:
— drafts, or dead spots behind doors and in corners.
— hot or cold air from ducts.
— radiant heat from sun or appliances.
— concealed pipes and chimneys.
— unheated (uncooled) areas such as an outside wall
behind the device.
Mounting
The housing base mounts over standard 2 in. x 4 in.
single gang junction box or flush to the wall:
1. Install the sensor about 5 ft (1.5m) above the floor
in an area with good air circulation at average
humidity and temperature. (See Fig. 1.)
2. Ensure the device receives adequate airflow.
3. Wire the device. (See Fig. 4 through 3.)
4. Ensure proper DIP switch settings.
5. Apply power to the unit.
6. Snap the cover into position.
7. Turn out the 1/16 in. allen screws at the bottom of
the enclosure until the cover cannot be removed.
Fig. 1. Typical sensor location.
5 FEET
(1.5 METERS)
YES NO
NO NO
M4823A

H7625A, H7635A HUMIDITY/TEMPERATURE SENSORS
62-0208—3 2
Output Settings (Table 1)
The board has three switch blocks:
— A six DIP switch block.
— A four DIP switch block.
— A white gang switch on a blue block.
1. Adjust the 4-switch block according to Table 1.
NOTE: The 6-switch block normally requires no
adjustment. (See the Appendix.)
2. Set the gang switch (white switch in blue block) to
correspond with the output (mA or Vdc).
NOTE: See Fig. 2 for DIP switch locations.
Table 1. Controller Compatibility
and Output Settings.
Fig. 2. DIP switch locations and settings.
WIRING
For voltage output, shielded cable (16-22 AWG) should
be used.
For current output, either shielded cable or twisted pair
(16-22 AWG) can be used.
IMPORTANT
When using shielded cable, ground the shield
only at the controller end (see Fig. 3). Grounding
both ends can cause a ground loop.
NOTE: See Table 2 for terminal designations.
Table 2. Terminal Designations.
Fig. 3. Typical wiring diagram for transducer with two-
wire mA output with external DC power supply.
Controller
Required
Sensor
Output
Setting
4-Switch Block
Settings
Blue and
White
Output
Switch
LONSPEC™
Setting4321
W7750, W7760,
W7761
4-20 mA — On — — 4-20 mA C7600C
W7750B,C
W7760C,
W7753, W7760
0-10 Vdc
(default)
On — — On Vout H7621/31
T7350, XL50,
XL100,
XL500 XF
Modules, XFL
0-10 Vdc
(default)
On — — On Vout n/a
Non-Honeywell 0-5 Vdc On — On — Vout n/a
M22659A
NORMAL
OPERATION
OFF ON
OFF
ON
0-10 VDC
OFF
ON
4-20 MA
0-5 VDC
OFF
ON
Terminal Designation
1mAout
2Vin(power)
3 GND (common)
4 Vdc (out)
520KNTC
620KNTC
mA OUTPUT
TRANSDUCER
ONLY
18 TO 36 Vdc
POWER SUPPLY
CONTROLLER, METER
OR RECORDER
INPUT SIGNAL
COMMON
Vin +
+
Io –
–
M22528
GROUND

H7625A, H7635A HUMIDITY/TEMPERATURE SENSORS
3 62-0208—3
Fig. 4. Humidity Sensor (0-10 Vdc output) wiring with T7350
(use with RH/Temperature combination T7350 units only).
Fig. 5. Typical wiring diagram for 5-wire temperature/humidity sensor with Vdc output
(used with the XL15A controller).
POWER SUPPLY. PROVIDE DISCONNECT MEANS AND OVERLOAD PROTECTION AS REQUIRED.
ENSURE TRANSFORMER IS SIZED TO HANDLE THE LOAD.
HEAT/COOL SYSTEMS WITH ONE TRANSFORMER REQUIRE THE FACTORY-INSTALLED JUMPER.
USE ECONOMIZER INSTRUCTIONS FOR INSTALLATION DIRECTIONS.
HC AND HP PROVIDE 24 VAC TO THE HUMIDITY SENSOR.
1
M22529
2
3
2
3
4
5
5
RCX
T7350
SUBBASE
W1 G
T7770 REMOTE SENSOR
Y1
W3/Y4 Y3 W2 Y2
AUXRH
T5 T6 T7 T4 T3
DISCHARGE
AIR
SENSOR
OUTDOOR
AIR
SENSOR
MOTION
SENSOR
HUMIDITY
SENSOR
M
OSOS ASAS
MHC HP
HS
Gnd Vin
Vo
1
4
L1
(HOT)
L2
COMPRESSOR
CONTACTOR 1
COMPRESSOR
CONTACTOR 2
HEAT
RELAY 1
123456789
FAN
RELAY
ECONOMIZER
HEAT
RELAY 2
COMPRESSOR
CONTACTOR 3
COMPRESSOR
CONTACTOR 4
E
GND
OUT
1
OUT
2
OUT
3
OUT
4
OUT
5
OUT
6
OUT
7
OUT
8
DI
1
DI
2
DI
3
DI
4
GND GND 24
VAC
COM
24
VAC
COM
24
VAC
24
VAC
24
VAC
24
VAC
24
VAC
OUT
COM
21
VDC
OUT
GND E-BUS E-BUS
AI
1
AI
2
AI
3
AI
4
AI
5
AI
6
AI
7
AI
8
ANALOG
OUT
AO
1
AO
2
17 18 19 20 21 22 23 24 25 26 27 28 29
L1
(HOT)
L2
31 32 33 34 35 36 37 38 39 40 41 42 43 44
12345 678 9101112 14 1615
13
W7760A AI
GND
AI
GND
AI
GND
AI
GND
AO
GND
+
–
O
P7640
+
–
O
P7640
+
–
O
H76XX
+
–
M18302A
Vin
Gnd
Vo
PWR
COM
OUT
PWR
COM
OUT
POWER SUPPLY. PROVIDE DISCONNECT MEANS AND OVERLOAD PROTECTION AS REQUIRED.
TEMPERATURE SIGNAL CONNECTIONS ARE NOT POLARITY SENSITIVE.
1
1
2
2

H7625A, H7635A HUMIDITY/TEMPERATURE SENSORS
62-0208—3 4
CHECKOUT
CAUTION
Equipment Damage Hazard.
Can short electric circuitry.
• Never connect 120 Vac to the transducer.
• Connect only DC voltage to a transducer
intended for DC supply.
NOTE: Use laboratory quality meters and gauges for
applications requiring a high degree of
accuracy.
1. Verify that the transducer is mounted in the correct
position.
2. Verify appropriate input signal and voltage supply.
3. Verify appropriate configuration range.
Converting Output Signal to Percent RH
4 to 20mA Signal
Example: 12 mA output signal
(12 - 4)/ 0.16 = 50% RH
0 to 10 Vdc Signal
Example: 8 VDC transmitter signal output
8 Vdc/0.10 = 80% RH
Table 3. Troubleshooting.
signal [in mA] 4–〈〉
0.16
------------------------------------------------- p e r c e n t R H=
Problem Items to Check
No reading •Verify correct supply voltage at the power terminal blocks.
•Verify correct wiring configuration and DIP switch settings.
•Verify that terminal screws are connected tightly with all wires firmly in place.
Erratic readings •Verify all wires are terminated properly.
•Ensure that there is no condensation on the board.
•Verify clean input power. In areas of high RF interference or noise, shielded cable can be
necessary to stabilize signal.

H7625A, H7635A HUMIDITY/TEMPERATURE SENSORS
5 62-0208—3
APPENDIX
RH Test and Configuration DIP Switch Settings (Table 4)
IMPORTANT
• Only adjust these switches for troubleshooting or
• recalibrating the sensor. (Adjustment is not
normally necessary.)
• For normal operation, always keep DIP switch 3
in the ON position. When DIP switch 3 is off, the
RH transmitter cannot read the sensor. This
inability-to-read forces the output to never
change.
Table 4. Test and Calibration Settings (6-Switch Block).
0% RH Output (for Testing Only)
Transmitter always outputs a signal of 4 mA or 0 Vdc. The
sensor does not affect the transmitter output.
50% RH Output (for Testing Only)
Transmitter always outputs a signal of 12 mA, 2.5 VDC, or
5 VDC. The sensor does not affect the transmitter output.
100% RH Output
Transmitter always outputs a signal of 20 mA, 5 VDC, or
10 VDC. The sensor does not affect the transmitter
output. Sensor doesn’t affect the transmitter output.
Normal Operating Condition
DIP switch 3 must be set in the On position for normal
operation. All other DIP switches must be set Off.
Setting 654321
Normal Operation (Default) — — — On — —
0%RHOutput On—————
50%RHOutput —On————
100% RH Output — — On — — —
Increment RH Output — — — — On —
DecrementRHOutput —————On
Reset to Original Calibration — — — — On On

H7625A, H7635A HUMIDITY/TEMPERATURE SENSORS
62-0208—3 6
CALIBRATION
All transducers are factory calibrated to meet/exceed published
specifications. Field adjustment should not be necessary.
IMPORTANT
• Do not verify comparative RH with a sling
psychrometer. There are too many variables
which induce errors into this process.
• Recalibration must be done in a controlled
environment. Relative humidity must be held sta-
ble while making any adjustment.
• Verify the device output directly with calibrated
instrumentation and verify RH with calibrated
instrumentation. Never use a controller output.
• With correct power applied, and only a meter
connected to the transducer output, ensure that
the output is proportional to the true RH.
Using Increment/Decrement Switches
Increment RH Output
This DIP switch allows you to calibrate the sensor through
the software. The switch must be toggled from the Off to
the On position and then returned to the Off position for
an increase of 0.5% RH. This means that if your humidity
has drifted 1% lower over a certain time period, you will
be able to toggle the Increment RH Output switch (2)
times in order to slide the whole curve upward 1%.
Decrement RH Output
This DIP switch allows calibration in the same way as the
Increment RH. The difference is that each toggle results
in a decrease of 0.5% RH.
Using Calibration Trim Potentiometers
IMPORTANT
• Due to the sensitive nature of humidity
calibration, adjusting trimmer potentiometers
is not highly recommended.
• Calibrate only in a stable humidity/temperature
chamber of laboratory grade.
Single Point Calibration
IMPORTANT
Use only one of the following two options.
OPTION 1
1. Select a controlled humidity environment between
10 and 40 percent RH. Be sure humidity is stable.
2. Adjust zero trimmer (z).
OPTION 2
1. Select a controlled humidity environment between
40 and 70 percent RH. Be sure humidity is stable.
2. Adjust span trimmer (s).
Two Point Calibration
1. Select a controlled humidity environment between
10 and 40 percent RH. Be sure humidity is stable.
2. Adjust zero trimmer (z).
3. Select a controlled humidity environment between
70 and 75 percent RH. Be sure humidity is stable.
4. Adjust span trimmer (s).

H7625A, H7635A HUMIDITY/TEMPERATURE SENSORS
7 62-0208—3

H7625A, H7635A HUMIDITY/TEMPERATURE SENSORS
Automation and Control Solutions
Honeywell International Inc. Honeywell Limited-Honeywell Limitée
1985 Douglas Drive North 35 Dynamic Drive
Golden Valley, MN 55422 Scarborough, Ontario M1V 4Z9
customer.honeywell.com
® U.S. Registered Trademark
© 2005 Honeywell International Inc.
62-0208—3 B.B. Rev. 01-05
LonSpec™ is a trademark of Echelon®Corporation.
