Honeywell Notifier TAD-FTT User manual

1/6
S-8109.1-TAD-FTT-ENG Rev. A.2 01/2018
Terminal with back light and display.
TAD-FTT
FEATURES
Multi-functional terminal for the management of central-
net
Features:
 Graphic display 128x64 pixel, 8 lines of 21
Characters
 Backlight 14 keys keyboard with tricolor led for each
key.
 8 function keys vith tricolor LEDs built-in, that can
be used in 4 pages (total 32 functions – 32 tri-color
LED)
 4 Tri-color LED for system messages (3
programmable)
 Integrated proximity reader (EM4100)
 Internal clock calendar
 Operation in degraded-mode, 10000 events storage
 2 digital input multi-balance
 2 digital output O/C
 1 Programmable buzzer
 1 Optical tamper
 1 temperature sensor
Terminal is prepared to connect:
 2 ISO7811/2 compatible badge reader
 Additional proximity reader AT-E and terminal
emulator AT-I
 Additional proximity reader AEI3 and terminal
emulator AEI3-I
 RADIOCAR radio receiver for TR-2P and TR-3P
radio-controls
 1 external MGP-E module with a double balance
input and a 5A relay output (excludes an input
output O/C)
 Displaying 32 functions selected by menù
APPLICATIONS
Depending on programming, TAD-FTT can be used as:
 System terminal
 Access control terminal
 Time and attendance terminal
OFF LINE MODE
When communication with the control panel is missing,
terminal can manage the controlled passage by itself or
together with another terminal. MGP outputs and inputs
used for actuator, local forcing alarm, sensor and
manual door open command are managed locally.
Events generated in offline mode are sent to the control
panel when connection is established again
N.B. For the central with fw 6.xx are handled only the
PIN, the first trasponder and badge of each operator.
Remote controls and second bedge or trasponder are not
stored in local memory
MOUNTING
The wheelbase of fixing holes is suitable for 503 boxes. It
can also be fixed through dowels for 3,9mm maximum
diameter screws. Fix the rear panel of the box to the wall,
connect cables, bring the terminal next to the rear panel
taking care of cables disposition in order not to touch
electrical components, then insert the case on the rear
panel on one side first, then on the other, pressing until it
is blocked.
.
Warning
Avoid flexing or bending the internal board and do not
use metallic tools when it is powered.
Before proceeding with electrical connections remove
power.
The connectors can be used both the input cables to the
top and down.
During the wiring the connector to check the direction in
which they were wired to avoid errors in links.
During connectors’ insertion/removal, fix the board to
avoid bending, and check the wire position.
To open the plastic container to unlock the block with
screwdriver form 5 to 8 mm.

2/6
S-8109.1-TAD-FTT-ENG Rev. A.2 01/2018
Terminal with back light and display.
TAD-FTT
INSTALLATION
TAD-M is designed to be installed covered sites, not
directly exposed to atmospheric conditions; direct
exposal to sunlight can damage the display
.
PROXIMITY READER
The proximity reader is position at the surface below the
keyboard
The reading distance, depending on the trasponder
used and the condition of installation, can change
between 10 and 60 mm.
Methal object and electromagnetic fields can interfere
with the reading, as well as the closeness of other
terminals/reader with the same frequency 125KHz
LONWORKS LINE
Please check P1 jumper’s position on line module. With
P1 jumper you can choose termination to apply to the
line
To choose points where add terminations, see technical
manual in NETWORK CONFIGURATION paragraph.
IN SERVICE
To put the peripheral in service:
 Power the peripheral; if it has never in service
before, the display shows:
Digit Nr.
PERIPHERAL : _ _ _
Where _ _ _ = spaces for pheripheral number
 Set peripheral number througt the keyboard then
press ENTER 
The display show BINDING IN PROGRESS
If the binding is accepted then the homepage related
to programmed mode and internal buzzer emits a long
beep.
If the binding is not accepted the dipslay shows for 3
seconds:
BINDING
FAULT
Hear three short beeps and returns to view
Digitare Nr.
PERIPHERAL : _ _ _
waiting for peripheral number’s insertion.
DELETE BINDING (Normal/Forced)
To put out o service the peripheral (binding delete) send
to command OUT OF SERVICE to specific menu from
the other peripheral or Software Monitor.
 remove peripheral power
 power the peripheral
 while viewing the line with the firmware version press
and hold  until you see the installer menu, press
L1 DELETE BINDING
The cancellation of binding is reported by the message:
RESET TAD_M and then
Type Nr.
PERIPHERAL : _ _ _
ALERTS
To maintain compatibility with existing programs, led the
LA, LB and LD, are the exits 5, 6 and 7, and then the L5,
L6 and L7 of the page 0.
Led 8 in page Zero coincide to the output 8 (buzzer)
So its functionality is limited.
Operator qualification
1 long beep + green power LEDs on the keypad + LED
flashes green slowly LC.
Refusal Operator
3 short beeps +3 flashing red LEDs on the keypad
Stato rete Lon
LC led is manage to the terminal
Fast red = Terminal out of service
Slow red = Terminal in service, correct communication
with the cpu
Slow yellow = Terminal in service, failure communication
Slow green = Terminal in service, correct communication
with the cpu, operator qualified.

3/6
S-8109.1-TAD-FTT-ENG Rev. A.2 01/2018
Terminal with back light and display.
TAD-FTT
No Power Supply, Battery, Fault.
Reports of NO POWER (led LA/L5 page 0), BATTERY
FAULT (LED LD/L6 page 0) and FAULT (LED LB/L7
page one) are managed by the CPU and can be
programmed..
Key Press
1 Beep + turned on LED keypad in YELLOW
Page Viewed
The page that appears is indicated by the
corresponding yellow LED on the keypad
SPECIAL FUNCTION BUTTON
 Enter, confirm the selection
 Exit, back to the previous menu, when there is not a
qualified operator, display show the device number and
firmware version.
 up/down, moving up / down one the selection.
L1 / L5 page up , move the selection up one page
(only in the list).
L4 / L8 page down, move the selection down one
page (only in the list).
L2 / L3 SX, Move the visualizzation on the left (only in
the list)
L6 / L7 DX, Move the visualizzation on the right (only
in the list)
LOCAL PERIPHERAL SET-UP
Factory terminals have enabled all the local devices,
the configuration is designed to eliminate those that are
not installed to improve the response time of the related
MGP_E
 Remove peripheral power
 Power the peripheral
 While viewing the Firmware versione, press
and hold untill you see installer menù
 Press L2 Local device, the terminal check and
automatically acquires the devices connected to the
local line, for external antennas as AT-E; AEI-3,
wich is necessary to read a transponder to
determinate the acquisition. The devices
recognized are highlighted by a S
 Press
 to confirm the configuration
 Press
 to return at the normal operation
RECEPTION / TRANSMISSION FIRMWARE
 Remove peripheral power
 Power the peripheral
 While viewing the Firmware versione, press and
hold untill you see installer menù
 Press L3, RECEPTION FIRMWARE if you want to
receive the firmware from another peripheral.
 Press L4 TRASMISSION FIRMWARE If you want
send our firmware to another peripheral
The performance of the reception/trasmissioni is
indicated by a meter, the procedure ends when the
counter reaches 512, and the display show the message
FW Scripture, after that the terminal is restarted
N.B. Do not carry out operations or remove power to the
terminal while the SCRIPTURE FW is displayed.
ENABLE PAGE DISPLAY WITHOUT
APPROVAL
Factory visualization of 4 pages of function keys and
LEDs is allowed only after the operator is enabled.
To change these parameters:
 Remove peripheral power
 Power the peripheral
 While viewing the Firmware versione, press and
hold untill you see installer menù
 Press L5, SEQ. VIS. ACS-E.
 Move up/down till correct line
 press 
  put the value
 press  to confirm the configuration
 press  to return at the normal operation.
AUTOMATIC PAGES DISPLAY WITHOUT
APPROVAL
When the visualizzation is permitted without autorizzation
is possible to enable automatically display. For each
pages you con set the display time, when time is zero the
page is not display, if there more pages configurated are
displayed in sequence.
 Remove peripheral power
 Power the peripheral
 While viewing the Firmware versione, press and
hold untill you see installer menù
 Press L5, SEQ. VIS. ACS-E.

4/6
S-8109.1-TAD-FTT-ENG Rev. A.2 01/2018
Terminal with back light and display.
TAD-FTT
 Check on the line UP/DOWN enable, there is
written YES, modify if it necessary
 move ' on correct ACSE- page
 press 
 put in the value (in second)
 press
 to confirm the configuration
 Press
 to return at the normal operation
TEMPERATURE SENSOR
The temperature sensor is already calibrated on the
factory configuration, to make a new calibration or to
adapt on the installation:
 Remove peripheral power
 Power the peripheral
 While viewing the Firmware versione, press
and hold untill you see installer menù
 Press L6, SENS. TEMP
 With
' adjust the teperature
 press
 to confirm the configuration
 Press
 to return at the normal operation
TECHNICAL DATA
Power Supply
9 - 30 Vcc
Standby current
70 mA
Maximun current
170 mA
Operating
Temperature -10 / +55 °C
Open Collector
Output 400 mA
Temperature sensor - 55 +
125 °C
Dimensions L = 135
H = 130
P = 35
mm

5/6
S-8109.1-TAD-FTT-ENG Rev. A.2 01/2018
Terminal with back light and display.
TAD-FTT
CONNECTIONS
JP1 Alimentazione / Rete 485
1 Positive +12V
2 Negative
3 485 (not enable)
4 485 (not enable)
JP2 Input / Output
1 MGP-I input address ccppp02
2 MGP-E input address ccppp03
3 MGP-I output address ccpp009
4 MGP-E output address ccppp010
JP3 Lon line / Local line
1 Lon
2 Lon
3 Local Line
4 Negative
JP4 Direct reader
1 DATA Brown Orange
2 CLS Red Yellow
3 CLK Orange Brown
4 + 5 V Yellow Red
5 Negative Green Black
JP5 Opposite reader
1 DATA Brown Orange
2 CLS Red Yellow
3 CLK Orange Brown
4 + 5 V Yellow Red
5 Negative Green Black
JP6 USB Programmation
Riserved
JP7 Programmation
Riserved
P1 Lon Line Configuration
1-2 Lon Bus
2-3 Lon Free
A Open = No Termination
P2 Termination RS 485
C (not enable)
A (not enable)
ST Temperature sensor
Analog input – address ccppp04
T1 Optical Tamper
Input – Address ccppp01

6/6
S-8109.1-TAD-FTT-ENG Rev. A.2 01/2018
Terminal with back light and display.
TAD-FTT
NOTIFIER ITALIA S.r.l. - A socio unico - 20097 San Donato Milanese (Ml) - Via Grandi, 22 - Tel.: [phone] - Fax: [phone] - E-mail:
[email protected] Capitale Sociale € 2.700.000,00 i.v. - C.C.A.A. 1456164 - Trib. Milano Reg. Soc. 348608 - Vol. 8549 Fasc. 8 - Partita IVA T
11319700156 (informativa privacy art. 3 Digs 196/03) - Ufficl Regionali: 10151 Torino - Via Pianezza, 181 - Tel.: [phone] - Fax: [phone] - E-mail:
[email protected] - 35010 Limena (PD) Via IV Novembre, 6/c Int. 9 - Tel.: [phone] - Fax: [phone] - E-mail: [email protected] - 40050
Funo di Argelato (BO) - Asta Servizi, Bl. 3B, Gall. B n. 85, Centergross - Tel.: [phone] - Fax: [phone] - E-mail: no[email protected] - 50136
Firenze –Via B.Telesio, 15 Tel: [phone] Fax: [phone] - 00118 Roma - Via Del Casale Santarelli, 51 - Tel.: [phone] - Fax: [phone] - E-
mail: [email protected] - 80143 Napoli - Palazzo Prof. Studi - Centro Direzionale, Isola E2, Scala B, Piano 5° - Tel.: [phone] - Fax: [phone]-
E-mail: [email protected] - 70125 Bari - Via Delia Costituente, 29 - Tel.: [phone] - Fax: [phone] - E-mail: [email protected] - 95128
Catania - Viale Alcide De Gasperi, 187 - Tel.: [phone] - Fax: [phone] - E-mail: [email protected]
www.notifier.it
Tutti i dati sono soggetti a cambiamento senza preavviso. Tutti i diritti di questa pubblicazione sono riservati.
SISTEMA GESTIONE
QUALITÀ
CERTIFICATO
UNI EN ISO 9001:2000
Example of connecting with balance input and outputs O/C
