Honeywell CT40 HomeBase User manual

CT40 HomeBase
Model CT40-HB, CT40-EB
Quick Start Guide
CT40-EHB-EN-QS Rev A
08/18

1
Out of the Box
Make sure that your shipping box contains these items:
• CT40 HomeBase (CT40-HB) or Ethernet HomeBase (CT40-
EB)
• Power supply
• Power cord (if purchased)
• Regulatory Sheet
If any of these items are missing or appear damaged, contact
your Customer Account Representative. Keep the original pack-
aging in the event that you need to return the HomeBase or
Ethernet HomeBase for service or if you want to store the char-
ger while not in use.
Caution: We recommend the use of Honeywell
accessories and power adapters. Use of any non-
Honeywell accessories or power adapters may cause
damage not covered by the warranty.
Mise en garde : Il est recommandé d'utiliser les
périphériques, les cordons d'alimentation et les
adaptateurs secteur conçus par Honeywell. L'utilisation
de tout périphérique, cordon d'alimentation ou
adaptateur secteur d'une autre marque est susceptible
de provoquer des dommages non couverts par la
garantie.

2
Connect Power
Use only a UL Listed power supply which has been qualified by
Honeywell with an output rated at 12 VDC and 3 A. The power
supply input rating is 90-264 VAC, 50/60 Hz. The operating
temperature is -10 °C to 50 °C (14 °F to 122 °F). The maximum
output of the base is 5VDC/2A.
1. Plug the power cord into the power supply.
2. Plug the power supply cable into the power connector on
the back of the HomeBase.
3. Plug the power cord into a standard wall outlet.
USB Port
DC Power
Ethernet
(CT40-EB)

3
Charge the Battery Pack
Caution: Make sure that all components are dry prior to
using the computers and batteries with accessories. Using
wet components may cause damage not covered by the
warranty.
Mise en garde : Assurez-vous que tous les composants sont
secs avant de connecter les terminaux/batteries à des
périphériques. L'insertion de composants humides risque
de provoquer des dommages non couverts par la garantie.
• Insert a battery pack into the HomeBase.

4
About the Status LED
The HomeBase has one LED for the battery status.
LED Status Description
Battery Solid green The battery is connected to external
power and is fully charged.
Solid amber The battery is connected to external
power and is charging.
Solid red There is a battery charging fault, such
as over-temperature.
Battery LED

5
Mount the HomeBase
You can mount the HomeBase on a flat, horizontal surface such
as a desktop or workbench with an optional DIN rail.
Mounting hardware required:
•DINrail
• 3/16-inch diameter x 5/8-inch long pan head screw
• 1/2-inch OD x 7/32-inch ID x 3/64-inch thick washer
• 3/16-inch diameter nut
1. Slide the DIN rail into the slot on the bottom of the Home-
Base.
2. Secure the DIN rail to the flat surface with the hardware.

6
Support
To search our knowledge base for a solution or to log into the
Technical Support portal and report a problem, go to
www.hsmcontactsupport.com.
User Documentation
For the user guide and other documentation, go to
www.honeywellaidc.com.
Limited Warranty
For warranty information, go to www.honeywellaidc.com and
click Get Resources > Product Warranty.
Patents
For patent information, see www.hsmpats.com.
Trademarks
Android and Google and other marks are trademarks of Google
Inc.
Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make
changes in specifications and other information contained in
this document without prior notice, and the reader should in all
cases consult HII to determine whether any such changes have
been made. The information in this publication does not repre-
sent a commitment on the part of HII.
HII shall not be liable for technical or editorial errors or omis-
sions contained herein; nor for incidental or consequential
damages resulting from the furnishing, performance, or use of

7
this material. HII disclaims all responsibility for the selection
and use of software and/or hardware to achieve intended
results.
This document contains proprietary information that is pro-
tected by copyright. All rights are reserved. No part of this docu-
ment may be photocopied, reproduced, or translated into
another language without the prior written consent of HII.
Copyright2018 Honeywell International Inc. All rights
reserved.
