Hoshizaki F-1500MAH User manual

Hoshizaki
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshizaki.com
FLAKER DIMENSIONS
WxDxH
F-1500M_H
4/08
Item # 13161
MODULAR FLAKER ICE MACHINE
Warranty
Valid in United States, Canada, Puerto ico, & U.S.Territories. Contact factory for warranty in
other countries.
wo Year - Parts & Labor on entire machine.
Five Year - Parts on Compressor, air-cooled condenser coil.
F-1500M_H
Item #
Project:
Qty:
Hoshizaki reserves the right to change specifications without notice.
F-1500M_H
30 x 271/2 x 347/16
*AutoCad available on KCL
•Up o 1590 lbs. of ice produc ion per 24 hours
•Durable s ainless s eel ex erior
•CleanCycle12®Design
•15 minu e flush cycle every 12 hours
•Removes sedimen
•Cleaner ice
•Longer life and easy main enance
•R-404A Refrigeran
®
B-900
B-800
B-700
B-500
F-1500MAH
Air-Cooled
Shown on an optional
B-900
F-1500MWH
Water-Cooled
F-1500MRH
emote Air-Cooled
Also availa le on Large Bins:
B-1150SS
B-1300SS
B-1500SS
B-1650SS

Hoshizaki
DIMENSIONS
WxDxH
F-1500M_H
30 x 271/2 x 347/16
©HOSHIZAKI AMERICA, INC.
F-1500M_H FLAKER ICE MACHINE
MODULAR SERIES
U ILI Y C O N S UMP ION
AIR-COOLED
Model Number
70˚
50˚ 70˚
1590
90˚
80˚
90˚
KWH per
100 LBS.
F-1500MAH
Air Temp˚ F.
Water Temp˚ F.
SPECIFICA IONS
Model Number Condenser Amperage Min. Circuit
Ampacity Shipping
Weight
16.3 20 325 lbs.
Air-Cooled
F-1500MAH
3.83
1382
1206
1514
1321
1447
1262
1100
F-1500MWH Water-Cooled 15.9 20 325 lbs.
1170
90/70
Potable
Water Gal.
per 100 lbs.
12.0
O P E R A I N G L I M I S
• Ambient Temp ange 45 - 100˚F
• Water Temp ange 45 - 90˚F
• Water Pressure 10 - 113psig
• Voltage ange 187 - 253V
ELEC RIC A L&PLUMBING/F-1500M_H
• 208-230V/60/1 (3 wire with dedicated neutral for 115V)
• 1/2” OD copper or equivalent independent potable water supply
• 3/4” FPT independent drain connection
SERVICE
• Panels easily removed and all components
accessible for service.
• emovable/cleanable air filter.
(Air-Cooled models only)
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshizaki.com Printe in U.S.A.
•Air-cooled
• Water-cooled
• emote Air-cooled
WA ER-COO L E D
70˚
50˚ 70˚
1435
90˚
80˚
90˚
Air Temp˚ F.
Water Temp˚ F.
1335
1260
1390
1310
1360
1285
1210
1245
F-1500MWH 3.4 12.0
S ORAGE BINS
Model Number Application Capacity ARI-Rated Capacity
B-500 500 lbs. 360 lbs.
B-700 700 lbs. 550 lbs.
B-900 900 lbs. 660 lbs.
B-1150 1150 lbs. N/A
B-800 800 lbs. 600 lbs.
B-1500 1490 lbs. N/A
B-1650 1605 lbs. N/A
B-1300 1275 lbs. N/A
REMO E AIR-COOLED
70˚
50˚ 70˚
1585
90˚
80˚
90˚
Air Temp˚ F.
Water Temp˚ F.
1439
1309
1532
1394
1484
1351
1230
1300
F-1500MRH 3.72 12.0
F-1500MRH Remote
Air-Cooled 18.9 20 325 lbs.
FRONT VIEW SIDE VIEW
1-11/16"
(43mm)
28-21/32"
(728mm)
Drain Outlet
Electrical Supply
7/8"Opening
(22mm)
1-3/4"
(45mm)
23-11/16"
(602mm)
5-1/4"
(133mm)
3-3/8"
(86mm)
IceMakingWater
Inlet 1/2"FPT
3/4" FPT
AIR-COOLED NIT WATER-COOLED NIT
Ice Making Water
Inlet 1/2" FPT
Fan MotorConnection
7/8"Opening
(22mm)
Electrical Supply
7/8"Opening
(22mm)
Drain Outlet
3/4" FPT
Liquid Refrig. Line
5/8"-18UNF Fitting
Discharge Refrig. Line
1-1/16"-12UNF Fitting
3-3/8"
(86mm)
5-1/4"
(133mm)
23-11/16"
(602mm)
3-7/16"
(36mm)
3-7/8"
(98mm)
20-5/8"
(524mm)
27-3/4"
(736mm)
31-15/16"
(811mm)
1-15/16"
(50mm)
1-13/16"
(46mm)
28-3/4"
(730mm)
REMOTE AIR-COOLED NIT
ICE DROP ZONE
Pre-Charged ubing Kits
(Sold Separately)
20’ 404-2068-2
35’ 404-3568-2
55’ 404-5568-2
URC-12F Remote Condenser (Sold Separately)
For Use with F-1500M H
Voltage supply for the URC Remote
Condenser is supplied from the Ice Maker.
No additional circuit is required.
35 11/16
14 1/16
36 7/8
Air Flow
211/16
23/4 215/16
18 1/8
21 15/16
Liqui
Refrigerant
Line
Discharge Line
Electrical Con uit
Access
37 13/16
URC-12F
