Hoshizaki KML-250MAH User manual

NO.
SEPT. 18, 2001
ISSUED:
71192
HOSHIZAKI
MODULAR CRESCENT CUBER
MODEL
KML-250MAH
KML-250MWH
PARTS LIST
SEPT. 25, 2001
ISSUED:

2
HA
KML-250MAH L-0 May 2001
KML-250MWH L-0 October 2001

3
HA MATERIAL ABBREVIATIONS
ALUMINUM
AL = Aluminum
COPPER
CU = Copper
PLASTIC
ABS = Acrylonitritrile -butadiene - styrene
AC = Polyacetal
EVA = Ethylene vinyl acetate
PA = Polyamide = Nylon
PC = Polycarbonate
PE = Polyethylene
PES = Polyester
PETP = Polyethylene terephthalate = Tetlon
PP = Polypropylene
PS = Polystyrene
PTFE = Polytetrafluoroethylene = Teflon
PUR = Polyurethane
PVC = Polyvinyl chloride
RUBBER
VN = Vinyl Nitrile
EPDM = EP rubber
NBR = Nitrile butadiene rubber
NR = Natural rubber
NP = Neoprene
SI.R = Silicone rubber
SY.R = Synthetic rubber
EPH = Epichlorohydrin
STEEL
GS = Galvanized steel
SS = Stainless steel
PS = Plated steel
PAS = Primed steel
AUXILIARY CODE
Ex.1 K-0
Parts are the same as in the preceding (Note) - = Part deleted.
year.
x = Part deleted and replaced
"K" is the tenth in alphabetical order with "I" by "o" (interchangeable)
skipped. So, "K" indicates "2000". part.
Ex.2 L-0 o = New part for "x" in the
"L" is the next in alphabetical same auxiliary code.
order. So, "L" indicates "2001".
Ex.3 L-1
Each time a part is changed non-interchangeably
in a year, this number advances.

4
HA
KML-250MAH A. ICE CUBER ASSEMBLY L-0

5
HA
MODEL: KML-250MAH TITLE:A. ICE CUBER ASSEMBLY
INDEX
NO.
DESCRIPTION MATERIAL OR
MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER L-0
B REFRIGERATION CIRCUIT - 1A0604A01 1
C WATER CIRCUIT - 1A0438A01 1
D CONT. BOX ASSEMBLY - 2A2291A01 1
D1 T2 SCREW 4X8 7P31-0408 3
E LABEL LOCATION - 3A2043A01 1
F TOP PANEL ASSEMBLY - 3A1862A01 1
G FRONT PANEL - 3A1859A01 1
G1 TRUSS HEAD SCREW 4X8, SS 7C32-0408 2
1 EVAPORATOR CASE - 2A2238G01 1
2 CONTROL BOX COVER GS 3A1828-01 1
2a T2 SCREW 4X8 7P31-0408 3
3 SQUARE WASHER BRASS 433537-02 1
4 SCREW - GROUNDING BRASS 433304-02 1
5 JUNCTION BOX COVER GS 433410-01 1
5a T2 SCREW 4X8 7P31-0408 1
6 BIN SWITCH - 4A2430-01 1
7 BRACKET (L) - 3A1433-01 1
8 THUMBSCREW SS, ABS 415949G09 2
9 BIN CONTROL COVER GS 3A0664G01 1
10 THUMBSCREW - 4H3270G01 1
11 TOP INSULATION PP 215730G01 1
12 FRONT INSULATION PP 2A0664G01 1
13 SIDE PANEL (R) SS 2A2111G01 1
13a T2 SCREW 4X8, SS 7P32-0408 1
14 LOUVER (B) ABS 1A0548-01 2
15 PUSH RETAINER - 4A2414-01 6
16 AIR FILTER (B) ABS 2A2063G01 2
17 BUSHING SR-34-2 420472-03 1
18 WIRE SADDLE VWS4238-C 4A0338-02 2
19 THUMBSCREW SS, ABS 415949G04 2

6
HA
MODEL: KML-250MAH TITLE:A. ICE CUBER ASSEMBLY
INDEX
NO.
DESCRIPTION MATERIAL OR
MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER L-0
20 GASKET L=762 4A0808L02 1
21 GASKET L=655 4A0808L02 2
22 GASKET L=190 4A0808L02 1

7
HA
KML-250MWH A. ICE CUBER ASSEMBLY L-0

8
HA
MODEL: KML-250MWH TITLE:A. ICE CUBER ASSEMBLY
INDEX
NO.
DESCRIPTION MATERIAL OR
MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER L-0
B REFRIGERATION CIRCUIT - 1A0634A01 1
C WATER CIRCUIT - 1A0438A01 1
D CONTROL BOX ASSEMBLY - 2A2291A01 1
D1 T2 SCREW 4X8 7P31-0408 3
E LABEL LOCATION - 3A1988A01 1
F TOP PANEL ASSEMBLY - 3A1862A01 1
G FRONT PANEL - 3A1859A02 1
G1 TRUSS HEAD SCREW 4X8, SS 7C32-0408 2
1 EVAPORATOR CASE - 2A2238G01 1
2 CONTROL BOX COVER GS 3A1828-01 1
2a T2 SCREW 4X8 7C31-0408 3
3 SQUARE WASHER BRASS 433537-02 1
4 SCREW - GROUNDING BRASS 433304-02 1
5 JUNCTION BOX COVER GS 433410-01 1
5a T2 SCREW 4X8 7C31-0408 1
6 BIN SWITCH - 4A2430-01 1
7 BRACKET (L) - 3A1433-01 1
8 THUMBSCREW SS, ABS 415949G09 2
9 BIN CONTROL COVER GS 3A0664G01 1
10 THUMBSCREW - 4H3270G01 1
11 TOP INSULATION PP 215730G01 1
12 FRONT INSULATION PP 2A0664G01 1
13 SIDE PANEL (R) SS 2A2111G01 1
13a T2 SCREW 4X8, SS 7P32-0408 1
14 BUSHING SR-30-1 420472-03 1
15 WIRE SADDLE VWS4238-C 4A0338-02 2
16 THUMBSCREW SS, ABS 415949G04 2
17 GASKET L=655 4A0808L02 2
18 GASKET L=190 4A0808L02 1
19 GASKET L=762 4A0808L02 1

9
HA
KML-250MAH B. REFRIGERATION CIRCUIT (1/2) L-0

10
HA
KML-250MAH B. REFRIGERATION CIRCUIT (2/2) L-0
DETAILED THERMISTOR ATTACHMENT

11
HA

12
HA

13
HA
KML-250MWH B. REFRIGERATION CIRCUIT (1/2) L-0

14
HA
KML-250MWH B. REFRIGERATION CIRCUIT (2/2) L-0
DETAILED THERMISTOR ATTACHMENT

15
HA

16
HA

17
HA
KML-250MAH, MWH C. WATER CIRCUIT L-0

18
HA MODEL: KML-250MAH, MWH TITLE:C. WATER CIRCUIT
INDEX
NO.
DESCRIPTION MATERIAL OR
MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER L-0
1 WATER SUPPLY PIPE COPPER 4A0768G04 1
1a T2 SCREW 4X8 7P31-0408 2
2 RUBBER GASKET NR 413854-03 1
3 WATER VALVE BRACKET GS 321443-01 1
3a T2 SCREW 4X8 7P31-0408 1
4 WATER VALVE J248-072 3U0111-04 1
5 SPRAY TUBE PE 1A0260-02 1
6 SPRAY GUIDE (A) PE 208586-01 6
7 WATER SUPPLY TUBE PE 2A0079-01 1
8 PLUG EPDM 4A0176-01 2
9 WATER SUPPLY TEE SANTOPRENE 4A1006-01 1
10 FLANGE EPDM 439267-01 1
11 INSULATION (E) PE FOAM 4A0392-01 1
12 ELBOW SANTOPRENE 4A0393-01 1
13 CONNECTING PIPE PE 3A1335-01 1
14 HOSE CLAMP SS, 25 mm 427443-03 3
15 CUBE GUIDE (A) ABS 2A0660-01 1
16 PUMP HOSE EPDM 4A1007-01 1
17 RUBBER RING EPDM 4A1004-01 1
18 BYPASS HOSE SANTOPRENE 4A1005-01 1
19 HOSE CLAMP SS, 18 mm 427443-05 5
20 SOLENOID VALVE 207CB-GS1873 439322-01 2
20a TRUSS HEAD SCREW 4X8 7C31-0408 4
21 ARROW LABEL PES 4A0096-01 1
22 SOLENOID COVER GS 4A0996-01 2
22a T2 SCREW 4X8 7P31-0408 4
23 PUMP - 2A0749-01 1
24 FLOAT SWITCH 163795 4A0886-01 1
24a T2 SCREW 4X8, SS 7P32-0408 2
25 FLOAT SWITCH BRACKET ABS 327757-01 1

19
HA
MODEL: KML-250MAH, MWH TI1TLE:C. WATER CIRCUIT
INDEX
NO.
DESCRIPTION MATERIAL OR
MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER L-0
25a T2 SCREW 4X12, SS 7P32-0412 2
26 FLOAT SWITCH COVER ABS 3A0665-01 1
26a T2 SCREW 4X12, SS 7P32-0412 2
27 VINYL HOSE L=150 7716-1216 1
28 VINYL HOSE L=275 7716-1519 1
29 BUSHING OCB-875 428394-04 1
30 WIRE SADDLE VWS4238-C 4A0338-02 8
31 WELL NUT 347011 4A1070-01 2
31a TRUSS HEAD SCREW 4X16, SS 7C32-0416 4
32 INSULATION (A) – PUMP BRACKET PE FOAM 4A1052-01 1
33 TOOTH WASHER ZINC, M4 7R21-0400 1
33a T2 SCREW 4X8 7P31-0408 1
34 INSULATION (B) – PUMP BRACKET PE FOAM 4A1053-01 1
35 HOSE CLAMP SS, 27 mm 427443-08 1
36 HOSE CLAMP SS. 20 mm 427443-06 3
37 INSULATION (A1) – BYPASS HOSE NP 4A1259-01 1
38 INSULATION (A2) – BYPASS HOSE NP 4A1260-01 1
39 DRAIN POLYACETAL 309246-01 1
40 O-RING 1AP15 7611-P015 1
41 ELBOW - 433467-01 1
42 JOINT PIPE - 439329-01 1
43 CABLE TIE - 8911-0150 2

20
HA
KML-250MAH, MWH D. CONTROL BOX ASSEMBLY L-0
