Hoshizaki DB-200C User manual

NO: 71012
DB-200C
MODEL
(FINAL) PARTS LIST
HOSHIZAKI
ICE DISPENSING BIN
ISSUED: SEPT. 6, 1989
REVISED: FEB. 25, 2002

2
HA
J-1 JULY 1989
J-2 OCTOBER 1989
K-1 DECEMBER 1989
K-2 SEPTEMBER 1990
A-0 MARCH 1991
A-1 NOVEMBER 1991
B-0 FEBRUARY 1992
B-1 APRIL1992
B-2 MAY 1992
C-0 FEBRUARY 1993
C-1 MARCH 1993
D-0 DECEMBER 1993
D-1 SEPTEMBER 1994
E-0 DECEMBER 1994
F-0 DECEMBER 1995
F-1 MARCH 1996
G-0 DECEMBER 1996
H-0 DECEMBER 1997
J-0 DECEMBER 1998
K-0 DECEMBER 1999
L-0 DECEMBER 2000

3
HA
MATERIALABBREVIATIONS
ALUMINUM
AL = Aluminum
COPPER
CU = Copper
PLASTIC
ABS = Acrylonitritrile -butadiene - styrene
AC = Polyacetal
EVA = Ethylene vinyl acetate
PA = Polyamide = Nylon
PC = Polycarbonate
PE = Polyethylene
PES = Polyester
PETP = Polyethylene terephthalate = Tetlon
PP = Polypropylene
PS = Polystyrene
PTFE = Polytetrafluoroethylene = Teflon
PUR = Polyurethane
PVC = Polyvinyl chloride
RUBBER
VN = Vinyl Nitrile
EPDM = EP rubber
NBR = Nitrile butadiene rubber
NR = Natural rubber
NP = Neoprene
SI.R = Silicone rubber
SY.R = Synthetic rubber
EPH = Epichlorohydrin
STEEL
GS = Galvanized steel
SS = Stainless steel
PS = Plated steel
PAS = Primed steel

4
HA
DB-200C A. DISPENSING BIN ASSEMBLY (1/2) J-1

5
HA
DB-200C A. DISPENSING BIN ASSEMBLY (1/2) J-2, K-1

6
HA
DB-200C A. DISPENSING BIN ASSEMBLY (1/2) K-2, A-0, A-1, B-0

7
HA
DB-200C A. DISPENSING BIN ASSEMBLY (1/2) B-1, B-2, C-0

8
HA
DB-200C A. DISPENSING BIN ASSEMBLY (1/2) C-1, D-0, D-1, E-0, F-0

9
HA
DB-200C A. DISPENSING BIN ASSEMBLY (1/2) F-1, G-0, H-0, J-0

10
HA
DB-200C A. DISPENSING BIN ASSEMBLY (1/2) K-0, L-0

11
HA
DB-200C A. DISPENSING BIN ASSEMBLY (2/2) J-1

12
HA
DB-200C A. DISPENSING BIN ASSEMBLY (2/2) J-2

13
HA
DB-200C A. DISPENSING BIN ASSEMBLY (2/2) K-1, K-2, A-0

14
HA
DB-200C A. DISPENSING BIN ASSEMBLY (2/2) A-1, B-0, B-1, B-2, C-0, D-0

15
HA
DB-200C A. DISPENSING BIN ASSEMBLY (2/2) D-1, E-0, F-0

16
HA
DB-200C A. DISPENSING BIN ASSEMBLY (2/2) F-1, G-0, H-0, J-0, K-0, L-0

17
HA
MODEL: DB-200C TITLE:A. DISPENSING BIN ASSEMBLY
INDEX
NO.
DESCRIPTION
MATERIAL
OR
MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER J-1 J-2 K-1
K-2 A-0 A-1 B-0
B-1
B-2
C-0
C-1
D-0 D-1 E-0
B MECHANISM
ASSEMBLY - 104513A01 1 1 1 1 1 1 1 -
- 1A0109A01 1
C CONTROL BOX
ASSEMBLY - 214147A01 1 1 1 1 -
- 214147A02 11-
D SPOUT SWITCH
ASSEMBLY - 437382A01 1 1 1 1 1 1 1 1
E SOLENOID
ASSEMBLY - 212961A01 1 1 1 1 -
- 212961A02 1 1 1 1
F DRAIN PAN
ASSEMBLY - 212963A01 1 1 1 1 1 -
- 212963A02 1 1 1
G SHUTTER - 435537A01 1 1 1 1 -
- 328650A01 1 1 1 1
H SAFETY SWITCH
ASSEMBLY - 435549A01 1 1 1 1 1 1 1 1
J SPOUT - 323043A01 1 1 -
- 324778A01 1 1 -
- 326007A01 1 1 1 1
K LABEL LOCATION - 323205A01 1 1 1 1 1 1 1 1
M FRAME - 3A0184A01 1 1
1 FRAME GS 104785G01 1 1 1 1 1 1 -
2 BIN BODY - 104509G02 1 1 1 1 -
- 104509G03 1-
- 106184G01 1 1 1
3 FRAME (E) GS 323052-01 1 1 1 1 1 1 1 1
4 SPOUT SWITCH
COVER GS 3A0043-01 1 1 1 1 1 1 1 1
5 COLLAR - BRACKET GS 435546-01 1 1 1 1 -
GS 439399-01 1 1 1 1
6 COLLAR - SHUTTER
POLYOXY-
METHYLEN
E
435533-01 1 1 1 1 1 1 1 1
7 HOOK SS 435547-01 1-
SS 4A0063-01 1 1 1 -
SS 439398-01 1 1 1 1
8 HOOK (L) SS 435548-01 1-
SS 4A0064-01 1 1 1 -
9 CONTROL BOX (B) GS 323683-01 1 1 1 1 1 1 1 1

18
HA
MODEL: DB-200C TITLE:A. DISPENSING BIN ASSEMBLY
INDEX
NO. DESCRIPTION MATERIAL
OR MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER F-0 F-1 G-0 H-0 J-0 K-0 L-0
B MECHANISM ASSEMBLY - 104513A01
-1A0109A01 1111111
CCONTROLBOX
ASSEMBLY -214147A01
-214147A02
D SPOUT SWITCH
ASSEMBLY -437382A01 1111111
E SOLENOID ASSEMBLY - 212961A01
-212961A02 1x1
2A0585A01 o111111
F DRAIN PAN ASSEMBLY - 212963A01
-212963A02 1111111
GSHUTTER - 435537A01
-328650A01 1111111
H SAFETY SWITCH
ASSEMBLY -435549A01 1111111
JSPOUT - 323043A01
-324778A01
-326007A01 1111111
K LABEL LOCATION - 323205A01 1111111
MFRAME - 3A0184A01 1111111
1FRAME GS 104785G01
2 BIN BODY - 104509G02
-104509G03
-106184G01 1111111
3FRAME(E) GS 323052-01 1111111
4 SPOUT SWITCH COVER GS 3A0043-01 1111111
5 COLLAR - BRACKET GS 435546-01
GS 439399-01 1111111
6 COLLAR - SHUTTER POLYOXY-
METHYLENE 435533-01 1111111
7HOOK SS 435547-01
SS 4A0063-01
SS 439398-01 1111111
8HOOK(L) SS 435548-01
SS 4A0064-01
9CONTROLBOX(B) GS 323683-01 1111111

19
HA
MODEL: DB-200C TITLE:A DISPENSING BIN ASSEMBLY
INDEX
NO.
DESCRIPTION
MATERIA
L OR
MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER J-1 J-2 K-1
K-2 A-0 A-1 B-0
B-1
B-2
C-0
C-1
D-0
D-1 E-0 F-0 F-1
G-0
H-0
J-0
K-0
L-0
10 CONTROL BOX (C) GS 323186G01 1 1 1 -
GS 323186G02 1 1 1 1 1
11 CLAMP NO. 4253 427902-05 4 4 4 4 4 4 4 4
12 SCREW -
GROUNDING BRASS 433304-01 1 1 1 -
BRASS
433304-02 1 1 1 1 1
13 SQUARE WASHER COPPER 433537-01 1 1 1 -
COPPER
433537-02 1 1 1 1 1
14 BUSHING SR-30-1 420472-03 1 1 1 1 1 1 1 1
15 JUNCTION BOX
COVER GS 433410-01 1 1 1 1 1 1 1 1
16 REAR PANEL GS 323051-01 1 1 1 1 1 1 1 1
17 SIDE PANEL SS 212965G01 2-
SS 214489-01 2 2 -
SS 214489-03 2 2 2 2 2
18 - - - - - - - - - -
19 CAPACITOR SH-JPSU 435648-01 1 1 1 1 1 1 -
25 MFD
370VAC
439943-02 1 1
20 BRACKET - FRONT
PANEL SS 3A0041-01 1 1 1 1 1 1 1 1
21 TOP PANEL SS 323046G01 1 1 1 -
TOP KIT PE 325258G01 1 1 -
PE 325258G02 1 1 1
22 SEAL (A1) NBR 435545-02 1-
23 SEAL (A2) NBR 435545-02 1-

20
HA
MODEL: DB-200C TITLE:A DISPENSING BIN ASSEMBLY
INDEX
NO. DESCRIPTION MATERIAL
OR MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER J-1 J-2
K-1 K-2
A-0 A-1 B-0 B-1 B-2 C-0 C-1
D-0
D-1
E-0
F-0
F-1
G-0
H-0
J-0
K-0
L-0
24 FRONT PANEL ABS 212967G01 1111111x1
ABS 212967G02 o1
25 CABLESTRAP 5782 430361-04 1111111
26 SNAP PIN SS, SSP-6 715S-0006 1111111
27 CONTROL BOX (D) GS 323808-01 1111111
28 BUSHING OCB-750 428394-01 1111111
29 DRAIN BOARD ABS 323054G01 1111111-
ABS 3A1655G01 1
30 THUMBSCREW ABS, SS 415949G01 33333332
31 PAD ABS 436580-01 11111111
32 BRACKET DRAIN BOARD SS 4A0044-01 2222222-
33 SUPPORTING PAD PE FOAM 4A0040-01 1111111
34 STOPPER SS 3A0045-01 111 -
35 BRACKET - FRONT
PANEL GS 3A0044-01 11111111
36 SOLENOID ASSEMBLY
BASE GS 4A0048-01 11111111
37 SEAL (REAR) PVC 4A0055-01 11 1 1 1 - -
GASKET L=620 4A0808L01 33
38 SEAL (FRONT) PVC 4A0056-01 11 1 1 1 - -
GASKET L=660 4A0808L01 22
39 SEAL (SIDE) PVC 4A0055-01 222 2 2 2 - -
40 CHAIN COVER (A) - 438282-01 1111111
41 CHAIN COVER (B) - 438283-01 1111111
42 TOP KIT (4) - 214339G01 111-
-2A0093-01 111
43 TOP KIT BRACKET GS 437729-01 444444
