OCT. 9, 2000
HOSHIZAKI STORAGE BIN
ITEM NUMBER:
ISSUED:
MODEL B-250PF
B-300PF
B-500PF
B-700PF
B-800PF
B-900PF
PARTS LIST
REVISED:
DEC. 17, 2002
71213

2
B-300PF L-5 JUNE, 2001
M-5 DEC., 2001
N-5 DEC. 2002
B-500PF L-5 JUNE, 2001
M-5 DEC., 2001
N-5 DEC. 2002
B-700PF L-5 SEPT., 2001
M-5 DEC., 2001
N-5 DEC. 2002
B-800PF L-5 SEPT., 2001
M-5 DEC., 2001
N-5 DEC. 2002
B-900PF L-5 JUNE, 2001
M-5 DEC., 2001
N-5 DEC. 2002

3
MATERIAL ABBREVIATIONS
ALUMINUM
AL = Aluminum
COPPER
CU = Copper
PLASTIC
ABS = Acrylonitritrile -butadiene - styrene
AC = Polyacetal
EVA = Ethylene vinyl acetate
PA = Polyamide = Nylon
PC = Polycarbonate
PE = Polyethylene
PES = Polyester
PETP = Polyethylene terephthalate = Tetlon
PP = Polypropylene
PS = Polystyrene
PTFE = Polytetrafluoroethylene = Teflon
PUR = Polyurethane
PVC = Polyvinyl chloride
RUBBER
VN = Vinyl Nitrile
EPDM = EP rubber
NBR = Nitrile butadiene rubber
NR = Natural rubber
NP = Neoprene
SI.R = Silicone rubber
SY.R = Synthetic rubber
EPH = Epichlorohydrin
STEEL
G.S = Galvanized steel
S.S = Stainless steel
PS = Plated steel
PAS = Primed steel
AUXILIARYCODE
Ex.1 K-0
Parts are the same as in the preceding (Note) - = Part deleted.
year.
x = Part deleted and replaced
"K" is the tenth in alphabetical order with "I" by "o" (interchangeable)
skipped. So, "K" indicates "2000". part.
Ex.2 L-0 o = New part for "x" in the
"L" is the next in alphabetical same auxiliary code.
order. So, "L" indicates "2001".
Ex.3 L-1
Each time a part is changed non-interchangeably
in a year, this number advances.

4
HA
B-250PF A. BIN ASSEMBLY L-5, M-5, N-5

5
MODEL: B-250PF TITLE:A. BIN ASSEMBLY
INDEX
NO.
DESCRIPTION MATERIAL
OR MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER L-5 M-5 N-5
1 BIN BODY - 1A0648A01 1 1 1
2 NAMEPLATE PES FILM 4A2580-01 1 1 1
3 - - -
4 HINGE-BODY(R) SS 3A0105G01 1 1 1
5 HINGE-BODY(L) SS 3A0106G01 1 1 1
6 TOP COVER(5) SS 3A0157-01 1 1 1
7 INSULATION(C3) PS FORM 437687-02 3 3 3
8 GASKET PVC, L=630 4A0808L01 2 2 2
9 GASKET PVC, L=757 4A0808L01 2 2 2
10 BAFFLE(5) PS 104322-01 1 1 1
11 THUMBSCREW ABS,SS 415949G01 2 2 2
12 THUMBSCREW ABS,SS 434168G01 2 2 2
13 FRONT FRAME SS 3A0420-01 1 1 1
14 FRONT FRAME COVER(5) ABS 324625-01 1 1 1
15 BIN DOOR - 3A2087G05 1 1 1
16 WASHER SS 4A0198-01 4 4 4
17 HEX HEAD TAPPING SCREW #8, ¾” 7B03I0834 2 2 2

6
HA
B-300PF A. BIN ASSEMBLY L-5, M-5, N-5

7
MODEL: B-300PF TITLE:A. BIN ASSEMBLY
INDEX
NO.
DESCRIPTION MATERIAL
OR MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER L-5 M-5 N-5
1 BIN BODY - 1A0648A02 1 1 1
2 NAMEPLATE PES FILM 4A2580-02 1 1 1
3 - - -
4 HINGE-BODY(R) SS 3A0105G01 1 1 1
5 HINGE-BODY(L) SS 3A0106G01 1 1 1
6 TOP COVER(3) SS 3A0156-01 1 1 1
7 INSULATION(C3) PS FORM 437687-01 3 3 3
8 GASKET PVC, L=630 4A0808L01 2 2 2
9 GASKET PVC, L=554 4A0808L01 2 2 2
10 BAFFLE(3) PS 104391-01 1 1 1
11 THUMBSCREW ABS,SS 415949G01 2 2 2
12 THUMBSCREW ABS,SS 434168G01 2 2 2
13 - - -
14 FRONT FRAME COVER(3) ABS 324617-01 1 1 1
15 BIN DOOR - 3A2087G04 1 1 1
16 WASHER SS 4A0198-01 4 4 4
17 WASHER - 4A0928-01 2 2 2

8
HA
B-500PF A. BIN ASSEMBLY L-5, M-5, N-5

9
MODEL: B-500PF TITLE:A. BIN ASSEMBLY
INDEX
NO.
DESCRIPTION MATERIAL
OR MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER L-5 M-5 N-5
1 BIN BODY - 1A0648A04 1 1 1
2 NAMEPLATE PES FILM 4A2580-04 1 1 1
3 - - -
4 HINGE-BODY(R) SS 3A0105G01 1 1 1
5 HINGE-BODY(L) SS 3A0106G01 1 1 1
6 TOP COVER(5) SS 3A0157-01 1 1 1
7 INSULATION(C2) PS FORM 437687-02 3 3 3
8 GASKET PVC, L=630 4A0808L01 2 2 2
9 GASKET PVC, L=757 4A0808L01 2 2 2
10 BAFFLE(5) PS 104322-01 1 1 1
11 THUMBSCREW ABS,SS 415949G01 2 2 2
12 THUMBSCREW ABS,SS 434168G01 2 2 2
13 FRONT FRAME(5) - 3A0420-01 1 1 1
14 FRONT FRAME COVER(5) ABS 324625-01 1 1 1
15 BIN DOOR - 3A2087G05 1 1 1
16 WASHER SS 4A0198-01 4 4 4
17 - - -
18- - -
19 HEX HEAD TAPPING SCREW #8, ¾” 7B03I0834 2 2 2

10
HA
B-700, 800, 900PF A. BIN ASSEMBLY L-5, M-5, N-5
