Hoshizaki B-250PF User manual

Hoshizaki
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshiza i.com
BIN DIMENSIONS
xDxH
PF/SF BINS
4/08
Item # 13163
ICE STORAGE BIN SERIES
arranty
alid in United States, Canada, Puerto Rico, & U.S.Territories. Contact factory for warranty in
other countries.
Two Year - Parts & Labor.
PF/SF BINS
Item #
Project:
Qty:
Hoshizaki reserves the right to change specifications without notice.
B-250PF
30 x 321/2 x 333/8*
*AutoCad available on KCL
PF BINS
•Ice storage capacity from 250 lbs. up to 900 lbs.
•Vinyl clad galvanized steel cabinet exterior design for easy cleaning
SF BINS
•Ice storage capacity from 300 lbs. up to 900 lbs.
•Stainless steel exterior design for easy cleaning
PF/SF BINS
•Protected by HoshiGuard Antimicrobial Agent
•Long lasting attractive appearance
•Polyethylene bin liner for sanitary storage
•Sturdy construction for side by side or stac ed ice machine installation
•Foamed-in-place polyurethane insulation, in all bin walls and bottom, provides dependable ice storage
B-250PF B-300PF B-500PF B-700PF B-800PF B-900PF
B-300SF B-500SF B-700SF B-800SF B-900SF
PF - P C Coated Galvanized Steel Finish
SF - Stainless Steel Finish
B-300PF/SF
22 x 321/2 x 46*
B-900PF/SF
52 x 321/2 x 46*
B-800PF/SF
48 x 321/2 x 46*
B-700PF/SF
44 x 321/2 x 46*
B-500PF/SF
30 x 321/2 x 46*
*with 6" adj. legs

Hoshizaki
©HOSHIZAKI AMERICA, INC.
PF/SF BINS
ICE STORAGE BIN SERIES
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshiza i.com Printed in U.S.A.
B-250PF
B-300PF/SF
B-500PF/SF
B-700PF/SF
B-800PF/SF
B-900PF/SF
ICE STORAGE BIN APPLICATION
Mod l Numb r Application
Capacity
Storag
ARI-Rat d
Storag
Capacity
B-300PF/SF 300 lbs. 260 lbs.
B-500PF/SF 500 lbs. 360 lbs.
B-250PF 250 lbs. 230 lbs.
• Up to 230 lbs. of ice storage
•Up to 260 lbs. of ice storage
• Up to 360 lbs. of ice storage
• Up to 550 lbs. of ice storage
• Up to 600 lbs. of ice storage
• Up to 660 lbs. of ice storage
B-800PF/SF 800 lbs. 600 lbs.
B-900PF/SF 900 lbs. 660 lbs.
B-700PF/SF 700 lbs. 550 lbs.
Dim nsions
W x D x H
Shipping
W ight
22" x 321/2" x 46*" 135 lbs.
30" x 321/2" x 46*"155 lbs.
30" x 321/2" x 333/8*"130 lbs.
48" x 321/2" x 46*" 210 lbs.
52" x 321/2" x 46*" 220 lbs.
44" x 321/2" x 46*"200 lbs.
Bin
22" Width
B-300PF/SF
30" Width
B-250PF
B-500PF/SF
44" Width
B-700PF/SF
48" Width
B-800PF/SF
52" Width
B-900PF/SF
22" Width
KM-320M
KM-461M
KM-501M
KM-650M
F-450M
F-801M
F-1001M
30" Width
KM-900M
KM-1340M
KM-1601M
KML Series
F-1500M
F-2000M
No
Top Kit
Nee e
ICE MACHINE MODEL APPLICATION
* KMD Top Kit - Call Factory
44" Width
2 KM-320M
2 KM-461M
2 KM-501M
2 KM-650M
2 F-450M
2 F-801M
2 F-1001M
48" Width
KM-1300S
KM-1600S
KM-1601S
KM-1800S
KM-2000S
KM-2400S
Nee
HS-2033
Nee
HS-2035
No
Top Kit
Nee e
Nee
HS-2034
No
Top Kit
Nee e
Nee
HS-2035
&
HS-2032
Nee
HS-2034
&
HS-2032
Nee
HS-2033
No
Top Kit
Nee e
Nee
HS-2035
&
HS-2033
Nee
HS-2035
Nee
HS-2033
Nee
HS-2032
30
3/4” FPT Drain
6
a j.
legs
273/8
333/8
321/2
15
30
B-250PF
22 x 321/2 x 333/8
Wx D x H
B-300PF/SF
22 x 321/2 x 46
W x D x H
B-500PF/SF
30 x 321/2 x 46
W x D x H
B-700PF/SF
44 x 321/2 x 46
W x D x H
B-800PF/SF
48 x 321/2 x 46
W x D x H
B-900PF/SF
52 x 321/2 x 46
W x D x H
46
40
6
281/2
311/2
321/2 Accepts 5/8 Shank Leg 3/4” FPT Drain
B-300PF/SF 22”
B-500PF/SF 30”
B-700PF/SF 44”
B-800PF/SF 48”
B-900PF/SF 52”
B-300PF/SF 11”
B-500PF/SF 15”
B-700PF/SF 22”
B-800PF/SF 24”
B-900PF/SF 26”
Slim-Lin
*height includes 6" adj. legs
