Hardware Reference Guide
HP Compaq Business Desktop
dc5000 Small Form Factor Model
Document Part Number: 359513-001
January 2004
This guide provides basic information for upgrading this computer
model.

© Copyright 2004 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
Microsoft, MS-DOS, Windows, and Windows NT are trademarks of Microsoft
Corporation in the U.S. and other countries.
Intel, Pentium, Intel Inside, and Celeron are trademarks of Intel Corporation in
the U.S. and other countries.
Adobe, Acrobat, and Acrobat Reader are trademarks or registered trademarks of
Adobe Systems Incorporated.
The only warranties for HP products and services are set forth in the express
warranty statements accompanying such products and services. Nothing herein
should be construed as constituting an additional warranty. HP shall not be liable
for technical or editorial errors or omissions contained herein.
This document contains proprietary information that is protected by copyright.
No part of this document may be photocopied, reproduced, or translated to
another language without the prior written consent of Hewlett-Packard
Company.
ÅWARNING: Text set off in this manner indicates that failure to follow
directions could result in bodily harm or loss of life.
ÄCAUTION: Text set off in this manner indicates that failure to follow
directions could result in damage to equipment or loss of information.
Hardware Reference Guide
HP Compaq Business Desktop
dc5000 Small Form Factor Model
First Edition January 2004
Document Part Number: 359513-001

Hardware Reference Guide www.hp.com iii
Contents
1 Product Features
Standard Configuration Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–1
Front Panel Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–2
Rear Panel Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–3
Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–4
Windows Logo Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–5
Special Mouse Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–6
Serial Number Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–6
2 Hardware Upgrades
Serviceability Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
Using the Small Form Factor Computer in a Minitower Configuration. . . . . . . . . . . . 2–2
Removing the Computer Access Panel and Front Bezel. . . . . . . . . . . . . . . . . . . . . . . . 2–3
Installing Additional Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–5
DIMMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–5
DDR-SDRAM DIMMs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–5
DIMM Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–6
Installing an Expansion Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–11
Installing Additional Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–14
Locating Drive Positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–15
Removing an Optical Drive or Diskette Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–16
Installing an Optional Optical Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–18
Upgrading the Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–21

iv www.hp.com Hardware Reference Guide
Contents
A Specifications
B PATA Hard Drive Installation Guidelines
Using the Cable-Select Feature with Parallel ATA (PATA) Devices. . . . . . . . . . . . . . B–1
Guidelines for Installing PATA Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B–1
C Battery Replacement
D Security Lock Provisions
Installing a Security Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D–1
E Port Security Bracket
Installing the Port Security Bracket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E–1
Removing the Port Security Bracket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E–6
F Electrostatic Discharge
Preventing Electrostatic Damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F–1
Grounding Methods. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F–1
G Routine Computer Care and Shipping Preparation
Routine Computer Care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G–1
Optical Drive Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G–2
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G–2
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G–2
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G–2
Shipping Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G–3
Index

Hardware Reference Guide www.hp.com 1-1
1
Product Features
Standard Configuration Features
The HP Compaq Small Form Factor features may vary depending on
the model. For a complete listing of the hardware and software
installed in the computer, run the Diagnostics for Windows utility.
Instructions for using this utility are provided in the Troubleshooting
Guide on the Documentation CD.
✎To use the computer in a minitower configuration, you must purchase
a tower stand from HP (part number 316593-001).For more
information, see the “Using the Small Form Factor Computer in a
Minitower Configuration” section in this guide.
Small Form Factor Configuration

1-2 www.hp.com Hardware Reference Guide
Product Features
Front Panel Components
Drive configuration may vary by model.
Front Panel Components
1Diskette Drive Activity Light (optional) 7USB (Universal Serial Bus) Ports
2Diskette Drive (optional) 8Hard Drive Activity Light
3Diskette Eject Button (optional) 9Power On Light
4Optical Drive (CD-ROM, CD-R/RW,
DVD-ROM, DVD +R/RW, or
CD-RW/DVD Combo Drive)
-Power Button
5Microphone Connector qOptical Drive Activity Light
6Headphone Jack wOptical Drive Eject Button

Hardware Reference Guide www.hp.com 1-3
Product Features
Rear Panel Components
Rear Panel Components
1Power Cord Connector 7nRJ-45 Network Connector
2Voltage Select Switch 8lParallel Connector
3bPS/2 Mouse Connector 9cMonitor Connector
4aPS/2 Keyboard Connector -hHeadphone/Line-Out Connector
5oUniversal Serial Bus (USB) qjLine-In Audio Connector
6mSerial Connector wgMicrophone Connector
✎Arrangement and number of connectors may vary by model.
When a PCI graphics card is installed, the connectors on the card and the system board may
be used at the same time. Some settings may need to be changed in F10 setup to use both
connectors. In F10 setup, go to Advanced > PCI VGA Configuration to change the settings. For
more information about F10 setup, refer to the Computer Setup (F10) Utility Guide on the
Documentation CD.

1-4 www.hp.com Hardware Reference Guide
Product Features
Keyboard
Keyboard Components
1Function Keys Perform special functions depending on the software application
being used.
2Editing Keys Includes the following: Insert, Home, Page Up, Delete,
End, and Page Down.
3Status Lights Indicate the status of the computer and keyboard settings
(Num Lock, Caps Lock, and Scroll Lock).
4Numeric Keys Work like a calculator keypad.
5Arrow Keys Used to navigate through a document or Web site. These keys
allow you to move left, right, up, and down, using the keyboard
instead of the mouse.
6Ctrl Key Used in combination with another key; its effect depends on the
application software you are using.
7Application Key* Used (like the right mouse button) to open pop-up menus in a
Microsoft Office application. May perform other functions in other
software applications.

Hardware Reference Guide www.hp.com 1-5
Product Features
Windows Logo Key
Use the Windows Logo key in combination with other keys to
perform certain functions available in the Windows operating system.
Refer to the “Keyboard” section to identify the Windows Logo key.
8Windows Logo Key* Used to open the Start menu in Microsoft Windows. Used in
combination with other keys to perform other functions.
9Alt Key Used in combination with another key; its effect depends on the
application software you are using.
*Keys available in select geographic regions.
Keyboard Components (Continued)
Windows Logo Key Functions
Windows Logo Key Displays or hides the Start menu.
Windows Logo Key + dDisplays the Desktop.
Windows Logo Key + mMinimizes all open applications.
Shift + Windows Logo Key + m Undoes Minimize All.
Windows Logo Key + eLaunches My Computer.
Windows Logo Key + fLaunches Find Document.
Windows Logo Key + Ctrl + f Launches Find Computer.
Windows Logo Key + F1 Launches Windows Help.
Windows Logo Key + lLocks the computer if you are connected to a
network domain, or allows you to switch users if you
are not connected to a network domain.
Windows Logo Key + rLaunches the Run dialog box.
Windows Logo Key + uLaunches the Utility Manager.
Windows Logo Key + Tab Activates the next Taskbar button.

1-6 www.hp.com Hardware Reference Guide
Product Features
Special Mouse Functions
Most software applications support the use of a mouse. The functions
assigned to each mouse button depend on the software applications
you are using.
Serial Number Location
Each computer has a unique serial number that is located on the
top cover or the back panel of the computer. Keep this number
available for use when contacting customer service for assistance.
Serial Number Location

Hardware Reference Guide www.hp.com 2-1
2
Hardware Upgrades
Serviceability Features
This computer includes features that make it easy to upgrade and
service. No tools are needed for most of the installation procedures
described in this chapter.
Warnings and Cautions
Before performing upgrades be sure to carefully read all of the
applicable instructions, cautions, and warnings in this guide.
ÅWARNING: To reduce the risk of personal injury from electrical shock
and/or hot surfaces, be sure to disconnect the power cord from the wall
outlet, and allow the internal system components to cool before touching.
ÅWARNING: To reduce the risk of electrical shock, fire, or damage to the
equipment, do not plug telecommunications/telephone connectors into the
network interface controller (NIC) receptacles.
ÄCAUTION: Static electricity can damage the electronic components of
the computer or optional equipment. Before beginning these procedures,
ensure that you are discharged of static electricity by briefly touching a
grounded metal object. Refer to Appendix F, “Electrostatic Discharge” in
this guide for additional information on preventing electrostatic discharge.
ÄCAUTION: Before removing the computer access panel ensure that the
computer is turned off and that the power cord is disconnected from
the electrical outlet.

2-2 www.hp.com Hardware Reference Guide
Hardware Upgrades
Using the Small Form Factor Computer in a
Minitower Configuration
The Small Form Factor computer can be used in either a minitower or
desktop configuration. To use it in the minitower configuration, you
must purchase a tower stand from HP (part number 316593-001).
ÄCAUTION: If the computer is in the desktop configuration, ensure at least
4 inches (10.2 cm) of space on all sides of the computer remains clear
and free of obstructions.
To install the tower stand:
1. Align the hole at the base of the computer with the post and
thumbscrew in the stand 12.
2. Tighten the screw to secure the computer to the stand 3. This
adds stability and helps to ensure proper airflow to the internal
components.

Hardware Reference Guide www.hp.com 2-3
Hardware Upgrades
Removing the Computer Access Panel and
Front Bezel
To remove the computer access panel:
1. Turn off the computer properly through the operating system,
then turn off any external devices.
2. Disconnect the power cord from the power outlet and the
computer, and disconnect any external devices.
ÄCAUTION: Before removing the computer access panel, ensure that the
computer is turned off and that the power cord is disconnected from
the electrical outlet.
3. On the top of the computer, locate the cover latch. Pull up and
hold the latch 1to release the computer access panel.
4. Slide the computer access panel back 2about 0.5 inch (1.25 cm),
then lift the access panel up and off the chassis.
Removing the Computer Access Panel

2-4 www.hp.com Hardware Reference Guide
Hardware Upgrades
5. To remove the front bezel, gently pull up all three tabs 1on the
top of the bezel, then pull the bezel 2away from the chassis.
Removing the Front Bezel
To reassemble the computer, reverse the above procedure.
Press down while replacing the access panel. Refer to the label on the
inside of the access panel for more information.
✎To re-install the front bezel, insert the two bezel bottom tabs, then
rotate the front bezel forward to snap the three tabs on the top of the
bezel in place.

Hardware Reference Guide www.hp.com 2-5
Hardware Upgrades
Installing Additional Memory
The computer comes with double data rate synchronous dynamic
random access memory (DDR-SDRAM) dual inline memory
modules (DIMMs).
DIMMs
The memory sockets on the system board can be populated with up to
four industry-standard DIMMs. These memory sockets are populated
with at least one preinstalled DIMM. To achieve the maximum
memory support, you can populate the system board with up to 4GB
of memory configured in a high-performing dual channel mode.
DDR-SDRAM DIMMs
For proper system operation, if the computer supports DDR-SDRAM
DIMMs, the DIMMs must be:
■industry-standard 184-pin
■unbuffered PC2100 266 MHz-, PC2700 333 MHz-, or PC3200
400 MHz-compliant
■2.5 volt DDR-SDRAM DIMMs.
The DDR-SDRAM DIMMs must also:
■support CAS latency 2 or 2.5 (CL = 2 or CL = 2.5)
■contain the mandatory JEDEC SPD information
In addition, the computer supports:
■128Mbit, 256Mbit, and 512Mbit non-ECC memory technologies
■single-sided and double-sided DIMMS
■DIMMs constructed with x8 and x16 DDR devices; DIMMs
constructed with x4 SDRAM are not supported

2-6 www.hp.com Hardware Reference Guide
Hardware Upgrades
The following processor bus frequencies are required for the system
to run at the supported memory frequencies.
If a memory frequency is paired with an unsupported processor bus
frequency, the system will run at the highest supported memory
speed. For example, if a 333 MHz DIMM is paired with a 400 MHz
processor bus, the system will run at 266 MHz, the highest supported
memory speed.
✎The system will not start if you install unsupported DIMMs.
DIMM Sockets
The system will automatically operate in single channel mode or a
higher-performing dual channel mode, depending on how the DIMMs
are installed.
■In single channel mode, the maximum operational speed is
determined by the slowest DIMM in the system. For example, if
the system is populated with a DIMM that is 266 MHz and a
second DIMM that is 333 MHz, the system will run at the slower
of the two speeds.
■In dual channel mode, all DIMMs must be identically matched.
DIMMs in the XMM1 and XMM3 black sockets must be
identical; DIMMs in the XMM2 and XMM4 blue sockets must
also be identical. Therefore, if you have one preinstalled DIMM
in socket XMM1 and are adding a second DIMM, it is
recommended that you install an identical DIMM into the XMM3
socket. If you are populating all four DIMM sockets, use identical
DIMMs in each socket. Otherwise, the system will not operate in
dual channel mode.
Memory Frequency Required Processor Bus Frequency
266 MHz 400 MHz, 533 MHz, or 800 MHz
333 MHz 533 MHz or 800 MHz
400 MHz 800 MHz

Hardware Reference Guide www.hp.com 2-7
Hardware Upgrades
There are four DIMM sockets on the system board, with two sockets
per channel. The sockets are labeled XMM1, XMM2, XMM3, and
XMM4. Sockets XMM1 and XMM2 operate in memory channel A.
Sockets XMM3 and XMM4 operate in memory channel B.
DIMM Socket Locations
Item Description Socket Color
1DIMM socket XMM4, Channel B Blue
2DIMM socket XMM3, Channel B Black
3DIMM socket XMM2, Channel A Blue
4DIMM socket XMM1, Channel A Black

2-8 www.hp.com Hardware Reference Guide
Hardware Upgrades
Installing DDR-SDRAM DIMMs
ÄCAUTION: The memory module sockets have gold metal contacts. When
upgrading the memory, it is important to use memory modules with gold
metal contacts to prevent corrosion and/or oxidation resulting from having
incompatible metals in contact with each other.
ÄCAUTION: Static electricity can damage the electronic components of
the computer or optional cards. Before beginning these procedures,
ensure that you are discharged of static electricity by briefly touching a
grounded metal object. Refer to Appendix F, “Electrostatic Discharge” for
more information.
ÄCAUTION: When handling a memory module, be careful not to touch
any of the contacts. Doing so may damage the module.
1. Turn off the computer properly through the operating system,
then turn off any external devices.
2. Disconnect the power cord from the power outlet and disconnect
any external devices.
3. Remove the computer access panel and front bezel.
ÄCAUTION: Check the position of all cables and wires before raising or
lowering the Easy Access drive bay to prevent damage.

Hardware Reference Guide www.hp.com 2-9
Hardware Upgrades
4. Rotate the Easy Access drive bay to an upright position.
Rotating the Easy Access Drive Bay
5. Locate the memory module sockets.
ÅWARNING: To reduce risk of personal injury from hot surfaces, allow
the internal system components to cool before touching.

2-10 www.hp.com Hardware Reference Guide
Hardware Upgrades
6. Open both latches of the memory module socket 1, then insert
the memory module into the socket 2.
Installing a DIMM
✎A memory module can be installed in only one way. Match the notch
on the module with the tab on the memory socket.
✎If you have one preinstalled DIMM in socket XMM1 and are adding a
second DIMM, it is recommended that you install an identical DIMM
into the XMM3 socket. Otherwise, the computer will not operate in
dual channel mode.
7. Push the module down into the socket, ensuring that the module
is fully inserted and properly seated. Make sure the latches are in
the closed position 3.
