QuickSpecs HP Workstation xw8000
DA-11506 North America — Version 11 — June 2, 2003 1
Overview
At A Glance
•Supports up to two Intel®Xeon™
processors, up to 3.06 GHz
•512 KB L2 cache integrated on
processor
•Intel E7505 chipset with dual memory
channels (4.2 GB/s throughput) and
533 MHz front side bus
•PC2100 ECC registered DDR-266
expandable to 12 GB (with 2GB
DIMMs)
•Ultra320 SCSI hard drives (10,000 or
15,000 rpm) or Ultra ATA/100 hard
drives (7200 rpm)
•Integrated dual-channel
Ultra320 SCSI and Ultra ATA/100
controllers
•Up to 730 GB of high-performance
internal storage
•Choice of leadership graphics:
NVIDIA Quadro NVS 200,
NVIDIA Quadro NVS 400,
NVIDIA Quadro4 380XGL,
NVIDIA Quadro2 EX,
ATI FIRE GL 8800,
ATI FIRE GL Z1-128p
NVIDIA Quadro4 750 XGL,
NVIDIA Quadro4 980 XGL,
NVIDIA Quadro4 900 XGL,
3Dlabs Wildcat III 6110,
ATI FIRE GL X1-256p,
NVIDIA Quadro FX2000
•Support for up to 8 displays
•Integrated Intel 10/100/1000 Mb
Ethernet adapter
•Six total slots – five PCI and one AGP
8X
•Eight bays (five internal, three external)
•CD-ROM, CD-RW, DVD-ROM, or
DVD+RW
•Windows®XP Professional, Windows
2000 Professional, or Red Hat Linux
•Protected by HP services, including a
three-year limited warranty in many
countries. Certain restrictions and
exclusions apply. Three-year onsite
labor not available in all countries.

QuickSpecs HP Workstation xw8000
DA-11506 North America — Version 11 — June 2, 2003 2
Standard Features
Processor Intel Xeon processor 2.4-GHz, 512-KB cache, 533-MHz front side bus
Intel Xeon processor 2.66-GHz, 512-KB cache, 533-MHz front side bus
Intel Xeon processor 2.8-GHz, 512-KB cache, 533-MHz front side bus
Intel Xeon processor 3.06-GHz, 512-KB cache, 533-MHz front side bus
Cache Memory 512-KB integrated, full speed Level 2 cache per processor
Chipset Intel E7505 chipset
Processor Upgradability Upgradable to dual processor
Standard 512-MB of PC2100 ECC registered DDR-266
Memory Maximum 12-GB of PC2100 ECC registered DDR-266*
Network Controller Integrated Intel 10/100/1000 Mb Ethernet adapter
I/O (Total) 6, up to 5 available
Expansion Slots PCI-X 1.0 64b/133MHz 1, up to 1 depending on model
PCI-X 1.0 64b/100MHz 2, up to 2 depending on model
PCI 2.2 32b/33MHz 2, up to 2 depending on model
AGP 8x Pro 50 (50w) 1, up to 1 depending on model
Expansion Bays (Total/Available) 8 total / 5 available
Internal 3.5 inch 5 bays / 4 available
External 5.25 inch 2 bays / 1 available
External 3.5 inch 1 external floppy drive
Controllers SCSI Integrated dual channel Ultra320 SCSI controller
Ultra ATA/100 Integrated Ultra ATA/100
Storage Diskette Drive 1.44 MB
Removable Media CD-ROM, DVD-ROM, CD-RW, or DVD+RW
Hard Drive 40-GB, 80-GB, 120-GB, 160-GB Ultra ATA/100 EIDE (7,200 rpm)
18-GB, 36-GB, or 73-GB Ultra320 SCSI (15,000 rpm);
36-GB, 73-GB, or 146-GB Ultra320 SCSI (10,000 rpm)
Parallel One 25-pin DIN (rear)
USB 2.0 6 (2 front, 4 rear)
Serial One 9-pin DIN (rear)
Ultra320 SCSI 2 (68-pin internal and optional 68-pin external)
Ultra ATA/100 2 (internal)
IEEE 1394 2 (1 front, 1 back)
Keyboard (PS/2) 1 (rear)
Pointing Device (PS/2 mouse) 1 (rear)
Video choice of professional graphics options
Network 1 RJ-45 connector (rear)
Microphone Jack 2 (front & rear)
Headphone Jack 1 (front)
Line-In Jack 1 (rear)
Interfaces
Line-Out Jack 1 (rear)

QuickSpecs HP Workstation xw8000
DA-11506 North America — Version 11 — June 2, 2003 3
Standard Features
Graphics
One of the following:
NVIDIA Quadro NVS 200 (AGP)
NVIDIA Quadro NVS 400 (AGP)
NVIDIA Quadro2 EX (AGP)
NVIDIA Quadro4 380 XGL (AGP)
ATI FIRE GL 8800 (AGP)
ATI FIRE GL Z1-128p (AGP)
NVIDIA Quadro4 750 XGL (AGP)
NVIDIA Quadro4 980 XGL (AGP)
NVIDIA Quadro4 900 XGL (AGP)
3Dlabs Wildcat III 6110 (AGP)
ATI FIRE GL X1-256p (AGP)
NVIDIA Quadro FX2000
Input devices Easy Access Keyboard (PS/2)
3-Button Mouse (PS/2)
Audio AC97/16-bit stereo full-duplex and Integrated speaker
Software Microsoft Windows XP Professional preinstall
Microsoft Windows 2000 Professional, service pack 3, preinstall
Red Hat Linux 7.3 preinstalled, preconfigured and supported
Red Hat Linux 8.0 supported
Management Bios Features
Advanced Configuration and Power Interface (ACPI) 1.0b
Desktop Management Interface (DMI) 2.0
System Management (SM) Bios 2.3
NIC Hardware
Remote Wakeup
Wake on LAN (WoL)
Web downloads
System Software Manager
Insight Management Agent
Altiris Express
Remote ROM Flash
Remote Shut Down
Security Diskette write and boot control
Flash ROM lock
Network server mode
Parallel interface control
Power-on password
Serial interface control
Setup password
Cable lock provision
Power Supply 450 watts, with Power Factor Correction
Service and Support Protected by HP services including a three-year, limited warranty with three-year parts coverage, three year, on-
site service, and three-year labor (in many countries); 7 x 24 hardware technical phone support and on-line
support through the Internet; Pre-Failure Warranty coverage of hard drives, memory.
NOTE: Certain restrictions and exclusions apply. Consult the customer support center for details.
Three-year, onsite and labor not available in all countries.

QuickSpecs HP Workstation xw8000
DA-11506 North America — Version 11 — June 2, 2003 4
Standard Features –Pre-configured Global Models
X8X/2.4/36S/512/Xd Processor Intel Xeon processor 2.4-GHz
Cache Memory 512-KB integrated L2 470047-461 Memory 512MB (2x256-MB) PC2100 ECC registered DDR-266
Optical Drive 16X/40X DVD-ROM Drive
Hard Drive 36-GB Ultra320 SCSI (10,000 rpm)
Graphics Not included in base configuration – Please choose a graphics card option
below:
NVIDIA Quadro NVS 200
NVIDIA Quadro NVS 400
NVIDIA Quadro2 EX LP
NVIDIA Quadro4 380XGL
ATI FIRE GL 8800
ATI FIRE GL Z1-128p
NVIDIA Quadro4 750 XGL
NVIDIA Quadro4 980 XGL
NVIDIA Quadro4 900 XGL
3DLabs Wildcat III 6110
ATI FIRE GL X1-256p
NVIDIA Quadro FX2000
NOTE: Please see Part Numbers in After market options/Standalone
accessories section.
Mouse HP 3-button mouse (PS/2)
OS Microsoft Windows XP Professional
X8K/2.4/18K/512/Xd Processor Intel Xeon processor 2.4-GHz
Cache Memory 512-KB integrated L2 470046-976 Memory 512MB (2x256-MB) PC2100 ECC registered DDR-266
Optical Drive 16X/40X DVD-ROM Drive
Hard Drive 18-GB Ultra320 SCSI (15,000 rpm)
ATI FIRE GL X1
Graphics Not included in base configuration – Please choose a graphics card option
below:
NVIDIA Quadro NVS 200
NVIDIA Quadro NVS 400
NVIDIA Quadro2 EX LP
NVIDIA Quadro4 380XGL
ATI FIRE GL 8800
ATI FIRE GL Z1-128p
NVIDIA Quadro4 750 XGL
NVIDIA Quadro4 980 XGL
NVIDIA Quadro4 900 XGL
3DLabs Wildcat III 6110
ATI FIRE GL X1-256p
NVIDIA Quadro FX2000
NOTE: Please see Part Numbers in After market options/Standalone
accessories section.
Mouse HP 3-button mouse (PS/2)
OS Microsoft Windows 2000 Professional

QuickSpecs HP Workstation xw8000
DA-11506 North America — Version 11 — June 2, 2003 5
Standard Features –Pre-configured Global Models
X8X/2.4/18K/512/Xd Processor Intel Xeon processor 2.4-GHz
Cache Memory 512-KB integrated L2 470046-977 Memory 512MB (2x256-MB) PC2100 ECC registered DDR-266
Optical Drive 16X/40X DVD-ROM Drive
Hard Drive 18-GB Ultra320 SCSI (15,000 rpm)
Graphics Not included in base configuration – Please choose a graphics card option
below:
NVIDIA Quadro NVS 200
NVIDIA Quadro NVS 400
NVIDIA Quadro2 EX LP
NVIDIA Quadro4 380XGL
ATI FIRE GL 8800
ATI FIRE GL Z1-128p
NVIDIA Quadro4 750 XGL
NVIDIA Quadro4 980 XGL
NVIDIA Quadro4 900 XGL
3DLabs Wildcat III 6110
ATI FIRE GL X1-256p
NVIDIA Quadro FX2000
NOTE: Please see Part Numbers in After market options/Standalone
accessories section.
Mouse HP 3-button mouse (PS/2)
OS Microsoft Windows XP Professional
X8X/2.4/36S/512/Xc Processor Intel Xeon processor 2.4-GHz
Cache Memory 512-KB integrated L2 470046-978 Memory 512MB (2x256-MB) PC2100 ECC registered DDR-266
Optical Drive CD-ROM
Hard Drive 36-GB Ultra320 SCSI (10,000 rpm)
Graphics Not included in base configuration – Please choose a graphics card option
below:
NVIDIA Quadro NVS 200
NVIDIA Quadro NVS 400
NVIDIA Quadro2 EX LP
NVIDIA Quadro4 380XGL
ATI FIRE GL 8800
ATI FIRE GL Z1-128p
NVIDIA Quadro4 750 XGL
NVIDIA Quadro4 980 XGL
NVIDIA Quadro4 900 XGL
3DLabs Wildcat III 6110
ATI FIRE GL X1-256p
NVIDIA Quadro FX2000
NOTE: Please see Part Numbers in After market options/Standalone
accessories section.
Mouse HP 3-button mouse (PS/2)
OS Microsoft Windows XP Professional

QuickSpecs HP Workstation xw8000
DA-11506 North America — Version 11 — June 2, 2003 6
Standard Features –Pre-configured Global Models
X8K/2.4/40A/512/Xc Processor Intel Xeon processor 2.4-GHz
Cache Memory 512-KB integrated L2 470046-979 Memory 512MB (2x256-MB) PC2100 ECC registered DDR-266
Optical Drive CD-ROM
Hard Drive 40-GB Ultra ATA/100 EIDE (7,200 rpm)
Graphics Not included in base configuration – Please choose a graphics card option
below:
NVIDIA Quadro NVS 200
NVIDIA Quadro NVS 400
NVIDIA Quadro2 EX LP
NVIDIA Quadro4 380XGL
ATI FIRE GL 8800
ATI FIRE GL Z1-128p
NVIDIA Quadro4 750 XGL
NVIDIA Quadro4 980 XGL
NVIDIA Quadro4 900 XGL
3DLabs Wildcat III 6110
ATI FIRE GL X1-256p
NVIDIA Quadro FX2000
NOTE: Please see Part Numbers in After market options/Standalone
accessories section.
Mouse HP 3-button mouse (PS/2)
OS Microsoft Windows 2000 Professional
X8X2.4/40A/512/Xc Processor Intel Xeon processor 2.4-GHz
Cache Memory 512-KB integrated L2 470046-980 Memory 512MB (2x256-MB) PC2100 ECC registered DDR-266
Optical Drive CD-ROM
Hard Drive 40-GB Ultra ATA/100 EIDE (7,200 rpm)
Graphics Not included in base configuration – Please choose a graphics card option
below:
NVIDIA Quadro NVS 200
NVIDIA Quadro NVS 400
NVIDIA Quadro2 EX LP
NVIDIA Quadro4 380XGL
ATI FIRE GL 8800
ATI FIRE GL Z1-128p
NVIDIA Quadro4 750 XGL
NVIDIA Quadro4 980 XGL
NVIDIA Quadro4 900 XGL
3DLabs Wildcat III 6110
ATI FIRE GL X1-256p
NVIDIA Quadro FX2000
NOTE: Please see Part Numbers in After market options/Standalone
accessories section.
Mouse HP 3-button mouse (PS/2)
OS Microsoft Windows XP Professional

QuickSpecs HP Workstation xw8000
DA-11506 North America — Version 11 — June 2, 2003 7
Standard Features –Pre-configured Global Models
X8K/2.4/36S2/Xc Processor Intel Xeon processor 2.4-GHz
Cache Memory 512-KB integrated L2 470046-981 Memory 512MB (2x256-MB) PC2100 ECC registered DDR-266
Optical Drive CD-ROM
Hard Drive 36-GB Ultra320 SCSI (10,000 rpm)
Graphics Not included in base configuration – Please choose a graphics card option
below:
NVIDIA Quadro NVS 200
NVIDIA Quadro NVS 400
NVIDIA Quadro2 EX LP
NVIDIA Quadro4 380XGL
ATI FIRE GL 8800
ATI FIRE GL Z1-128p
NVIDIA Quadro4 750 XGL
NVIDIA Quadro4 980 XGL
NVIDIA Quadro4 900 XGL
3DLabs Wildcat III 6110
ATI FIRE GL X1-256p
NVIDIA Quadro FX2000
NOTE: Please see Part Numbers in After market options/Standalone
accessories section.
Mouse HP 3-button mouse (PS/2)
OS Microsoft Windows 2000 Professional
X8X/2.66/36S/512/Xd Processor Intel Xeon processor 2.66-GHz
Cache Memory 512-KB integrated L2
Memory 512MB (2x256-MB) PC2100 ECC registered DDR-266
Optical Drive 16X/40X DVD-ROM Drive
470047-466
Hard Drive 36-GB Ultra320 SCSI (10,000 rpm)
Graphics Not included in base configuration – Please choose a graphics card option
below:
NVIDIA Quadro NVS 200
NVIDIA Quadro NVS 400
NVIDIA Quadro2 EX LP
NVIDIA Quadro4 380XGL
ATI FIRE GL 8800
ATI FIRE GL Z1-128p
NVIDIA Quadro4 750 XGL
NVIDIA Quadro4 980 XGL
NVIDIA Quadro4 900 XGL
3DLabs Wildcat III 6110
ATI FIRE GL X1-256p
NVIDIA Quadro FX2000
NOTE: Please see Part Numbers in After market options/Standalone
accessories section.
Mouse HP 3-button mouse (PS/2)
OS Microsoft Windows XP Professional

QuickSpecs HP Workstation xw8000
DA-11506 North America — Version 11 — June 2, 2003 8
Standard Features –Pre-configured Global Models
X8K/2.66/18K/512/Xd Processor Intel Xeon processor 2.66-GHz
Cache Memory 512-KB integrated L2
Memory 512MB (2x256-MB) PC2100 ECC registered DDR-266
Optical Drive 16X/40X DVD-ROM Drive
470046-998
Hard Drive 18-GB Ultra320 SCSI (15,000 rpm)
Graphics Not included in base configuration – Please choose a graphics card option
below:
NVIDIA Quadro NVS 200
NVIDIA Quadro NVS 400
NVIDIA Quadro2 EX LP
NVIDIA Quadro4 380XGL
ATI FIRE GL 8800
ATI FIRE GL Z1-128p
NVIDIA Quadro4 750 XGL
NVIDIA Quadro4 980 XGL
NVIDIA Quadro4 900 XGL
3DLabs Wildcat III 6110
ATI FIRE GL X1-256p
NVIDIA Quadro FX2000
NOTE: Please see Part Numbers in After market options/Standalone
accessories section.
Mouse HP 3-button mouse (PS/2)
OS Microsoft Windows 2000 Professional
X8X/2.66/18K/512/Xd Processor Intel Xeon processor 2.66-GHz
Cache Memory 512-KB integrated L2
Memory 512MB (2x256-MB) PC2100 ECC registered DDR-266
Optical Drive DVD-ROM
470047-001
Hard Drive 18-GB Ultra320 SCSI (15,000 rpm)
Graphics Not included in base configuration – Please choose a graphics card option
below:
NVIDIA Quadro NVS 200
NVIDIA Quadro NVS 400
NVIDIA Quadro2 EX LP
NVIDIA Quadro4 380XGL
ATI FIRE GL 8800
ATI FIRE GL Z1-128p
NVIDIA Quadro4 750 XGL
NVIDIA Quadro4 980 XGL
NVIDIA Quadro4 900 XGL
3DLabs Wildcat III 6110
ATI FIRE GL X1-256p
NVIDIA Quadro FX2000
NOTE: Please see Part Numbers in After market options/Standalone
accessories section.
Mouse HP 3-button mouse (PS/2)
OS Microsoft Windows XP Professional

QuickSpecs HP Workstation xw8000
DA-11506 North America — Version 11 — June 2, 2003 9
Standard Features –Pre-configured Global Models
X8K/2.66/18K/512/Xr Processor Intel Xeon processor 2.66-GHz
Cache Memory 512-KB integrated L2
Memory 512MB (2x256-MB) PC2100 ECC registered DDR-266
Optical Drive CD-RW Drive
470047-002
Hard Drive 18-GB Ultra320 SCSI (15,000 rpm)
Graphics Not included in base configuration – Please choose a graphics card option
below:
NVIDIA Quadro NVS 200
NVIDIA Quadro NVS 400
NVIDIA Quadro2 EX LP
NVIDIA Quadro4 380XGL
ATI FIRE GL 8800
ATI FIRE GL Z1-128p
NVIDIA Quadro4 750 XGL
NVIDIA Quadro4 980 XGL
NVIDIA Quadro4 900 XGL
3DLabs Wildcat III 6110
ATI FIRE GL X1-256p
NVIDIA Quadro FX2000
NOTE: Please see Part Numbers in After market options/Standalone
accessories section.
Mouse HP 3-button mouse (PS/2)
OS Microsoft Windows 2000 Professional
X8X/2.66/18K/512/Xr Processor Intel Xeon processor 2.66-GHz
Cache Memory 512-KB integrated L2
Memory 512MB (2x256-MB) PC2100 ECC registered DDR-266
Optical Drive CD-RW Drive
470047-003
Hard Drive 18-GB Ultra320 SCSI (15,000 rpm)
Graphics Not included in base configuration – Please choose a graphics card option
below:
NVIDIA Quadro NVS 200
NVIDIA Quadro NVS 400
NVIDIA Quadro2 EX LP
NVIDIA Quadro4 380XGL
ATI FIRE GL 8800
ATI FIRE GL Z1-128p
NVIDIA Quadro4 750 XGL
NVIDIA Quadro4 980 XGL
NVIDIA Quadro4 900 XGL
3DLabs Wildcat III 6110
ATI FIRE GL X1-256p
NVIDIA Quadro FX2000
NOTE: Please see Part Numbers in After market options/Standalone
accessories section.
Mouse HP 3-button mouse (PS/2)
OS Microsoft Windows XP Professional

QuickSpecs HP Workstation xw8000
DA-11506 North America — Version 11 — June 2, 2003 10
Standard Features –Pre-configured Global Models
X8K/2.66/36S/512/Xc Processor Intel Xeon processor 2.66-GHz
Cache Memory 512-KB integrated L2
Memory 512MB (2x256-MB) PC2100 ECC registered DDR-266
Optical Drive CD-ROM
470047-004
Hard Drive 36-GB Ultra320 SCSI (10,000 rpm)
Graphics Not included in base configuration – Please choose a graphics card option
below:
NVIDIA Quadro NVS 200
NVIDIA Quadro NVS 400
NVIDIA Quadro2 EX LP
NVIDIA Quadro4 380XGL
ATI FIRE GL 8800
ATI FIRE GL Z1-128p
NVIDIA Quadro4 750 XGL
NVIDIA Quadro4 980 XGL
NVIDIA Quadro4 900 XGL
3DLabs Wildcat III 6110
ATI FIRE GL X1-256p
NVIDIA Quadro FX2000
NOTE: Please see Part Numbers in After market options/Standalone
accessories section.
Mouse HP 3-button mouse (PS/2)
OS Microsoft Windows 2000 Professional
X8X/2.66/36S/512/Xc Processor Intel Xeon processor 2.66-GHz
Cache Memory 512-KB integrated L2
Memory 512MB (2x256-MB) PC2100 ECC registered DDR-266
Optical Drive CD-ROM
470047-005
Hard Drive 36-GB Ultra320 SCSI (10,000 rpm)
Graphics Not included in base configuration – Please choose a graphics card option
below:
NVIDIA Quadro NVS 200
NVIDIA Quadro NVS 400
NVIDIA Quadro2 EX LP
NVIDIA Quadro4 380XGL
ATI FIRE GL 8800
ATI FIRE GL Z1-128p
NVIDIA Quadro4 750 XGL
NVIDIA Quadro4 980 XGL
NVIDIA Quadro4 900 XGL
3DLabs Wildcat III 6110
ATI FIRE GL X1-256p
NVIDIA Quadro FX2000
NOTE: Please see Part Numbers in After market options/Standalone
accessories section.
Mouse HP 3-button mouse (PS/2)
OS Microsoft Windows XP Professional
