HP Xw6200 - Workstation - 2 GB RAM Installation guide

HP recommends Windows Vista™
Business
1. Monitor (sold separately) 7. 4 PCI, 1 PCI Express 8x prime slots
2. 2004 Standard Keyboard 8. 1 PCI Express x16 Graphics Bus
3. 2-Button Scroll Mouse 9. 6 USB 2.0, 1 standard serial port, 1 parallel port, 2 PS/2, 1 RJ-
45, audio in/out
4. Front IO: 2 USB 2.0, IEEE-1394 (requires optional
PCI card to enable), headphone and microphone
10. Dual 64-bit Intel® Xeon® processors
5. 3.5" external bay for optional diskette drive or other
3.5" device
11. 500 watt power supply
6. 2 internal 3.5" bays, 2 external 5.25" bays
QuickSpecs
HP xw6200 Workstation
Overview
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 1

At A Glance
64-bit Intel® Xeon® processors
Choice of operating systems: Genuine Windows XP Professional,
Genuine Windows XP Professional x64 Edition,
Red Hat Linux Workstation 4
HP Linux Installer Kit (see http://h20331.www2.hp.com/hpsub/cache/537200-0-0-225-121.html for details)
Up to 8 GB of DDR-2 memory
PCI-Express I/O and graphics
Integrated Broadcom NetXtreme Gigabit ethernet
800 MHz processor front side bus support
Intel Hyper-Threading technology support
SATA and Ultra 320 SCSI drives
Digital AC97 integrated audio with internal speaker
Pre-loaded Manageability tools
Energy Star compliance with energy-saving features
Protected by HP Services, including a 3-3-3 standard warranty. Terms and conditions vary by country. Certain restrictions and
exclusions apply.
QuickSpecs
HP xw6200 Workstation
Overview
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 2

Processor and Speed –
One of the following
64-bit Intel Xeon Processor with 800 MHz Front Side Bus
2.80 GHz (2 MB L2 cache)
3.00 GHz (2 MB L2 cache)
3.20 GHz (2 MB L2 cache)
3.40 GHz (2 MB L2 cache)
3.60 GHz (2 MB L2 cache)
3.80 GHz (2 MB L2 cache)
2nd 64-bit Intel Xeon Processor with 800 MHz Front Side Bus (optional – speed must match processor 1)
2.80 GHz (2 MB L2 cache)
3.00 GHz (2 MB L2 cache)
3.20 GHz (2 MB L2 cache)
3.40 GHz (2 MB L2 cache)
3.60 GHz (2 MB L2 cache)
3.80 GHz (2 MB L2 cache)
Operating System –
One of the following
Genuine Windows XP Professional
Genuine Windows XP Professional x64 Edition ( http://www.hp.com/workstations/pws/windowsxp64/ )
Red Hat Linux Workstation 4
HP Installer Kit for Linux (includes drivers for both 32-bit & 64-bit OS versions)
NOTE: Although HP Personal Workstations can be ordered with the HP Installer Kit for Linux and an IEEE
1394 card, HP cannot provide customer support for this configuration. Please refer to the Linux Hardware
Support Matrix ( http://www.hp.com/support/linux_hardware_matrix ) for details, and to the Linux User
Manual ( http://www.hp.com/support/linux_user_manual ) for tips on user-enablement of the IEEE 1394
Card.
1st Hard Disk Drive –
One of the following
Serial ATA 3.0-Gb/s Hard Drives
(Currently supported only at 1.5-Gb/s. To get 3.0-Gb/s performance,
a SATA 3.0-Gb/s controller must be added)
Windows XP Red Hat Linux
80 GB 7200 rpm Serial ATA drive (8 MB cache) 32-Bit, 64-Bit WS3, WS4
160 GB 7200 rpm Serial ATA NCQ drive (8 MB cache) 32-Bit, 64-Bit WS3, WS4
250 GB 7200 rpm Serial ATA drive (8 MB cache) 32-Bit, 64-Bit WS3, WS4
500 GB 7200 rpm Serial ATA NCQ drive (8 MB cache) 32-Bit, 64-Bit WS3, WS4
Serial ATA 1.5-Gb/s Hard Drives
74 GB 10K rpm Serial ATA drive (8 MB cache) 32-Bit, 64-Bit WS3, WS4
Ultra320 SCSI Hard Drives (SCSI Controller required)
73 GB 10K Ultra320 SCSI drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
146 GB 10K Ultra320 SCSI drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
300 GB 10K Ultra320 SCSI drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
36 GB 15K Ultra320 SCSI drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
QuickSpecs
HP xw6200 Workstation
Standard Features - Custom Components
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 3

73 GB 15K Ultra320 SCSI drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
2nd Hard Disk Drive –
One of the following
Serial ATA 3.0-Gb/s Hard Drives **
2nd hard drive, 80 GB 7200 rpm Serial ATA drive (8 MB cache) 32-Bit, 64-Bit WS3, WS4
2nd hard drive, 160 GB 7200 rpm Serial ATA NCQ drive (8 MB cache) 32-Bit, 64-Bit WS3, WS4
2nd hard drive, 250 GB 7200 rpm Serial ATA drive (8 MB cache) 32-Bit, 64-Bit WS3, WS4
2nd hard drive, 500 GB 7200 rpm Serial ATA NCQ drive (8 MB cache) 32-Bit, 64-Bit WS3, WS4
Serial ATA 1.5-Gb/s Hard Drives **
2nd hard drive, 74 GB 10K rpm Serial ATA drive (8 MB cache) 32-Bit, 64-Bit WS3, WS4
Ultra320 SCSI Hard Drives ***
2nd hard drive, 73 GB 10K Ultra320 SCSI drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
2nd hard drive, 146 GB 10K Ultra320 SCSI drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
2nd hard drive, 300 GB 10K Ultra320 SCSI drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
2nd hard drive, 36 GB 15K Ultra320 SCSI drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
2nd hard drive, 73 GB 15K Ultra320 SCSI drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
NOTE :
**May mix hard drive types. First hard drive must be a Serial ATA drive.
*** May mix hard drive types. SCSI Controller required. Mixed drive types not supported with Linux.
3rd Hard Disk Drive –
One of the following
Serial ATA 3.0-Gb/s Hard Drives **
3rd hard drive, 80 GB 7200 rpm Serial ATA drive (8 MB cache) 32-Bit, 64-Bit WS3, WS4
3rd hard drive, 160 GB 7200 rpm Serial ATA NCQ drive (8 MB cache) 32-Bit, 64-Bit WS3, WS4
3rd hard drive, 250 GB 7200 rpm Serial ATA drive (8 MB cache) 32-Bit, 64-Bit WS3, WS4
3rd hard drive, 500 GB 7200 rpm Serial ATA NCQ drive (8 MB cache) 32-Bit, 64-Bit WS3, WS4
Ultra320 SCSI Hard Drives ***
3rd hard drive, 73 GB 10K Ultra320 SCSI drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
3rd hard drive, 146 GB 10K Ultra320 SCSI drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
3rd hard drive, 300 GB 10K Ultra320 SCSI drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
3rd hard drive, 36 GB 15K Ultra320 SCSI drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
3rd hard drive, 73 GB 15K Ultra320 SCSI drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
QuickSpecs
HP xw6200 Workstation
Standard Features - Custom Components
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 4

NOTE :
**May mix hard drive types. First hard drive must be a Serial ATA drive.
*** May mix hard drive types. SCSI Controller required. Mixed drive types not supported with Linux.
Factory Integrated
RAID*
RAID 0 Configuration – Striped Array 32-Bit Not supported
RAID 1 Configuration – Mirrored Array 32-Bit Not supported
* NOTE: Requires 2 identical hard drives (speeds, capacity, interface).
No Linux support. 64-Bit not supported with Serial ATA Drives.
Drive controllers Integrated serial ATA controller 32-Bit, 64-Bit 7.2, 7.3,
WS3, WS4
Optional Ultra 320 SCSI controller (required if HDs are SCSI) - basic 32-Bit, 64-Bit 7.2, 7.3,
WS3, WS4
Optional U320 SCSI Controller - LSI 20320AR RAID 0,1 (required with
SCSI HDDs)and external connector
32-Bit, 64-Bit 7.2, 7.3,
WS3, WS4
* NOTE: Can be sold and used with 1 or 2 SATA drives as a stand alone controller (no SCSI HDD).
Memory -
One of the following
Windows XP Red Hat Linux
256 MB DDR-2 PC2-3200 (400 MHz) ECC Registered (1 x 256 MB) 32-Bit, 64-Bit 7.2, 7.3
512 MB DDR-2 PC2-3200 (400 MHz) ECC Registered (2 x 256 MB) 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
1 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (2 x 512 MB) 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
2 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (2 x 1 GB) 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
2 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (4 x 512 MB) 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
3 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (2 x 1 GB + 2 x 512
MB)
32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
4 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (2 x 2 GB) 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
4 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (4 x 1 GB) 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
6 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (2 x 2 GB + 2 x 1 GB) 64-Bit 7.2, 7.3, WS3,
WS4
8 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (4 x 2 GB) 64-Bit 7.2, 7.3, WS3,
WS4
QuickSpecs
HP xw6200 Workstation
Standard Features - Custom Components
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 5

Removable Storage Windows XP Red Hat Linux
1.44 MB Diskette Drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
48X CD-ROM Drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
48X CD-RW Drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
16X DVD-ROM Drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
48X Combo CD-RW/DVD-ROM Drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
16X DVD+/-RW, Dual-Layer LightScribe 32-Bit
HP No Optical Drive Option 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
2nd Removable Storage* 48X CD-RW Drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
16X DVD-ROM Drive** 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
48X Combo CD-RW/DVD-ROM Drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
16X DVD+/-RW, Dual-Layer LightScribe*** 32-Bit WS3, WS4
NOTES : *Can not order with No Optical Option. **Can not have two of the same in one workstation.
*** LightScribe software works with Windows only.
Keyboard*** -
One of the following
Windows XP Red Hat Linux
PS/2 Standard Keyboard 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
USB Standard Keyboard 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
*** NOTE: Not supported in configurations which include both USB mouse and Linux nor PS/2 mouse and
Linux.
Mouse -
One of the following
PS/2 2-Button Scroll Mouse 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
USB 2-Button Optical Scroll Mouse 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
USB 3-Button Optical Mouse 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
QuickSpecs
HP xw6200 Workstation
Standard Features - Custom Components
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 6

Audio Integrated Digital AC97 audio with internal speaker WS3 & WS4
Sound Blaster® X-Fi™ XtremeMusic PCI 32-Bit, 64-Bit Not supported
HP Optical Drive Internal Audio Cable* 32-Bit, 64-Bit WS3 & WS4
* NOTE: Not available with No Optical Option nor with the Sound Blaster X-Fi card.
NIC Broadcom 5751 Netxtreme™ Gigabit PCIe NIC 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
Graphics Windows XP Red Hat Linux
NVIDIA Quadro NVS 285 with TurboCache Technology PCI Express
(128 MB, VGA & DVI)
(Two of these graphics cards can be integrated in the factory or in
addition to an NVIDIA Quadro NVS 440).
32-Bit, 64-Bit WS3, WS4
ATI FireGL V3100 PCI Express (128 MB) 32-Bit, 64-Bit
NVIDIA Quadro FX 540 PCI Express (128 MB) 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
NVIDIA Quadro FX 1400 PCI Express (128 MB) 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
ATI FireGL V5100 PCI Express (128 MB) 32-Bit, 64-Bit
NVIDIA Quadro NVS 440 PCI Express (256 MB)
(Two of these graphics cards can be integrated in the factory or in
addition to an NVIDIA Quadro NVS 285).
32-Bit, 64-Bit
NVIDIA Quadro FX 3450 PCI Express (256 MB) 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
Miscellaneous Solenoid lock and hood sensor 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
HP FireWire IEEE 1394a 3-Port PCI Card 32-Bit, 64-Bit Not Supported
Trusted Platform Module 32-Bit
HP 64-bit Transition Tool Kit 32-Bit, 64-Bit
HP Workstations Mouse Pad N/A N/A
Software Symantec Norton AntiVirus (optional)* 32-Bit
CA eTrust 64-bit Anti-Virus Software 64-Bit
HP Performance Tuning Framework* 32-Bit, 64-Bit
Altiris Recovery* 32-Bit
HP Client Manager Software v6.0* 32-Bit
* Not available with Linux Operating System
QuickSpecs
HP xw6200 Workstation
Standard Features - Custom Components
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 7

Operating System (choice) Microsoft Windows XP Professional
Windows XP Professional x64 Edition ( http://www.hp.com/workstations/pws/windowsxp64/ )
OR Red Hat Enterprise Linux Workstation 4
OR HP Installer Kit for Linux (includes drivers for both 32-bit & 64-bit OS versions on HP xw8200, xw6200
and xw4200)
Form factor Minitower
Color Carbonite/Alloy metallic
System Board Form Factor Non-standard ATX
Processor Single or dual 64-bit Intel Xeon processors (Nocona) with Hyper-Threading Technology
CPU Bus Speed Supported 800 MHz FSB
Standard L2 Cache 2 MB L2 cache
Chipset Intel E7525
Memory Expansion Slots 4 DIMM's
Memory Type Supported DDR-2 (ECC registered)
Memory Speed Supported DDR-2 Synch DRAM PC2-3200 (400 MHz) Registered ECC
Maximum Memory 8 GB (4 DIMMs slots, 2 GB DIMMs required to meet maximum configurations)
Network controller Integrated Broadcom 5751 10/100/1000 for HP
Audio Integrated AC'97 digital audio with S/PDif 6-channel pass-through, stereo microphone, and Yamaha XG Lite
Softsynth support
PCI slots 4 PCI slots (full-height)
1 PCI Express (x8 mechanically, x4 electrically)
1 PCI Express x16 graphics
AGP slot none
Bays Total Bays = 5
Internal Bays Two 3.5 inch bays with acoustic dampening rail assemblies
External Bays Two 5.25 inch full length 2003 mm maximum device depth (top bay is limited to 198 mm depth
when optional smart cover solenoid lock is installed). Bottom bay can be converted to an internal 3.5
inch 3rd Hard Drive bay using optional bracket
One 3.5 inch bay for optional floppy drive
Parallel Port 1
Serial Port 1
Front I/O 2 USB 2.0, Headphone, Microphone, optional IEEE 1394
NOTE: Although HP Personal Workstations can be ordered with the HP Installer Kit for Linux and an IEEE
1394 card, HP cannot provide customer support for this configuration. Please refer to the Linux Hardware
Support Matrix ( http://www.hp.com/support/linux_hardware_matrix ) for details, and to the Linux User
Manual ( http://www.hp.com/support/linux_user_manual ) for tips on user-enablement of the IEEE 1394
Card.
Rear I/O 6 USB 2.0, 1 standard serial port, 1 parallel port, PS/2 keyboard and mouse, 1 RJ-45 to integrated Gigabit
LAN, Audio In, Audio Out, Mic In
USB Keyboard Optional
USB Mouse Optional
PS/2 Keyboard 1
PS/2 Mouse 1
Chassis Dimensions
(H x W x D)
17.3 x 6.5 X 17.3 in (44.1 x 16.5 x 44.0 cm)
System weight Standard config – 35 lb
QuickSpecs
HP xw6200 Workstation
Standard Features - Specs
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 8

Shipping weight Varies by region
Temperature Operating 40° to 95° F (5° to 35° C)
Non-operating -40° to 140° F (-40° to 60° C)
Humidity Operating 8% to 85%
Non-operating 8% to 90%
Maximum Altitude
(nonpressurized)
Operating 10,000 ft (3,000 m)
Non-operating 30,000 ft (9,100 m)
Power Supply 500W wide-ranging, active Power Factor Correction
Interfaces Supported 1 SATA interface (2 serial-ATA connectors), 1 EIDE interface (2 EIDE connectors) for optical drives, optional
multi-bay interface
Hard Drive Controller (PCI)
Supported
Ultra160 or Ultra320, or SATA RAID, or Ultra320 RAID
Preinstalled Software
HP Client Manager Software v6.0*
Altiris Local Recovery*
Alert Standard Format specification*
Norton AntiVirus 2004 (optional preinstall)*
CD/DVD software dependent on optical drive choices
* Not available on Linux
QuickSpecs
HP xw6200 Workstation
Standard Features - Specs
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 9

xw6200X/XE2.8/B80/
H1.0/285/dF/s
EN557AW#XXX
(See Country Code Key at end of
section.)
Processor 64-bit Intel Xeon processor 2.80 GHz 2 MB/800
OS Genuine Windows XP Professional
Cache Memory 2 MB L2
Memory 1 GB (2x512MB) DDR2-400 ECC Registered
Optical Drive 16X DVD-ROM
Hard Drive 80 GB SATA 3.0-Gb/s 7200 rpm (1st)
HDD Controller Serial ATA controller
Floppy Drive 1.44 MB 3.5" Floppy Drive
Graphics NVIDIA Quadro NVS 285 with TurboCache Technology PCI Express
included in base configuration.
Mouse HP scroll mouse (PS/2)
Keyboard Standard PS/2 Keyboard
Other Integrated Broadcom 10/100/1000 GBIT LOM, and AC97 audio
xw6200X/XE3.2+/B80/
H1.0/285/dF/s
EN558AW#XXX
(See Country Code Key at end of
section.)
Processor 64-bit Intel Xeon processor 3.20 GHz 2 MB/800
2nd Processor 64-bit Intel Xeon processor 3.20 GHz 2 MB/800
OS Genuine Windows XP Professional
Cache Memory 2 MB L2
Memory 1 GB (2x512MB) DDR2-400 ECC Registered
Optical Drive 16X DVD-ROM
Hard Drive 80 GB SATA 3.0-Gb/s 7200 rpm (1st)
HDD Controller Serial ATA controller
Floppy Drive 1.44 MB 3.5" Floppy Drive
Graphics NVIDIA Quadro NVS 285 with TurboCache Technology PCI Express
included in base configuration.
Mouse HP scroll mouse (PS/2)
Keyboard Standard PS/2 Keyboard
Other Integrated Broadcom 10/100/1000 GBIT LOM, and AC97 audio
QuickSpecs
HP xw6200 Workstation
Standard Features - Preconfigured Global Models
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 10

xw6200X/XE3.2+/S73b/
H1.0/285/dF/p
EN559AW#XXX
(See Country Code Key at end of
section.)
Processor 64-bit Intel Xeon processor 3.20 GHz 2 MB/800
2nd Processor 64-bit Intel Xeon processor 3.20 GHz 2 MB/800
OS Genuine Windows XP Professional
Cache Memory 2 MB L2
Memory 1 GB (2x512MB) DDR2-400 ECC Registered
Optical Drive 16X DVD-ROM
Hard Drive 73 GB SCSI 10k rpm (1st)
HDD Controller U320 SCSI Controller (No RAID)
Floppy Drive 1.44 MB 3.5" Floppy Drive
Graphics NVIDIA Quadro NVS 285 with TurboCache Technology PCI Express
included in base configuration.
Mouse HP optical scroll mouse (USB)
Keyboard Standard USB Keyboard
Other Integrated Broadcom 10/100/1000 GBIT LOM, and AC97 audio
xw6200X/XE3.2+/D80/
H2.0/285/d/s
EQ644AW#XXX
(See Country Code Key at end of
section.)
Processor 64-bit Intel Xeon processor 3.20 GHz 2 MB/800
2nd Processor 64-bit Intel Xeon processor 3.20 GHz 2 MB/800
OS Genuine Windows XP Professional
Cache Memory 2 MB L2
Memory 2 GB (2x1GB) DDR2-400 ECC Registered
Optical Drive 16X DVD-ROM
Hard Drive 80 GB SATA 3.0-Gb/s 7200 rpm (1st)
HDD Controller Serial ATA controller
Floppy Drive None
Graphics NVIDIA Quadro NVS 285 with TurboCache Technology PCI Express
included in base configuration.
Mouse HP scroll mouse (PS/2)
Keyboard Standard PS/2 Keyboard
Other Integrated Broadcom 10/100/1000 GBIT LOM, and AC97 audio
QuickSpecs
HP xw6200 Workstation
Standard Features - Preconfigured Global Models
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 11

xw6200X/XE3.2+/D80/
H2.0/285+/d/p
EQ646AW#XXX
(See Country Code Key at end of
section.)
Processor 64-bit Intel Xeon processor 3.20 GHz 2 MB/800
2nd Processor 64-bit Intel Xeon processor 3.20 GHz 2 MB/800
OS Genuine Windows XP Professional
Cache Memory 2 MB L2
Memory 2 GB (2x1GB) DDR2-400 ECC Registered
Optical Drive 16X DVD-ROM
Hard Drive 80 GB SATA 3.0-Gb/s 7200 rpm (1st)
HDD Controller Serial ATA controller
Floppy Drive None
Graphics Dual NVIDIA Quadro NVS 285 with TurboCache Technology PCI Express
Graphics cards included.
Mouse HP optical scroll mouse (USB)
Keyboard Standard USB Keyboard
Other Integrated Broadcom 10/100/1000 GBIT LOM, and AC97 audio
xw6200X/XE3.4+/C74/
H2.0/285/dF/s
EN560AW#XXX
(See Country Code Key at end of
section.)
Processor 64-bit Intel Xeon processor 3.40 GHz 2 MB/800
2nd Processor 64-bit Intel Xeon processor 3.40 GHz 2 MB/800
OS Genuine Windows XP Professional
Cache Memory 2 MB L2
Memory 2 GB (2x1GB) DDR2-400 ECC Registered
Optical Drive 16X DVD-ROM
Hard Drive 74 GB SATA 1.5-GB/S 10k rpm (1st)
HDD Controller Serial ATA controller
Floppy Drive 1.44 MB 3.5" Floppy Drive
Graphics NVIDIA Quadro NVS 285 with TurboCache Technology PCI Express
included in base configuration.
Mouse HP scroll mouse (PS/2)
Keyboard Standard PS/2 Keyboard
Other Integrated Broadcom 10/100/1000 GBIT LOM, and AC97 audio
QuickSpecs
HP xw6200 Workstation
Standard Features - Preconfigured Global Models
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 12

xw6200X/XE3.2+/D80/
H2.0/285+/d/p
EQ647AW#XXX
(See Country Code Key at end of
section.)
Processor 64-bit Intel Xeon processor 3.40 GHz 2 MB/800
2nd Processor 64-bit Intel Xeon processor 3.40 GHz 2 MB/800
OS Genuine Windows XP Professional
Cache Memory 2 MB L2
Memory 2 GB (2x1GB) DDR2-400 ECC Registered
Optical Drive 16X DVD-ROM
Hard Drive 160 GB SATA 3.0-Gb/s 7200 rpm NCQ (1st)
HDD Controller Serial ATA controller
Floppy Drive 1.44 MB 3.5" Floppy Drive
Graphics Dual NVIDIA Quadro NVS 285 with TurboCache Technology PCI Express
Graphics cards included.
Mouse HP scroll mouse (PS/2)
Keyboard Standard PS/2 Keyboard
Other Integrated Broadcom 10/100/1000 GBIT LOM, and AC97 audio
xw6200X/XE3.6+/C74/
H2.0/285/d/p
EQ648AW#XXX
(See Country Code Key at end of
section.)
Processor 64-bit Intel Xeon processor 3.60 GHz 2 MB/800
2nd Processor 64-bit Intel Xeon processor 3.60 GHz 2 MB/800
OS Genuine Windows XP Professional
Cache Memory 2 MB L2
Memory 2 GB (2x1GB) DDR2-400 ECC Registered
Optical Drive 16X DVD-ROM
Hard Drive 74 GB SATA 1.5-GB/S 10k rpm (1st)
HDD Controller Serial ATA controller
Floppy Drive None
Graphics NVIDIA Quadro NVS 285 with TurboCache Technology PCI Express
included in base configuration.
Mouse HP optical scroll mouse (USB)
Keyboard Standard USB Keyboard
Other Integrated Broadcom 10/100/1000 GBIT LOM, AC97 audio, and Serial ATA controller
QuickSpecs
HP xw6200 Workstation
Standard Features - Preconfigured Global Models
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 13

xw6200X/XE3.8+/C74/
H2.0/285+/dF/s
EQ649AW#XXX
(See Country Code Key at end of
section.)
Processor 64-bit Intel Xeon processor 3.80 GHz 2 MB/800
2nd Processor 64-bit Intel Xeon processor 3.80 GHz 2 MB/800
OS Genuine Windows XP Professional
Cache Memory 2 MB L2
Memory 2 GB (2x1GB) DDR2-400 ECC Registered
Optical Drive 16X DVD-ROM
Hard Drive 74 GB SATA 1.5-GB/S 10k rpm (1st)
HDD Controller Serial ATA controller
Floppy Drive 1.44 MB 3.5" Floppy Drive
Graphics Dual NVIDIA Quadro NVS 285 with TurboCache Technology PCI Express
Graphics cards included.
Mouse HP scroll mouse (PS/2)
Keyboard Standard PS/2 Keyboard
Other Integrated Broadcom 10/100/1000 GBIT LOM, AC97 audio, and Serial ATA controller
Country Code Key
N. America #ABA Switzerland (German/French) #AR8
Fr. Canadian #ABC Switzerland (Italian/English) #ACN
L. America #ABM Dutch #ABH
Japan (English) #ACF Denmark #ACE
Japan (Japanese) #ABJ Asia/Pacific (English) #AB4
UK #ABU Korea #AB1
Germany #ABD China #AB2
France #ABF Taiwan #AB0
Italy #ABZ India #ACJ
Spain #ABE Australia #ABG
Europe #AK6 Thailand #AKL
QuickSpecs
HP xw6200 Workstation
Standard Features - Preconfigured Global Models
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 14

Processors 2nd 64-bit Intel Xeon® processor with Hyper-Threading Part Number
64-bit Intel Xeon processor at 2.80 GHz with 800 MHz FSB & 1 MB of L2 cache DY665A
64-bit Intel Xeon processor at 2.80 GHz with 800 MHz FSB & 2 MB of L2 cache EC421AA
64-bit Intel Xeon processor at 3.00 GHz with 800 MHz FSB & 1 MB of L2 cache DY666A
64-bit Intel Xeon processor at 3.00 GHz with 800 MHz FSB & 2 MB of L2 cache PQ903A
64-bit Intel Xeon processor at 3.20 GHz with 800 MHz FSB & 1 MB of L2 cache DY667A
64-bit Intel Xeon processor at 3.20 GHz with 800 MHz FSB & 2 MB of L2 cache PQ904A
64-bit Intel Xeon processor at 3.40 GHz with 800 MHz FSB & 1 MB of L2 cache DY668A
64-bit Intel Xeon processor at 3.40 GHz with 800 MHz FSB & 2 MB of L2 cache PQ905A
64-bit Intel Xeon processor at 3.60 GHz with 800 MHz FSB & 1 MB of L2 cache DY669A
64-bit Intel Xeon processor at 3.60 GHz with 800 MHz FSB & 2 MB of L2 cache PQ906A
64-bit Intel Xeon processor at 3.80 GHz with 800 MHz FSB & 2 MB of L2 cache PH202A
Graphics Multi display solutions PCI PCI-
Express
Windows XP Red Hat Linux Part Number
NVIDIA Quadro NVS 280 (64 MB, VGA
& DVI)
X 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
AA932A
NVIDIA Quadro NVS 400 (64 MB, quad
head, VGA & DVI)
X 32-Bit, 64-Bit AA605A
NVIDIA Quadro NVS 285 with
TurboCache Technology PCI Express
(128 MB)
X 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
EE061AA
NVIDIA DVI Dual-head Connector
Cablefor NVS cards
X X 32-Bit, 64-Bit DL139A
NVIDIA Quadro FX 330 (64 MB) X 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
PB332A
ATI FireGL V3100 (128 MB) X 32-Bit, 64-Bit PE949A
NVIDIA Quadro FX 540 (128 MB) X 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
PH791A
NVIDIA Quadro FX 1400 (128 MB) X 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
PM979A
ATI FireGL V5100 (128 MB) X 32-Bit, 64-Bit PB330A
NVIDIA Quadro NVS 440 PCI Express
(256 MB)
X 32-Bit, 64-Bit PT453A
NVIDIA Quadro FX 3450 PCI Express
(256 MB)
X 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
PY640AA
QuickSpecs
HP xw6200 Workstation
After-Market Options
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 15

Hard Drives Serial ATA Hard Drives
(Currently supported only at 1.5Gb/s. To get
3Gb/s performance, a SATA 3.0Gb/s controller
must be added)
Windows XP Red Hat Linux Part Number
74 GB SATA 1.5GB/S Hard Drive (10,000 rpm) 32-Bit, 64-Bit WS3, WS4 DX760A
80 GB SATA 3.0Gb/s Hard Drive (7200 rpm) 32-Bit, 64-Bit WS3, WS4 PY276AA
160 GB SATA 3.0Gb/s NCQ Hard Drive
(7200 rpm)
32-Bit, 64-Bit WS3, WS4 PV944A
250 GB SATA 1.5Gb/s NCQ Hard Drive
(7200 rpm)
32-Bit, 64-Bit WS3, WS4 EA788AA
500 GB SATA 3.0Gb/s NCQ Hard Drive
(7200 rpm)
32-Bit, 64-Bit WS3, WS4 PV943A
SCSI Hard Drives
73 GB Ultra320 SCSI Hard Drive (10,000 rpm) 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
AA613A
146 GB Ultra320 SCSI Hard Drive (10,000 rpm) 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
AA614A
300 GB Ultra320 SCSI Hard Drive (10,000 rpm) 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
DY672A
36 GB Ultra320 SCSI Hard Drive (15,000 rpm) 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
AA616A
73 GB Ultra320 SCSI Hard Drive (15,000 rpm) 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
AA617A
146 GB Ultra320 SCSI Hard Drive (15,000 rpm) 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
DY671A
Hard Drive Accessories
Bracket HDD 3.5to5.25 xw6200 N/A N/A DY659A
Cable, 3 port SCSI xw4200/6200 N/A N/A DY661A
Removable Drive Enclosures
StorCase DX115 SATA Removable Enclosure All All EA332AA
StorCase DX115 SATA/SAS Carrier Tray All All RA697AA
Controllers SCSI Controllers PCI PCI-X Windows XP Red Hat Linux Part Number
Adaptec Serial ATA 3Gb/s RAID
1420SA card
X 32-Bit, 64-Bit WS3 ED090AA
U320 SCSI Controller - LSI 20320AR
RAID 0,1& external connector
X 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
DZ554A
Ultra320 SCSI RAID Adaptec 2120S
(Windows only, includes external
connector)
X 32-Bit, 64-Bit AA850A
QuickSpecs
HP xw6200 Workstation
After-Market Options
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 16

Input Devices Windows XP Red Hat Linux Part Number
Keyboards
HP PS/2 Standard Keyboard (Carbonite/Silver) 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
DT527A
HP USB Standard Keyboard (Carbonite/Silver) 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
DT528A
HP USB Smart Card Keyboard 32-Bit, 64-Bit Not Supported ED707AA
Smartcard Adapter for Modular Keyboard 32-Bit, 64-Bit DT531A
Pointing Devices
HP PS/2 2-Button Scroll Mouse (Carbonite) 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
DD440B
HP USB 2-Button Optical Scroll Mouse
(Carbonite/Silver)
32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
DC172B
HP USB Optical 3-Button Mouse 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
DY651A
HP USB Optical 3-button 2.9M OEM Mouse 7.2, 7.3, WS3,
WS4
ET424AA
USB Spaceball 5000 32-Bit, 64-Bit Not Supported DV675A
USB SpaceMouse 32-Bit, 64-Bit Not Supported DZ203A
HP SpacePilot 3D USB Intelligent Controller 32-Bit, 64-Bit Not Supported EF390AA
Networking NICs PCI PCI-
Express
Windows XP Red Hat Linux Part Number
Intel Pro/1000 PT Gigabit PCIe NIC X 32-Bit WS3 EH352AA
Intel Pro/1000 GT Gigabit PCI NIC X 32-Bit WS3, WS4 AG393AA
Broadcom 5782 Netxtreme Gigabit
PCI NIC
X 32-Bit, 64-
Bit
7.2, 7.3, WS3,
WS4
DC194A
Broadcom 5751 Netxtreme Gigabit
PCIe NIC
X 32-Bit, 64-
Bit
WS3, WS4 EA833AA
Memory (DIMMs) 400 MHz DDR-2 PC2-3200 ECC Registered DIMMs Windows XP Red Hat Linux Part Number
256 MB DDR-2 PC2-3200 (400 MHz) ECC
Registered
32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
DY656A
512 MB DDR-2 PC2-3200 (400 MHz) ECC
Registered
32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
DY658A
1 GB DDR-2 PC2-3200 (400 MHz) ECC Registered 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
DY655A
2 GB DDR-2 PC2-3200 (400 MHz) ECC Registered 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
DY657A
QuickSpecs
HP xw6200 Workstation
After-Market Options
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 17

Monitors (Supported by all
Operating Systems offered
by HP)
TFTs
HP TFT LP2465 (24-inch) EF224A5#
HP TFT L2335 (23-inch) P9615W#
HP TFT LP2065 (20.1-inch) TCO03 Two Tone (Carbonate/Silver) EF227A5#
HP TFT L2035 (20.1-inch) P9614W#
HP TFT L1955 2T Top (19.1-inch) PH466AT#
HP TFT L1755 (17-inch) PL777AA#
Multimedia PCI PCI-Express
Adaptec Fireconnect 2100 Firewire 400 (1394a)
PCI Card (Windows only)
X PA997A
NOTE: Although HP Personal Workstations can be ordered with the HP Installer Kit for Linux and an IEEE
1394 card, HP cannot provide customer support for this configuration. Please refer to the Linux Hardware
Support Matrix ( http://www.hp.com/support/linux_hardware_matrix ) for details, and to the Linux User
Manual ( http://www.hp.com/support/linux_user_manual ) for tips on user-enablement of the IEEE 1394
Card.
Multimedia Windows XP Red Hat Linux Part Number
SoundBlaster X-Fi XtremeMusic Audio Card 32-Bit Not Supported
EA326AA
EA326AA
HP Satellite Speakers ZD929AA
Optical Drives DVD-ROM Drive Windows XP Red Hat Linux Part Number
16X DVD-ROM w/ +R read 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
AA620B
CD-ROM Drive
48X Max CD-ROM Drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
DC143B
CD-RW Drive
48X CD-RW Drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
DE205B
Combo Drive
48X Combo DVD-ROM/CD-RW Drive 32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
DE206B
DVD+/-RW Drive
16X DVD+/-RW, Dual-Layer LightScribe
(LightScribe labeling functionality not supported
on Linux)
32-Bit, 64-Bit 7.2, 7.3, WS3,
WS4
DZ555B
QuickSpecs
HP xw6200 Workstation
After-Market Options
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 18

Removable Storage Windows XP Red Hat Linux Part Number
HP 256-MB Drive Key II Flash Drive 32-Bit, 64-Bit WS3, WS4 PH657A
HP 1-GB Drive Key II Flash Drive 32-Bit, 64-Bit WS3, WS4 AG382AA
512 MB USB 2.0 Drive Key II 32-Bit, 64-Bit WS3, WS4 ED516AA
1.44 MB Internal Floppy Drive 32-Bit, 64-Bit WS3 DY670A
HP StorageWorks DAT 24 USB external tape drive 32-Bit, 64-Bit WS3, WS4 DW070A
HP StorageWorks DAT 24 USB internal tape drive 32-Bit, 64-Bit WS3, WS4 DW069A
HP StorageWorks DAT 40 USB external tape drive 32-Bit, 64-Bit WS3, WS4 DW023A
HP StorageWorks DAT 40 USB internal tape drive 32-Bit, 64-Bit WS3, WS4 DW022A
HP StorageWorks DAT 72 USB external tape drive 32-Bit, 64-Bit WS3, WS4 DW027A
HP StorageWorks DAT 72 USB internal tape drive 32-Bit, 64-Bit WS3, WS4 DW026A
HP StorageWorks DAT 72 SCSI external tape drive 32-Bit, 64-Bit WS3, WS4, 7.2,
7.3
Q1523B
HP StorageWorks DAT 72 SCSI internal tape drive 32-Bit, 64-Bit WS3, WS4, 7.2,
7.3
Q1522B
The following Removable Drive Enclosure products are available from and supported by 3rd party:
StorCase Rhino Jr. SATA 1.5Gb/s Removable Disk Enclosure
(For NA, use: HP P/N A466720, for WW, use: vendor P/N S21J111)
Security Part Number
Chassis clamp lock, universal, no cable DE817A
Chassis clamp lock, universal, with cable DE818A
Brackets/Stands Part Number
HP xw6200 sliding rack kit
Exclusively designed for the xw6200
Standard-width, ball bearing sliding rails
Includes hardware to work with IT racks only (not broadcast)
DY663A
Other Devices Part Number
Front Card Guide and Fan Kit DY648A
Operating Systems Part Number
Red Hat Enterprise Linux Workstation 3 Update 7 (32-bit version) RA354AA
Red Hat Enterprise Linux Workstation 4 Update 1 (32/64-bit version) EA700AA
Red Hat Enterprise Linux Workstation 4 Update 3 (32/64-bit version) RA356AA
QuickSpecs
HP xw6200 Workstation
After-Market Options
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 19

Software Windows XP Red Hat Linux Part Number
HP Remote Graphics V3LTU for HP WS 32-Bit 7.2, 7.3, WS3,
WS4
PY682AA
HP Remote Graphics V4 LTU for HP WS 32-Bit, 64-Bit WS3, WS4 RG088AA
HP Remote Graphics V3 Receiver LTU 32-Bit 7.2, 7.3, WS3,
WS4
PY684AA
HP Remote Graphics V4 Receiver LTU 32-Bit, 64-Bit WS3, WS4 RG090AA
HP Remote Graphics V3 software media 32-Bit 7.2, 7.3, WS3,
WS4
PY685AA
HP Remote Graphics V4 software media
(available 8/1/06)
32-Bit, 64-Bit WS3, WS4 RG091AA
HP Remote SW for HP 1 year Update Subscription 32-Bit 7.2, 7.3, WS3,
WS4
PN681A
HP Remote SW Receiver 1 year Update
Subscription
32-Bit 7.2, 7.3, WS3,
WS4
PN680A
QuickSpecs
HP xw6200 Workstation
After-Market Options
DA - 11975 Worldwide — Version 46 — May 25, 2007 Page 20
