HP DC367B - Compaq Basic Port Replicator 1.2 User manual

Reference Guide
HP Docking Station
Document Part Number: 367055-002
January 2005
This guide provides information on installing and operating the
HP Docking Station and on using it with your computer, as well
as tips on solving common problems.

© Copyright 2004, 2005 Hewlett-Packard Development Company, L.P.
Microsoft is a U.S. registered trademark of Microsoft Corporation.
The information contained herein is subject to change without notice. The
only warranties for HP products and services are set forth in the express
warranty statements accompanying such products and services. Nothing
herein should be construed as constituting an additional warranty. HP shall
not be liable for technical or editorial errors or omissions contained herein.
Reference Guide
HP Docking Station
Second Edition January 2005
First Edition September 2004
Document Part Number: 367055-002

Reference Guide iii
Contents
1 Getting Started
Identifying Top Components . . . . . . . . . . . . . . . . . . . . . . 1–1
Identifying Left-Side Components. . . . . . . . . . . . . . . . . . 1–3
Identifying Right-Side Components . . . . . . . . . . . . . . . . 1–4
Identifying Rear Components . . . . . . . . . . . . . . . . . . . . . 1–5
Getting More Information . . . . . . . . . . . . . . . . . . . . . . . . 1–7
2 Docking and Undocking
Connecting to AC Power . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
Docking the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–3
Undocking the Computer . . . . . . . . . . . . . . . . . . . . . . . . . 2–5
3 Using the Docking Station
Turning the Computer On and Off. . . . . . . . . . . . . . . . . . 3–1
Installing the HP/Kensington Cable Lock . . . . . . . . . . . . 3–2
ATroubleshooting
Solving Common Problems . . . . . . . . . . . . . . . . . . . . . . . A–2

Reference Guide 1–1
1
Getting Started
Identifying Top Components
Component Description
1Power button Turns on power to the computer.
2Power light Indicates the state of the computer and
is turned on when the computer is
turned on.
3Docking posts (2) Align and secure the computer for
proper connection to the HP Docking
Station.
(Continued)

1–2 Reference Guide
Getting Started
4Computer eject
mechanisms (4)
Disconnect the computer from
the docking station when you
press the eject button.
5Docking connector Connects the computer to the
docking station.
6Visual alignment indicator Helps you correctly align the computer
when connecting it to the docking
station.
7Computer eject button
and docking light
Ejects the computer from the docking
station. Docking light is turned
on when the computer is properly
aligned.
✎Refer to Chapter 2, “Docking
and Undocking,” for details.
Component Description

Getting Started
Reference Guide 1–3
Identifying Left-Side Components
Component Description
1Power button and
power light
Turns on power to the computer.
The light indicates the state of the
computer, and is turned on when
the computer is turned on.
2USB 2.0 port Allows you to connect USB devices.
3Powered USB 2.0 port Allows you to connect select USB
devices, such as the HP External
MultiBay II.

1–4 Reference Guide
Getting Started
Identifying Right-Side Components
Component Description
1Computer eject button
and docking light
Ejects the computer from the docking
station. Docking light is turned on
when the computer is properly aligned.
✎Refer to Chapter 2, “Docking
and Undocking,” for details.
2Integrated cable lock slot Supports the HP/Kensington Cable
Lock, which secures the docking
station and a connected computer.

Getting Started
Reference Guide 1–5
Identifying Rear Components
Component Description
1Security cable slot Connects an optional security
cable lock.
2Monitor stand port Connects an optional HP Monitor
Stand to the docking station.
3Audio-out (headphone) jack Connects an audio output device
such as headphones or speakers.
4Mouse connector Connects a PS/2 mouse.
5Parallel port Connects a parallel device such
as a printer.
6Digital video (DVI) port Connects a DVI device such as a
flat panel monitor.
7Power light Is turned on when the docking station
is connected to AC power.
(Continued)

1–6 Reference Guide
Getting Started
8RJ-11 (modem) jack Connects a telephone cable.
9RJ-45 (network) jack Connects a network cable.
-USB 2.0 ports (2) Connect USB devices.
qPower connector Connects the docking station to
the AC adapter.
wExternal monitor port Connects a VGA monitor.
eSerial port Connects a serial device such
as a mouse.
rKeyboard connector Connects a PS/2 keyboard.
tAudio-in (microphone) jack Connects home audio equipment
such as CD and MP3 players.
yComposite video port Connects a composite video device
such as a TV.
uS-Video jack Connects an S-Video device such
as a TV, VCR, or camcorder.
Component Description

Getting Started
Reference Guide 1–7
Getting More Information
ÅWARNING: To reduce the risk of serious injury, read the Safety and
Comfort Guide. It describes proper workstation setup, and proper
posture, health, and work habits for notebook users. The Safety and
Comfort Guide also provides important electrical and mechanical safety
information. This guide is available on the Web at
http://www.hp.com/ergo, on the notebook hard drive, and through the
Help and Support Center at Start > Help and Support.
■The Notebook Documentation CD, included with the
computer, contains comprehensive information about your
computer, as well as governmental agency and safety
information about the use of your computer.
■The Accessory Documentation CD, included with the
docking station, contains governmental agency and safety
information about the use of this device.
■The HP Web site http://www.hp.com provides product news
and software updates.

Reference Guide 2–1
2
Docking and Undocking
Connecting to AC Power
Connect the docking station to AC power at all times.
ÅWARNING: To reduce the risk of electric shock or damage to your
equipment:
■Plug the power cord into an AC outlet that is easily accessible at
all times.
■Disconnect the power from the product by unplugging the power
cord from the AC outlet.
■If provided with a 3-pin attachment plug on your power cord, plug
the cord into a grounded (earthed) 3-pin outlet. Do not disable the
power cord grounding pin; for example, by attaching a 2-pin
adapter. The grounding pin is an important safety feature.
■Do not place anything on power cords or cables. Arrange them
so that no one can accidentally step on or trip over them.
■Do not pull on a cord or cable. When unplugging a cord from
the AC outlet, grasp the cord by the plug.
ÅWARNING: To reduce the risk of electric shock, fire, or damage to the
equipment, do not attempt to operate the computer and docking station
with a voltage converter kit sold for appliances. Use only the power
cord included with the docking station.

2–2 Reference Guide
Docking and Undocking
1. Insert the AC adapter 1into the power connector on the
docking station.
2. Insert one end of the power cord 2into the AC adapter.
3. Insert the other end of the power cord 3into an AC outlet.
✎The docking station requires AC power for full functionality of
all ports.
✎The light above the power connector is turned on when the
docking station is connected to AC power.

Docking and Undocking
Reference Guide 2–3
Docking the Computer
1. Close the computer. If you close the computer when the
power is on, the computer may enter standby mode. To
resume operation after docking, open the computer, and then
press the power button.
2. Angle the front of the computer downward.
3. Line up the visual alignment indicator on the computer
with the indicator on the docking station.

2–4 Reference Guide
Docking and Undocking
4. Align the posts on the docking station with the receptors
on the bottom of the computer, and then gently press the
computer down onto the docking station until you hear
aclick. When the computer is properly aligned, the
docking station docking light is turned on.
✎Make sure the computer is properly aligned and seated, and
fully docked. For help with most common docking problems,
refer to Appendix A, “Troubleshooting.”
✎The docking light will not be turned on when you dock the
computer unless the AC adapter is connected to the docking
station.

Docking and Undocking
Reference Guide 2–5
Undocking the Computer
1. Close the computer. If you close the computer when the
power is on, the computer may enter standby mode. To
resume operation after undocking, open the computer, and
then press the power button.

2–6 Reference Guide
Docking and Undocking
2. Press the eject button 1. The computer disconnects from
the docking station.
3. Lift up the computer 2.

Reference Guide 3–1
3
Using the Docking Station
Turning the Computer On and Off
When you connect a computer to the docking station, you can
turn the computer on and off using either the computer power
button or the docking station power button 1. When you turn
on the system, the power button light is turned on 2. When you
properly align the computer to the docking station, the docking
light 3is turned on.
✎The docking light will not be turned on when you dock the
computer unless the AC adapter is connected to the docking
station. For help with most common docking problems, refer
to Appendix A, “Troubleshooting.”

3–2 Reference Guide
Using the Docking Station
Installing the HP/Kensington
Cable Lock
✎Security solutions are designed to act as deterrents. These
deterrents may not prevent a product from being mishandled
or stolen.
The HP/Kensington Cable Lock (purchased separately) allows
you to secure the docking station and a docked computer. Install
the cable lock into the integrated cable lock slot on the right side
of the docking station, as shown in the following illustrations.

Using the Docking Station
Reference Guide 3–3
To install the cable lock:
1. Loop the cable around a stationary object.
2. Turn the docking station upside down, and then remove
the screws from the cable lock bezel 1.
3. Remove the bezel from the docking station 2, and then
remove the bezel blank from the cable lock bezel 3.

3–4 Reference Guide
Using the Docking Station
4. With the lock and key in the unlocked position and with the
T-bar on the back of the lock in the vertical position, insert
the lock into the center groove in the cable lock slot in the
docking station 1.
5. Insert the cable into the recessed cable channel in the base
of the docking station 2.
