Olicom OC-3137 Token Ring 16/4
PCI Adapter
Installation Guide

Notice
The information contained in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this
material, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose.
Hewlett-Packard shall not be liable for errors contained herein or for incidental
or consequential damages in connection with the furnishing, performance, or use
of this material.
Hewlett-Packard assumes no responsibility for the use or reliability of its
software on equipment that is not furnished by Hewlett-Packard.
This document contains proprietary information that is protected by copyright.
All rights are reserved. No part of this document may be photocopied,
reproduced, or translated to another language without the prior written consent
of Hewlett-Packard Company.
Microsoft®, Windows® and MS-DOS® are registered trademarks of Microsoft
Corporation.
MMXTM is a trademark of Intel Corporation.
Pentium® is a registered trademark of Intel Corporation.
Hewlett-Packard France
Commercial Desktop Computing Division
38053 Grenoble Cedex 9
France
©1999 Hewlett Packard Company

General information to read before installing
General information to read before installing
On all systems: before installing LAN card, go into Bios setup and set PnP OS field to NO.
• How to change LAN card configuration if needed (Advanced users only)
This is a general advisory on how to forcibly modify resources for ISA and PCI network
cards.
ISA cards:
• For ISA network adapters, start the configuration tool provided in driver
kit (See install documentation)
• Under CMOS setup, go to Advanced > PnP/PCI ISA IRQ Resource Exclu-
sion > reserve an IRQ for the adapter.
PCI cards:
• For PCI network adapters, go to CMOS setup > Advanced > PnP/PCI ISA
IRQ Resource Exclusion > reserve the IRQ for Legacy ISA.
• ISA cards can’t use IRQ9
• IRQ 9 is reported as being used by ACPI during POST. This is due to ISA’s
inability to share IRQs.
• Using a different IRQ (e.g. 5, 7, 10, and 11) will work. For this:
1Install the NIC then power up the system.
2Press F2 to go to CMOS setup.
3Set PnP OS to NO and reserve IRQ 5, 7, 10, or 11 (explained in installation
section)
4Save the configuration settings and boot to the applicable OS.
5Follow installation steps.
Sound conflict under Win 95 on VLi8 only
• On VLi8, LAN cards cause an IRQ conflict with the embedded sound de-
vice under Win95.
• To solve the problem: Reserve IRQ 5 and sett PNP OS to no. For this:
1Install the NIC then power up the system

General information to read before installing
2Press F2 to go to CMOS setup.
3Set PNP OS to NO and reserve IRQ 5.
4Save settings and boot to applicable OS.

1 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Microsoft Windows 95 SR2.5
1 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Microsoft Windows 95
SR2.5
Connecting to a
Windows NT 3.51 Server
Requirements
• HP Vectra with Windows 95 SR2.5.
• Olicom 3137 Token Ring 16/4 PCI adapter and drivers disk version 29.4.0.
• Driver: OCTOK16.SYS, version 4.16
• Microsoft Windows 95 SR2.5 media.
• Microsoft Windows NT 3.51 Server system that supports NetBEUI,
NWLink IPX/SPX Compatible Transport, and NWLink NetBIOS network
protocols.
Device Configuration
Procedure
1With the HP Vectra turned off, install the Olicom 3137 Token Ring 16/4
PCI card into a PCI slot.
2Connect network cable media to the Olicom 3137 Token Ring 16/4 PCI
card.
3Power on the machine and boot to Windows 95.
4When Windows 95 restarts, a message will appear to indicate that new
hardware has been found.
5Windows 95 will recognize a “Olicom 3137 Token Ring 16/4 PCI Adapter”.
6Specify your Computer name, Workgroup name, and Computer
Description, and click on “Close”.
7When prompted, set the path to your Windows 95 files and click on “OK”.
8When prompted, click on “Yes” to reboot your machine.
Device Configuration Vectra Vli8 Vectra VEi7 Vectra VEi8
Interrupt 09 03 10
I/O Address 1000 DCC0 E400

2 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Microsoft Windows 95 SR2.5
2 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Microsoft Windows 95
SR2.5
Connecting to a
Windows NT 4.0 Server
Requirements
• HP Vectra with Windows 95 SR2.5.
• Olicom 3137 Token Ring 16/4 PCI adapter and driver disk version 29.4.0.
• Driver: OCTOK16.SYS, version 4.16
• Microsoft Windows 95 SR2.5 media.
• Microsoft Windows NT 4.0 Server system that supports NetBEUI, NWLink
IPX/SPX Compatible Transport, and NWLink NetBIOS network protocols.
Device Configuration
Procedure
1With the HP Vectra turned off, install the Olicom 3137 Token Ring 16/4
PCI card into a PCI slot.
2Connect network cable media to the Olicom 3137 Token Ring 16/4 PCI
card.
3Power on the machine and boot to Windows 95.
4When Windows 95 restarts, a message will appear to indicate that new
hardware has been found.
5Windows 95 will recognize a “Olicom 3137 Token Ring 16/4 PCI Adapter”.
6Specify your Computer name, Workgroup name, and Computer
Description, and click on “Close”.
7When prompted, set the path to your Windows 95 files and click on “OK”.
8When prompted, click on “Yes” to reboot your machine.
Device Configuration Vectra Vli8 Vectra VEi7 Vectra VEi8
Interrupt 10 03 11
I/O Address 1000 DCC0 E400

3 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Microsoft Windows 95 SR2.5
3 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Microsoft Windows 95
SR2.5
Connecting to a Novell
NetWare 3.12 Server
Requirements
• HP Vectra with Windows 95 SR2.5.
• Olicom 3137 Token Ring 16/4 PCI adapter and drivers disk version 29.4.0.
• Driver: OCTOK16.SYS, version 4.16
• Microsoft Windows 95 SR2.5 media.
• Novell NetWare 3.12 Server system that supports IPX network protocol.
• Novell Client for Windows 95 v2.5 installation media.
Device Configuration
Procedure
1With the HP Vectra turned off, install the Olicom 3137 Token Ring 16/4
PCI card into a PCI slot.
2Connect network cable media to the Olicom 3137 Token Ring 16/4 PCI
card.
3Power on the machine and boot to Windows 95.
4When Windows 95 restarts, a message will appear to indicate that new
hardware has been found.
5Windows 95 will recognize a “Olicom 3137 Token Ring 16/4 PCI Adapter”.
6Specify your Computer name, Workgroup name, and Computer
Description, and click on “Close”.
7When prompted, set the path to your Windows 95 files and click on “OK”.
8When prompted, click on “Yes” to reboot your machine.
9From the location of the “Novell Client for Windows 95 v.2.5” installation
files, execute “Setup.exe”.
Device Configuration Vectra Vli8 Vectra VEi7 Vectra VEi8
Interrupt 10 03 10
I/O Address 1000 DCC0 E400

3 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Connecting to a Novell NetWare 3.12 Server
10 Click on “Yes” to accept the License Agreement.
11 Select “Custom” installation and click on “Next”.
12 Select “Bindery (NetWare 3.x)” and click on “Next”.
13 Click on “Install” to start the installation.
14 Click on “Yes” to set the Preferred Server. (If you do not have the
required information, contact your network administrator).
15 Click on “Reboot” to complete the installation.

4 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Microsoft Windows 95 SR2.5
4 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Microsoft Windows 95
SR2.5
Connecting to a Novell
NetWare 4.11 Server
Requirements
• HP Vectra with Windows 95 SR2.5.
• Olicom 3137 Token Ring 16/4 PCI adapter and drivers disk version 29.4.0.
• Driver: OCTOK16.SYS, version 4.16
• Microsoft Windows 95 SR2.5 media.
• Novell NetWare 4.11 Server system that supports IPX network protocol.
• Novell Client for Windows 95 v2.5 installation media.
Device Configuration
Procedure
1With the HP Vectra turned off, install the Olicom 3137 Token Ring 16/4
PCI card into a PCI slot.
2Connect network cable media to the Olicom 3137 Token Ring 16/4 PCI
card.
3Power on the machine and boot to Windows 95.
4When Windows 95 restarts, a message will appear to indicate that new
hardware has been found.
5Windows 95 will recognize a “Olicom 3137 Token Ring 16/4 PCI Adapter”.
6Specify your Computer name, Workgroup name, and Computer
Description, and click on “Close”.
7When prompted, set the path to your Windows 95 files and click on “OK”.
8When prompted, click on “Yes” to reboot your machine.
9From the location of the “Novell Client for Windows 95 v.2.5” installation
files, execute “Setup.exe”.
Device Configuration Vectra Vli8 Vectra VEi7 Vectra VEi8
Interrupt 10 03 11
I/O Address 1000 DCC0 E400

4 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Connecting to a Novell NetWare 4.11 Server
10 Click on “Yes” to accept the License Agreement.
11 Select “Custom” installation and click on “Next”.
12 Select “NDIS (NetWare 4.x or higher)” and click on “Next”.
13 Click on “Install” to start the installation.
14 Click on “Yes” to set the Preferred Tree, Server, etc. (If you do not have
the required information, contact your network administrator).
15 Click on “Reboot” to complete the installation.

5 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Microsoft Windows NT 4.0 Workstation
5 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Microsoft Windows NT
4.0 Workstation
Connecting to a
Windows NT 3.51 Server
Requirements
• HP Vectra with Windows NT 4.0 Workstation.
• Olicom 3137 Token Ring 16/4 PCI adapter and drivers disk version 29.4.0.
• Driver: OCTOK16.SYS, version 4.16
• Microsoft Windows NT 4.0 Workstation media.
• Microsoft Windows NT 4.0 Service Pack 4 media.
• Microsoft Windows NT 3.51 Server system that supports NetBEUI,
NWLink IPX/SPX Compatible Transport, and NWLink NetBIOS network
protocols.
Device Configuration
Procedure
1With the HP Vectra turned off, install the Olicom Token-Ring PCI adapter
into a PCI slot.
2Connect network cable media to the Olicom Token-Ring PCI card.
3Log into Windows NT with administrator privileges.
4Open the “Network Properties” window and agree to install “Windows NT
Networking”.
5With “Wired to the Network” checked, click on “Next”.
6Click on the option to “Select from list” then on “Have Disk”.
7Insert the Olicom Token-Ring PCI driver disk into the floppy drive.
8Confirm choice, “Olicom 3137 Token Ring Adapter”, and press the “OK”
button.
9Select the applicable network protocols and click on “Next”.
Device Configuration Vectra Vli8 Vectra VEi7 Vectra VEi8
Interrupt 09 03 10
I/O Address 1000 DCC0 E400

5 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Connecting to a Windows NT 3.51 Server
10 At the “Network Services:” prompt, accept default settings and click on
“Next”.
11 Finish the network card installation by clicking on “Next”.
12 Designate the path to your NT files and select “Continue”.
13 Click on “Yes” to use DHCP or choose “NO” if you know your IP Address.
14 At the “Show Bindings for:” prompt, accept default settings and click on
“Next”.
15 When “Windows NT is now ready to start the network…” click on “Next”.
16 Specify your Computer Name, Workgroup or Domain and click on “Next”.
17 After “Network has been installed on this computer” click on “Finish”.
18 Install the Windows NT4 Service Pack 4 application to correct the error
messages in the Event Viewer.
19 Install the Hewlett-Packard Soft-Power Down application once the
Service Pack 4 has been installed.

6 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Microsoft Windows NT 4.0 Workstation
6 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Microsoft Windows NT
4.0 Workstation
Connecting to a
Windows NT 4.0 Server
Requirements
• HP Vectra with Windows NT 4.0 Workstation.
• Olicom 3137 Token Ring 16/4 PCI adapter and drivers disk version 29.4.0.
• Driver: OCTOK16.SYS, version 4.16
• Microsoft Windows NT 4.0 Workstation media.
• Microsoft Windows NT 4.0 Service Pack 4 media.
• Microsoft Windows NT 4.0 Server system that supports NetBEUI, NWLink
IPX/SPX Compatible Transport, and NWLink NetBIOS network protocols.
Device Configuration
Procedure
1With the HP Vectra turned off, install the Olicom Token-Ring PCI adapter
into a PCI slot.
2Connect network cable media to the Olicom Token-Ring PCI card.
3Log into Windows NT with administrator privileges.
4Open the “Network Properties” window and agree to install “Windows NT
Networking”.
5With “Wired to the Network” checked, click on “Next”.
6Click on the option to “Select from list” then on “Have Disk”.
7Insert the Olicom Token-Ring PCI driver disk into the floppy drive.
8Confirm choice, “Olicom 3137 Token Ring Adapter”, and press the “OK”
button.
9Select the applicable network protocols and click on “Next”.
Device Configuration Vectra Vli8 Vectra VEi7 Vectra VEi8
Interrupt 11 03 11
I/O Address 1000 DCC0 E400

6 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Connecting to a Windows NT 4.0 Server
10 At the “Network Services:” prompt, accept default settings and click on
“Next”.
11 Finish the network card installation by clicking on “Next”.
12 Designate the path to your NT files and select “Continue”.
13 Click on “Yes” to use DHCP or choose “NO” if you know your IP Address.
14 At the “Show Bindings for:” prompt, accept default settings and click on
“Next”.
15 When “Windows NT is now ready to start the network…” click on “Next”.
16 Specify your Computer Name, Workgroup or Domain and click on “Next”.
17 After “Network has been installed on this computer” click on “Finish”.
18 Install the Windows NT4 Service Pack 4 application to correct the error
messages in the Event Viewer.
19 Install the Hewlett-Packard Soft-Power Down application once the
Service Pack 4 has been installed.

7 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Microsoft Windows NT 4.0 Workstation
7 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Microsoft Windows NT
4.0 Workstation
Connecting to a Novell
NetWare 3.12 Server
Requirements
• HP Vectra with Windows NT 4.0 Workstation.
• Olicom 3137 Token Ring 16/4 PCI adapter and drivers disk version 29.4.0.
• Driver: OCTOK16.SYS, version 4.16
• Microsoft Windows NT 4.0 Workstation media.
• Microsoft Windows NT 4.0 Service Pack 4 media.
• Novell NetWare 3.12 Server system that supports IPX network protocol.
• Novell IntranetWare Client for Windows NT v4.11b installation media.
Device Configuration
Procedure
1With the HP Vectra turned off, install the Olicom Token-Ring PCI adapter
into a PCI slot.
2Connect network cable media to the Olicom Token-Ring PCI card.
3Log into Windows NT with administrator privileges.
4Open the “Network Properties” window and agree to install “Windows NT
Networking”.
5With “Wired to the Network” checked, click on “Next”.
6Click on the option to “Select from list” then on “Have Disk”.
7Insert the Olicom Token-Ring PCI driver disk into the floppy drive.
8Confirm choice, “Olicom 3137 Token Ring Adapter”, and press the “OK”
button.
9Select the applicable network protocols and click on “Next”.
Device Configuration Vectra Vli8 Vectra VEi7 Vectra VEi8
Interrupt 09 03 10
I/O Address 1000 DCC0 E400

7 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Connecting to a Novell NetWare 3.12 Server
10 At the “Network Services:” prompt, accept default settings and click on
“Next”.
11 Finish the network card installation by clicking on “Next”.
12 Designate the path to your NT files and select “Continue”.
13 Click on “Yes” to use DHCP or choose “NO” if you know your IP Address.
14 At the “Show Bindings for:” prompt, accept default settings and click on
“Next”.
15 When “Windows NT is now ready to start the network…” click on “Next”.
16 Specify your Computer Name, Workgroup or Domain and click on “Next”.
17 After “Network has been installed on this computer” click on “Finish”.
18 From the location of the “Novell IntranetWare Client v.4.11b” installation
files, execute “Setupnw.exe”.
19 Click on “Continue” to continue with the Novell IntranetWare Client
installation.
20 Click on “Yes” to agree to the Software License Agreement to begin
installation.
21 Click on the “Reboot” button at the completion of the Novell NetWare
Client installation to restart the machine for changes to take effect.
22 Click on the “IntranetWare” tab of the Novell IntranetWare Client Services
Login screen.
23 Select “Bindery Login” and specify the Server Name (Contact your
network administrator if you do not have the required information).
24 Click on the “Login” tab and specify your Name and Password to login.
25 Install the Windows NT4 Service Pack 4 application to correct the error
messages in the Event Viewer.
26 Install the Hewlett-Packard Soft Power Down application once the
Service Pack 4 has been installed.

8 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Microsoft Windows NT 4.0 Workstation
8 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Microsoft Windows NT
4.0 Workstation
Connecting to a Novell
NetWare 4.11 Server
Requirements
• HP Vectra with Windows NT 4.0 Workstation.
• Olicom 3137 Token Ring 16/4 PCI adapter and drivers disk version 29.4.0.
• Driver: OCTOK16.SYS, version 4.16
• Microsoft Windows NT 4.0 Workstation media.
• Microsoft Windows NT 4.0 Service Pack 4 media.
• Novell NetWare 4.11 Server system that supports IPX network protocol.
• Novell IntranetWare Client for Windows NT v4.11b installation media.
Device Configuration
Procedure
1With the HP Vectra turned off, install the Olicom Token-Ring PCI adapter
into a PCI slot.
2Connect network cable media to the Olicom Token-Ring PCI card.
3Log into Windows NT with administrator privileges.
4Open the “Network Properties” window and agree to install “Windows NT
Networking”.
5With “Wired to the Network” checked, click on “Next”.
6Click on the option to “Select from list” then on “Have Disk”.
7Insert the Olicom Token-Ring PCI driver disk into the floppy drive.
8Confirm choice, “Olicom 3137 Token Ring Adapter”, and press the “OK”
button.
9Select the applicable network protocols and click on “Next”.
Device Configuration Vectra Vli8 Vectra VEi7 Vectra VEi8
Interrupt 11 03 10
I/O Address 1000 DCC0 E400

8 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Connecting to a Novell NetWare 4.11 Server
10 At the “Network Services:” prompt, accept default settings and click on
“Next”.
11 Finish the network card installation by clicking on “Next”.
12 Designate the path to your NT files and select “Continue”.
13 Click on “Yes” to use DHCP or choose “NO” if you know your IP Address.
14 At the “Show Bindings for:” prompt, accept default settings and click on
“Next”.
15 When “Windows NT is now ready to start the network…” click on “Next”.
16 Specify your Computer Name, Workgroup or Domain and click on “Next”.
17 After “Network has been installed on this computer” click on “Finish”.
18 Log onto Windows NT4 Workstation with administrator privileges.
19 From the location of the “Novell IntranetWare Client v.4.11b” installation
files, execute “Setupnw.exe”.
20 Click on “Continue” to continue with the Novell IntranetWare Client
installation.
21 Click on “Yes” to agree to the Software License Agreement to begin
installation.
22 Click on the “Reboot” button at the completion of the Novell NetWare
Client installation to restart the machine for changes to take effect.
23 Click on the “IntranetWare” tab of the Novell IntranetWare Client Services
Login screen.
24 Select “NDS Login” and specify the Tree, Server Name, etc. (Contact your
network administrator if you do not have the required information).
25 Click on the “Login” tab and specify your Name and Password to login.
26 Install the Windows NT4 Service Pack 4 application to correct the error
messages in the Event Viewer.
27 Install the Hewlett-Packard Soft Power Down application once the
Service Pack 4 has been installed.

9 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Microsoft Windows NT 3.51 Workstation
9 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Microsoft Windows NT
3.51 Workstation
Connecting to a
Windows NT 3.51 Server
Requirements
• HP Vectra with Windows NT 3.51 Workstation.
• Olicom 3137 Token Ring 16/4 PCI adapter and driver disk version 29.4.0.
• Driver: OCTOK16.SYS, version 4.16
• Microsoft Windows NT 3.51 Workstation media.
• Microsoft Windows NT 3.51 Service Pack 5 media.
• Microsoft Windows NT 3.51 Server system that supports NetBEUI,
NWLink IPX/SPX Compatible Transport, and NWLink NetBIOS network
protocols.
Device Configuration
Procedure
1With the HP Vectra turned off, install the Olicom 3137 16/4 Token-Ring
PCI adapter into a PCI slot.
2Connect network cable media to the Olicom 3137 16/4 Token-Ring PCI
card.
3Log into Windows NT with administrator privileges.
4Open the “MAIN” program group, and double click on the “Control Panel”
icon.
5Select the “Network” icon in the “Control Panel” program group.
6Click on “YES” in the “Network Settings” dialog box, and NT Networking
will be installed on your computer.
7Insert the Windows NT Workstation CD.
8In the “Windows NT Setup” enter the path to your NT files, and click on
the “Continue” button.
Device Configuration Vectra Vli8 Vectra VEi7 Vectra VEi8
Interrupt 05 03 10
I/O Address 1000 DCC0 E400

9 Installing the Olicom OC-3137 Token Ring 16/4 PCI Adapter
Connecting to a Windows NT 3.51 Server
9Click on the “Do Not Detect” button from the “Network Adapter Card
Detection” dialog box, and click on “Continue” in the second “Network
Adapter Card Detection” dialog box.
10 From the “Drop Down List”, scroll down and select “<Other> Requires
disk from manufacturer”, then click “Continue”.
11 Set the path to “A:\” in the “Insert Disk” dialog box, and then insert the
Olicom driver disk.
12 Click “OK” at the “Install Driver” dialog box.
13 Select “Olicom 3137 16/4 TokenRing PCI” in the “Select OEM Option”
dialog box, and click “OK”.
14 Choose the default Protocols and any additional Network Protocols by
clicking the check boxes in the ”Windows NT Setup” dialog box, and click
“Continue”.
15 At the “Domain/Workgroup Settings” dialog box, click on “OK” to accept
the default “Workgroup” as your workgroup name.
16 To complete the installation, remove the floppy disk, and click on “Restart
Computer” in the “Windows NT Workstation Network Setup” dialog box.
17 Install the Windows NT3.51 Service Pack 5 application.
