HP Indigo press 3050 User manual

HP Indigo press 3050
User guide
English version

hp indigo press 3050
user guide

Printed in Israel
© copyright
Hewlett-Packard Company
2006
All Rights Reserved.
Reproduction, adaptation,
or translation without prior
written permission is
prohibited, except as
allowed under the
copyright laws.
The information furnished
in this manual is for
informational use only, is
subject to change without
notice, and should not be
construed as a
commitment by HP. All
intellectual rights arising
from, accruing to, and
residing in this manual are
the property of HP. HP
assumes no responsibility
or liability for any errors or
inaccuracies that may
appear in this manual.
Except as permitted by HP,
nothing herein may be
copied, reproduced or
distributed in any form or
any medium without the
express written permission
of HP.
HP, HP Indigo Press,
HP Indigo Press RIP, and
HP ElectroInk are
trademarks or registered
trademarks of HP.
Adobe® PostScript® is a
trademark of Adobe
Systems Incorporated.
MS Windows® and
Windows® are U.S.
registered trademarks of
Microsoft Corp.
All other products or name
brands are trademarks of
their respective holders.
The HP Indigo press is a
Class 1 Laser Product
containing high voltage
power supplies and laser
light sources. There is no
danger to persons or
equipment when the
system is operated in
accordance with the
directions provided by HP
in this and other
publications. All high
voltage power supplies and
laser sources are located
behind protective covers.
Warning labels are
attached to each protective
cover. Do not remove
covers.
Part Number:
CA294-01131
First Edition:
January, 2006

ENWW 3
Contents
1 Preface
About this user guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Conventions used in this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2 Getting started
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Digital offset color printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Press specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Printing rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
A tour of the press . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
HP Indigo press 3050 jobs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
A look inside the press . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Print cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Starting up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Charging and discharging the PIP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Inking the PIP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Transferring to the blanket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Printing the image. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3 Safety
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Warning signs and labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Warning labels on the press . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Warning signs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Placement of warning labels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Safety devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Material safety data sheets (MSDS). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Fire extinguishing equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Eye wash stations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Noise levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Heat insulating tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Electrical safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Emergency power shutdown. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Door interlocks and warning indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Maintenance safety and emergency procedures . . . . . . . . . . . . . . . . . . . . . . . . 31
Standby status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Inching button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Inch-safe-service method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Machine lockout procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Flammable liquids and fumes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Isopropyl alcohol (IPA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
IPA contamination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Handling and storing imaging oil, inks, and IPA . . . . . . . . . . . . . . . . . . . . . . 33
Disposing of consumables and cleaning materials. . . . . . . . . . . . . . . . . . . . 34
Additional information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4 HP Indigo press 3050 basics
The press interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

4 Contents ENWW
User level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Windows and sub-windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Wizards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
HP Indigo online help suite . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
About the online help suite . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Reference guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Operation guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Help Topics window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Related topics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5 The main windows
Using the control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Machine state indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Current print job panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Print buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
The schematic animated indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Managing jobs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
The Job Manager window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
The Loaded Jobs list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Changing the order of the Print Queue. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Retained Jobs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Archiving. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Using the Job Editor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Job Editor functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Accessing the Job Editor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Configuring the Hotfolder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Job imposition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
6 Operating the press
Turning the press on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Turning the press on. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Turning the press off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Preparing the press . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Printing jobs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Stage 1: Preparing the press . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Stage 2: Proofing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Stage 3: Printing the full run . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Divider between pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Job maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Editing job properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Job look-up tables (LUTs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Screening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Inks “double-hit” printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Color match . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Image placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Annotation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Service operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Control pad button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Emergency Stop buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Inching button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Paper Feed button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Sample Tray button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Handwheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Consumables Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Ink replenishment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

ENWW 5
Imaging oil replenishment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Paper transport adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Blanket maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Impression paper maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Replacing the impression paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Photo imaging plate (PIP) maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Calibrating the press colors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Color Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Calibrating the machine LUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Substrate-related parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Workflow for machine LUT generation and substrate-related parameters . . 77
Calibrating the inline densitometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Performing the full densitometer calibration . . . . . . . . . . . . . . . . . . . . . . . . . 81
7 Operator routines
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Practical tips before performing maintenance routines . . . . . . . . . . . . . . . . 84
Start-of-day routine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Pre-conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Power-up procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
End-of-day routine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Weekly routines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Monthly routines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Mechanical system lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Paper feed unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Input Conveyor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Front section. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Paper exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Rear section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
8 Handling ink
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Draining the ink tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Replacing ink cans and rebuilding ink. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Replacing ink cans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Rebuilding the ink in a tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Adjusting ink density . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Calibrating ink density wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Decreasing ink density . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Adjusting ink conductivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Adding imaging agent. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Decreasing ink conductivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Viewing the ink can log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Accessing the ink log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Cleaning the ink pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
9 Blanket
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Replacing the blanket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Removing the old blanket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Installing a new blanket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Cleaning the blanket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Recovering the blanket surface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Automatic blanket cleaner page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

6 Contents ENWW
Shifting separations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
For simplex printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
For duplex printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
ITM temperature sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
First pressure adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Removing the ITM hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
10 PIP
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Replacing the PIP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Removing the old PIP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Installing the new PIP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Replacing the PIP underlayer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Updating your system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
Viewing the PIP log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
11 Paper transport
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Paper storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Paper specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Grain direction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Sheet trimming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Sheet size. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Paper transport subsystems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Paper feed unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Feed conveyor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Grippers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Perfector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Exit unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Paper transport control pads. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Paper feed unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Press . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Adjusting the paper transport system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
At your workstation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Paper path adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Defining substrate type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Loading a substrate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
Mounting a paper tray base plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
Loading a new substrate in the main tray. . . . . . . . . . . . . . . . . . . . . . . . . . 160
Loading a new substrate in the secondary tray . . . . . . . . . . . . . . . . . . . . . 160
Adjusting the input tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
Before you begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
Adjusting paper tray guides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
Adjusting suction and blower flow rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Adjusting the top paper guides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
Adjusting the double feed sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
Adjusting the conveyor belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
Adjusting the first friction wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
Adjusting the front static guide and rear jogger . . . . . . . . . . . . . . . . . . . . . . . . 168
Testing the substrate transport system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Front-to-back registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Sample tray configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
Accessing the impression drum area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175
Clearing paper jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176

ENWW 7
Maintaining the paper transport system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Cleaning the paper path sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Cleaning the paper transport rollers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181
Replacing the sheet separators on the Paper Feed Unit . . . . . . . . . . . . . . 181
Removing paper jammed under cleaning station . . . . . . . . . . . . . . . . . . . . . . . 183
Removing paper shreds under the air knife . . . . . . . . . . . . . . . . . . . . . . . . . . . 186
12 Impression drum
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
Replacing the impression paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
13 Imaging oil
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194
Imaging oil filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194
Refilling the imaging oil tank. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
Replacing the imaging oil filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196
Imaging oil cleanness sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199
14 Cleaning station
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202
Cleaning the cleaning station blade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202
Rotating and replacing the cleaning station blade . . . . . . . . . . . . . . . . . . . . . . 204
Removing the cleaning station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206
Installing the cleaning station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
Sponge roller replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
15 Scorotron
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212
Scorotron maintenance procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212
Maintaining the scorotron . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212
Replacing the scorotron corona . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213
Replacing the damper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216
Maintaining the scorotron . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217
16 Binary ink developer (BID)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220
Replacing the BID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221
Removing the BID unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 222
Installing the BID unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225
Registering BID replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227
Returning the BID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228
Reusing the BID unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229
Storing the BID unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229
Reinstalling a BID unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229
Adjusting the BID to the PIP pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230
Adjusting the BID engage and disengage angle. . . . . . . . . . . . . . . . . . . . . . . . 232
Adjusting BID engage/disengage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
Correcting an inkless spot on the leading edge . . . . . . . . . . . . . . . . . . . . . 237
Press long-term shutdown maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 238
Bellows position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239
BID troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239
Black BID cleaning procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244

8 Contents ENWW
Checking ink flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 246
Calibrating ink density using an external densitometer . . . . . . . . . . . . . . . 248
Adjusting ink conductivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248
Manual BID control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249
BID Washer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249
Cleaning the ink tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249
Procedure for activating BID ink pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . 251
17 Pre-transfer erase (PTE)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254
Cleaning the PTE cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254
18 Blower cabinet
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 258
Draining the cooler waste . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 258
Draining the solids air compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
19 Chiller
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
Chiller type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
Warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
Operating conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 263
Control panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 264
Components of the control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 264
Control thermostat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265
Weekly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265
Monthly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265
Yearly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
Chiller timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Setting the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
20 Long-term shutdown
Long-term shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272
Initializing after a long-term shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272
21 Glossary
A Parts and supplies
Imaging products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 278
Operator maintenance parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 279
Special tools and jigs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 279
Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280
Substrate treatment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280
Index
B Service and support

ENWW 9
1Preface
Welcome to the HP Indigo press 3050. This preface provides an overview of the user
guide contents and explains conventions used in this guide.
This preface contains the following sections:
zAbout this user guide
zConventions used in this guide

10 Chapter 1 Preface ENWW
About this user guide
This user guide assumes that you are familiar with the basic Windows environment and
that you have basic Windows skills, such as using a mouse and selecting menu items. If
you do not, please see the Windows documentation that came with the computer.
The user guide contains the following information:
zPreface: Provides an overview of the user guide contents and explains conventions
used in this guide.
zGetting started: Provides an overview of the HP Indigo press 3050 and describes
the print cycle.
zSafety: Provides important safety information for using the HP Indigo press 3050.
zHP Indigo press 3050 basics: Describes the press user interface and the help
system.
zThe main windows: Describes the control panel and job management procedures.
zOperating the press: Provides an overview of press operations basics, including job
maintenance and press maintenance.
zOperator routines: Describes start-of-day routines, end-of-day routines, weekly
routines, and mechanical system lubrication.
zHandling ink: Describes replacement and maintenance of HP ElectroInk.
zBlanket: Describes replacement and maintenance of the blanket.
zPIP: Provides PIP replacement procedures.
zPaper transport: Provides detailed instructions for adjustment and maintenance of
the paper transport system.
zImpression drum: Describes the impression paper replacement procedure.
zImaging oil: Provides maintenance and replacement procedures for the imaging oil
system.
zCleaning station: Describes the cleaning station maintenance procedures.
zScorotron: Describes the scorotron maintenance procedures.
zBinary ink developer (BID): Provides BID troubleshooting, maintenance and
replacement procedures.
zPre-transfer erase (PTE): Describes PTE maintenance procedures.
zBlower cabinet: Provides blower cabinet maintenance procedures.
zChiller: Provides inspection and maintenance procedures for the press chiller.
zLong-term shutdown: Describes long-term shutdown procedures.
zGlossary: Provides definitions of terms used throughout the HP Indigo press 3050
documentation set.
zParts and supplies: Provides information on the press imaging products,
maintenance parts, and supplies.
zService and support: Provides HP Indigo service and support contact information.

ENWW Conventions used in this guide 11
Conventions used in this guide
This guide uses the following documentation conventions:
zKeyboard keys to press appear in all capital letters, for example: Press the SHIFT key.
zMenu options are indicated in bold type, for example: On the File menu, click New.
zWindow names appear in italics, for example: After selecting the options in the Print
window, click OK.
zReferences to other sections in the guide appear in quotes, for example: See the
“Installation” on page 37.

12 Chapter 1 Preface ENWW

ENWW 13
2Getting started
This chapter contains the following sections:
zOverview
zPress specifications
zA look inside the press
zPrint cycle

14 Chapter 2 Getting started ENWW
Overview
This chapter contains a tour of the HP Indigo press 3050 and a description of the press
workflow.
The HP Indigo press 3050 is a sheet-fed digital offset color press that incorporates the
patented HP ElectroInk liquid ink technology and high-speed electronic imaging to
produce fully-finished, high-volume, high-quality color print jobs. The press features an
intuitive and user-friendly interface, provides diagnostic screens that take the guess work
out of printing, accepts very large files, and simplifies the entire archiving process.
Digital offset color printing
Digital offset color printing is the HP Indigo electronic printing process that combines
high-performance digital imaging technology with the liquid ink offset printing process.
The merging of electronic imaging with the properties of liquid ink offset printing combines
the flexibility of on-demand electronic printing with the quality of offset printing.
As in offset printing, digital offset color printing transfers the inked image from the image
carrier to a blanket, and from the blanket to the substrate. However, unlike offset printing,
digital offset color printing creates a different image with each revolution without the use of
film separations or printing plates.
The press is equipped with an embedded HP Indigo raster image processor (RIP).
The HP Indigo embedded RIP enables you to process PostScript or portable document
format (PDF) files at your press station. The HP Indigo RIP is fast, has proofing and
previewing capabilities, and lets you perform light editing. It RIPs the jobs immediately
upon arrival at the station.
The press supports the HP Indigo proprietary Swift Native Accelerated Personalization
(SNAP) technology. SNAP technology enables you to print large database driven
personalization jobs without delay.
Press specifications
Printing rate
Paper feed unit rate
z4000 impressions/hour for all substrates
Note Printing should be performed at the rate of 4000 impressions/hour, whenever possible.
zbest printing performance may be achieved at 8000 impressions/hour for substrates
between 135 and 225 g/m2(90 lb text/50 lb cover and 84 lb cover)

ENWW Press specifications 15
Printing productivity
1(number of color separations on side 1 / number of color separations on side 2)
Color
Up to seven colors are supported. One option is four process colors (cyan, magenta,
yellow, and black), plus three spot colors. Another option is the HP IndiChrome process
(six color process), plus one spot color.
Input formats
The following input formats are supported:
zPostScript®
zPortable document format (PDF)
zEncapsulated PostScript (EPS)
zTagged image format (TIF)
zJoint photographic experts group (JPG)
zHP Indigo’s proprietary Job Layout format (JLT)
Input job definition Press productivity
PFU rate
(impressions/hour)
Job type1A4 pages/hour Separations/hour
8,000 A4 (1/0) 16,000 8,000
4,000 A4 (1/0) 8,000 4,000
8,000 or 4,000 A4 (4/0) 4,000 8,000
8,000 or 4,000 A4 (4/4) 2,000 8,000
8,000 A4 (1/1) 8,000 8,000
4,000 A4 (1/1) 6,400 6,400

16 Chapter 2 Getting started ENWW
A tour of the press
The press is divided into four basic sections: the front, rear, paper input side, and paper
exit side.
HP Indigo press 3050 jobs
Jobs begin at desktop publishing stations, often at a distance from the press. At the
stations, text and graphics are designed and integrated, flats are imposed, and PostScript
or portable document format (PDF) files are created. The PostScript or PDF files are then
transferred to the press.
The system consists of two subsystems: the HP Indigo RIP and the press. The RIP
software reads the files from the pre-press station, converts them to bitmaps (one per
separation), and then sends them to the press for printing.
Figure 2-1. HP Indigo press 3050
Figure 2-2. From pre-press to the press
Front
Rear
Input side
Exit side
Pre-press station
Input: text, photos, and graphics
Output: PostScript or PDF files
Press
Input: PostScript or PDF files
Output: printed substrate

ENWW A look inside the press 17
A look inside the press
Figure 2-3. Press schematic
Writing head — Transfers the image to the PIP by laser beam Duplex conveyor PIP drum — Image carrier
Ink cans store concentrated solid inks Impression drum — Applies counterpressure on printed sheet
Scorotrons — This is where the PIP is charged
Ink tanks store heated inks
BID units — Apply ink to the PIP
Cleaning station — Cleans the PIP Paper feed unit
Perfector — Holds sheets between first and second side printing
ITM Drum — This is where the blanket is located
Rotors — Carry output sheets

18 Chapter 2 Getting started ENWW
Print cycle
Once the job is in the print queue, the press can begin the print cycle. The following steps
are used in printing a job with the press:
zstarting up
zcharging and discharging the PIP
zinking the PIP
ztransfer to the blanket
zprinting the image
Starting up
To initiate the print cycle, in the control panel, click Print. The drums start rotating and the
support systems begin to work.
Charging and discharging the PIP
The scorotron unit electrically charges the photo-conductive imaging plate (PIP) as it
rotates on the PIP drum. The writing head laser beams selectively discharge the PIP.
A latent image forms on the PIP.
Figure 2-4. Control panel window
Figure 2-5. Charging the PIP
Print button
Writing head
PIP drum
Three scorotron
units charging the
PIP
PIP foil

ENWW Print cycle 19
Inking the PIP
Binary ink developer (BID) units apply ink on the PIP. Ink is applied only to the discharged
areas of the PIP. Ink particles are attracted either to the BID developer drum or to the PIP.
The PIP discharged areas, which are the image areas, attract the ink particles. The
charged areas, which are the non-image areas, repel the ink. When the image on the PIP
surface is inked, the image is ready to be transferred to the blanket.
.
Figure 2-6. Discharging the PIP
Figure 2-7. BID unit engaged to the PIP
Laser beams (12)
selectively discharging the
PIP
PIP drum
Writing head
PIP foil
BID unit
Ink reservoir BID
developer
