Hardware Reference Guide
HP t5325 Thin Clients

© Copyright 2009 Hewlett-Packard
Development Company, L.P. The
information contained herein is subject to
change without notice.
Microsoft and Windows are trademarks of
Microsoft Corporation in the U.S. and other
countries.
The only warranties for HP products and
services are set forth in the express warranty
statements accompanying such products
and services. Nothing herein should be
construed as constituting an additional
warranty. HP shall not be liable for technical
or editorial errors or omissions contained
herein.
This document contains proprietary
information that is protected by copyright. No
part of this document may be photocopied,
reproduced, or translated to another
language without the prior written consent of
Hewlett-Packard Company.
Hardware Reference Guide
HP t5325 Thin Clients
First Edition (September 2009)
Document Part Number: 588605-001

About This Book
WARNING! Text set off in this manner indicates that failure to follow directions could result in bodily
harm or loss of life.
CAUTION: Text set off in this manner indicates that failure to follow directions could result in damage
to equipment or loss of information.
NOTE: Text set off in this manner provides important supplemental information.
ENWW iii

iv About This Book ENWW

Table of contents
1 Overview
2 Thin Client Management Solutions
3 Front Panel Components
4 Rear Panel Components
5 Installing the Rubber Feet
6 Serial Number Location
Appendix A Specifications
Appendix B Security Provisions
Securing the Thin Client ....................................................................................................................... 9
Appendix C Mounting the Thin Client
HP Quick Release .............................................................................................................................. 10
Supported Mounting Options ............................................................................................. 12
Non-supported Mounting Option ........................................................................................ 14
Appendix D Thin Client Operation
Routine Thin Client Care .................................................................................................................... 15
Supported Orientations ...................................................................................................................... 15
Non-supported Orientation ................................................................................................................. 17
Appendix E Electrostatic Discharge
Preventing Electrostatic Damage ....................................................................................................... 18
Grounding Methods ............................................................................................................................ 18
ENWW v

Appendix F Shipping Information
Shipping Preparation .......................................................................................................................... 19
Important Service Repair Information ................................................................................................. 19
Index ................................................................................................................................................................... 20
vi ENWW

1Overview
Thank you for purchasing an HP thin client. We hope you have years of use from our thin clients. Our
goal is to provide you with award-winning clients that are easy to deploy and manage with the power
and reliability you expect.
The next sections describe the features of the thin client. For a complete list of the hardware and software
installed on a specific model, visit http://www.hp.com and search for your specific thin client model.
The following features are common to all HP thin clients:
●no hard drives or diskette drives
●5-minute hardware setup time
●central deployment and management using HP Management Solutions
Various options are available for your thin client. For more information about available options, visit the
HP Web site at http://www.hp.com and search for your specific thin client model.
NOTE: Your computer model may look different than the model in the following illustrations.
ENWW 1

2 Thin Client Management Solutions
HP has a comprehensive suite of management solutions to fit your needs. This allows you to choose
solutions that will work best in your environment.
HP ThinState Tools are a set of handy utilities that allow you to copy settings and software images from
one thin client to another using a USB drive key. HP ThinState tools complement other management
solutions and are included with HP thin client operating systems.
HP Device Manager is an enterprise-class thin client management software application that allows
customers to view their thin client assets remotely and to manipulate those thin clients to meet the
required business need. It is robust, yet easy to install and use. HP Device Manager lets you track,
configure, upgrade, clone, and manage thousands of individual devices from a centralized location. HP
Device Manager agents are included in most HP thin clients.
2 Chapter 2 Thin Client Management Solutions ENWW

3 Front Panel Components
For more information, http://www.hp.com and search for your specific thin client model to find the model-
specific QuickSpecs.
Figure 3-1 Front panel components
(1) Power button (4) Line-out (headphone) audio connector
(2) Flash activity LED (5) Universal serial bus (USB) connectors (2)
(3) Line-in (microphone) connector
ENWW 3

4 Rear Panel Components
For more information, http://www.hp.com and search for your specific thin client model to find the model-
specific QuickSpecs.
Figure 4-1 Rear panel components
(1) Power connector (4) Ethernet RJ-45 connector
(2) DVI-I connector (5) Cable lock slot
(3) Universal serial bus (USB) connectors (2)
4 Chapter 4 Rear Panel Components ENWW

5 Installing the Rubber Feet
To install the rubber feet:
1. Remove the feet from their backing.
2. Line up the hole in each foot with a VESA hole on the bottom of the thin client. Press the foot down
firmly to secure it to the thin client.
NOTE: The feet provide a protective cushion between the thin client and whatever surface it sits
on or is mounted to.
Figure 5-1 Installing the rubber feet
ENWW 5

6 Serial Number Location
Every thin client includes a unique serial number located as shown in the following illustration. Have this
number available when contacting HP customer service for assistance.
Figure 6-1 Serial number location
6 Chapter 6 Serial Number Location ENWW

A Specifications
Table A-1 HP t5325 Thin Client
Dimensions
Width (front to back)
Height (top to bottom)
Depth (side to side)
160 mm
32 mm
123 mm
6.3 in.
1.3 in
4.8 in.
Approximate Weight 490 g 17.3 oz
Temperature Range (fanless design)*
Operating**
(max. rate of change is 10° C per hour or 18° F per hour)
Nonoperating
(max. rate of change is 20° C per hour or 36° F per hour)
10° to 35° C
-30° to 60° C
50° to 95° F
-22° to 140° F
*Specifications are at sea level with altitude derating of 1° C/
300 m (1.8° F/1000ft) to a maximum of 3 Km (10,000 ft), with
no direct, sustained sunlight. Upper limit may be limited by
the type and number of options installed.
** The operating temperature range when the thin client
is attached to a flat panel using the HP Quick Release
is 50° to 95° F (10° to 35° C).
Relative Humidity (non-condensing)
Operating
(max. wet bulb temperature is 28° C or 84.2° F)
Nonoperating
(max. wet bulb temperature is 38.7° C or 101.6° F)
10–90%
5–95%
10–90%
5–95%
Maximum Altitude (unpressurized)
Operating
(max. allowed rate of change is 457 m per minute or 1500 ft
per minute)
Nonoperating
(max. allowed rate of change is 457 m per minute or 1500 ft
per minute)
3048 m
9144 m
10,000 ft
30,000 ft
Power Supply
Operating Input Voltage Range
Rated Line Frequency
100–240 VAC
50–60 Hz
100–240 VAC
50–60 Hz
ENWW 7

Power Output (maximum) 36 W 36 W
Rated Output Current (maximum) 3 A 3 A
Output Voltage +12 V DC +12 V DC
Table A-1 HP t5325 Thin Client (continued)
8 Appendix A Specifications ENWW

B Security Provisions
Securing the Thin Client
These thin clients are designed to accept a security cable lock. This cable lock prevents unauthorized
removal of the thin client, as well as locking the secure compartment. To order this option, visit the HP
Web site at http://www.hp.com and search for your specific thin client model.
1. Locate the cable lock slot on the back panel.
2. Insert the cable lock into the slot, and then use the key to lock it.
Figure B-1 Securing the thin client
ENWW Securing the Thin Client 9

C Mounting the Thin Client
HP Quick Release
This thin client incorporates four mounting points on the bottom of the unit. These mounting points follow
the VESA (Video Electronics Standards Association) standard, which provides industry-standard
mounting interfaces for Flat Displays (FDs), such as flat panel monitors, flat displays, and flat TVs. The
HP Quick Release connects to the VESA-standard mounting points, allowing you to mount the thin client
in a variety of orientations.
NOTE: When mounting to a thin client, use the 10 mm screws supplied with the HP Quick Release.
Figure C-1 HP Quick Release
10 Appendix C Mounting the Thin Client ENWW

To use the HP Quick Release:
1. Using four 10 mm screws included in the mounting device kit, attach one side of the HP Quick
Release to the thin client as shown in the following illustration.
Figure C-2 Connecting the HP Quick Release to the thin client
2. Using four screws included in the mounting device kit, attach the other side of the HP Quick Release
to the device to which you will mount the thin client. Make sure the release lever points upward.
Figure C-3 Connecting the HP Quick Release to another device
ENWW HP Quick Release 11

3. Slide the side of the mounting device attached to the thin client (1) over the other side of the
mounting device (2) on the device on which you want to mount the thin client. An audible 'click'
indicates a secure connection.
Figure C-4 Connecting the thin client
NOTE: When attached, the HP Quick Release automatically locks in position. You only need to slide
the lever to one side to remove the thin client.
CAUTION: To ensure proper function of the HP Quick Release and a secure connection of all
components, make sure both the release lever on one side of the mounting device and the rounded
opening on the other side face upward.
Supported Mounting Options
The following illustrations demonstrate some of the supported and not supported mounting options for
the mounting bracket.
●You can mount a thin client between a flat panel monitor and the wall.
Figure C-5 Thin client mounted with flat panel on wall
●You can mount the thin client on the back of a flat panel monitor stand.
12 Appendix C Mounting the Thin Client ENWW

Figure C-6 Thin client mounted on back of monitor stand
●You can mount the thin client on a wall.
Figure C-7 Thin client mounted on wall
●You can mount the thin client under a desk.
Figure C-8 Thin client mounted under desk
ENWW HP Quick Release 13

Non-supported Mounting Option
CAUTION: Mounting a thin client in an non-supported manner could result in failure of the HP Quick
Release and damage to the thin client and/or other equipment.
Do not mount the thin client on a flat panel monitor stand between the panel and the stand.
Figure C-9 Unsupported mounting position—thin client between stand and monitor
