HP StorageWorks Fabric OS 6.2.0b
release notes
Part number: 5697-0352
Second edition: March 2010

Legal and notice information
© Copyright 2009-2010 Hewlett-Packard Development Company, L.P.
© Copyright 2009-2010 Brocade Communications Systems, Incorporated
Confidential computer software. Valid license from HP required for possession, use or copying. Consistent with FAR 12.211 and 12.212,
Commercial Computer Software, Computer Software Documentation, and Technical Data for Commercial Items are licensed to the U.S.
Government under vendor's standard commercial license.
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the
express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional
warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Microsoft and Windows are registered trademarks of Microsoft Corporation.

Version
6.2.0b
NOTE:
This software conforms to the Fibre Channel standards and to accepted engineering practices and
procedures.
Effective date
March 2009
Description
Fabric OS 6.2.0b introduces support for the HP StorageWorks Encryption SAN Switch and the HP
DC Switch Encryption FC Blade. These products provide the following features:
•Data encryption support for B-Series fabrics
•Key Management support for HP Secure Key Manager (SKM)
Fabric OS 6.2.0a integrated the following new features (these features continue to be supported in
Fabric OS 6.2.0b):
•Support for the new HP StorageWorks DC04 SAN Director
•192 ports, 8–Gb technology in 8U chassis (without required front airflow mounting kit, 9U
with kit)
•Supports existing 8–Gb FC blades (16, 32, and 48 port)
•Supports existing 10–Gb 6 port ISL blade
•Supports existing Multi-protocol Router blade
•Supports ICL connectivity to other DC04 and DC SAN Backbone directors
•Virtual Fabrics (VF)
•Full VF feature support on HP StorageWorks DC SAN Backbone Director, HP StorageWorks
DC04 SAN Director, HP StorageWorks 8/80 SAN Switch, and HP StorageWorks 8/40 SAN
Switch.
•Single physical chassis can be subdivided into two or more logical switches, creating a logical
fabric with other switches.
•Per-port assignment of ports to logical switches
•Shared ISLs provide connectivity for multiple logical fabrics.
•FCR and FCIP enhancements
•FCIP (SCSI) read tape pipelining
•Enhancements to SoTCP
•LSAN tagging
•Support Pathinfo over MetaSAN
HP StorageWorks Fabric OS 6.2.0b release notes 3

•Use FSPF cost in FCR backbone fabric to find shortest path to edge fabric
•In-band management link over FCIP connections for HP StorageWorks 400 Multi-protocol
Router
•TCP byte streaming for FCIP connections with WAN optimization hardware
•Improved FCIP statistics support, including TCP connection history, high watermark information,
and connection snapshot capability
•Support temporary licenses for Adaptive Networking, Integrated Routing, and Fabric Watch
•Security enhancements
•IPv6 auto-configuration
•IPSec with IPv6 (for management port)
•Configurable switch-wide policy requiring authentication of all HBAs
•RADIUS enhancements allowing password expiration and source IP address information
•LPAD enhancement allowing for alternate domain UPN
•IPv6 certified for JITC Approved Product List
•FICON enhancements
•RNID support for CUP
•New FC addressing modes for support with virtual fabrics
•Support for HP StorageWorks SAN Director 48 Port 8Gb FC Blade with VF-enabled HP Stor-
ageWorks DC SAN Backbone Director and DC04 SAN Director for FICON environments
•Access Gateway enhancements
•AG mode support on HP StorageWorks 8/40 SAN Switch.
•Miscellaneous
•FC ping support between switches (ping switch WWN)
•Provision of path information via CLI
•Frame redirection support in interopmode 3 (McDATA Open Fabric Mode)
•Support for M-EOSn's 239 Domain ID mode via FCR in interopmode 3
•System-wide RASLOG
•Port auto-disable support
•Ethernet port bonding for management ports
•New CLI command to configure F_Port receive buffer credits
New feature descriptions
This section describes the new features that were introduced in Fabric OS 6.2.0a.
Virtual fabrics
•Virtual Fabrics (VF) is a new capability supported on the HP StorageWorks DC SAN Backbone
Director, DC04 SAN Director, HP StorageWorks 8/80 SAN Switch, and HP StorageWorks 8/40
SAN Switch. Once enabled, VF allows the user to divide a single physical chassis or switch into
multiple logical switches by assigning individual ports to a logical switch. Each of these logical
switches is managed as a completely independent layer 2 Fibre Channel switch, and can be de-
ployed in independent fabrics known as logical fabrics.
•VF also allows the user to create a special logical switch known as the base switch, used for
connectivity to other base switches and also as a backbone fabric for Fibre Channel Routing. In-
dividual logical fabrics may utilize this shared base fabric for connectivity to other switches,
4

providing efficient use of resources by sharing common ISL and ICL connections among multiple
logical fabrics.
•The Virtual Fabrics feature is part of the base Fabric OS and does not require a license. Virtual
Fabrics is fully compatible with legacy Brocade products as well as M-Series switches and directors.
FCR and FCIP enhancements
•FCIP (SCSI) Read Tape Pipelining anticipates host read operations and buffers data to reduce
latency from the FCIP WAN.
•LSAN Tagging provides special behavior for designated LSAN zones using either a new speed
tag or enforce tag. The enforce tag allows individual FCRs to be configured only to import devices
in specific LSAN zones, increasing scalability. The speed tag allows designated targets to remain
imported, allowing sensitive hosts to discover targets much faster. This is useful when performing
boot over LSAN operations
•SoTCP Enhancements improve network congestion management in Slow Start Mode and helps
prevent host I/O timeouts.
•Support for Pathinfo over MetaSAN. The Pathinfo command has been enhanced to provide
path information across routed fabrics, which is especially useful when troubleshooting connectivity
problems across routed fabrics.
•FSPF cost in FCR backbone fabric uses the most efficient route to reach a destination fabric, pre-
venting the use of an FCIP link when an ISL is available.
•In-band management link over FCIP connections for the HP StorageWorks 400 Multi-protocol
Router allows a management station to communicate with a remote 400 Multi-protocol Router
through the GE ports. This allows a single management station located on the WAN side of the
400 Multi-protocol Router to communicate with the management interface on the CP for management
tasks such as firmware downloads, snmp polling, snmp traps, trouble shooting, and configuration.
Enhanced Native Connectivity with McDATA products
•Fabric OS 6.2 and M-EOS 9.9 now support Frame Redirection in McDATA Open Fabric Mode
(interopmode 3) fabrics. Frame Redirection zones must be created and activated from Fabric OS
platforms.
•Fabric OS platforms now support EX_Port connections to McDATA Open Fabric Mode Mi10ks
using the 239 DID setting.
Security enhancements
•Configurable stateless IPv6 auto-configuration support.
•IPSec with IPv6 support provides greater security for management ports and configurable security
policies for IPv4/6 addresses.
•A switch-wide policy requiring HBA authentication requires the FC-SP bit to be set in FLOGI. If the
bit is not set, the FLOGI is rejected and the port is disabled.
•A new warning for RADIUS login allows users to configure how many days in advance they should
be notified of password expiration.
•An LDAP enhancement adds the ability to provide an alternate UPN (userPrincipalName) to domain
authentication.
Contact your switch vendor regarding the use of other backup applications.
Optionally licensed software
The following are optionally licensed features in Fabric OS 6.2:
•Ports on Demand allows customers to instantly scale the fabric by provisioning additional ports
via license key upgrade (applies to select models of switches).
HP StorageWorks Fabric OS 6.2.0b release notes 5

•Extended Fabrics provides greater than 10 km of switched fabric connectivity at full bandwidth
over long distances (depending on platform, the distance can be up to 3000 km).
•ISL Trunking provides the ability to aggregate multiple physical links into one logical link for en-
hanced network performance and fault tolerance. This also includes Access Gateway ISL Trunking
on those products that support Access Gateway deployment.
•Advanced Performance Monitoring enables performance monitoring of networked storage resources.
This license includes the TopTalkers feature.
•High Performance Extension over FCIP/FC (formerly known as FC-IP Services) for the HP Storage-
Works B-Series Multi-protocol Router blade and 400 Multi-protocol Router). This license key also
includes the FC-Fastwrite feature and IPsec capabilities.
•Accelerator for FICON license enables unique FICON emulation support for IBM’s Global Mirror
(formerly XRC) application (including Hitachi Data Systems HXRC and EMC’s XRC) as well as
Tape Pipelining for all FICON tape and virtual tape systems to significantly improve XRC and tape
backup/recovery performance over virtually unlimited distance for HP StorageWorks 400 Multi-
protocol Router and B-Series Multi-protocol Router blade.
•Fabric Watch monitors mission-critical switch operations. Fabric Watch now includes new Port
Fencing capabilities.
•The FICON Management Server (also known as CUP or Control Unit Port) enables host-control of
switches in Mainframe environments.
•ICLs, or Inter Chassis Links, provide dedicated high-bandwidth links between two HP StorageWorks
DC SAN Backbone Directors or DC04 SAN Director switch chassis, without consuming valuable
front-end 8G ports. Each DC Backbone Director/DC04 SAN Director must have the ICL license
installed in order to enable the ICL connections. (Available on the DC Backbone Director/DC04
SAN Director only)
•Adaptive Networking provides a rich framework of capability allowing a user to ensure high pri-
ority connections and obtain the network resources necessary for optimum performance, even in
congested environments. The QoS SID/DID Prioritization and Ingress Rate Limiting features are
the first components of this license, and are fully available on all 8G platforms.
•The Integrated Routing license allows ports in an HP StorageWorks DC SAN Backbone Director,
HP StorageWorks DC04 SAN Director, HP StorageWorks 8/80 SAN Switch, or HP StorageWorks
8/40 SAN Switch, to be configured as EX_ports supporting Fibre Channel Routing. This eliminates
the need to add an B-Series Multi-protocol Router blade or use the 400 Multi-protocol Router for
FCR purposes, and also provides double the bandwidth for each FCR connection (when connected
to another 8G-capable port).
•A Server Application Optimization license, introduced with Fabric OS 6.2, when deployed with
Server Adapters, optimizes overall application performance for physical servers and virtual machines
by extending virtual channels to the server infrastructure. Application specific traffic flows can be
configured, prioritized, and optimized throughout the entire data center infrastructure.
Included licensed software
The Enhanced Group Management license is included with all HP 8Gb switches. Enhanced Group
Management enables full management of the device in a datacenter fabric with deeper element
management functionality and greater management task aggregation throughout the environment.
This license is used in conjunction with Data Center Fabric Manager (DCFM) application software.
Temporary license support
Temporary licenses are not currently supported by HP.
6

Previously licensed software now part of base Fabric OS
The following capabilities are included as part of the base Fabric OS capability and no additional
purchase or licensing is necessary.
NOTE:
Advanced Zoning and Web Tools licenses are no longer necessary, beginning with Fabric OS 6.1.
These features are automatically enabled on all products running Fabric OS 6.1 or later
Supported switches
The following switches are supported with Fabric OS 6.2.0b:
•HP StorageWorks 4/8 and 4/16 SAN Switch
•HP StorageWorks 8/8 and 8/24 SAN Switch
•Brocade 4Gb SAN Switch for HP p-Class BladeSystem
•Brocade 4Gb SAN Switch for HP c-Class BladeSystem
•HP StorageWorks EVA4400 Embedded Switch Module
•HP StorageWorks 8Gb SAN Switch for HP BladeSystem c-Class
•HP StorageWorks SAN Switch 4/32
•HP StorageWorks 4/64 SAN Switch
•HP StorageWorks SAN Switch 4/32B
•HP StorageWorks 8/40 SAN Switch
•HP StorageWorks 8/80 SAN Switch
•HP StorageWorks Encryption SAN Switch
•HP StorageWorks 400 Multi-protocol Router
•HP StorageWorks 4/256 SAN Director
•HP StorageWorks DC SAN Backbone Director
•HP StorageWorks DC04 SAN Director
•HP DC Switch Encryption FC Blade
•HP StorageWorks 4/256 SAN Director 16 Port 4–Gb Blade
•HP StorageWorks 4/256 SAN Director 32 Port 4–Gb Blade
•HP StorageWorks 4/256 SAN Director 48 Port 4–Gb Blade
•HP StorageWorks Multiprotocol Router Blade
•HP StorageWorks B-Series iSCSI Director Blade
•HP StorageWorks SAN Director 16 Port 8–Gb FC Blade
•HP StorageWorks SAN Director 32 Port 8–Gb FC Blade
•HP StorageWorks SAN Director 48 Port 8–Gb FC Blade
•HP StorageWorks SAN Director 6 Port 10–Gb FC ISL Blade
Standards compliance
This software conforms to the Fibre Channel Standards in a manner consistent with accepted
engineering practices and procedures. In certain cases, HP might add proprietary supplemental
HP StorageWorks Fabric OS 6.2.0b release notes 7

functions to those specified in the standards. For a list of standards conformance, visit the following
HP Web site: http://www.hp.com.
Update recommendations
All products supported by Fabric OS 6.0.x can be upgraded to Fabric OS 6.2.0b. If applicable, HP
recommends that users upgrade to Fabric OS 6.2.0b as soon as possible to take advantage of the
latest fixes and features.
See Firmware upgrades and downgrades for further information.
Supersedes
Fabric OS 6.2.0a released in January, 2009.
New hardware support
Support for HP StorageWorks DC04 SAN Director Switch was introduced with Fabric OS 6.2.0a:
•Has 192 ports, 8 Gb/sec technology in an 8U chassis with horizontal slots (9U with standard
port side air flow kit)
•Supports HP StorageWorks SAN Director 16 Port 8Gb FC blade, SAN Director 32 Port 8Gb FC
blade, and SAN Director 48 Port 8Gb FC blade
•Supports all special purpose blades available for HP StorageWorks DC SAN Backbone Director
•Supports ICL connectivity to other HP StorageWorks DC04 SAN Director Switch or DC SAN
Backbone Director chassis
Fabric OS 6.2.0b introduces support for the HP StorageWorks Encryption SAN Switch and the HP
DC Switch Encryption FC Blade. The encryption switch provides:
•48 Gb/s of encryption processing power, upgradable to 96 Gb/s
•Industry standard AES-256 algorithms for data-at-rest encryption
•32 Fibre Channel ports, 8 Gb/s in 2U form factor
•Integration with HP StorageWorks Secure Key Manager (SKM)
The encryption blade provides 16 ports and is supported in the DC SAN Backbone and DC04 SAN
Directors.
NOTE:
The encryption switch and blade are unique products compared to standard Fibre Channel switches.
HP highly recommends that you read the Fabric OS Encryption Administrator's Guide before
configuring these products into any fabric.
Supported product models
The following product models can be upgraded to Fabric OS 6.2.0b:
•HP StorageWorks 4/8 SAN Switch and 4/16 SAN Switch (Brocade 200E)
•HP StorageWorks 4/64 SAN Switch (Brocade 4900)
•HP StorageWorks 400 Multi-protocol Router (Brocade 7500)
8

•HP StorageWorks 16 Port 4-Gb Blade (FC4-16)
•HP StorageWorks 32 Port 4-Gb Blade (FC4-32)
•B-Series MP Router Blade (Brocade FR4-18i Blade)
•HP StorageWorks 4/48 SAN Director Blade (FC4-48)
•HP StorageWorks SAN Switch 4/32 (Brocade 4100)
•HP StorageWorks 4/32B SAN Switch (Brocade 5000)
•HP StorageWorks 4/256 SAN Director (Brocade 48000)
•HP StorageWorks B-Series iSCSI Director Blade (Brocade FC4-16IP) compatible with the 4/256
SAN Director model only, not supported in the DC SAN Backbone Director or DC04 SAN Director
•Brocade 4-Gb SAN Switch for HP p-Class BladeSystem (Brocade 4012)
•Brocade 4-Gb SAN Switch for HP c-Class BladeSystem (Brocade 4024)
•Brocade 8–Gb SAN Switch for HP BladeSystem c-Class (Brocade 5480)
•HP StorageWorks DC SAN Backbone Director (Brocade DC Director Data Center Backbone)
•HP StorageWorks SAN Director 16 Port 8-Gb FC blade (Brocade FC8-16)
•HP StorageWorks SAN Director 32 Port 8-Gb FC blade (Brocade FC8-32)
•HP StorageWorks SAN Director 48 Port 8-Gb FC blade (Brocade FC8-48)
•HP StorageWorks SAN Director 6 Port 10-Gb FC ISL blade (Brocade FC10-6)
•HP StorageWorks EVA4400 embedded switch module (Brocade 5410)
•HP StorageWorks DC04 SAN Director
HP StorageWorks Fabric OS 6.2.0b release notes 9

Unsupported product models
The following product models cannot be upgraded to Fabric OS 6.2.0b:
•HP StorageWorks Core Switch 2/64, which operates with Fabric OS 5.0.x (Brocade 12000)
•HP StorageWorks SAN Director 2/128 (Brocade 24000)
•HP StorageWorks MSA SAN Switch 2/8, which operates with Fabric OS 3.2.x (Brocade 3000)
•HP StorageWorks SAN Switch 2/8V (Brocade 3250)
•HP StorageWorks SAN Switch 2/16V (Brocade 3850)
•HP StorageWorks SAN Switch 2/16, which operates with Fabric OS 3.2.x (Brocade 3800)
•HP StorageWorks SAN Switch 2/32 (Brocade 3900)
•HP StorageWorks Multi-protocol (MP) Router, which operates with XPath OS 7.4.x (Brocade
AP7420)
IMPORTANT:
Any enhancements for the models listed above will be delivered in Fabric OS 3.2.x, Fabric OS 5.x,
and XPath OS 7.4.x sustaining releases.
Devices supported
For a list of supported devices, see the HP website:
http://www.hp.com/go/san
Operating systems
For a list of operating systems, see the HP website:
http://www.hp.com/go/san
Access Gateway support
Access Gateway is supported with the following HP products only:
•Brocade 4-Gb SAN Switch for HP p-Class BladeSystem (Brocade 4012)
•Brocade 4-Gb SAN Switch for HP c-Class BladeSystem (Brocade 4024)
•HP StorageWorks 4/16 SAN Switch (Brocade 200E)
•HP StorageWorks 8/8 SAN Switch (Brocade 300)
•HP StorageWorks 8/24 SAN Switch (Brocade 300)
•HP StorageWorks 8/40 SAN Switch (Brocade 5100)
10

IMPORTANT:
Although the HP StorageWorks 4/8 SAN Switch uses the same hardware as the 4/16 SAN Switch,
it does not support Access Gateway. The same applies to the HP StorageWorks 8/8 and 8/24 SAN
Switches. Both use the same hardware, but only the 8/24, which has all ports licensed, has Access
Gateway support. Also, Access Gateway mode is not supported with the Brocade 4-Gb SAN Switch
for HP p-Class BladeSystem (Brocade 4012) if any half-height BladeServers (BL3xp) are configured
in the same sleeve in the p-Class enclosure. For the latest updates, see the HP website:
http://www.hp.com
Access Gateway connectivity is supported by the switches listed in Access Gateway support and also
by the following B-Series switches:
•HP StorageWorks EVA4400 embedded switch module
•HP StorageWorks 8/40 SAN Switch
•HP StorageWorks 8/80 SAN Switch
•HP StorageWorks DC SAN Backbone Director
•HP StorageWorks 4/256 SAN Director
•HP StorageWorks SAN Switch 4/32
•HP StorageWorks SAN Switch 4/32B
•HP StorageWorks SAN Switch 4/64
•HP StorageWorks 400 Multi-Protocol Router
Access Gateway was introduced with Fabric OS 5.2.1b. It allows a switch to operate in agmode ,
which allows simplified connectivity between large numbers of servers and the SAN. Access Gateway
leverages N_Port ID Virtualization (NPIV) to hide the complexity of the servers (both physical and
virtual) attached to it, while allowing easy SAN connectivity. The edge fabric switch provides all fabric
services, while Access Gateway connects to the edge switch by what appears as a host bus adapter
(HBA) connection. This architecture allows the deployment of many additional servers without requiring
a domain and the associated fabric rebuild traffic. Rebuild traffic is prevalent when switches are
powered on, added, or removed from a fabric.
See the Brocade Access Gateway Administrator's Guide, available on http://www.hp.com/go/san
for more information.
Access Gateway support in non-Brocade fabrics
In addition to being supported in Brocade fabrics, Access Gateway is supported for connectivity to
the following:
•McDATA fabrics running EOS 09.00.xx with Brocade Fabric OS 5.2.1b
•McDATA fabrics running EOS 09.02.xx or 09.03.xx with Brocade Fabric OS 5.3.0, 5.3.0a,
5.3.0b, 5.3.0c, 5.3.0d
•McDATA fabrics running EOS 09.06.x with Brocade Fabric OS 5.3.1, 5.3.1a, 6.0.0b, 6.0.1a
•Cisco fabrics running SAN-OS 3.0(2a) with Brocade Fabric OS 5.2.1b
•Cisco fabrics running SAN-OS versions 3.1(2a), 3.1(3), 3.1(3a) with Brocade Fabric OS 5.3.0,
5.3.0a, 5.3.0b, 5.3.0c, 5.3.0d
•Cisco fabrics running SAN-OS versions 3.0(2a) with Brocade Fabric OS 5.3.1, 5.3.1a, 6.0.0b,
6.0.1a
HP StorageWorks Fabric OS 6.2.0b release notes 11

Secure Fabric OS feature not compatible with Fabric OS 6.x
and later
Fabric OS 5.3.x is the last Fabric OS version which was compatible with SFOS. However, all of the
security features of SFOS have been fully integrated into the base Fabric OS, starting with Fabric OS
5.3.x.
Zoning and fabric operations
When configuring zoning or other fabric-wide settings in a fabric that has products operating with
different versions of Fabric OS, HP recommends that you perform the configuration via an interface
(such as Web Tools) to a product with the most recent version of Fabric OS. Some older versions of
Fabric OS do not fully support newer hardware models, and problems may arise when configuring
settings through these older products.
NOTE:
Never perform a zoning configuration through a switch operating with Fabric OS 3.x in a fabric that
also has products operating with newer versions of Fabric OS.
Prerequisites
Table 1 lists the supported Fabric OS firmware versions. HP recommends using the latest supported
firmware release versions to get the greatest benefit from the SAN.
For a list of retired products, see the HP website:
http://www.hp.com
IMPORTANT:
The Fabric OS versions listed in the Earliest compatible version column in Table 1 are the earliest
versions supported by HP at the time of the Fabric OS 6.2.0b release.
Table 1 Supported Fabric OS versions
Recommended versionEarliest compatible versionModel
N/A
Not supported, end of sup-
port (December 2007)
HP StorageWorks 1-Gb Switch
3.2.1c3.2.1b
HP StorageWorks SAN Switch 2/8 EL
nl
HP StorageWorks SAN Switch 2/16
nl
MSA SAN Switch 2/8
5.0.5f5.0.5e
HP StorageWorks Core Switch 2/64
nl
HP StorageWorks SAN Director 2/128 in Chassis
Config modes 3 and 4 only
12

5.3.25.1.1b
HP StorageWorks SAN Switch 2/8V
nl
HP StorageWorks SAN Switch 2/16V
nl
HP StorageWorks SAN Switch 2/32
nl
HP StorageWorks SAN Director 2/128
nl
6.2.0b5.1.1b
HP StorageWorks 4/256 SAN Director
nl
HP StorageWorks 4/8 SAN Switch
nl
HP StorageWorks 4/16 SAN Switch
nl
HP StorageWorks 4/64 SAN Switch
nl
HP StorageWorks B-Series MP Router Blade (FR4-
18i)
nl
HP StorageWorks 16 Port 4-Gb Blade (FC4-16)
nl
HP StorageWorks 32 Port 4-Gb Blade (FC4-32)
nl
HP StorageWorks 400 MP Router
nl
HP StorageWorks 4/32 SAN Switch
6.2.0b5.3.1
Brocade 4-Gb SAN Switch for HP p-Class
BladeSystem
nl
Brocade 4-Gb SAN Switch for HP c-Class
BladeSystem
6.2.0b5.3.1HP StorageWorks 48 Port 4-Gb Blade (FC4-48)
6.2.0b5.3.1
HP StorageWorks B-Series iSCSI Director Blade
(FC4-16IP)
6.2.0b5.3.1HP StorageWorks 4/32B SAN Switch
XPath OS 7.4.1eXPath OS 7.4.1dHP StorageWorks MP Router
6.2.0b6.0.0bHP StorageWorks DC SAN Backbone Director
6.2.0b6.0.0b
HP StorageWorks SAN Director 16 Port 8-Gb FC
blade (FC8-16)
6.2.0b6.0.0b
HP StorageWorks SAN Director 32 Port 8-Gb FC
blade (FC8-32)
6.2.0b6.0.0b
HP StorageWorks SAN Director 48 Port 8-Gb FC
blade (FC8-48)
6.2.0b6.0.0b
HP StorageWorks SAN Director 6 Port 10-Gb ISL
blade (FC10-6)
5.55.2.0a
Fabric Manager1
10.1.010.0.2Data Center Fabric Manager
6.2.0b6.2.0bHP StorageWorks Encryption SAN Switch
6.2.0b6.2.0bHP DC Switch Encryption FC blade
1Using HP StorageWorks Fabric Manager (FM) 5.5 or earlier with Fabric OS 6.1.1 or later can result in problems with Zoning,
Performance monitoring, SYSLOG configuration, FICON wizards, IOD Delay, AAA replication, Port enable/disable and other
functions. Unless you are using Admin Domains, HP recommends that you upgrade to HP StorageWorks Data Center Fabric
Manager (DCFM) 10.3.x to use with Fabric OS 6.1.1 or later. If you are using Admin Domains, HP recommends that you
downgrade Fabric OS to 6.1.0h.
HP StorageWorks Fabric OS 6.2.0b release notes 13

4/256 SAN Director blade support
Fabric OS 6.2.0b is fully qualified and supports the Director blades listed in Table 2.
Table 2 4/256 SAN Director blade support matrix
Number of bladesDirector blade
Supported with any mix, and up to eight blades of each
type. No intermix restrictions. The 4/256 SAN Director
must run Fabric OS 6.0.0b or later to support the FC8-
16 port blade, and Fabric OS 6.1.0a or later to support
the FC8-32 and FC8-48 port blades.
FC4-16
FC4-32
FC4-48
FC8-16
FC8-32
FC8-48
FC10-6
Up to four blades of this typeFC4-16IP (iSCSI blade)
Up to two blades of this type. Up to eight FR4-18i blades
can be installed if they are used only for FC Fast Write
or FCIP without routing.
FR4-18i (FCIP/FC Router blade)
DC SAN Backbone and DC04 SAN Director blade support
Fabric OS 6.2.0b is fully qualified and supports the DC Director blades listed in Table 3.
Table 3 DC Director blade support matrix
Number of bladesDirector blade
Supported with Fabric OS 6.0.0b and later with any mix
and up to eight blades of each type on DC SAN Director
Backbone. No intermix restrictions. The DC04 SAN
Director requires Fabric OS 6.2.0a and later, and supports
up to 4 blades.
FC8-16
FC8-32
FC8-48
FC10-6
Not supported with the DC SAN Director Backbone, or
DC04 SAN Director
FC4-16IP (iSCSI blade)
Supported with Fabric OS 6.0.0b and later with a
maximum of four blades of this type on DC SAN Director
Backbone. Up to eight FR4-18i blades can be installed if
they are used only for FC Fast Write or FCIP without routing
in the DC SAN Director Backbone. The DC04 SAN Director
requires Fabric OS 6.2.0a and later, and supports up to
4 blades.
FR4-18i (FCIP/FC Router blade)
Supported with Fabric OS 6.2.0b and later with a maxim-
um of four blades of this type on DC SAN Director Back-
bone and DC04 SAN Director.
FS8–18 (HP DC Switch Encryption FC blade)
14

Power supply requirements for Director blades
Table 4 lists power supply requirements for Director blades to provide full redundancy (220 VAC
power is assumed).
IMPORTANT:
Director blades must meet minimum Fabric OS levels to operate in the Director chassis. For example,
the FC8-32 is not supported in the 4/256 SAN Director with Fabric OS 6.0.x.
Table 4 Power supplies required for blades in Director chassis
DC SAN Backbone Director and
DC04 SAN Director1
4/256 SAN DirectorDirector blade
Two power suppliesTwo power supplies
FC4-16
FC4-32
FC4-48
FC8-16
FC8-32
Two power suppliesFour power supplies
FC8-48
FC10-6
Two power supplies. The FC4-16IP
blades are not supported in the DC
SAN Backbone and DC04
Directors.
Four power supplies
FR4-18i (FCIP/FC Router blade)
FC4-16IP (iSCSI blade)
Two power supplies. Requires 220
VAC in the DC04 SAN director.
Not supported
FS8–18 (HP DC Switch Encryption
FC blade)
1The DC Director can operate with nominal power of 110 VAC. See the appropriate hardware reference guide for power
specifications.
Fibre Channel Routing scalability
For the latest FCR scalability support information, see the HP StorageWorks SAN design reference
guide, available at:
http://www.hp.com/go/sandesignguide
HP StorageWorks Fabric OS 6.2.0b release notes 15

Important notes
This section contains information that you should consider before you use this Fabric OS release.
DCFM compatibility
Fabric OS 6.2 is fully compatible with HP StorageWorks Data Center Fabric Manager (DCFM) 10.1.x
management software. DCFM is a comprehensive SAN management application that enables
end-to-end management of HP B-Series Data Center Fabrics. It is the next-generation product and the
successor to existing B-Series management products, including HP StorageWorks Fabric Manager
(FM) and Enterprise Fabric Connectivity Manager (EFCM).
DCFM is available in two versions: DCFM Professional, an application bundled with B-Series switches
that is ideally suited for small and medium size businesses that need a light weight management
product to manage their smaller fabrics (one physical fabric at a time, up to 1,000 ports); and DCFM
Enterprise, that is designed for enterprise-class customers and showcases unparalleled performance
and scalability (24 physical fabrics, up to 9,000 switch ports). DCFM Enterprise configures and
manages HP StorageWorks DC SAN Backbone Directors, along with other B-Series directors, routers,
and switches. and HBAs. Existing EFCM and FM customers that have active Maintenance and Support
contracts are provided a seamless migration path to DCFM Enterprise.
Fabric OS compatibility
Table 1 on page 12 lists the earliest versions of software supported in this release, that is, the earliest
supported software versions that interoperate. Brocade recommends using the latest software versions
to get the greatest benefit from the SAN.
When using the new Virtual Fabrics feature, it is HP recommends that all switches participating in a
fabric with a logical switch use the latest firmware available for those switches. All switches must be
operating at minimum firmware levels noted in the Fabric OS Interoperability table.
16

Fabric OS feature compatibility in native connectivity modes
Some Fabric OS features are not fully supported when operating in the native connectivity modes for
deployment with M-EOS-based products. All HP StorageWorks models that are supported by Fabric
OS 6.2.0b support both interopmodes 2 and 3, with the exception of the HP StorageWorks 4/32
SAN Switch.
NOTE:
HP may not support all of these switches in this mode. See “Merging Fabrics based on M-Series and
B-Series FC switches”application note available at http://www.hp.com for specific support in
interopmodes 2 and 3.
Table 5 specifies the support of various Fabric OS features when operating in either interopmode 2
(McDATA Fabric Mode) or interopmode 3 (Open Fabric Mode) with Fabric OS 6.2.0b.
Table 5 Feature support in interopmodes 2 and 3
Fabric OS 6.2.0xFabric OS Features (supported in interopmode 0)
IM 3IM 2IM = interopmode
YesYesL2 Fabric OS Hot Code Load
YesYesFabric OS Hot Code Load with FCR
Yes1
YesZone Activation Support
NoYes
Traffic Isolation Zones2
Yes1
Yes
Frame Redirection (devices attached to Fabric OS)2
Yes1
Yes
Frame Redirection (devices attached to M-EOS)2
Yes1
Yes
Frame Redirection over FCR3
YesYes
FCR Fabric Binding (route to M-EOS fabric with Fabric Binding)4
No5
YesL2 Fabric Binding
NoNoDCC policies
No5 Yes6
SCC policies
YesYesE/Ex_Port Authentication
Yes7 Yes7
ISL Trunking (frame level)
Yes8 Yes8
Dynamic Path Selection (DPS, exchange-based routing)
YesYesDynamic Load Sharing (DLS, port-based routing)
Yes7 Yes7
Virtual Channels (VC RDY)
HP StorageWorks Fabric OS 6.2.0b release notes 17

No5
YesFICON Management Server (Cascading)
No5
YesFICON MIHPTO
YesYesFull Scalability (to maximum M-EOS fabric limits)
NoNoAdaptive Networking QoS
No5 No5
Adaptive Networking: Ingress Rate Limiting
No5 No5
Advanced Performance Monitoring (APM)
No5 No5
APM: TopTalkers
NoNoAdmin Domains
N/AN/A
Secure Fabric OS9
YesYesFabric Watch
YesYesPorts on Demand (POD)
YesYesNPIV
NoNoTimer Server Function (NTP)
N/AN/A
Open E_Port10
NoNoBroadcast Zoning
NoNoFDMI
NoNoRemote Switch
YesYesPort Mirroring
Yes11
YesExtended Fabrics
NoNoAlias Server
NoNoPlatform Service
YesYesFCIP (VE_Ports)
Yes12 Yes12
IPFC (IP over FC)
YesYesM-EOS ALPA 0x13 configuration
YesYesVE to VEX Port
YesYes
Integrated Routing4
NoNoDomain Offset Support
Yes13
N/A239 Domain Support (available on Mi120k only)
YesYesMasterless F_Port Trunking (AG connect to Fabric OS switches only)
YesYesFC10-6-to-FC10-6 ISL
18

YesYesRASLog Events on duplicate WWNs
YesYesVirtual Fabrics
NoNoLogical Fabric using LISLs (XISLs in base Fabric)
1Only Frame Reduction zones can be configured on Fabric OS platforms and sent to fabrics operating in McDATA Open
Fabric Mode (interopmode 3). M-EOS 9.9 is required to support FR zones in McDATA Open Fabric Mode.
2Requires M-EOS 9.7 or later for redirection between devices attached to Fabric OS switches, M-EOS 9.8 for redirection
between devices attached to M-EOS switches, M-EOS 9.9 for use in McDATA Open Fabric Mode. Supported EOS platforms
include M4400, M4700, M6140, and Mi10K.
3To support Frame Reduction to an edge M-EOS fabric, there must be at least one Fabric OS switch in the edge fabric to
configure Frame Redirection Zones.
4All routers (EX_Ports) must reside in a backbone fabric running in interopmode 0 only. Only edge fabrics with devices imported
to the backbone fabric or other edge fabrics can be operating in IM2 or IM3.
5This feature is available, but not officially tested or supported.
6SCC policies supported only in conjunction with 1.2 Fabric Binding support.
7Allowed only between Fabric OS-based switches.
8DPS is supported outbound from Fabric OS-based switches. M-EOS can provide reciprocal load balancing using OpenTrunking.
9Not supported in Fabric OS 6.0 or later.
10Mode 3 qualified only with M-EOS switches
11Not on FCR.
12Supported only locally within the Fabric OS switch.
13Supported via FC Routing only. All routers in the backbone must be running Fabric OS 6.2.
NOTE:
FICON Cascaded CUP is qualified only on select platforms.
Firmware upgrades and downgrades
Upgrading to Fabric OS 6.2.0b is allowed only from Fabric OS 6.1.0a or later. The policy to support
only one-level migration, which began with Fabric OS 6.0.0, provides more reliable and robust
migrations for customers. By having fewer major changes in internal databases, configurations, and
subsystems, the system is able to perform the upgrade more efficiently, taking less time and ensuring
a truly seamless and non-disruptive process for the fabric. The one-release migration policy also
reduces the large number of upgrade-downgrade permutations that must be tested, allowing for the
thorough test and verification of supported migration paths.
The HP StorageWorks DC04 SAN Director Switch may not be downgraded from Fabric OS 6.2.0a.
All downgrades from Fabric OS 6.2.0a require a restart and are disruptive to traffic. Platforms
supporting Virtual Fabrics must have the feature disabled before downgrading to a version earlier
than 6.2.0a.
To ensure non-disruptive Hot Code Load (HCL), neighbor switches should be operating with Fabric
OS 6.2.0a or later prior to loading Fabric OS 6.2.0b on the following platforms:
•Brocade 4Gb SAN Switch for HP p-Class BladeSystem
•Brocade 4Gb SAN Switch for HP c-Class BladeSystem
•HP StorageWorks SAN Switch 4/32
•HP StorageWorks 4/8 and 4/16 SAN Switches
When upgrading to Fabric OS 6.2.0b from Fabric OS 6.1.0g or earlier, the CPs do not fully
synchronize until both the new active and new standby CPs are running Fabric OS 6.2.0b. This is
normal behavior and the firmware upgrade is still not disruptive.
HP StorageWorks Fabric OS 6.2.0b release notes 19

Fabric OS 6.2.0b does not support concurrent FC Routing (EX_Ports) and TopTalkers features Upgrading
to Fabric OS 6.2.0b requires that one of these features be disabled first.
Firmware upgrade instructions
IMPORTANT:
HP strongly recommends that users upgrade to Fabric OS 6.2.0b as soon as possible. Upgrading to
Fabric OS 6.2.0b is allowed only from Fabric OS 6.1.x. See “Update recommendations”on page
8 for additional guidelines.
NOTE:
With the introduction of Fabric OS 6.1.1, certain features and functions were removed from Web
Tools (resident in the firmware) and migrated to the Data Center Fabric Manager (DCFM) management
application. This has been carried forward to Fabric OS 6.2.x. HP recommends that before upgrading
to Fabric OS 6.2.x or later, if you are not running DCFM on your fabric, you review the “Web Tools
functionality Moved to DCFM”on page 25 and note what has changed in order to assess the impact
to your fabric.
To access the latest Fabric OS 6.2.0b firmware, configuration files, and MIB files, see the HP website:
http://www.hp.com/support/downloads
At the website:
1. User Storage, select Storage Networking.
2. Select the link for the appropriate switch, select your product, and then select Cross operating
system (BIOS, firmware, Diagnostics, etc.)
3. Select Firmware (HP StorageWorks Fabric OS release notes 13).
4. Select V6.x Firmware for HP StorageWorks B-Series Fibre Channel Switches for Fabric OS 6.2.0b:
•To download the firmware, select Download.
•To read the release notes, select the Release Notes tab.
Scalability
Refer to the HP SAN Design Guide, available on http://www.hp.com for specifics on supported
scalability.
FICON support
The HP StorageWorks DC04 SAN Director Switch is not supported for FICON Cascading in
interopmode 2 or 3 for use in mixed fabrics with M-EOS platforms.
NOTE:
For information about specific versions of Fabric OS support for FICON, see the B-series FICON
Connectivity Stream.
20
