HPC COPPER FIRE/WATER BOWL Series Installation instructions

COPPER FIRE/WATER
BOWL SERIES
Installation&OperationInstructions
Hearth Products Controls
Fire-inspired since 1975.
860-EION/OFF
C US
TEMP31-EING/120VAC
TEMP31W-EI-NG/120AC

2
This is a Safety Alert Symbol
Whenyouseethissymbolonthefirepitinsert,or inthismanual,
lookfor oneofthefollowingsignalwordpanelsalertingyouto
thepotentialforpersonalinjury,death,or majorproperty
damage.
WARNING: For Outdoor Use Only.
Installation and service must be performed by a qualified
installer, service agency, or the gas supplier.
WARNING
Do not store or use gasoline or other flammable vapors
and liquids in vicinity of this or any other appliance.
An LP-cylinder not connected for use shall not be stored
in the vicinity of this or any other appliance.
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
•Shut off gas to the appliance.
•Extinguish an open flame.
•If odor continues, leave the area immediately.
•After leaving the area, call your gas supplier or fire
department.
Failure to follow these instructions could result in fire or
explosion, which could cause property damage, personal
injury, or death.
DANGER
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide
which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed
space
such as a camper, tent, car, or home.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.

3
1 Important Safety Information
SELECT MODELS
Certified to
ANSI Z21.97-2014
CSA 2.41-2014
• HearthProductsControlsCompanyrecommendsthatourproductsareinstalled
byprofessionalslocallylicensedbytheauthorityhavingjurisdictioningaspiping.
Allinstallationinstructionsmustbefollowedtoensureproperperformanceand
safety.HearthProductsControlsCompanyassumesnoresponsibilityforproblems
relatingtotheinstallation.
• Toqualifyforwarranty,allinstructionsmustbestrictlyfollowed.Otherwise,
warrantymay bevoid.Neveralter productorconfigurationinanyway.
• Annualservicing shouldbe handled byprofessionalscertified inthe USby the
NationalFireplaceInstitute(NFI)asNFIGasSpecialistsorinCanadabyWETT
(Wood Energy Technical Training).
• Itistheinstaller’sresponsibilitytoensureasafeinstallationandtoeducatethe
end-userregardingthefeatures,safetyrecommendationsandproperoperation
of this product.
• Pleasereferencepage1forallwarnings.
Technical Support
ForinformationandsupportcontactyourHearthProductsControlsdealer.
INSTALLER:
Leavethismanualwith
the appliance.
ENDUSER:
Retainthismanualfor
future reference.

4
1 Important Safety Information
Symbol Legend
This is a Safety Alert Symbol
Whenyouseethissymbolonthe firepitinsert,orin this manual,lookfor one
ofthefollowingsignalwordpanelsalertingyoutothepotentialfor personal
injury,death,or majorpropertydamage.
Necessary instructions

1 Important Safety Information
5
Please reference page 1 for all warnings.
Important Safety Information for Installers
Leavethismanual withthe end-userand instruct themtoretainit forfuture
reference.Instructionsandproductupdates arealso availableatwww.hpcfire.com
under the Support tab.
Installersmustcarefullyfollowtheinstructionsinthismanualtopreventpersonal
injuryorpropertyloss.Theseinstructionscontaininformationcriticaltothesafe
installationandoperationofthefirepit.
• Instructionsareupdatedasneeded. Itis the responsibilityofthe installersto
check for product updates and installation manual updates at
www.hpcfire.com/ support.htmlpriortoinstallation.
• Itistheresponsibilityofthe installertofollow:
- TheNationalFuelGasCode,ANSIZ223.1/NFPA54orInternationalFuel GasCode.
- Natural Gas and Propane Installation Code CSA B149.1 or CSA B149.2.
- TheNationalElectricalCode,ANSI/NFPA70. In Canada, Canadian Electrical Code CSA22.1.
- Localcodes
• Controloptions:Useofwallswitch, optionalremotecontrol(#578-C), automatic
shut-offtimerorwhole housesystem.
Gas
• Onlyuse thegas/fueltype specifiedfor thisfirepit,refer to the labelon thefirepit
controlbox.Neveruseanalternativefueltoincludebiofuel,ethanol,lighterfluid,
or anyotherfuel.
• Gaspressureandtype shouldbechecked prior touseandinstallation.
- Natural Gas Fire Pit: Supply Pressure: Minimum: 3.5 inches W.C.; Maximum: 7.0 inches W.C.
- LP Gas: Supply Pressure: Minimum: 8.0 inches W.C.; Maximum: 11.0 inches W.C.
If pressure is low, this will reduce flame height on HIGH
setting, resulting in little to no flame variation.
• Ifnotusingsuppliedflexline,ensureany flexlinethatmaybeusedfrom the
permanent main fuel supply to the product is rated to the stated max BTU of the
productandcertified toANSI Z21.75*CSA 6.27.

6
1 Important Safety Information
ImportantSafetyInformationforEnd-Users
• Neverleaveanoperatingfirepitunattendedorwithsomeonenotfamiliarwith
itsoperationoremergencyshut-offlocations.
• Bothchildrenandadults shouldbe alerted tothe hazards ofhigh surface
temperaturesandshouldstayawaytoavoidburnsandclothingignition.
• Youngchildrenshouldbecarefullysupervisedwhentheyarein firepit.
• Keeptheapplianceareaclearandfreefromcombustiblematerials,gasoline,
andotherflammablevaporsandliquids.
NOTE: All fire pits and systems are designed and intended for outdoor use only.
It is recommended that material such as granite, marble
or other dense stone be kept away from heat and
especially flame due to risk of cracking. HPC is not
responsible for damage resulting from failure to follow
these recommendations.
• Selectalocationthat
- ensuresabove-gradeinstallationofthefirepit.
- offersgooddrainage.
- allowseasyaccessforinstallationandmaintenanceofthefirepit.
- providessufficienthorizontalroomtoenjoythefirepitwhileallowingasafe
distancefromtheheatandflame.
Deck installation —If installing fire pit on a wood
or composite deck, it is required to use the Deck
Insulation Kit(s) and locally bought paver stones.
Kit includes basalt material and instructions.
#FPI-DECK39SQ; #FPI-DECK20SQ. Also refer to
drawing- Deck Insulation Kit- Install.
• Firepitscreateextremely elevated temperatures.Forclearancesreferto
table3.1. Clothingorotherflammablematerialsshould notbeplacedonor
nearfirepit.
ClearancesaroundFirePit
Fire Pit Clearances
Up to 200k BTU
UnderValveBoxwhenapplicablefordrainage
2"
Sidessurroundingfirepitfromstructureorcombustibles
36" (12" for
non-combustibles)
Overheadclearanceaboveproduct
84"
Table3.1–FirePitClearances

7
2 Copper Bowl Install
Mounting Options
Match Lit
Electronic Ignition
Available with or
without water scupper
Ventilation blocks
installed under Copper
Bowl
Fuel supply
fixed piping
only
Fuel supply
fixed piping
only
Water inlet
when applicable
Access
Door
Fuel supply
fixed piping
only
Ventilation blocks
installed under Copper
Bowl
Minimum of 18
sq.in. vents on
opposing sides
Available with or
without water scupper
Access
Door
Fuel supply
fixed piping
only
Water inlet
when applicable

8
2 Bowl/Container Install
1. Follow all electronic ignition and/or match lit instructions carefully (Included and available at hpcfire.com)
2. Proper venting is required as illustrated above
a. Vent blocks must be installed on all Copper Bowls
i. Utilize the provided vent blocks
b. Additional venting is requited if there is a cavity under the Copper bowls
3. If using a manual key valve, this is NOT a replacement for the safety shut off valve
4. Manual key valves are NOT to be used to control flame height. Manual key valves should be fully on or fully
off
Warranty will be voided if there is no proper ventilation
5. Hook up water if applicable
a. Water flow is estimated to be 700~900 GPH
b. It is recommended to put a valve after the pump to trim water flow if desired
c. Consult your pool or pond professional for line and pump sizing
6. Leak test all gas and/or water fittings
7. If using an electronic ignition system, it must be kept dry
8. Access panel is included on applicable models
9. On product with CSA certified fire pits install the startup shut down instructions near the valve or switch
which is used to start the fire pit
a. CSA certified match lit models will have startup shut down labels on the inside of the access door on
applicable models.
WARNING: Follow all attached electronic ignition and/or match lit instructions
carefully. If you do not have the additional instructions, contact your dealer or
salesperson.

9
