HPE FlexNetwork MSR Series User manual

HPE FlexNetwork MSR Router Series
Interface Module Guide
P
art number: 5200-2346
Document version: 6W108-20161111

i
© Copyright 2016 Hewlett Packard Enterprise Development LP
The information contained herein is subject to change without notice. The only warranties for Hewlett Packard
Enterprise products and services are set forth in the express warranty statements accompanying such
products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett
Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
Confidential computer software. Valid license from Hewlett Packard Enterprise required for possession, use, or
copying. Consistent with FAR 12.211 and 12.212, Commercial Computer Software, Computer Software
Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government under vendor’s
standard commercial license.
Links to third-party websites take you outside the Hewlett Packard Enterprise website. Hewlett Packard
Enterprise has no control over and is not responsible for information outside the Hewlett Packard Enterprise
website.
Acknowledgments
Intel®, Itanium®, Pentium®, Intel Inside®, and the Intel Inside logo are trademarks of Intel Corporation in the
United States and other countries.
Microsoft® and Windows® are trademarks of the Microsoft group of companies.
Adobe® andAcrobat® are trademarks ofAdobe Systems Incorporated.
Java and Oracle are registered trademarks of Oracle and/or its affiliates.
UNIX® is a registered trademark of The Open Group.

ii
Contents
SIC/DSIC ·······················································································1
Ethernet switching module···········································································································1
SIC-4FSW/SIC-4FSW-PoE/DSIC-9FSW/DSIC-9FSW-PoE ··························································1
SIC-4GSW/SIC-4GSW-POE··································································································2
SIC-4GSWF·······················································································································3
Ethernet interface module············································································································4
SIC-1FEA··························································································································5
SIC-1FEF ··························································································································5
SIC-1GEC-V2/SIC-1GEC-H3·································································································6
E1/T1 interface module ···············································································································7
SIC-1E1-F ·························································································································8
SIC-2E1-F ·························································································································9
SIC-EPRI/SIC-1EPRI ·········································································································10
SIC-1T1-F························································································································ 11
Serial interface module··············································································································12
SIC-8AS·························································································································· 12
SIC-16AS ························································································································ 13
SIC-1SAE/SIC-2SAE/SIC-4SAE···························································································14
XDSL interface module ·············································································································16
DSIC-1SHDSL-8W ············································································································16
SIC-1ADSL······················································································································ 17
SIC-1ADSL-I ···················································································································· 18
ISDN BRI interface module ········································································································19
SIC-1BS·························································································································· 20
Voice interface module··············································································································21
SIC-1FXS/SIC-1FXO/SIC-2FXS/SIC-2FXO·············································································21
SIC-2FXS1FXO ················································································································ 22
DSIC-4FXS1FXO·············································································································· 23
SIC-1BSV/SIC-2BSV ·········································································································24
SIC-1VE1 ························································································································ 26
SIC-1VT1 ························································································································ 27
SIC-1VE1T1·····················································································································28
WLAN interface module·············································································································29
SIC-WLAN-b/g/n/SIC-WLAN-b/g/n(NA)··················································································30
3G interface module ················································································································· 30
SIC-3G-GSM····················································································································31
SIC-3G-HSPA ·················································································································· 32
SIC-3G-HSPA+················································································································· 33
4G interface module ················································································································· 35
SIC-4G-LTE-V (JG742A) ····································································································35
SIC-4G-LTE-V (JG742B) ····································································································37
SIC-4G-LTE-A (JG743A) ····································································································38
SIC-4G-LTE-A (JG743B) ····································································································40
SIC-4G-LTE-G (JG744A) ····································································································42
SIC-4G-LTE-G (JG744B) ····································································································44
MIM/DMIM/XMIM ···········································································47
Ethernet switching module·········································································································47
XMIM-16FSW/XMIM-24FSW ·······························································································47
MIM-16FSW/MIM-16FSW-PoE/DMIM-24FSW/DMIM-24FSW-PoE ··············································48
Ethernet interface module··········································································································50
MIM-2FE/MIM-4FE············································································································ 50
MIM-2GBE·······················································································································51
ATM interface module···············································································································52
MIM-1ATM-OC3················································································································ 52
MIM-IMA-8E1··················································································································· 53
MIM-IMA-4T1 ···················································································································54

iii
POS (SDH/SONET) interface module···························································································55
MIM-1POS·······················································································································55
E1/T1 interface module ············································································································· 56
MIM-2E1/MIM-4E1/MIM-4E1-F modules·················································································56
MIM-8E1/MIM-8E1-F··········································································································58
MIM-2T1/MIM-4T1-F··········································································································59
MIM-8T1/MIM-8T1-F··········································································································61
E3/T3 interface module ············································································································· 62
MIM-1CE3 ·······················································································································62
MIM-1CT3 ······················································································································· 63
xDSL interface module··············································································································64
MIM-1SHL-4W··················································································································64
Serial interface module··············································································································65
MIM-2SAE/MIM-4SAE/MIM-8SAE························································································· 66
MIM-8ASE/MIM-16ASE ······································································································67
Voice interface module··············································································································68
MIM-16FXS······················································································································ 69
MIM-4BSV······················································································································· 70
MIM-2FXO and MIM-4FXS/MIM-4FXO··················································································· 71
MIM-4E&M·······················································································································72
MIM-1VE1 ·······················································································································73
MIM-1VT1························································································································ 74
MIM-2VE1 ·······················································································································75
MIM-2VT1························································································································ 76
HMIM ··························································································78
Ethernet interface switching module·····························································································78
HMIM-8GSW/HMIM-24GSW/HMIM-24GSW-PoE·····································································78
HMIM-8GSWF··················································································································79
Ethernet interface module··········································································································80
HMIM-2GEE/HMIM-4GEE/HMIM-8GEE························································································80
HMIM-2GEF/HMIM-4GEF/HMIM-8GEF··················································································81
POS (SDH/SONET) interface module···························································································82
HMIM-1POS·····················································································································82
CPOS (SDH/SONET) interface module ························································································83
HMIM-1CPOS ·················································································································· 83
E1/T1 interface module ············································································································· 84
HMIM-2E1/HMIM-4E1/HMIM-4E1-F ······················································································85
HMIM-8E1 ······················································································································· 86
HMIM-2T1/HMIM-4T1-F······································································································ 87
HMIM-8E1T1/HMIM-8E1T1-F ······························································································88
E3/T3 interface module ············································································································· 91
HMIM-1CE3····················································································································· 91
HMIM-1CT3 ····················································································································· 92
HMIM-1E3T3····················································································································93
Serial interface module··············································································································94
HMIM-4SAE/HMIM-8SAE ··································································································· 94
HMIM-16ASE ··················································································································· 96
Voice interface module··············································································································97
HMIM-16FXS ···················································································································97
HMIM-2VE1 ····················································································································· 98
HMIM-2VT1 ····················································································································· 99
HMIM-1VE1 ··················································································································· 100
HMIM-1VT1 ··················································································································· 101
HMIM-4FXS/HMIM-4FXO ································································································· 102
HMIM-4E&M ·················································································································· 103
FIC/DFIC···················································································· 104
Ethernet switching module······································································································· 104
FIC-16FSW/FIC-16FSW-PoE/DFIC-24FSW/DFIC-24FSW-PoE ················································ 104
Ethernet interface module········································································································ 106

iv
FIC-2FE/FIC-4FE············································································································ 106
FIC-1GBE/FIC-2GBE······································································································· 107
FIC-1GEF/FIC-2GEF ······································································································· 108
ATM interface module············································································································· 109
FIC-IMA-4E1/FIC-IMA-8E1································································································ 110
FIC-IMA-8T1 ·················································································································· 111
FIC-1AE3 ······················································································································ 112
FIC-1AT3······················································································································· 113
FIC-1ATM-OC3··············································································································· 114
POS (SDH/SONET) interface module························································································· 115
FIC-1POS······················································································································ 115
CPOS (SDH/SONET) interface module ······················································································ 116
FIC-1CPOS···················································································································· 116
E1/T1 interface module ··········································································································· 117
FIC-2E1/FIC-4E1 and FIC-4E1-F························································································ 117
FIC-8E1 ························································································································ 119
FIC-4T1-F······················································································································ 120
E3/T3 interface module ··········································································································· 121
FIC-1CE3 ······················································································································ 121
FIC-1CT3 ······················································································································ 122
ISDN BRI interface module ······································································································ 124
FIC-4BSE······················································································································ 124
Serial interface module············································································································ 126
FIC-4SAE/FIC-8SAE········································································································ 126
FIC-8ASE/FIC-16ASE······································································································ 128
Voice interface module············································································································ 129
FIC-4FXS/FIC-4FXO········································································································ 130
FIC-4E&M······················································································································ 131
FIC-24FXS····················································································································· 132
FIC-2VE1 ······················································································································ 132
FIC-2VT1······················································································································· 133
FIC-1VE1 ······················································································································ 135
FIC-1VT1······················································································································· 136
ESM/VCPM/VPM········································································· 138
ESMs ·································································································································· 138
ESM-ANDE···················································································································· 138
ESM-SNDE···················································································································· 139
VCPM/VPM ·························································································································· 139
VCPM/VPM purchase guide ······························································································ 139
VCPM··························································································································· 140
VPM····························································································································· 141
Cables and connection methods······················································ 142
Ethernet interface··················································································································· 142
Fiber port ····························································································································· 144
E1 interface ·························································································································· 149
T1 interface ·························································································································· 156
E3/T3 interface······················································································································ 158
Synchronous/asynchronous serial ports······················································································ 159
Asynchronous serial ports········································································································ 160
ADSL/BS/FXS/FXO/AM/FCM interface······················································································· 165
E&M interface ······················································································································· 166
24FXS interface····················································································································· 167
BSV/BSE interface················································································································· 168
G.SHDSL interface················································································································· 171
WLAN interface ····················································································································· 173
3G interface·························································································································· 173
4G interface·························································································································· 175

v
Appendix A Interface module list ····················································· 177
Appendix B Purchase guide ··························································· 182
SIC/DSIC purchase guide········································································································ 182
MIM/XMIM/DMIM purchase guide······························································································ 187
HMIM purchase guide············································································································· 189
FIC/DFIC purchase guide ········································································································ 190
ESM/VPM/VCPM purchase guide······························································································ 192
Index························································································· 193

1
SIC/DSIC
MSR series routers use modular design and support a wide range of SICs and DSICs. A SIC
occupies one SIC slot and a DSIC occupies two SIC slots. The SIC/DSIC series interface modules
provide interfaces such as synchronous/asynchronous serial interface, Ethernet interface, E1/T1,
ISDN BRI/PRI, ADSL, audio interface, and Layer 2 switching interface.
Among this series interface modules, the Layer 2 switching interface modules (SIC-4FSW and
DSIC-9FSW) each have a corresponding PoE-capable module. The module can provide -48 VDC
power to remote powered devices (PDs, such as IP phone, WLAN AP, network camera) through
straight-through cables if it is installed in a PoE router.
Ethernet switching module
•SIC-4FSW
•SIC-4FSW-PoE
•DSIC-9FSW
•DSIC-9FSW-PoE
•SIC-4GSW
•SIC-4GSW-PoE
•SIC-4GSWF
SIC-4FSW/SIC-4FSW-PoE/DSIC-9FSW/DSIC-9FSW-PoE
Introduction
The 4/9-port 10/100 Mbps Ethernet Layer 2 interface modules SIC-4FSW/SIC-4FSW-PoE and
DSIC-9FSW/DSIC-9FSW-PoE can provide up to 4/9 10/100 Base-Tx Ethernet ports for Layer 2 and
Layer 3 switching. A router installed with SIC-4FSW/DSIC-9FSW modules can work as a
switching/routing integrated device on a small-sized enterprise network to connect PCs and network
devices inside the network. The SIC-4FSW-PoE/DSIC-9FSW-PoE interface modules can supply
power to powered devices (PDs) through power over Ethernet (PoE).
Interface specifications
Table 1 Interface specifications
Item
Specification
SIC-4FSW/SIC-4FSW-PoE
DSIC-9FSW/DSIC-9FSW-PoE
Connector RJ-45
Interface type MDI/MDIX
Number of
connectors Four 100 Mbps RJ-45 connectors Nine 100 Mbps RJ-45 connectors
Transmission
distance 100 m (328.08 ft) over category-5 twisted pair cables (both crossover and straight-through)
Operating mode 10/100 Mbps autosensing, full/half duplex

2
Interface LEDs
Figure 1 SIC-4FSW panel
Figure 2 SIC-4FSW-PoE panel
Figure 3 DSIC-9FSW panel
Figure 4 DSIC-9FSW-PoE panel
Table 2 LED description
LED
Description
Steady green A link is present.
Off No link is present.
Flashing green Data is being transmitted and received (ACT).
In addition, the SIC-4FSW-POE and DSIC-9FSW-POE each provide a PoE LED.
Table 3 LED description
LED
Description
Steady green The module is supplying power to PDs.
Flashing green at
8 Hz An alarm has occurred on the ports that connects to the PDs.
Off The module is not supplying power to any PDs.
Interface cables and connection methods
For more information about the Ethernet interface cables and connection methods, see "Ethernet
interface."
SIC-4GSW/SIC-4GSW-POE
Introduction
The 4-port 1000 Mbps Ethernet Layer 2 SIC interface module SIC-4GSW/SIC-4GSW-POE provides
four 1000 Mbps RJ-45 connectors. It is designed for switching/routing integrated routers on a

3
small-sized enterprise network. You can use it to connect PCs and network devices inside the
network. The SIC-4GW-PoE interface module can supply power to PDs through PoE.
Interface specifications
Table 4 Interface specifications
Item Specification
Connector RJ-45
Interface type MDI/MDIX
Number of connectors 4
Transmission distance 100 m (328.08 ft) over category-5 twisted pair cables (both
crossover and straight-through)
Operating mode 10/100/1000 Mbps autosensing, full/half duplex
Interface LEDs
Figure 5 SIC-4GSW
Figure 6 SIC-4GSW-PoE
Table 5 LED description
LED
Description
Off No link is present.
Steady green A 1000 Mbps link is present.
Flashing green The interface is sending or receiving data at 1000 Mbps.
Steady yellow A 10/100 Mbps link is present.
Flashing yellow The interface is sending or receiving data at 10/100 Mbps.
Interface cables and connection methods
For more information about the Ethernet interface cables and connection methods, see "Ethernet
interface."
SIC-4GSWF
Introduction
The 4-port 100/1000 Mbps Ethernet Layer 2/Layer 3 SIC interface module SIC-4GSWF provides
four fiber ports. It is designed for switching/routing integrated routers on a small-sized enterprise
network. You can use it to connect network devices inside the network.
The interface module has the following features:

4
•Support for multiple types of 100/1000 Mbps transceiver modules.
•1000/100 Mbps interface rate.
•Full duplex operating mode.
Interface specifications
Table 6 Interface specifications
Item
Description
Number of interfaces 4
Connector SFP/LC
Standard 802.3/802.3u/802.3ab
Operating mode 1000/100 Mbps, full duplex
Interface LEDs
Figure 7 SIC-4GSWF panel
The SIC-4GSWF interface module provides a double-color (green/yellow) LED for each port to
indicate the operating status of the port.
Table 7 LED description
LED
Description
Off No link is present.
Steady green A link is present on the port and the port is operating at 1000 Mbps.
Flashing green The port is sending and receiving data at 1000 Mbps.
Steady yellow A link is present on the port and the port is operating at 100 Mbps.
Flashing yellow The port is sending and receiving data at 100 Mbps.
Transceiver modules, optical fibers, and connection methods
For more information about transceiver modules, optical fibers, and connection methods, see "Fiber
port."
Ethernet interface module
•SIC-1FEA
•SIC-1FEF
•SIC-1GEC-V2
•SIC-1GEC-H3

5
SIC-1FEA
Introduction
The 1-port 10Base-T/100Base-TX Ethernet interface module (SIC-1FEA) implements
communication between Routers and LANs.
Interface specifications
Table 8 Interface specifications
Item
Specification
Connector RJ-45
Interface type MDI
Number of connectors 1
Transmission distance 100 m (328.08 ft) over category-5 twisted pair cables (both
crossover and straight-through)
Operating mode 10/100 Mbps autosensing, full duplex/half duplex
Interface LEDs
Figure 8 SIC-1FEA panel
Table 9 LED description
LED
Description
LINK •Off means no link is present;
•On means a link is present.
ACT •Off means no data is being transmitted or received;
•Flashing means data is being received or/and transmitted.
Interface cables and connection methods
For more information about the Ethernet interface cables and connection methods, see "Ethernet
interface."
SIC-1FEF
Introduction
The 1-port 100 Mbps fiber Ethernet interface module (SIC-1FEF) implements communication
between the router and LAN.
Interface specifications
Table 10 Interface specifications
Item
Specification
Number of
connectors 1

6
Item
Specification
Connector SFP/LC
Interface standard 802.3, 802.3u, and 802.3ab
Operating mode 100 Mbps, full duplex
Interface LEDs
Figure 9 SIC-1FEF panel
Table 11 LED description
LED
Status
Description
LINK/ACT
Off No link is present.
Steady green A link is present.
Flashing green Data is being received and transmitted at 100 Mbps.
Steady yellow Information detection failed.
Fiber ports, optical fibers, and the connection methods
For more information about fiber ports, optical fibers, and the connection methods, see "Fiber port."
SIC-1GEC-V2/SIC-1GEC-H3
Introduction
The 1-port 10/100/1000 Mbps copper and fiber Ethernet interface module
SIC-1GEC-V2/SIC-1GEC-H3 provides the following features:
•Receipt, transmission and processing of GE data stream.
•CE copper and fiber interface access.
•1000/100/10 Mbps on the copper interface.
•1000 Mbps on the fiber interface.
Interface specifications
Table 12 Interface specifications
Item
Specification
Connector RJ-45
Interface type MDI
Frame format
•Ethernet_II
•Ethernet_SNAP
•IEEE 802.2
•IEEE 802.3
Operating mode 10/100/1000 Mbps autosensing, full/half duplex

7
NOTE:
The
SIC-1GEC-V2/SIC-1GEC-H3 provides an interface that combines a fiber port and a copper
port.
Only one port of the combo interface can be activated
at a time. The copper port is activated by
default. To use the fiber port, execute the related command at the command line interface (CLI).
Interface LEDs
Figure 10 SIC-1GEC-H3 panel
Figure 11 SIC-1GEC-V2 panel
Table 13 LED description for the SIC-1GEC-V2/SIC-1GEC-H3
LED
Description
LINK
•On means carrier signal is received.
•Off means no carrier signal is received.
•Green: Data is being received and transmitted at a speed of 1000 Mbps.
•Yellow: Data is being received and transmitted at a speed of 100/10 Mbps.
ACT •Off: No data is being received and transmitted.
•Flashing: Data is being received and transmitted.
Table 14 LED description for the SIC-1GEC-V2/SIC-1GEC-H3
LED
Description
LINK
•On means carrier signal is received.
•Off means no carrier signal is received.
•Green: Data is being received and transmitted at a speed of 1000 Mbps.
•Yellow: The module is faulty.
ACT •Off: No data is being received and transmitted.
•Flashing: Data is being received and transmitted.
Interface cables and connection methods
For more information about the Ethernet interface cables and connection methods, see "Ethernet
interface."
For more information about fiber ports, optical fibers, and the connection methods, see "Fiber port."
E1/T1 interface module
•SIC-1E1-F
•SIC-2E1-F
•SIC-EPRI

8
•SIC-1EPRI
•SIC-1T1-F
SIC-1E1-F
Introduction
The 1-port fractional E1 interface module (SIC-1E1-F) provides the following features:
•Transmission, receiving, and handling of E1 data streams
•CE1 (channelized E1) access
•Remote loopback and local loopback functions, facilitating fault test and location
The FE1 operating mode supported by the SIC-1E1-F module allows only one bundle. The time slots
can only be bundled into one n ×64 kbps channel, where n is in the range of 1 to 31.
The SIC-1E1-F does not support the PRI mode.
Interface specifications
Table 15 Interface specifications
Item
Specification
Connector type D15
Number of connectors 1
Interface standard G.703, G.704
Interface rate 2.048 Mbps
Cable type 75-ohm unbalanced coaxial cable (D15 to BNC)
Operating modesE1
CE1
Supported servicesBackup
Terminal access
Interface LEDs
Figure 12 SIC-1E1-F panel
Table 16 LED description
LED
Description
LINK/ACT
•On means carrier signal has been received.
•Flashing means data is being transmitted or received.
•Off means no carrier signal has been received.
LP/AL
•On means the interface is in a loopback.
•Flashing means an AIS, LFA, or RAI alarm signal is present.
•Off means neither loopback nor alarm is present.
Note:
AIS = Alarm indication signal; LFA = loss of frame alignment; RAI = Remote alarm indication

9
Interface cables and connection methods
For more information about E1 interface cables, see "E1 interface."
SIC-2E1-F
Introduction
The 2-port fractional E1 interface module (fractional) provides the following features:
•Transmission/Receiving and handling of E1 data streams
•CE1 (channelized E1) access
•Remote loopback and local loopback functions, facilitating fault test and location.
The FE1 operating mode supported by the SIC-2E1-F module allows only one bundle. The time slots
can only be bundled into one n ×64 kbps channel, where n is in the range of 1 to 31.
The SIC-2E1-F does not support the PRI mode.
Interface specifications
Table 17 Interface specifications
Item
Specification
Connector type D15
Number of connectors 1
Interface standard G.703, G.704
Interface rate 2.048 Mbps
Cable type 75-ohm unbalanced coaxial cable (D15 to BNC)
Operating modesE1
CE1
Supported servicesBackup
Terminal access
Interface LEDs
Figure 13 SIC-2E1-F panel
Table 18 LED description
LED
Description
LINK/ACT
•On means carrier signal has been received.
•Flashing means data is being transmitted or received.
•Off means no carrier signal has been received.
LP/AL
•On means the interface is in a loopback.
•Flashing means an AIS, LFA, or RAI alarm signal is present.
•Off means neither loopback nor alarm is present.

10
LED
Description
Note:
AIS = Alarm indication signal; LFA = loss of frame alignment; RAI = Remote alarm indication
Interface cables and connection methods
For more information about E1 interface cables, see "E1 interface."
SIC-EPRI/SIC-1EPRI
Introduction
The 1-port E1/CE1/PRI SIC interface module (SIC-EPRI/SIC-1EPRI) provides the following
features:
•Transmission/Receiving and handling of E1 data streams.
•CE1 (channelized E1) access.
•ISDN PRI.
•Remote loopback and local loopback functions, facilitating fault test and location.
Interface specifications
Table 19 Interface specifications
Item
Specification
Connector type D15
Number of connectors 1
Interface standard G.703, G.704
Interface rate 2.048 Mbps
Cable type
75-ohm unbalanced coaxial cable (D15 to BNC)
Coaxial connector, network interface connector, and 75-to-120-ohm
adaptor (with BNC connector)
Operating modes
E1
CE1
ISDN PRI
Supported services
Backup
Terminal access
ISDN
Interface LEDs
Figure 14 SIC-EPRI/SIC-1EPRI panel

11
Table 20 LED description
LED
Description
LINK/ACT
•On means carrier signal has been received.
•Flashing means data is being transmitted or received.
•Off means no carrier signal has been received.
LP/AL
•On means the interface is in a loopback.
•Flashing means an AIS, LFA, or RAI alarm signal is present.
•Off means neither loopback nor alarm is present.
Note:
AIS = Alarm indication signal; LFA = loss of frame alignment; RAI = Remote alarm indication
Interface cables and connection methods
A 70-to-120-ohm adaptor is required to connect a 120-ohm cable to the 75-ohm SIC-1EPRI. For
more information about E1 interface cables, see "E1 interface."
SIC-1T1-F
Introduction
1-port Fractional T1 interface module provides the following features:
•Transmission/Receiving and handling of T1 data streams.
•Remote loopback and local loopback, facilitating the effective and flexible debugging.
The FT1 operating mode supported by the SIC-1T1-F module allows only one bundle. The time slots
can only be bundled into one n ×56 kbps channel, where n is in the range of 1 to 24.
The SIC-1T1-F does not support the PRI mode.
Interface specifications
Table 21 Interface specifications
Item
Specification
Connector type RJ-45
Number of connectors 1
Interface standard
•G.703/T1.102
•G.704
•AT&T TR 54016
•AT&T TR 62411
•ANSI T1.403
Interface rate 1.544 Mbps
Cable type T1 cable (100-ohm standard shielded network cable)
Operating mode FT1
Supported service
•Backup
•Terminal access

12
Interface LEDs
Figure 15 SIC-1T1-F panel
Table 22 LED description
LED
Description
LINK/ACT
•On means the carrier signal has been received.
•Off means no carrier signal has been received.
•Flashing means data is being transmitted or/and received.
LP/AL
•On means the interface is in a loopback.
•Flashing means an AIS, LFA, or RAI alarm signal is present.
•Off means no loopback or alarm is present.
Note:
AIS = Alarm indication signal; LFA = loss of frame alignment; RAI = Remote alarm indication
Interface cables and connection methods
For more information about T1 Interface cables and connection methods, see "T1 interface."
Serial interface module
•SIC-8AS
•SIC-16AS
•SIC-1SAE
•SIC-2SAE
•SIC-4SAE
SIC-8AS
Introduction
The 8-port asynchronous serial interface module (SIC-8AS) transmits and processes asynchronous
data streams.
The SIC-8AS provides the following features:
•Each asynchronous serial port provides a rate up to 115.2 Kbps.
•Supports the terminal access service and asynchronous dedicated line.
•Acts as the small-/medium-sized ISP dial-up access server when an asynchronous serial port is
used for dial-up.
Interface specifications
Table 23 Interface specifications
Item
Specification
Connector DB60
Number of connectors 1

13
Item
Specification
Interface cable Customized cable with 8-port RJ-45 connector
Interface standard RS232
Minimum baud rate 300 bps
Maximum baud rate 115.2 Kbps
Supported services
•Modem dial-up
•Backup
•Terminal access service
•Asynchronous dedicated line
Interface LEDs
Figure 16 SIC-8AS front panel
Table 24 LED description
LED
Description
LINK/ACT
•Off means no link is present;
•On means a link is present.
•Flashing means data is being received or/and transmitted.
Interface cables and connection methods
For more information about asynchronous serial port cables, see "Asynchronous serial ports."
SIC-16AS
Introduction
The 16-port asynchronous serial interface module (SIC-16AS) transmits and processes
asynchronous data streams.
SIC-16AS provides the following features:
•Each asynchronous serial port provides a rate of up to 115.2 Kbps.
•Supports the terminal access service and asynchronous dedicated line.
•Acts as the small-/medium-sized ISP dial-up access server when an asynchronous serial port is
used for dial-up.
Interface specifications
Table 25 Interface specifications
Item
Specification
Connector D28 (male)
Number of connectors 1
Interface cable Customized cable with 16-port RJ-45 connector (female)

14
Item
Specification
Interface standard RS232
Minimum baud rate 300 bps
Maximum baud rate 115.2 Kbps
Supported services
•Modem dial-up
•Backup
•Terminal access service
•Asynchronous dedicated line
Interface LEDs
Figure 17 SIC-16AS panel
Table 26 LED description
LED
Description
LINK/ACT
•Off means no link is present;
•On means a link is present.
•Flashing means data is being received or/and transmitted.
Interface cables and connection methods
For more information about asynchronous serial port cables, see "Asynchronous serial ports."
SIC-1SAE/SIC-2SAE/SIC-4SAE
Introduction
The 1-port/2-port/4-port enhanced high-speed synchronous/asynchronous serial interface module
(SIC-1SAE/SIC-2SAE/SIC-4SAE) provides features similar to SA, but its serial interfaces support
additional protocols, such as RS449, X.21, and RS530.
Interface specifications
Table 27 Interface specifications
Item
Specification
Synchronous
Asynchronous
Connector D28
Number of connectors
•1 (SIC-1SAE)
•2 (SIC-2SAE)
•4 (SIC-4SAE)
Interface standard and
operating mode V.24 V.35, RS449, X.21,
RS530 RS232
DTE, DCE DTE, DCE
Minimum baud rate
(bps) 1200 1200 300
