HPE ProLiant DL320 Gen11 User manual

HPE ProLiant DL320 Gen11 Server User GuideHPE ProLiant DL320 Gen11 Server User Guide
Part Number: 30-676781BE-003
Published: July 2023
Edition: 3

HPE ProLiant DL320 Gen11 ServerHPE ProLiant DL320 Gen11 Server User Guide User Guide
AbstractAbstract
This document is for the person who installs, administers, and troubleshoots servers and storage systems. Hewlett Packard Enterprise
assumes you are qualified in the servicing of computer equipment and trained in recognizing hazards in products with hazardous energy
levels, and are familiar with the weight and stability precautions for rack installations.
Part Number: 30-676781BE-003
Published: July 2023
Edition: 3
© Copyright 2023 Hewlett Packard Enterprise Development LP
NoticesNotices
The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and
services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as
constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained
herein.
Confidential computer software. Valid license from Hewlett Packard Enterprise required for possession, use, or copying. Consistent with FAR
12.211 and 12.212, Commercial Computer Software, Computer Software Documentation, and Technical Data for Commercial Items are
licensed to the U.S. Government under vendor's standard commercial license.
Links to third-party websites take you outside the Hewlett Packard Enterprise website. Hewlett Packard Enterprise has no control over and is
not responsible for information outside the Hewlett Packard Enterprise website.
AcknowledgmentsAcknowledgments
Intel®, Xeon®, and Intel® Virtual RAID on CPU (Intel® VROC) are trademarks of Intel Corporation or its subsidiaries.
Microsoft®, Windows®, and Windows Server® are either registered trademarks or trademarks of Microsoft Corporation in the United States
and/or other countries.
NVIDIA® and NVIDIA logos are trademarks and/or registered trademarks of NVIDIA Corporation in the U.S. and other countries.
Linux® is the registered trademark of Linus Torvalds in the U.S. and other countries.
VMware® is a registered trademark of VMware, Inc in the United States and other jurisdictions.
All third-party marks are property of their respective owners.
Revision historyRevision history
Part numberPart number Publication datePublication date EditionEdition Summary of changesSummary of changes

30-676781BE-003 July 2023 3 In the Front panel components, added GPU dense configurations.
In the Riser board components , added GPU riser.
In the Fan and heatsink requirements, added GPU dense
configurations.
Updated the following hardware operation topics for GPU dense
configuration:
Remove the middle cover
Remove the riser cage
Install the riser cage
Install the middle cover
Remove the fan wall
Install the fan wall
System board components
Front I/O cabling
Updated the Drive power cabling topic.
Added the following topics:
GPU riser slot numbering
EDSFF SSD LED definitions
E3.S drive bay numbering
Installing an E3.S drive
Installing the 4 SFF drive cage
Installing the E3.S drive cage
Installing an accelerator in the GPU riser cage
4 SFF drive controller cabling
4 E3.S drive controller cabling
8 E3.S drive controller cabling
GPU riser cabling
HPE 1600 W Flex Slot -48 VDC Hot-plug Power Supply
30-676781BE-002 April 2023 2 In the Installing a processor heatsink assembly topic, added
support for Intel® MCC processors.
In the Fan options topic, added a table for standard fan
configuration.
Added the following topics:
Fan and heatsink requirements
Accelerator options
Installing an accelerator in the rear riser cage
Part numberPart number Publication datePublication date EditionEdition Summary of changesSummary of changes

Table of contentsTable of contents
Component identification
Front panel components
iLO Service Port
Front panel LEDs and buttons
Server UID LED
Using the UID button to view the Server Health Summary
Front panel LED power fault codes
Rear panel components
Display device setup
Rear panel LEDs
System board components
System maintenance switch descriptions
DIMM label identification
DIMM slot numbering
Heatsink and processor socket components
Riser board components
PCIe5 slot description
GPU riser slot numbering
HPE Basic Drive LED definitions
EDSFF SSD LED definitions
Drive box identification
Drive bay numbering
SFF drive bay numbering
LFF drive bay numbering
E3.S drive bay numbering
Drive backplane naming
Fan numbering
Fan and heatsink requirements
Trusted Platform Module 2.0
Trusted Platform Module 2.0 guidelines
BitLocker recovery key/password retention guidelines
HPE NS204i-u Boot Device components
HPE NS204i-u Boot Device LED definitions
Setup
Initial system installation
HPE Installation Service
Setting up the server
Operational requirements
Space and airflow requirements

Temperature requirements
Power requirements
Electrical grounding requirements
Rack warnings and cautions
Server warnings and cautions
Electrostatic discharge
Operations
Power up the server
Power down the server
Open the cable management arm
Extend the server out of the rack
Remove the server from the rack
Remove the front bezel
Remove the access panel
Remove the M.2 air baffle
Remove the middle cover
Remove the fan
Remove the fan wall
Remove the riser cage
Install the access panel
Install the M.2 air baffle
Install the middle cover
Install the fan wall
Install the riser cage
Install the server into the rack
Hardware options installation
Server data backup
Hardware option installation guidelines
Rack mounting options
Rack mounting interfaces
Rail identification markers
Installing the rack rail option
Installing the rack rail hook-and-loop strap
Installing the cable management arm
Installing the front bezel
Drive options
Drive installation guidelines
Installing a hot-plug SAS, SATA or NVMe drive
Installing a hot-plug LFF SAS, SATA or NVMe drive in box three or box five
Installing an E3.S drive
Installing the 8 SFF drive backplane

Drive cage options
Installing the 2 SFF drive cage
Installing the 4 SFF drive cage
Installing the E3.S drive cage
Optical drive option
Installing an optical drive in the SFF drive chassis
Installing an optical drive in the LFF drive chassis
Display port option
Installing an 8 SFF display port/USB/optical blank option
Installing the 4 LFF display port/USB option
PCIe riser option
Installing a riser board in the secondary riser cage
Power supply options
Power supply warnings and cautions
DC power supply warnings and cautions
Connecting a DC power cable to a DC power source
Installing a DC power supply
Installing an AC power supply
Transceiver option
Transceiver warnings and cautions
Installing a transceiver
Fan options
Fan mode behavior
Installing a fan
Expansion card options
HPE Smart Storage Hybrid Capacitor
Installing an expansion card
Accelerator options
Installing an accelerator in the GPU riser cage
Installing an accelerator in the rear riser cage
Energy pack options
HPE Smart Storage Battery
HPE Smart Storage Hybrid Capacitor
Minimum firmware versions
Installing an energy pack
Memory options
DIMM population information
HPE SmartMemory speed information
Installing a DIMM
Storage controller options
Preparing the server for storage controller installation

Installing a type-p controller
Installing a type-o storage controller
OCP NIC 3.0 adapter option
Installing the OCP NIC 3.0 adapter
HPE NS204i Boot Device option
Installing the HPE NS204i-u Boot Device
M.2 SSD options
Installing an M.2 SSD
Processor heatsink assembly option
Processor cautions
Installing a processor heatsink assembly
Serial port option
Installing the serial port
Chassis intrusion detection switch option
Installing the chassis intrusion detection switch
Internal USB device option
Installing an internal USB device
Configuration resources
Updating firmware or system ROM
Configuring the server
Configuring storage controllers
Managing the HPE NS204i Boot Device
Deploying an OS
Configuring security
Optimizing the server
Server management
Managing Linux-based high performance compute clusters
Cabling
Cabling guidelines
Internal cabling management
Cabling diagrams
Storage cabling
Drive power cabling
Storage controller cabling
2 SFF drive controller cabling
4 SFF drive controller cabling
4 E3.S drive controller cabling
8 E3.S drive controller cabling
8 SFF drive controller cabling
4 LFF drive controller cabling
10 LFF drive controller cabling

12 LFF drive controller cabling
Energy pack cabling
Storage controller backup cabling
Accelerator cabling
GPU riser cabling
HPE NS204i Boot Device cabling
Optical drive cabling
Display port cabling
Serial port cabling
Front I/O cabling
VGA cabling
Chassis intrusion detection switch cabling
Troubleshooting
NMI functionality
Troubleshooting resources
Safety, warranty, and regulatory information
Regulatory information
Notices for Eurasian Economic Union
Turkey RoHS material content declaration
Ukraine RoHS material content declaration
Warranty information
Specifications
Environmental specifications
Mechanical specifications
Power supply specifications
HPE 500 W Flex Slot Platinum Hot-plug Low Halogen Power Supply
HPE 800 W Flex Slot Platinum Hot-plug Low Halogen Power Supply
HPE 1000 W Flex Slot Titanium Hot-plug Power Supply
HPE 1600 W Flex Slot -48 VDC Hot-plug Power Supply
Websites
Support and other resources
Accessing Hewlett Packard Enterprise Support
Accessing updates
Customer self repair
Remote support
Documentation feedback

Component identificationComponent identification
This chapter describes the external and internal server features and components.
SubtopicsSubtopics
Front panel componentsFront panel components
Front panel LEDs and buttonsFront panel LEDs and buttons
Rear panel componentsRear panel components
Rear panel LEDsRear panel LEDs
System board componentsSystem board components
Riser board componentsRiser board components
PCIe5 slot descriptionPCIe5 slot description
GPU riser slot numberingGPU riser slot numbering
HPE Basic Drive LED definitionsHPE Basic Drive LED definitions
EDSFF SSD LED definitionsEDSFF SSD LED definitions
Drive box identificationDrive box identification
Drive bay numberingDrive bay numbering
Drive backplane namingDrive backplane naming
Fan numberingFan numbering
Fan and heatsink requirementsFan and heatsink requirements
Trusted Platform Module 2.0Trusted Platform Module 2.0
HPE NS204i-u Boot Device componentsHPE NS204i-u Boot Device components
HPE NS204i-u Boot Device LED definitionsHPE NS204i-u Boot Device LED definitions
Front panel componentsFront panel components
SFF drive configurationSFF drive configuration
HPE ProLiant DL320 Gen11 Server User Guide 9

ItemItem DescriptionDescription
1 Serial number/iLO information pull tab
2 ODD/display port + USB (optional)
3 2 SFF side-by-side drive cage assembly (optional)
4 iLO Service Port
5 USB 3.2 Gen1 port
6 8 SFF drives
The serial number/ iLO information pull tab is double-sided. One side shows the server serial number and the customer asset tag label.
The other side shows the default iLO account information.
This drive cage assembly includes in the front USB and DisplayPort option.
4 LFF drive configuration4 LFF drive configuration
ItemItem DescriptionDescription
1 ODD (optional)
2 Serial number/iLO information pull tab
3 Display port 1.1a (optional)
4 USB 2.0 port (optional)
5 USB 3.2 Gen1 port
6 iLO Service Port
7 4 LFF drives
12 LFF drive configuration12 LFF drive configuration
1
2
1
2
HPE ProLiant DL320 Gen11 Server User Guide 10

ItemItem DescriptionDescription
1 Serial number/iLO information pull tab
2 USB 3.2 Gen1 port
3 iLO Service Port
4 4 LFF drives
4 SFF drives with a GPU riser cage4 SFF drives with a GPU riser cage
ItemItem DescriptionDescription
1 4 SFF drives
2 Serial number/ iLO information pull tab
3 GPU riser cage (optional)
4 iLO Service Port
5 USB 3.2 Gen1 port
8 8 E3.SE3.S drives with a GPU riser cage drives with a GPU riser cage
HPE ProLiant DL320 Gen11 Server User Guide 11

ItemItem DescriptionDescription
1 8 E3.S drives
2 Serial number/iLO information pull tab
3 GPU riser cage
4 iLO Service Port
5 USB 3.2 Gen1 port
SubtopicsSubtopics
iLO Service PortiLO Service Port
iLOiLO Service Port Service Port
When you have physical access to a server, you can use the Service Port to do the following:
Download the Active Health System Log to a supported USB flash drive.
When you use this feature, the connected USB flash drive is not accessible by the host operating system.
Connect a client (such as a laptop) with a supported USB to Ethernet adapter to access the following:
iLO web interface
Remote console
iLO RESTful API
CLI
When you use the iLO Service Port:
Actions are logged in the iLO event log.
The server UID flashes to indicate the Service Port status.
You can also retrieve the Service Port status by using a REST client and the iLO RESTful API.
You cannot use the Service Port to boot any device within the server, or the server itself.
You cannot access the server by connecting to the Service Port.
You cannot access the connected device from the server.
Front panel LEDs and buttonsFront panel LEDs and buttons
HPE ProLiant DL320 Gen11 Server User Guide 12

ItemItem DescriptionDescription StatusStatus DefinitionDefinition
1 Power On/Standby button and
system power LED
Solid green System on
Flashing green Performing power-on sequence
Solid amber System in standby
Off No power present
2 Health LED Solid green Normal
Flashing green iLO is rebooting
Flashing amber System degraded
Flashing red System critical
3 NIC status LED Solid green Linked to network
Flashing green Network active
Off No network activity
4 UID button/LED Solid blue Activated
Flashing blue 1 flash per second—Remote management or
firmware upgrade in progress
4 flashes per second— iLO manual reboot
sequence initiated
8 flashes per second— iLO manual reboot
sequence in progress
Off Deactivated
When all LEDs flash simultaneously, a power fault has occurred. For more information, see Front panel LED power fault codes.
Facility power is not present, power cord is not attached, no power supplies are installed, or power supply failure has occurred.
If the health LED indicates a degraded or critical state, review the system Integrated Management Log (IML) or use HPE iLO to review
the system health status.
SubtopicsSubtopics
Server UID LEDServer UID LED
Using the UID button to view the Server Health SummaryUsing the UID button to view the Server Health Summary
Front panel LED power fault codesFront panel LED power fault codes
Server UID LEDServer UID LED
The UID LED is used to locate a particular server when it is deployed in a dense rack with other equipment. Activating the UID LED helps an
1
2
1
3
3
1
1
1
2
3
HPE ProLiant DL320 Gen11 Server User Guide 13

on-site technician to quickly identify a server for maintenance tasks.
Using the UID button to view the Server Health SummaryUsing the UID button to view the Server Health Summary
PrerequisitesPrerequisites
An external monitor is connected.
In the iLO web interface, the Show Server Health on External Monitor feature is enabled on the Access Settings page.
About this taskAbout this task
Use the UID button to display the iLO Server Health Summary screen on an external monitor. This function works when the server is
powered on or off. Use this feature for troubleshooting if the server will not start up.
CAUTION:CAUTION: Press and release the UID button. Holding it down at any time for more than five seconds initiates a graceful iLO
reboot or a hardware iLO reboot. Data loss or NVRAM corruption might occur during a hardware iLO reboot.
ProcedureProcedure
1. Press and release the UID button.
The Server Health Summary screen is displayed on the external monitor. For more information, see the iLO troubleshooting guide:
https://www.hpe.com/support/ilo6https://www.hpe.com/support/ilo6
2. Press the UID button again to close the Server Health Summary screen.
Front panel LED power fault codesFront panel LED power fault codes
The following table provides a list of power fault codes, and the subsystems that are affected. Not all power faults are used by all servers.
SubsystemSubsystem LED behaviorLED behavior
System board 1 flash
Processor 2 flashes
Memory 3 flashes
Riser board PCIe slots 4 flashes
FlexibleLOM 5 flashes
Storage controller 6 flashes
System board PCIe slots 7 flashes
Power backplane 8 flashes
Storage backplane 9 flashes
Power supply 10 flashes
PCIe expansion cards installed in riser board 11 flashes
Chassis 12 flashes
GPU card 13 flashes
Rear panel componentsRear panel components
HPE ProLiant DL320 Gen11 Server User Guide 14

ItemItem DescriptionDescription
1 Slot 1 PCIe5 x16 (16, 8, 4, 2 (Gen4))
2 Slot 2 PCIe5 x16 (16, 8, 4, 2 (Gen4))
3 Power supply 2 (PS2)
4 Power supply 1 (PS1)
5 Slot 14 OCP PCIe5 x16
6 Video (VGA) port
7 USB 3.2 Gen1 ports
8 iLO Management Port
9 Embedded 1x2 network port
10 Serial port (optional)
SubtopicsSubtopics
Display device setupDisplay device setup
Display device setupDisplay device setup
This server supports both VGA port and Display port 1.1a. Before connecting a display device to this server, review the information below.
Whenever possible, use the same display connection type. For example, if your PC or monitor only has a VGA output, connect it to the
server VGA port. Use of any kind of adapter or converter cable or dongle might lead to decreased display quality or a lag over the
connection.
DisplayPort connection: When connecting an HDMI or DVI display to the DisplayPort, use an active type adapter. Passive type adapter—
marked with the DP++ symbol—is not supported.
Display output modes:
If you connect two display devices to the VGA port and DisplayPort, the same image is shown on both devices—screen mirroring
mode.
The embedded video controller in the iLO 6 chipset does not support dual display or screen extension mode. To enable dual display
mode, install a compatible PCIe5 graphics card that supports this feature in the expansion slot.
Rear panel LEDsRear panel LEDs
HPE ProLiant DL320 Gen11 Server User Guide 15

ItemItem LEDLED StatusStatus DefinitionDefinition
1 Power supply Solid green The power supply is operating normally.
Off One or more of the following conditions exists:
Power is unavailable
Power supply failure
Power supply is in standby mode
Power supply error
2 UID Solid blue Activated
Flashing blue 1 flash per sec—Remote management or firmware upgrade
in progress
4 flashes per sec— iLO manual reboot sequence initiated
8 flashes per sec— iLO manual reboot sequence in progress
Off Deactivated
3 iLO status Solid green Linked to network
Flashing green Network active
Off No network activity
4 iLO link Solid green Network link
Off No network link
System board componentsSystem board components
HPE ProLiant DL320 Gen11 Server User Guide 16

HPE ProLiant DL320 Gen11 Server User Guide 17

ItemItem DescriptionDescription
1 Serial port cable connector
2 Internal USB 2.0 port
3 Primary riser connector
4 Video (VGA) cable connector
5 Storage controller backup power connector
6 System battery
7 MCIO port 1
8 MCIO port 2
9 MCIO port 3
10 MCIO port 4
11 GPU Auxiliary power connector
12 GPU riser power connector
13 Front I/O connector
14 SATA sideband connector
15 Internal USB 3.2 Gen1 port
16 Optical drive connector
17 Drive box 5 power connector
18 Drive box 3 power connector
19 Drive box 1 power connector
20 Media bay power connector
21 Energy pack connector
22 Chassis Intrusion Detection connector
23 M.2 module connectors
24 Switch board sideband connector
25 NS204i-u power connector
26 SATA 6 Gb/s port
27 x8 slimSAS port 1
28 Display port cable connector
29 Secondary riser connector
X System maintenance switch
This component is used in the 4 SFF and 8 E3.S drive configurations.
SubtopicsSubtopics
System maintenance switch descriptionsSystem maintenance switch descriptions
DIMM label identificationDIMM label identification
DIMM slot numberingDIMM slot numbering
Heatsink and processor socket componentsHeatsink and processor socket components
System maintenance switch descriptionsSystem maintenance switch descriptions
1
1
1
HPE ProLiant DL320 Gen11 Server User Guide 18

PositionPosition DefaultDefault FunctionFunction
S1 Off Off—iLO 6 security is enabled.
On—iLO 6 security is disabled.
S2 Off Reserved
S3 Off Reserved
S4 Off Reserved
S5 Off Off—Power-on password is enabled.
On—Power-on password is disabled.
S6 Off Off—No function
On—Restore default manufacturing settings
S7 Off Reserved
S8 Off Reserved
S9 Off Reserved
S10 Off Reserved
S11 Off Reserved
S12 Off Reserved
To access the redundant ROM, set S1, S5, and S6 to On.
When the system maintenance switch position 6 is set to the On position, the system is prepared to restore all configuration settings
to their manufacturing defaults.
When the system maintenance switch position 6 is set to the On position and Secure Boot is enabled, some configurations cannot be
restored. For more information, see Configuring the server.
DIMM label identificationDIMM label identification
To determine DIMM characteristics, see the label attached to the DIMM. The information in this section helps you to use the label to locate
specific information about the DIMM.
For more information about product features, specifications, options, configurations, and compatibility, see the HPE DDR5 SmartMemory
QuickSpecs:
https://www.hpe.com/docs/server-memoryhttps://www.hpe.com/docs/server-memory
1
1
1,2 3
1
2
3
HPE ProLiant DL320 Gen11 Server User Guide 19

ItemItem DescriptionDescription ExampleExample
1 Capacity 16 GB
32 GB
64 GB
128 GB
256 GB
2 Rank 1R—Single rank
2R—Dual rank
4R—Quad rank
8R—Octal rank
3 Data width on DRAM x4—4-bit
x8—8-bit
4 Memory generation PC5—DDR5
5 Maximum memory speed 4800 MT/s
6 CAS latency B—42-42-42
B—50-42-42 (for 128 GB and 256 GB capacities)
7 DIMM type R—RDIMM (registered)
DIMM slot numberingDIMM slot numbering
HPE ProLiant DL320 Gen11 Server User Guide 20
