HPE Aruba 6200F Owner's manual

HPE Aruba Networking CX
6200F Switches and Accessories
Start Here: Installation, Safety, and Regulatory
Information
Published: January 2024
Edition: 3

Start Here: Installation, Safety, and Regulatory Information 2
Copyright Information
© Copyright 2024 Hewlett Packard Enterprise Development LP.
Open Source Code
This product includes code licensed under certain open source licenses which require source
compliance. The corresponding source for these components is available upon request. This offer is
valid to anyone in receipt of this information and shall expire three years following the date of the final
distribution of this product version by Hewlett Packard Enterprise Company. To obtain such source
code, please check if the code is available in the HPE Software Center at
https://myenterpriselicense.hpe.com/cwp-ui/software but, if not, send a written request for specific
software version and product for which you want the open source code. Along with the request, please
send a check or money order in the amount of US $10.00 to:
Hewlett Packard Enterprise Company
Attn: General Counsel
WW Corporate Headquarters
1701 E Mossy Oaks Rd, Spring, TX 77389
United States of America

All Product Documentation
For the latest release of hardware and software documentation for HPE Aruba Networking switches and
accessories, including the Installation and Getting Started Guide, which provides detailed installation
instructions, visit the Aruba Support Portal at the following link:
https://asp.arubanetworks.com/downloads
See the rest of this guide for important pre-setup information.
NOTE:
There are no user-serviceable parts in this product. For switch or accessory service needs, contact an authorized Aruba
representative.
Applicable products
Non-TAA TAA
HPE Aruba Networking CX 6200F 12G Class4 PoE
2G/2SFP+ 139W Switch (R8Q72A)
HPE Aruba Networking CX 6200F 12G Class4 PoE
2G/2SFP+ 139W TAA Switch (R8V13A)
HPE Aruba Networking CX 6200F 24G 4SFP+ Switch
(JL724B)
HPE Aruba Networking CX 6200F 24G 4SFP+ TAA-
compliant Switch (S0M86A)
HPE Aruba Networking CX 6200F 24G Class 4 PoE
4SFP+ 370W Switch (JL725B)
HPE Aruba Networking CX 6200F 24G Class 4 PoE
4SFP+ 370W TAA-compliant Switch (S0M87A)
HPE Aruba Networking CX 6200F 48G 4SFP+ Switch
(JL726B)
HPE Aruba Networking CX 6200F 48G 4SFP+ TAA-
compliant Switch (S0M88A)
HPE Aruba Networking CX 6200F 48G Class 4 PoE
4SFP+ 370W Switch (JL727B)
HPE Aruba Networking CX 6200F 48G Class 4 PoE
4SFP+ 370W TAA-compliant Switch (S0M89A)
HPE Aruba Networking CX 6200F 48G Class 4 PoE
4SFP+ 740W Switch (JL728B)
HPE Aruba Networking CX 6200F 48G Class 4 PoE
4SFP+ 740W TAA-compliant Switch (S0M90A)
Aruba 6200F 24G 4SFP+ Switch (JL724A) HPE Aruba Networking CX 6200F 24G 4SFP TAA-
compliant Switch (S0G13A)
Aruba 6200F 24G Class 4 PoE 4SFP+ 370W Switch
(JL725A)
HPE Aruba Networking CX 6200F 24G Class 4 PoE 4SFP
370W TAA-compliant Switch (S0G14A)
Aruba 6200F 48G 4SFP+ Switch (JL726A) HPE Aruba Networking CX 6200F 48G 4SFP TAA-
compliant Switch (S0G15A)
Aruba 6200F 48G Class 4 PoE 4SFP+ 370W Switch
(JL727A)
HPE Aruba Networking CX 6200F 48G Class 4 PoE 4SFP
370W TAA-compliant Switch (S0G16A)
Aruba 6200F 48G Class 4 PoE 4SFP+ 740W Switch
(JL728A)
HPE Aruba Networking CX 6200F 48G Class 4 PoE 4SFP
740W TAA-compliant Switch (S0G17A)
Start Here: Installation, Safety, and Regulatory Information 3

Start Here: Installation, Safety, and Regulatory Information 4
Non-TAA TAA
HPE Aruba Networking CX 6200F 24G 4SFP Switch
(S0M81A)
HPE Aruba Networking CX 6200F 24G Class 4 PoE 4SFP
370W Switch (S0M82A)
HPE Aruba Networking CX 6200F 48G 4SFP Switch
(S0M83A)
HPE Aruba Networking CX 6200F 48G Class 4 PoE 4SFP
370W Switch (S0M84A)
HPE Aruba Networking CX 6200F 48G Class 4 PoE 4SFP
740W Switch (S0M85A)
Overview
The HPE Aruba Networking CX 6200F Switch Series is a family of edge networking stackable switches,
ideal for enterprise network access. They provide the foundation for high-performance networks
supporting IoT, mobile, and cloud applications.
These switches are intended for indoor use only. They are for use in commercial applications. A typical
installation is in an environmentally controlled location. The end use environment may or may not be a
restricted access location.
A tool is required to remove the top cover; however, the product is not considered serviceable by an
operator.
Installation precautions and guidelines
To help avoid personal injury or product damage when installing your switch, read the following
installation precautions and guidelines.
WARNING:
nWith the exception of HPE Aruba Networking CX 6200F 12G Class4 PoE 2G/2SFP+ 139W switch
(R8Q72A) and HPE Aruba Networking CX 6200F 12G Class4 PoE 2G/2SFP+ 139W TAA Switch (R8V13A),
do not mount the switch on a wall, under a table, or under any other horizontal surface.
nMount devices installed in a rack or cabinet as low as possible. Put the heaviest devices at the bottom
and progressively lighter devices positioned higher.
nTo prevent the rack or cabinet from becoming unstable and/or falling over, ensure that it is
adequately secured.
This section provides precautions and guidelines to observe when installing your switch. For full
installation instructions, see the Installation and Getting Started Guide.

Start Here: Installation, Safety, and Regulatory Information 5
CAUTION:
nDo not ship any switch in a rack without checking for restrictions in the latest Installation and
Getting Started Guide. Otherwise, you may void the switch warranty.
nEnsure the power source circuits are properly grounded. Then connect the switch to the power
source by using the power cord supplied with the switch. For more information on power cords,
see the Power cords section.
nWhen installing the switch, the AC outlet should be near the switch and be easily accessible in
case the switch must be powered off.
nEnsure that the power cord and network cables at the switch mounting location do not create a
tripping hazard.
nDo not install the switch in an environment where the operating ambient temperature exceeds its
specification. See the environmental operating temperature information in the latest Installation
and Getting Started Guide.
nEnsure that the switch does not overload the power circuits, wiring, and over-current protection.
To determine the possibility of overloading the supply circuits, add the ampere ratings of all
devices installed on the same circuit as the switch. Then compare the total with the rating limit for
the circuit. The maximum ampere ratings for a device are usually printed near the device AC
power connectors.
nDo not block any ventilation openings on the front or rear of the switch.Ensure that the air flow
around the switch is not restricted.
oFor all other 24- and 48-port 6200F models: In the front or the back of the switch, leave at
least 7.6 cm (3 inches) of space for the twisted-pair and fiber-optic cabling. For the air flow
direction, see the latest Installation and Getting Started Guide.
oFor Aruba 6200F 12G Class4 PoE 2G/2SFP+ 139W Switch (R8Q72A) and Aruba 6200F 12G
Class4 PoE 2G/2SFP+ 139W TAA Switch (R8V13A) models: In the front or the back of the
switch, leave at least 15.24 cm (6 inches) of space for the twisted-pair and fiber-optic cabling.
nMarking label (includes power rating) is at the bottom of the switch.
nThe switch equipment is not suitable for use in locations where children are likely to be present.
NOTE:
nUse only supported Aruba transceivers and DACcabes.
nThe HPEAruba Networking CX 6200F switch port side transceiver slots support SFP and SFP+
transceivers.
nFor more information, see the latest version of the following two guides:
oInstallation and Getting Started Guide
oTransceiver Guide
Power cords
HPE Aruba Networking includes the power cord intended for use with your HPE Aruba Networking
switch. Different countries/regions may require different power cords. For a list of the power cords that
apply to your switch, see the section that lists power cords in the latest edition of the Installation and
Getting Started Guide for your switch.

Start Here: Installation, Safety, and Regulatory Information 6
CAUTION:
OnlyHPE Aruba Networking-approved power cords may be used with HPE Aruba Networking devices.
To access power cord information for your switch, see the latest edition of the HPE Aruba Networking
CX 6200F/M Installation and Getting Started Guide. Lost or damaged power cords must be replaced only
with HPE Aruba Networking-approved power cords. If your installation requires a different power cord
than the one supplied with the switch, be sure that the cord is adequately sized for the current
requirements of the switch. In addition, be sure to use a power cord displaying the mark of the safety
agency that defines the regulations for power cords in your country/region. The mark is your assurance
that the power cord can be used safely with the switch.
CAUTION:
Do not use a damaged or non-recommended power cord with your switch. Using such power cords voids
the switch warranty. It can also cause serious electrical problems, including injury or death to personnel,
and damage to the switch and other property. If you cannot verify that you have a power cord approved
for use with your switch model, contact your authorized HPE Aruba Networking dealer or sales
representative for assistance.
WARNING:
Remove the power cord from the switch before mounting or dismounting the switch.
Japan power cord warning
CAUTION:
FOR INDOOR USE ONLY. The switch, power cords, and all connected cables are not designed for outdoor
use.
Brazil Statement
Este equipamento deve ser conectado obrigatoriamente em tomada de rede de
energia elétrica que possua aterramento (três pinos), conforme a Norma NBR
ABNT 5410, visando a segurança dos usuários contra choques elétricos.)
CAUTION: Shock hazard. To completely remove power from the switch,
disconnect all power cords.
Environmental specifications

Start Here: Installation, Safety, and Regulatory Information 7
Table 1: Environmental Specifications for all HPE Aruba Networking CX 6200F switch models
Aruba CX 6200FSwitches
Operating temperature 32°F to 113°F (0°C to 45°C) up to 5,000 ft; Derate -1°C for every 1,000
ft from 5,000 ft to 10,000 ft
Non-operating temperature 5% to 95% @ 104°F (40°C) non-condensing
Operating relative humidity -40°F to 158°F (-40°C to 70°C) up to 15000 ft
Non-operating storage relative humidity 5% to 95% @ 149°F (65°C) non-condensing
Max operating altitude 10,000 ft (3.048 km) Max
Max non-operating altitude 15,000 ft (4.6 km) Max
Table 2: Dimensions and weights for HPE Aruba Networking CX 6200F switch models
Switch Weight Dimensions (W x D x H)
HPE Aruba Networking CX 6200F 24G
4SFP+ Switch (JL724B)
3.77 kg(8.32 lbs) 44.25 cm x 28.4 cm x 4.37 cm
(17.42 in x 11.2 in x 1.72 in)
HPE Aruba Networking CX 6200F 24G
4SFP Switch (S0M81A)
HPE Aruba Networking CX 6200F 24G
4SFP+ TAA-compliant Switch (S0M86A)
HPE Aruba Networking CX 6200F 24G
4SFP TAA-compliant Switch (S0G13A)
HPE Aruba Networking CX 6200F 48G
4SFP+ Switch (JL726B)
3.9 kg (8.59 lbs)
HPE Aruba Networking CX 6200F 48G
4SFP Switch (S0M83A)
HPE Aruba Networking CX 6200F 48G
4SFP+ TAA-compliant Switch (S0M88A)
HPE Aruba Networking CX 6200F 48G
4SFP TAA-compliant Switch (S0G15A)

Start Here: Installation, Safety, and Regulatory Information 8
Switch Weight Dimensions (W x D x H)
HPE Aruba Networking CX 6200F 24G
Class 4 PoE 4SFP+ 370W Switch (JL725B)
4.39 kg (9.68 lbs) 44.25 cm x 30.43 cm x 4.37 cm
(17.42 in x 11.98 in x 1.72 in)
HPE Aruba Networking CX 6200F 24G
Class 4 PoE 4SFP 370W Switch (S0M82A)
HPE Aruba Networking CX 6200F 24G
Class 4 PoE 4SFP+ 370W TAA-compliant
Switch (S0M87A)
HPE Aruba Networking CX 6200F 24G
Class 4 PoE 4SFP 370W TAA-compliant
Switch (S0G14A)
HPE Aruba Networking CX 6200F 48G
Class 4 PoE 4SFP+ 370W Switch (JL727B)
4.87 kg (10.74 lbs)
HPE Aruba Networking CX 6200F 48G
Class 4 PoE 4SFP 370W Switch (S0M84A)
HPE Aruba Networking CX 6200F 48G
Class 4 PoE 4SFP+ 370W TAA-compliant
Switch (S0M89A)
HPE Aruba Networking CX 6200F 48G
Class 4 PoE 4SFP 370W TAA-compliant
Switch (S0G16A)
HPE Aruba Networking CX 6200F 48G
Class 4 PoE 4SFP+ 740W Switch (JL728B)
5.13 kg (11.32 lbs) 44.25 cm x 32.66 cm x 4.37 cm
(17.42 in x 12.86 in x 1.72 in)
HPE Aruba Networking CX 6200F 48G
Class 4 PoE 4SFP 740W Switch (S0M85A)
HPE Aruba Networking CX 6200F 48G
Class 4 PoE 4SFP+ 740W TAA-compliant
Switch (S0M90A)
HPE Aruba Networking CX 6200F 48G
Class 4 PoE 4SFP 740W TAA-compliant
Switch (S0G17A)
HPE Aruba Networking CX 6200F 12G
Class4 PoE 2G/2SFP+ 139W Switch
(R8Q72A)
3.24 kg (7.14 lbs) 25.4 cm x 30.5 cm x 4.39 cm
(10.0 in x 12.0 in x 1.73 in)
HPE Aruba Networking CX 6200F 12G
Class4 PoE 2G/2SFP+ 139W TAA Switch
(R8V13A)

Start Here: Installation, Safety, and Regulatory Information 9
Switch Weight Dimensions (W x D x H)
Aruba 6200F 24G 4SFP+ Switch (JL724A) 4.36 kg (9.61 lbs) 44.25 cm x 32.7 cm x 4.37 cm
(17.42 in x 12.9 in x 1.72 in)
Aruba 6200F 24G Class4 PoE 4SFP+
370W Switch (JL725A)
4.9 kg (10.8 lbs)
Aruba 6200F 48G 4SFP+ Switch (JL726A) 4.45 kg (9.81 lbs)
Aruba 6200F 48G Class4 PoE 4SFP+
370W Switch (JL727A)
5.05 kg (11.13 lbs)
Aruba 6200F 48G Class4 PoE 4SFP+
740W Switch (JL728A)
5.10 kg (11.24 lbs)
xxx
Safety and regulatory information
NOTE:
For important safety, environmental, and regulatory information, see Safety and Compliance Information for Server, Storage,
Power, Networking, and Rack Products, available at http://www.hpe.com/support/Safety-Compliance-EnterpriseProducts.
JL724A, JL725A, JL726A,
JL727A, JL728A
R8Q72A,
R8V13A
JL724B, JL725B, JL726B,
JL727B, JL728B, S0M81A,
S0M82A, S0M83A,
S0M84A, S0M85A,
S0M86A, S0M87A,
S0M88A, S0M89A,
S0M90A, S0G13A,
S0G14A, S0G15A,
S0G16A, S0G17A
Safety-EU
EN 62368-1:2014 +A11:2017 2nd Ed.
EN 62368-1:2020 +A11:2020 3rd Ed.
Safety-Worldwide
IEC 60950-1:2005 + A1:2009 + A2:2013 with all known
National Deviations IEC 62368-1:2014 2nd ed. with all
known National Deviations IEC 62368-1:2018 3rd Ed. with
all known National Deviations
IEC 62368-1:2014 2nd ed.
with all known National
Deviations
IEC 62368-1:2018 3rd Ed. with
all known National Deviations
Safety-North America
US:UL 60950 2nd Ed.
CAN:CSA-C22.2 No. 60950-1-07
US:UL 62368 3rd Ed.
CAN:CSA-C22.2 No. 62368-1:14 3rd Ed.
EMC
BS/EN 55032:2015 +A11:2020/CISPR 32, Class A
BS/EN 55035:2017 +A11:2020/CISPR 35
FCC CFR47 Part 15:2014, Class A
Table 3: Safety and Regulatory information for HPE Aruba Networking CX 6200F switches

Start Here: Installation, Safety, and Regulatory Information 10
JL724A, JL725A, JL726A,
JL727A, JL728A
R8Q72A,
R8V13A
JL724B, JL725B, JL726B,
JL727B, JL728B, S0M81A,
S0M82A, S0M83A,
S0M84A, S0M85A,
S0M86A, S0M87A,
S0M88A, S0M89A,
S0M90A, S0G13A,
S0G14A, S0G15A,
S0G16A, S0G17A
ICES-0013, Class A
AS/NZS CISPR 32, Class A
VCCI-32, Class A
CNS 15936:2016
KS C 9832:2019
KS C 9835:2019
BS/EN 61000-3-2:2014
BS/EN 61000-3-3:2013
BS/EN 61000-3-2:2019
BS/EN 61000-3-3:2013/A1:2019
RoHS EN IEC 63000:2018
Regulatory Model
Number Model Number Descriptions
RSVLC-1910 JL728A Aruba 6200F 48G Class4 PoE 4SFP+ 740W Switch
RSVLC-1911 JL727A Aruba 6200F 48G Class4 PoE 4SFP+ 370W Switch
JL725A Aruba 6200F 24G Class4 PoE 4SFP+ 370W Switch
RSVLC-1912 JL726A Aruba 6200F 48G 4SFP+ Switch
JL724A Aruba 6200F 24G 4SFP+ Switch
RSVLC-2108 R8Q72A HPE Aruba Networking CX 6200F 12G Class4 PoE 2G/2SFP+
139W Switch
R8V13A HPE Aruba Networking CX 6200F 12G Class4 PoE 2G/2SFP+
139W TAA Switch
RSVLC-2205 JL726B HPE Aruba Networking CX 6200F 48G 4SFP+ Switch
JL724B HPE Aruba Networking CX 6200F 24G 4SFP+ Switch
S0M83A HPE Aruba Networking CX 6200F 48G 4SFP Switch
Table 4: Regulatory Model Numbers for Aruba 6200F switches
