HPE R1500 G5 Assembly instructions
MF877-00 Page 1
Template Revision A
HPE instructions for this template are available at MF877-01
Product End-of-Life Disassembly Instructions
Product Category: Servers
Marketing Name / Model
[List multiple models if applicable.]
HPE R1500 G5 INTL UPS
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic
instructions for the disassembly of HPE products to remove components and materials requiring selective treatment,
as defined by EU directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Notes
Quantity
of items
included
in
product
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
With a surface greater than 10 sq cm
2
Batteries
All types including standard alkaline and lithium
coin or button style batteries
3
Mercury-containing components
For example, mercury in lamps, display
backlights, scanner lamps, switches, batteries
0
Liquid Crystal Displays (LCD) with a surface
greater than 100 sq cm
Includes background illuminated displays with
gas discharge lamps
0
Cathode Ray Tubes (CRT)
0
Capacitors / condensers (Containing PCB/PCT)
0
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
Electrolytic Capacitors
2
External electrical cables and cords
2
Gas Discharge Lamps
0
Plastics containing Brominated Flame
Retardants weighing > 25 grams (not including
PCBs or PCAs already listed as a separate item
above)
0
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and
toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
0
Components and waste containing asbestos
0
Components, parts and materials containing
refractory ceramic fibers
0
MF877-00 Page 2
Template Revision A
HPE instructions for this template are available at MF877-01
Item Description
Notes
Quantity
of items
included
in
product
Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where
components and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Star Head Screw Driver
M3
Cross Head Screw Driver
M3, M4
Plastic Nipper
Normal
Nut Driver
M4
Electric Iron
Normal
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective
treatment:
1. Remove the middle bezel and left panel.
2. Disconnect the battery connector, and press on/off button to discharge the rest electricity.
3. Loosen the screws fixing the battery door, remove the battery door, and pull out the battery.
4. Loosen the screws fixing the right panel ASSY, and remove the right panel ASSY.
5. Disconnect the LCD cable and PCBA.
6. Loosen the screws fixing the top cover, and remove the top cover.
7. Disconnect the cables connecting to Slot box, AVR, rear FAN, COM PCBA, and rear panel ASSY, and
disassemble the cable clips sticking on the mainframe, and loosen the screws fixing the main PCBA, then
remove the main PCBA, then remove the main PCBA..
8. Cut off the cable tie, disconnect the cable connecting to COM PCBA, loosen the nuts fixing the AVR, and then
remove the AVR.
9. Loosen the screws fixing rear panel ASSY, and then remove the rear panel ASSY.
10. Remove the RPO connector, loosen the screws fixing Slot box, COM PCBA, and rear FAN, loosen the nut
fixing ground cable and then remove the Slot box, COM PCBA, and rear FAN, outlet.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
Batteries
