HST HS101B User manual

INSTALLATION AND MAINTENANCE INSTRUCTIONS
HS101B
Conventional Sound Strobe
SPECI ICATIONS
Operating Voltage Range: 9 to 32 VDC Volts
Alarm Current ≤50 mA @ 24 VDC
Strobe lash Rate: ≤0.5S
Alarm Sound Intensity: Minimum 100dB
Operating Humidity Range: 10% to 93% Relative Humidity, Non-condensing
Operating Temperature Range: -10°C to 50°C (14° to 122° )
Input terminal Wire Gauge: 12 to 18 AWG
Height: 1.8˝ (45 mm) installed in Base
Diameter: 4.0˝ (103 mm)
Weight: 5.6 oz. (158 g)
INSTALLATION
BE ORE INSTALLING
NOTICE: This manual should be left with the
owner/user of this equipment.
GENERAL DESCRIPTION
The Sound Strobe of notification appliances offers a wide
range of Sound/strobes, for wall and ceiling applications,
indoors and outdoors. They are designed to be used in 24
volt DC systems.
Loop Design and Wiring
The system designer must make sure that the total current
drawn by the devices on the loop does not exceed the
current capability of the panel supply, and that the last
device on the circuit is operated within its rated voltage.
When calculating the voltage available to the last device,
it is necessary to consider the voltage drop due to the
resistance of the wire. The thicker the wire, the smaller
the voltage drops. Wire resistance tables can be obtained
from electrical handbooks.
INSTALLATION
NOTE: All wiring must conform to applicable local
codes, ordinances, and regulations.
Mounting Indoor Wall or Ceiling Products
1. Attach mounting base to ceiling or wall.
2. Connect field wiring to terminals:
Terminal 4: Sound+
Terminal 3: Sound-
3. To attach product to mounting base.
4. Secure product by tightening the two mounting screws
in the front of the product housing.
Figure 1. Install and Wiring diagram:
�
60mmm
F i r e A l a r m
C o n t r o l P a n e l
E O L R e s i s t o r ( 1 0 K )
S o u n d +
S o u n d -

THREE-YEAR LIMITED WARRANTY
We warrants its enclosed smoke detector to be free from defects in materials and workmanship under normal use and service for a period of three years from date of
manufacture. We make no other express warranty for this smoke detector. No agent, representative, dealer, or employee of the Company has the authority to increase or
alter the obligations or limitations of this Warranty. The Company’s obligation of this Warranty shall be limited to the repair or replacement of any part of the smoke
detector which is found to be defective in materials or workmanship under normal use and service during the three year period commencing with the date of manufacture.
After phoning Convoy Security’s technical support number for a Return Authorization number, send defective units postage prepaid to Convoy Security local
representative office. Please include a note describing the malfunction and suspected cause of failure. The Company shall not be obligated to repair or replace units which
are found to be defective because of damage, unreasonable use, modifications, or alterations occurring after the date of manufacture. In no case shall the Company be
liable for any consequential or incidental damages for breach of this or any other Warranty, expressed or implied whatsoever, even if the loss or damage is caused by the
Company’s negligence or fault. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not
apply to you. This Warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Please refer to insert for the Limitations of Fire Alarm Systems
